Summary of Contents for Satson HDM-4150
- Page 1 Instruction Manual HDM-4150/HDM-4250/HDM-2150 Product Name Model no. Quad HD Digital Modulator 1x RF Carriers HDM-4150 Quad HD Digital Modulator HDM-4250 2x RF Carriers HDM-4150 Twin HD Digital Modulator HDM-2150 1x RF Carriers Version Date 04/2018...
- Page 2 Contents P3 Introduction & Main features P3 General Safety Introduction P5 Technical Specifications P7 Basic Installation P8 Quick Menu Guide P9 Operating Adjustment Via LCD & Buttons P14 Operating Adjustment Via Web Interface P16 Channel Table List – Europe...
- Page 3 The newest solution for a simple & affordable video distribution, anywhere. The HDM-4150/4250/2150 can distribute 4 or 2 HD video signals to all TVs through the existing coax cables. Available for DVB-T off air (combine with antenna channels) & QAM (Combine with cable operator’s channels), can change the standard at any time via software.
- Page 4 General Safety Introduction ◆ Read Instruction All the safety and operating instructions should be read before the product is operated. ◆ Retain Instruction The safety and operating instructions should be retained for future reference. ◆ Heed Warnings All warnings on the product and in the operating instructions should be adhered to. ◆...
-
Page 5: Technical Specification
－ If an outside antenna or cable system Is connected to the product, be sure the antenna or cable sys- tem is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding elec- trodes, and requirements for the grounding electrode. - Page 6 Type/Reference HDM-4150 / H15101707100 INPUT Video & Audio input 4 x HDMI Connector type Type A receptacle ENCODER Video resolution Up to 1080p@30Hz Video encoding format H.264/AVC Audio encoding format MPEG-1 audio layer ll (ISO/IEC 11172-3) PID setting PMT/ Video & Audio/ PCR NID/ ONID/P.D.S./TS ID...
-
Page 7: Basic Installation
Basic Installation... -
Page 8: Quick Menu Guide
Quick Menu Guide System Booting Please wait… HDM-4150 DVBC 474.000MHZ Set RF Output RF Out Advanced RF Setting Rtrv Status Set Video Source Video Rtrv Status Audio Set Audio Set Service Name Submenu Set Service ID Set LCN Set PID... - Page 9 Operating Adjustment Via LCD & Buttons For ‘Menu & Submenu’ settings, press the OK button to access the adjustment mode. In this mode ‘＊’ will be displayed in the upper right corner. Use the UP or DOWN buttons to select parameter values, then press OK button to confirm the setting.
- Page 10 When all the item in ‘Setup RF Output’ are done, there will be a confirmation on Are you sure? the display. Press UP or Down button to select YES or NO. Select ‘y’ for YES, all the settings above will be stored in memory. Select ‘n’ for NO to cancel. B.
- Page 11 AUDIO Encoder Rate: 128K, 256K, 384K 128K STREAM A. Set Service Name Stream Following the main Submenu flow charts enter the ’Set Service Name’. Press the OK button to enter the Submenu. Set Service Name Service Name: Edit the service name by preference. 0-9;...
- Page 12 PCR: 32~8191, exluding 71 Video: 32~8191, exluding 71 2064 Audio: 32~8191, exluding 71 2068 When all the item in ‘Stream set PID’ are done, there will be a Are you sure? confirmation on the display. Press UP or Down button to select YES or NO.
- Page 13 Service Type: HD Service, SD Service HD service When all the item in ‘Set Service Type’ are done, there will be Are you sure? a confirmation on the display. Press UP or Down button to select YES or NO. Select ‘y’ for YES, all the settings above will be stored in memory.
-
Page 14: Operating Adjustment Via Web Browser
Select ‘n’ for NO to cancel. OPERATING ADJUSTMENT VIA WEB BROWSER The web browser will allow the user to fully configure the HDM-4150 unit via an Ethernet connection. Your computer will require a static IP address in the range 192.168.1.XXX 1. - Page 15 4. Enter the HDM-4150 IP address 5. Click on ENTER to access the welcome screen. Enter the default password ‘1234’...
- Page 16 Appendix-Channel Table List of Europe...
