Thank you very much for choosing the Yoshitake's product. To ensure the correct and safe use of the product,
please read this manual before use. This manual shall be kept with care for future references.
The symbols used in this manual have the following meanings.
Warning
Caution
1. Specifications ···························································· 1
2. Dimensions and Weights ············································· 2
3. Structure ·································································· 2
4. Operation ································································· 3
5. Flow rate ·································································· 4
9. Exploded view ·························································· 20
Warranty Information
PF-7000
PUMPING TRAP
INSTRUCTION MANUAL
This symbol indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury.
This symbol indicates a hazardous situation that, if not avoided, may result in
minor or moderate injury or may result in only property damage.

Table of Contents

6.1 Piping example ·················································· 5-6
6.2 Warning and caution for installation ······················· 7-8
7.1 Warning and caution for operation ··························· 9
7.2 Operation method ················································ 9
8.2.1 Daily inspection ··········································· 10
8.2.2 Periodic inspection ······································· 11
8.2.3 Periodic replacement ···································· 11
8.3 Troubleshooting ············································· 12-13
8.4.2 Disassembly method ······························· 14-15
8.4.3 Assembly method ··································· 16-18
8.4.4 How to replace each part ······························· 19
-1-
.
■EPDT-292■

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PF-7000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yoshitake PF-7000

  • Page 1: Table Of Contents

    PUMPING TRAP INSTRUCTION MANUAL Thank you very much for choosing the Yoshitake’s product. To ensure the correct and safe use of the product, please read this manual before use. This manual shall be kept with care for future references. The symbols used in this manual have the following meanings.

  • Page 2: Specifications

    1. Specifications Model PF-7000 25A (Condensate inlet: 25A / Condensate outlet: 25A) 40A (Condensate inlet: 40A / Condensate outlet: 40A) Nominal size 50A (Condensate inlet: 50A / Condensate outlet: 50A) 80A (Condensate inlet: 80A / Condensate outlet: 50A) Application Steam condensate / Non-hazardous fluid...

  • Page 3: Dimensions And Weights

    2. Dimensions and Weights * Bush is attached at condensate inlet for the product of size 50A, and at condensate inlet and outlet for size 40A or less. * The unit is mm. Weight Size (kg) Rc1-1/2 Rc1-1/2 Driving Vent port fluid port Rc1/2 Fig.

  • Page 4: Operation

    4. Operation <State 1> Condensate flows into body [1] via the condensate inlet and then float [9] moves upward due to buoyancy. (See Fig. 3.) In this state, vent valve part of vent valve P is open and inlet valve part of inlet valve P is closed.

  • Page 5: Flow Rate

    5. Flow rate <Driving fluid: steam> Driving pressure <Driving fluid: air> Driving pressure * Flow rate described above indicates condensate volume when condensate flow-in height is 1,000 mm above the bottom of the product. (See 6.1 Piping example) Discharge capacity varies depending on condensate flow-in height. Multiply the volume by the following factors according to condensate flow-in height.

  • Page 6: Installation

    <Open system> Fig. 5 Name Name Name Pressure reducing Pumping Trap Sight glass valve GD-30 15A (GD-1000T 15A PF-7000 SLM-1S or 1F 50A if driving fluid is air) Strainer Strainer SY-5 15A SY-5 15A (80 mesh) (80 mesh) Steam trap...
  • Page 7 <Closed system> Fig. 6 Name Name Name Pressure reducing Pumping Trap Sight glass valve PF-7000 GD-30 15A SLM-1S or 1F 50A Strainer Strainer Check valve SY-5 15A SY-5 15A SCV-2 or 3 15A (80 mesh) (80 mesh) Steam trap Strainer...

  • Page 8: Warning And Caution For Installation

    6.2 Warning and caution for installation Warning 1. Condensate may blow out from vent port following driving pressure drop or stop or failure of the product. Connect a pipe to the port and extend the pipe to safe place. * Failure to follow this notice may scald your skin by blowout of condensate. Caution Before installing the product, remove foreign substances and scale from the piping, and note that seal materials must not flow into the inside of the product or piping.
  • Page 9 11. Be sure to secure maintenance space needed for disassembly and repair of the product. (See Fig 7) The unit is mm. Fig. 7: Maintenance space 12. Recommended height of the condensate inlet is 300 mm or more. (See 6.1. Piping example.) 13.

  • Page 10: Operation Procedure

    7. Operation procedure 7.1 Warning and caution for operation Warning 1. Do not touch the product by bare hands when steam is flowing. * Failure to follow this notice may cause burn or injury. 2. Confirm that pipe joints are connected firmly and not unstable before letting the steam flow. * Failure to follow this notice may cause blowout of steam or condensate, resulting in scalds.

  • Page 11: Maintenance

    8. Maintenance Most of product failure is due to foreign substance inside piping. Be careful for foreign substance inside piping fully. Note that the customer will be required to pay repair charge for any defect that occurs due to foreign matter. Please understand. 8.1 Warning and caution for maintenance and inspection Warning 1.

  • Page 12: Periodic Inspection

    8.2.2 Periodic inspection Check the following items once a year, in addition to daily inspection items. (See Fig. 8 for the numbers inside the brackets [ ].) Actions to Items How to inspect Remedy be taken 1. Close all stop valves in pipes that are connected to the product.

  • Page 13: Troubleshooting

    8.3 Troubleshooting (See 6.1 Piping example for marks and numbers of stop valves, and see Fig. 8 for the numbers inside the brackets [ ].) Trouble Cause Remedy Stop valve V2 at Open stop valve V2. condensate inlet is closed. Pipes at condensate inlet Connect the pipes correctly.

  • Page 14: Disassembly/Assembly Method

    Trouble Cause Remedy Leakage from gasket [3] between body [1] and cover Replace gasket [3]. (See Fig. 8.4.4.) [2]. Leakage from gasket [7] Leakage of steam to between vent valve seat [5] Replace gasket [7]. (See Fig. 8.4.4.) external area of the and cover [2].

  • Page 15: Disassembly Method

    8.4.2 Disassembly method (See Fig. 8) Tools used Name of tool Details (size, nominal size, etc.) Spanner Width across flats: 24 mm, 41 mm Hex socket wrench Width across flats: 19 mm, 32 mm Socket wrench Use with hex socket wrench. Procedure 1: Loosen cap [10] using socket wrench (width across flats: 32 mm), and then remove cap [10] and gasket [11].
  • Page 16 Procedure 4: Remove hex bolts [12] using socket wrench (width across flats: 19 mm), and remove cover [2] and gasket [3] from body [1]. Procedure 5: Fix float arm part of vent valve P [4] using spanner (width across flats: 24 mm), apply spanner (width across flats: 24 mm) to hex part of float [9], and remove float [9].
  • Page 17 8.4.3 Assembly method (See Fig. 8) *Tools used Name of tool Details (size, nominal size, etc.) Any of those that can apply 50, 70, 100, 140 N•m torque Torque wrench (Use hex socket) Width across flats of wrench: 24 mm, any of those that Spanner torque can apply 50 N•m torque wrench...
  • Page 18 Procedure 4: Apply Loctite 620 to screw part of hex bolt [13], and attach vent valve P [4] to cover [2] at 50 N•m torque using wrench (width across flats: 19 mm). Procedure 5: Assemble float [9] to vent valve P [4]. Firstly, apply Loctite 620 to screw part of vent valve P [4].
  • Page 19 Procedure 8: Apply Loctite 620 to screw part of inlet valve P [6]. Then apply lubricant oil (machine oil) to new gasket [8], let it into inlet valve P [6], and put it into cover [2] by hand. Gasket [8] Procedure 9: Attach inlet valve P [6] at 140 N•m torque using torque wrench (width across flats: 32 mm).

  • Page 20: Assembly Method

    8.4.4 How to replace each part How to replace gasket [3] Disassemble the product according to procedure 4 in “8.4.2 Disassembly method”, and replace and assemble the gasket according to procedure 6 and 7 in “8.4.3 Assembly method”. How to replace gasket [11] Disassemble the product according to procedure 4 in “8.4.2 Disassembly method”, and replace and assemble the gasket according to procedure 6 and 7 in “8.4.3 Assembly method”.

  • Page 21: Exploded View

    9. Exploded view *(Enclosed parts are offered as consumables.) Fig. 8. Exploded view -20- ■EPDT-292■...
