SUPEX-PT-ML

VARIABLE SPEED PAN TILT DRIVER

USER MANUAL

rev 1.00b _ 100313en

Table of Contents

Need help?

Do you have a question about the SUPEX-PT-ML and is the answer not in the manual?

Questions and answers

Summary of Contents for Also Security SUPEX-PT-ML

Page 1 SUPEX-PT-ML VARIABLE SPEED PAN TILT DRIVER USER MANUAL rev 1.00b _ 100313en...
Page 2: Table Of Contents
INDEX 1. COMPONENTS -------------------------------2 2. SPECIFIC FEATURES -------------------------------3 3. FUNCTIONAL DESCRIPTION -------------------------------4 1) Pan Tilt Structure -------------------------------4 2) Power Unit Structure -------------------------------6 4. INSTALLATION AND CONNECTION -------------------------------8 1) Connector and Pin Assignment -------------------------------8 2) DIP Switch Setting -------------------------------9 3) Installation -------------------------------16 5.
Page 3: Components
1. COMPONENTS Main Unit 24P Housing Connector User's Manual Warranty Card 1. Main Unit ------- 1 EA 2. 24P Housing Connector ------- 1 EA 3. User's Manual ------- 1 EA 4. Warranty Card ------- 1 EA Power Unit (Optional Item) 10P Power connector (Optional Item)
Page 4: Specific Features
2. SPECIFIC FEATURES 1) BLDC Motor As adopted the BLDC motor to this pan-tilt unit which has a longer lifetime, it also avaliable to control the motor operating speed in detail. 2) Low noise design To implements the low noise structure, this pan-tilt unit using the worm gears only and do not using the breaker to reduce the speed while the operation.
Page 5: Functional Description
3. FUNCTIONAL DESCRIPTION 1) Pan Tilt Driver...
Page 6 (1) TOP PLATE Mounting the camera unit on this plate. (2) DIP SWITCH COVER Unscrew this cover to selects and setting the Address, Protocol, Baud-rate, Half or Full Duplex and Line-impedance. (3) CAMERA & LENS CONNECTOR It connects the camera power and lens control signals. (4) VIDEO IN BNC It connects the video signal from camera.
Page 7: Power Unit Structure
2) Power Unit...
Page 8 (1) AC 230V INPUT The port for AC 230V input. (2) AC 230V OUT The outlet port for AC 230V. (3) AC 24V OUT The outlet for AC 24V. (4) DC 32V OUT The outlet for DC 32V and connects "+" and "-" terminal correctly. (5) RS-485 OUT It connects the RS-485 output signal to the Driver.
Page 9: Installation And Connection
4. INSTALLATION AND CONNECTION 1) Connectors and Pin Assignment Camera & Lens Connector (24P) Power & RS-485 Connector (10P) POWER & RS-485 CAMERA & LENS CONNECTOR CONNECTOR DC +32V Rx + Rx - DC GND Tx + AC H Tx - AC N ZOOM Rx -...
Page 10: Dip Switch Setting
2) DIP Switch Setting (1) Remove the cover from the DIP Switch box to set the switches and fix the cover tightly and correctly to prevent the water leaking. All the settings must be done after the power off. It will be applied after power off and on again if you change the settings on power-on state.
Page 11 ADDRESS...
Page 12 ADDRESS ID　...
Page 13 ADDRESS ID　...
Page 14 ADDRESS ID　...
Page 15 ADDRESS ID　...
Page 16 ADDRESS ID　...
Page 17: Installation
3) Installation The main power of driver must be off when connect and disconnect the cables, otherwise it may cause the fatal demage to the electronic circuit boards which considered as user's faults.
Page 18 1) Camera & Lens control connection Connects the 24P Camera and Lens control cable. Be careful for the order of cables. 2) Top Plate Dissemble and Fix Housing After disassemble the 3 screws on the top plate, than fix a camera housing on it. [NOTE] Check the housing and adjust the place on the top plate not to contactor touch the power connector before fixing it.
Page 19: Setting And Control
8) Connect GND Connects the Earthing GND to the Base after product installation. 5. SETTING AND CONTROL 1) Setting Menu by OSD Main Menu ▷ Display Setup RS-485 Setup Control Setup Auto Setup Others Exit (1) Display Setup Display Title and Functions on the monitor. (2) RS-485 Setup User can select DIP switch or Menu to change the RS-485 Protocol, Baud rate, Address and Duplex type...
Page 20 [ About Sub Menu ] The user can change and select the setting by moving the joystick to the left, right un and down direction. This operation is same for each protocol. Display Setup ▷ Title Setup Mode Display Exit Display Setup : Set up for Title of each camera and Function Display Title Setup ▷...
Page 21 Display Mode ▷ Title : On Function : On Direction : On Temperature : Off Exit - Normal Mode - Preset 001 ② ④ 20℃ Camera 001 ① ③ ES41˚ Title : ① Display Title in the Normal Mode. Function : ②...
Page 22 RS-485 Setup ▷ Priority : Dip Switch Protocol : Pelco-D Baudrate : 9600 Address : 001 Duplex : Half Exit Priority: User can select RS-485 parameter setting by DIP Switch or Menu. Dip Switch : Change RS-485 parameter by DIP Switch. Manu Value : Change RS-485 parameter by Menu selection.
Page 23 Always On - Set the Fan always on. Always Off - Set the Fan always off. Fan On : Set the Fan on temperature range between 30℃ ~ 55℃. Fan Off : Set the Fan off temperature range between 10℃ ~ 40℃. Heater : Temperature / Always Off Temperature - Set the Heater operating temperature.
Page 24 By push the close or open button, command mode will be released. “ Exit to Iris Command. " Save : Preset will be saved at the assigned no. Delete : Preset will be deleted from the assigned no. Scan Set ▷...
Page 25 Autopan Set ▷ Autopan No : 01 Left Side : Set Right Side : Set Speed : 10 Dwell Time : 10 Sec Exit Auto pan Set : Set the Auto pan function. Auto pan No : Select the Auto pan Group (1 ~ 4) Left Side : Set the Left Side location of the Pan.
Page 26 P/T Calibration Pan Left Side Tilt Down Side Preforms the readjustment of the initial location of sensor. This function reset the parameter value for Pan and Tilt. P/T Speed Adjust ▷ Pan Speed: +00 Tilt Speed: +00 Speed Test Exit Control the PT Driver speed range between -15 ~ +15 and it manages Low and High speed.
Page 27 P/T Slow Stop ▷ Pan Slow: Level 1 Tilt Slow: Level 1 Slow Stop Test Exit It adjusts the Slow Stop time according to the weight on the PT Driver when user manually controls PT Driver by the Joystick. Provided adjustment Level is 6 steps, from Level 1 to 6, and the higher level allows the longer stop time.
Page 28: Control Pan Tile
Baud rate : Display assigned data speed. Address : Display PT Driver address Duplex : Display RS-485 type. 2) CONTROL PANTILT DRIVER Preset 001 20℃ Camera 001 ES41˚ ◈ Use system controller Select the Pantilt driver address to control from the controller. Control the direction by using Joystick or direction key.
Page 29 together. And by this process, previous data is erased. On the monitor if Function character is activated "Preset XXX" will be appeared for 5 seconds. ③ AUTOPAN By the Auto pan command unit performs auto-panning. Speed and Pan range is determined by the parameter set in the Menu. Auto pan start from the left side in the beginning.
Page 30 The indication order is clockwise and it's sequence is N = North, NE = NorthEast, E = East, ES = EastSouth, S = South, SW = SouthWest, W = West, WN = WestNorth, range between 0~90 degrees. ⑨ Temperature Indication The temperature of Pantilt Driver will be displayed by the setting parameter to operate Fan and Heater properly.
Page 31 PELCO-D / PELCO-P Menu Preset Call(Save) + 95 Remarks Preset Save & Call 1 ~ 128 95 except Scan 1 Preset Call + 141 Scan 2 Preset Call + 142 Scan 3 Preset Call + 143 Scan 4 Preset Call + 144 Autopan 1 Preset Call + 151 Autopan 2...
Page 32: Dimension
6. DIMENSION FRONT REAR SIDE...
Page 33 BOTTOM...
Page 34: Specifications
SPECIFICATIONS SYSTEM SPECIFICATION 1° ~ 40°/ Sec ±0.2° CONTROL SPEED TILT 1° ~ 20°/ Sec ±0.2° 360° Endless ANGLE TILT -85°~ 30° LOADING CAPA. MAX 30Kg ACCURACY 0.04° NTSC NTSC - L12V VIDEO SYSTEM PAL - L12V * L12V = Lens Voltage 12V VIDEO INPUT COMPOSITE SIGNAL 1.0 Vp-p, 1 INPUT VIDEO OUTPUT...
Page 35 - MEMO...
