Aeris System Debugging Guide
d
August 2015
Aeris SmartSense ®
Debugging Guide
Part Number: 01-571-8301
Revision: 8/26/15
Rev: A
Instructions: To help us better understand the issue, before returning the parts for warranty, please check
with an "X" each box below and briefly explain the malfunction of the system on the blank space provided.
☐ Are all hoses connected together from the axle to the control box?
See setup section in
debugging guide.
☐ Did light blink 3 times in control box on power up?
See step 1 in debugging guide.
☐ Did light at front of trailer blink 3 times on power up?
See steps 2 & 3 in debugging guide.
☐ Is the light at the front blinking inconsistently after the 3 blinks?
See step 4 in debugging guide.
☐ Is the light at the front staying on or blinking consistently?
See step 5 in debugging guide.
☐Does the light eventually turn off?
See step 6 in debugging guide.

Setup

Connect the Driver Left Rear (Curbside rear) Axle Pressure line to the far left point on the flow manifold
closest to the regulator.
Connect the Driver Left Front (Curbside front) Axle Pressure line to the second position on the flow
manifold.
Connect the Driver Right Front (Roadside Front) Axle Pressure line to the third position on the flow manifold.
Connect the Driver Right Rear (Roadside Rear) Axle Pressure line to the far right point on the flow manifold
farthest from the regulator.
Note: On single axle systems the two middle ports should be plugged as the front axle will not be used.
Connect control box to ABS connector pigtail
Connect Driver Warning Light (DWL) to 7 way connector power and ground
Page 1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartSense and is the answer not in the manual?

Questions and answers

Summary of Contents for Aeris SmartSense

  • Page 1 Aeris System Debugging Guide August 2015 Aeris SmartSense ® Debugging Guide Part Number: 01-571-8301 Revision: 8/26/15 Rev: A Instructions: To help us better understand the issue, before returning the parts for warranty, please check with an “X” each box below and briefly explain the malfunction of the system on the blank space provided.
  • Page 2 Aeris System Debugging Guide August 2015 AERIS SmartSense installation debugging guide 1. With the entire system connected apply power. Does the red light D1 on the control box circuit board blink at power up 3 times?  If no then check power connections +12 and Ground continuity to the circuit board and the 7 pin connector and verify the ABS harness is firmly plugged in.
  • Page 3 Aeris System Debugging Guide August 2015  It is absolutely paramount that both the DWL and the control box have power cycled on them at the same time for the system to associate correctly. If power is only cycled to one unit then the “1” on the display will never change.
  • Page 4 Aeris System Debugging Guide August 2015 8. If the system has consistently taken air on a particular wheel end on a number of recent trips then the severe alert indication or maintenance alert triangle will be given on the display and will remain on until the system has completed a couple of trips without taking air.
