Summary of Contents for Tricel Puraflo Series
- Page 1 Tricel ® Puraflo 1-50 Wastewater Treatment Plants Engineering a green future 125 Rev 4 Jan 2019...
-
Page 2: Table Of Contents
How a Tricel Puraflo Plant works: ....................9 Tricel Puraflo: Typical Layout ......................10 2.2.1 Plan view of Typical Tricel Puraflo Secondary System ............10 2.2.2 Plan view of Typical Tricel Puraflo Tertiary System ............10 Tricel Puraflo Applications ......................11 2.3.1... - Page 3 10 Troubleshooting ............................. 23 10.1 Plant Operation ........................... 23 10.2 Odours ............................24 11 Certification ............................25 Declaration of Performance - Tricel Puraflo with Tricel Fortis ............... 25 11.1 11.2 Declaration of Performance – Tricel Puraflo with Tricel Vento ........... 28...
-
Page 6: Health & Safety Precautions
1 Health & Safety Precautions This manual contains basic information on the installation, operation and maintenance of the Tricel Puraflo wastewater treatment system. For this reason, it is essential that these instructions are carefully read and understood before installation or commissioning by both the installation crew as well as those responsible for the operation and maintenance of the system. -
Page 7: Electrical/Maintenance
All electrical work to be carried out by competent persons using suitable materials for the application. • Do not open the Tricel Puraflo alarm cover without firstly isolating the mains power. All power isolation switches should be turned off [Follow Lock-out/Tag-Out Procedure] before any maintenance/inspection work is done at the wastewater treatment plant. -
Page 8: Introduction: Tricel Puraflo
2 Introduction: Tricel Puraflo Tricel Puraflo is a modular wastewater treatment system which can cater for large or small populations. It is a flexible system which can treat effluent from one-off domestic houses, small communities and light commercial applications through the implementation of additional Puraflo modules. -
Page 9: How A Tricel Puraflo Plant Works
2.1 How a Tricel Puraflo Plant works: Typical Tricel Puraflo System Stage 1 Liquid effluent is pumped, by submersible pump, intermittently on- demand to the Puraflo modules. Stage 2 Effluent is distributed evenly onto the peat filter via a distribution grid at the top of each Puraflo module. -
Page 10: Tricel Puraflo: Typical Layout
Manhole Cover – Outlet from Septic Tank (access to filter) * Tricel Puraflo Kiosk (contains control panel & alarm) Manhole Cover – Tricel Puraflo Pump Chamber Tricel Puraflo Modules – Number of modules depend on loadings Sampling Chamber Distribution Box – Flowing to percolation area/pump chamber to discharge treated liquid. -
Page 11: Tricel Puraflo Applications
Puraflo modules, within which the wastewater is treated to a higher treatment level this is known as tertiary treatment. Tertiary treatment will achieve very high-level pathogen and nutrient reduction. • A Tricel Puraflo tertiary treatment kit consists of a pump with control and alarm kiosk, the Puraflo modules as well as a sampling chamber. -
Page 12: Tricel Puraflo Range
EPA CoP. If the owner feels that the modules are being overloaded, please contact Tricel, as it is possible to add modules to accommodate any extra loadings. -
Page 13: Effluent Filter (Secondary Treatment Only)
• The submersible pump and float switch is fitted with a thermal overload protection. • Effluent from the septic tank or waste water treatment is pumped via a 1.5inch pipe to the Tricel Puraflo modules. • The standard pump can cater for a total head of up to 5 metres. For systems that are subject to a total head greater than 5m, alternative pumps can be sourced. -
Page 14: Pipework
3.2.4 Pipework The pipework supplied with the Tricel Puraflo modules to collect the treated wastewater from the Puraflo modules, and the pipework used for the dispersion of wastewater on top of the peat inside the Puraflo modules, is in accordance with BS 3505: 1986* *Specification for unplasticized polyvinyl chloride (PVC-U) pressure pipes for cold potable water. - Page 15 Important If you required drawings for larger Tricel Puraflo systems from 12 to 50PE, please visit http://ie.tricel.eu/downloads/.
-
Page 16: Transportation & Lifting
Figure 1 - Lifting Puraflo Module Figure 2 - Setting Puraflo Module in position 5 Installation Important The installation of a Tricel Puraflo system must only be done by a Tricel-authorised distributer or a Tricel service technician. 6 Commissioning Important The commissioning of a Tricel Puraflo system must only be done by a Tricel-authorised distributer or a Tricel service technician. -
Page 17: Disposal Of Treated Water
Wash hands and face prior to eating, drinking or smoking. Refer to section. The Tricel Puraflo system is designed with the best of quality and performance in mind to meet your specific wastewater treatment requirements and to provide years of trouble-free use. However, a certain amount of system maintenance is required on an on-going basis to ensure that the system is working correctly. -
Page 18: Effluent Filter (If Applicable)
• Ensure the air blower is working by listening for a gentle hum when standing beside the plant. • The inlet and outlet should be inspected and rodded to remove any blockages if necessary. • Ensure that no storm or surface water enters the system. •... -
Page 19: Control Panel
If a circuit breaker switch is tripped, the power supply to the alarm/pump should be restored as soon as possible. • Tertiary treatment systems: The control panel is located in the wastewater treatment plant. Respond to alarm conditions promptly. Kiosk Tricel Puraflo Control Panel... -
Page 20: Annual Service (Available From Your Supplier)
8.2 Annual Service (Available from your supplier) • The Tricel Puraflo system will require a full service (available from your supplier) once a year to guarantee the efficiency of the system is maintained. Service personnel must be accommodated with clear access to the system. -
Page 21: Operating Conditions
9.1 Conditions: • De-sludging is a critical part of the successful operation of the Tricel Puraflo system and is the responsibility of the customer. Only competent and approved personnel should carry out de-sludging. De- sludging must be carried out when required as specified, and the system should by inspected regularly to check the depth of sludge in the primary chamber. - Page 22 Tricel Puraflo system. Fats or grease present in the system will greatly reduce the operating efficiency of the system and will greatly reduce the life expectancy of the peat fibre.
-
Page 23: Troubleshooting
10 Troubleshooting 10.1 Plant Operation Symptom Possible causes Solution Fuse blown (if applicable). Replace with fuse of suitable size. Tripped breaker. Reset breaker. Pump won’t start or Low line voltage and wet An electrician should check the power electrics. supply to the plant. Pump must be checked by a qualified Defective pump. -
Page 24: Odours
10.2 Odours When the Tricel Puraflo system is correctly installed and operated there should be no strong odour in the area adjacent to the system. The presence of a strong odour would indicate that the plant is not working effectively. -
Page 25: Certification
11 Certification 11.1 Declaration of Performance - Tricel Puraflo with Tricel Fortis - Declaration of Performance DOP05CPRIRL01201712 1. Classification of Product: Small wastewater treatment system for up to 50PT – Packaged and/or Site Assembled Domestic Wastewater Treatment Plant as set out in EN12566 Part3 2. - Page 26 8. Declared Performance: Treatment Performance Essential Characteristics Performance* Harmonised Technical Specification Nominal Organic Daily Design Load 0.36 kg/d Nominal Hydraulic Daily Design 0.90 m Load 95.4% 31 mg/l 98.2% 6mg/l 97.7% 8 mg/l EN12566-3 96.9% 1.1mg/l Electrical Power Consumption 0.06 kWh/d *Performance results obtained at average organic daily load of 0.33kg/d and hydraulic daily load of 0.9m **Determined at temperatures >12...
- Page 27 Killarney Co. Kerry Ireland DOP05CPRIRL01201712 EN 12566-3 Packaged wastewater treatment plants for treatment of domestic wastewater Product: Tricel Puraflo with Fortis Wastewater Treatment Plants Material: GRP and PE Notified Body: Prüfinstitut für Abwassertechnik GmbH Hergenrather Weg 30 52074 Aachen Number:...
-
Page 28: Declaration Of Performance - Tricel Puraflo With Tricel Vento
11.2 Declaration of Performance – Tricel Puraflo with Tricel Vento - Declaration of Performance DOP06CPRIRL01201712 1. Classification of Product: Small wastewater treatment system for up to 50PT – Packaged and/or Site Assembled Domestic Wastewater Treatment Plant as set out in EN12566 Part3 2. - Page 29 8. Declared Performance: Treatment Performance Essential Characteristics Performance* Harmonised Technical Specification Nominal Organic Daily Design Load 0.36 kg/d Nominal Hydraulic Daily Design 0.90 m Load 95.4% 31 mg/l 98.2% 6mg/l 97.7% 8 mg/l EN12566-3 96.9% 1.1mg/l Electrical Power Consumption 0.06 kWh/d *Performance results obtained at average organic daily load of 0.33kg/d and hydraulic daily load of 0.9m **Determined at temperatures >12...
- Page 30 Killarney Co. Kerry Ireland DOP06CPRIRL01201712 EN 12566-3 Packaged wastewater treatment plants for treatment of domestic wastewater Product: Tricel Puraflo with Vento Wastewater Treatment Plants Material: PE Vento Notified Body: CERIB 1,rue des Longs Reges - B.P. 30059 28231 Epernon Cedex France Number.:...
- Page 32 Tricel Environmental UK, A trading brand of Dewey Waters Ltd Heritage Works, Winterstoke Road, Weston-super-Mare, BS24 9AN, United Kingdom Tel: 44 (0) 1934 422 311 I Email: environment@tricel.co.uk I www.tricel.co.uk In accordance with Tricel’s normal policy of product development these specifications are subject to change without notice.
