5-40 Watt, C-Band LP BUC

Transmitter Module

Operation and Maintenance Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTX-596437-60-ES-20 and is the answer not in the manual?

Questions and answers

Summary of Contents for MiTEC MTX-596437-60-ES-20

  • Page 1: Transmitter Module

    5-40 Watt, C-Band LP BUC Transmitter Module Operation and Maintenance Manual...
  • Page 2 This page has been intentionally left blank.
  • Page 3 Low Power Transmitter Module This document contains information proprietary to mitec telecom inc., or its affiliates, or to a third party to which mitec telecom inc. may have a legal obligation to protect such information from unauthorized disclosure, use, or duplication. Any disclosure, use, or duplication of this document or of any of the information contained herein is expressly prohibited except as mitec telecom inc.
  • Page 4 This page has been intentionally left blank.

  • Page 5: Table Of Contents

    Table of Contents Table of Contents 1 INTRODUCTION ................1 1.1 Receiving and Inspection ..................1 1.1.1 Equipment Damage or Loss ................2 1.1.2 Return of Equipment ..................2 1.2 Preparing for Installation ..................2 1.2.1 Safety Precautions ....................3 2 INSTALLATION & OVERVIEW............. 5 2.1 General Description ....................5...
  • Page 6 Figure 1 – Recommended Distance for Mounting on the Hub..........10 Figure 2 - System Block Diagram ..................11 Figure 3 - Cooling Fan Replacement .................17 Figure 4 - MTX-596437-60-ES-20 - Outline drawing ............1 Figure 5 - MTX-596440-60-ES-20 - Outline drawing ............2 Figure 6 - MTX-596443/46-60-ES-20 – Outline drawing...........3...
  • Page 7 40 Watts To make inquiries, or to report errors of fact or omission in this document, please contact the Telecom Inc technical writing department at Mitec . at (514) 694-9000. IMPORTANT Important information concerning the operation and care of this product, as well as the safety of...
  • Page 8 Table of Contents CAUTION! Identifies situations that have the potential to cause equipment damage. WARNING!! Identifies hazardous situations that have the potential to cause equipment damage, as well as serious personal injury. Rev 7...

  • Page 9: Introduction

    Introduction 1 Introduction The Low Power Transmitter module is a highly reliable, high quality, cost efficient Low Power Transmitter systems designed for use in VSAT applications. This line of superior products, engineered using state of the art technology, is characterized by unparalleled durability and dependability.

  • Page 10: Equipment Damage Or Loss

    2. Refer to the sales order, Purchase Order and the date the equipment was received. Notify Mitec Sales Administration Department of the equipment condition and obtain a Return Material Authorization (RMA) number and shipping instructions. Mitec will pay for the cost of shipping the product to the customer after the repairs are completed.

  • Page 11: Safety Precautions

    Introduction When you are ready to begin your installation, use the information in Section 2 (Installation & Overview) as a guide for making all the required electrical connections. 1.2.1 Safety Precautions Carelessness or mishandling of the transmitter module may damage the unit, causing serious injury to yourself or others.
  • Page 12 This page has been intentionally left blank.

  • Page 13: Installation & Overview

    Installation & Overview 2 Installation & Overview General Description This section describes the installation and theory of operation of the transmitter module. The module is a stand-alone Transmitter System powered from DC source. It will amplify an input signal from an L-Band RF source up to a power level of 5, 10, 20 or 40 Watts CW in C- Band.
  • Page 14 Installation & Overview RF Performance Frequency Sense Positive Output Power @ 1 dB G.C.P. MTX-596x37-60-ES-20 +37 dBm min, at room temperature MTX-596x40-60-ES-20 +40 dBm typ, at room temperature MTX-596x43-60-ES-20 +43 dBm min, at room temperature MTX-596x46-60-ES-20 +46 dBm min, at room temperature...
  • Page 15 Installation & Overview RF Performance Absolute Maximum Current MTX-596x37-60-ES-20 3.3 AMPS @ 18V MTX-596x40-60-ES-20 4.2 AMPS @ 18V MTX-596x43-60-ES-20 5.6 AMPS @ 32V MTX-596x46-60-ES-20 8.7 AMPS @ 32V Mute internally built Shuts off the BUC when L.O. unlocked Status LED Bicolor ;...

  • Page 16: Controls And Status

    Installation & Overview 2.2.1 Controls and status The controls and indicators pertaining to this specific model are described in Appendix B. 2.2.2 General Considerations The module shall meet all specifications over full bandwidth and under all environmental conditions when terminated with a load of VSWR at 1.5:1 unless otherwise specified. All RF specifications shall be met within five minutes after applying DC power, except gain stability and gain flatness, which shall be met after a warm-up period of twenty minutes.

  • Page 17: Assembly And Installation

    Installation & Overview Assembly and Installation Use the information in this section as a guide to assemble and install the transmitter module. CAUTION! Only authorized technical personnel should perform the installation and proper electrical hookups of the transmitter module.

  • Page 18: Figure 1 - Recommended Distance For Mounting On The Hub

    Installation & Overview Top View 3 inches IF Input N- Type 3 inches 3 inches CPRG137 min. RF Output 3 inches min. 3 inches Tall heat sink fins Pointing towards sky Cover pointing towards ground 3 inches min. Side View Figure 1 –...

  • Page 19: Functional Overview

    Installation & Overview Functional Overview 2.5.1 General This section describes the transmitter module functions in detail. The functional overview explains the RF amplification, protection circuit and power distribution. The block diagram in Figure 3 illustrates the transmitter module. IF In...
  • Page 20 This page has been intentionally left blank.

  • Page 21: Operation

    Operation 3 Operation This Section describes the verification of the operation and control of the transmitter module. It shall be performed by authorized personnel prior to maintenance and/or repair. Procedure Verify that the installation procedure described in Section 2 was completed. A complete physical check of the customer’s system is suggested.
  • Page 22 Operation CAUTION! It is strongly recommended not to exceed -5 dBm maximum IF Input level. The transmitter module will be in deep saturation if overdriven. RF performance will degrade significantly, and proper operation will not be possible. This operational condition is the survival mode for the transmitter module.

  • Page 23: Maintenance

    Maintenance 4 Maintenance This Section contains information on how to maintain and troubleshoot the transmitter module. The transmitter module is extremely reliable, requiring very little preventive maintenance or repair. Should there be a malfunction, this Section also contains technical information to help diagnose basic failures.

  • Page 24: Transmitter Module Cooling System Preventive Maintenance

    Maintenance With an IF Input signal level within the small signal region of the transmitter module, measure the VSWR (Return Loss) at the RF input and RF output. Refer to the outline drawing in Appendix A. Plot the swept return loss for both the IF Input and RF Output signals on a test data sheet.

  • Page 25: Figure 3 - Cooling Fan Replacement

    Maintenance AIR FLOW DIRECTION Figure 3 - Cooling Fan Replacement To replace the fan in the 20W and 40W transmitter module, perform the following: 1. Remove the four screws, lock washers and flat washers from the shroud on both sides of the transmitter module. Keep all fasteners for installation later.

  • Page 26: Troubleshooting

    Use Table 2 to quickly isolate a fault within the transmitter module. If the transmitter module is defective, notify mitec and follow the process detailed in section 1.1.2. Symptom Action...

  • Page 27: Out-Of Warranty Repair

    Maintenance 4.1.6 Out-of Warranty Repair A non-warranty and out-of-warranty repair service is available from for a nominal charge. mitec The customer is responsible for paying the cost of shipping the BUC both to and from mitec these repairs. Rev 7...
  • Page 28 This page has been intentionally left blank.

  • Page 29: Drawings & Schematic Diagrams

    Appendix A Appendix A Drawings & Schematic Diagrams 5 to 40 Watt C Band Low Power Transmitter Module - Outline Drawings Rev 7 A - 1...
  • Page 30 This page has been intentionally left blank.
  • Page 31 Appendix A Figure 4 - MTX-596x37-60-ES-20 - Outline drawing...
  • Page 32 This page has been intentionally left blank.
  • Page 33 Appendix A mitec Figure 5 - MTX-596x40-60-ES-20 - Outline drawing C- 1 Rev 7...
  • Page 34 This page has been intentionally left blank.
  • Page 35 Appendix A Figure 6 - MTX-596x43/46-60-ES-20 – Outline drawing...
  • Page 36 This page has been intentionally left blank.

  • Page 37: Serial Protocol Documentation

    Appendix B Appendix B Serial Protocol Documentation Appendix B contains the serial protocol documentation relevant to this product. Rev 7 B - 1...
  • Page 38 This page has been intentionally left blank.
  • Page 39 9000 Trans Canada, Pointe Claire, QC, Canada H9R 5Z8 Confidential and Proprietary to Mitec. This is a Controlled Document. Document Technical Specification Revision: Name: File Name: CBand_BUC_FSK_Protocol V1 Page: Page 1 of 6 Model Number: Originator: Qingjun Zhang Revision Date...
  • Page 40 TABLE OF CONTENT INTRODUCTION........................3 ........................3 EFERENCE OCUMENTS USART S ..........................3 ETTINGS PACKETS ANALYSIS......................4 RX P ............................. 4 ACKETS 2.1.1 Status Request ......................4 2.1.2 Set Transmission (Enable/Disable)................4 2.1.3 Set RFT Address......................4 2.1.4 Set RFT Frequency ....................4 TX P ) ....................

  • Page 41: Reference Documents

    Transmitter) is used here to designate the whole system RFT + MCU excluding the IDU. 1.1 Reference Documents [1]. SkyWan Monitor and Control Protocol Version 1 (SMCP-V1), ND SatCom [2]. SMCP-V1.doc Rev2, mitec telecom [3]. CDM-570/570L Installation and Operation Manual, Chapter 16. 1.2 USART Settings As per the IDU SMCP “Physical Layer”...
  • Page 42 2 Packets Analysis 2.1 RX Packets The packets received by the RFT is 7 bytes long and have the following generic format: ADDR DATA0 DATA1 DATA2 DATA3 Where: Byte Definition Value ADDR Address of the RFT 0x01 to 0x0F Command type 0x01 to 0x04 DATA0 Data byte0 0x00 to 0xFF...
  • Page 43 FREQ1: Input Frequency modulo 256 (in MHz.) 2.2 TX Packets (Response Packets) To the received packet of figure-a the Packet Handler will generate a packet that looks like figure-b: Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 ADDR 0x01...
  • Page 44 2.2.6 Transmit Enable/Disable (TX) – BYTE4 (Bit3) This is the flag that tells about the unit mute status. TX=0: transmission disabled (the unit is muted). TX=1: transmission enabled (the unit is unmuted). 2.2.7 Consistency (C) – BYTE4 (Bit2) This flag tells whether the last packet received by the unit had consistent parameters or not.

  • Page 45: Accessories

    Appendix C Appendix C Accessories: Power supply: 057-0024: 1U rack mount Indoor Power Supply, 110/220Vac, for 5/10/20/40W C-Band MTX BUCs. 215559-001MD: 1U rack mount Indoor Power Supply, 110/220Vac, + Bias-Tee, for 5/10/20/40W C-Band MTX BUCs, used for standalone option.
  • Page 46 This page has been intentionally left blank.
  • Page 48 This page has been intentionally left blank.
  • Page 50 This page has been intentionally left blank.
  • Page 52 This page has been intentionally left blank.
  • Page 54 This page has been intentionally left blank.
  • Page 56 This page has been intentionally left blank.
  • Page 58 This page has been intentionally left blank.
  • Page 60 This page has been intentionally left blank.
  • Page 62 This page has been intentionally left blank.
  • Page 64 This page has been intentionally left blank.
  • Page 66 This page has been intentionally left blank.

  • Page 67: Spare Parts

    Please make sure to include all identifying information to facilitate the processing of your order. The order may also be sent via email or regular mail delivery, at the following address. Mitec Telecom inc. 9000 Trans Canada Blvd. Pointe Claire, Québec, Canada...
  • Page 68 This page has been intentionally left blank.
  • Page 69 Spare Parts Order Form Power Transmitter Module From: Place By: Signature: Telephone: Email: Part Description Part Number Quantity Unit Line Price* Total* * To be completed by Mitec Sales Department Fax to: Customer Service (514) 694-3814 C- 1 Rev 7...
