Dear customer,

this is a short description to give you some basic informa-

tions about the GSM modem you purchased.

Informations to the AT commands you will find on the CD

as a PDF file. As well informations can be downloaded from

our website www.coniugo.com. Those documents can be

read and printed with the Adobe Acrobat Reader.

GPRS GSM modem:

UMTS/HSPA- modem:

LTE modem:

modem module GL865

modem module UL865

modem module HE910

Table of Contents

Need help?

Do you have a question about the UL865 and is the answer not in the manual?

Questions and answers

Summary of Contents for ConiuGo UL865

Page 1 Informations to the AT commands you will find on the CD as a PDF file. As well informations can be downloaded from our website www.coniugo.com. Those documents can be read and printed with the Adobe Acrobat Reader. GPRS GSM modem:...
Page 2 Introduction / Declaration of Conformity Thank you for buying the ConiuGo GSM/GPRS-modem. This product was produced according to the latest technology. It is a device suited for data transmission in GSM networks The manufacturer is: ConiuGo® GmbH Berliner Strasse 4A...
Page 3: Table Of Contents
Table of contents 1. Limited Warranty / Limitation of Liability ..........4 2. Use as agreed.................... 5 3. Safety notes ....................6 4. Description of the modem ............... 7 5. Installation of the modem ................ 7 6. Electrical installation ................8 7.
Page 4: Limited Warranty / Limitation Of Liability
Proof of purchase must accompany the product re- turned for consideration under this warranty. Any use of the modem is carried out at your own risk. In no event shall ConiuGo be liable for incidental or consequential damages, including, without limitation, loss to property other than the ConiuGo GmbH product, loss of the use of the ConiuGo GmbH product or other property, or other economic loss.
Page 5: Use As Agreed
2. Use as agreed The modem is designed for use in Germany and the European Community. Accor- ding to the rules of CE-conformity, it is not allowed to distribute this device without a manual in the national language. The manual has to be authorised by the manufac- turer.
Page 6: Safety Notes
Safety hints have to be regarded! 3. Safety notes The modem corresponds to broadly valid GSM standards. At the use of a GSM transceiver for the mobile communication, certain safety precautions have to be made. GSM products can ignite explosive or inflammable gases. The use of the modem in an environment with a potential for these conditions must be definitely excluded.
Page 7: Description Of The Modem
Because of the RF-radiation of the GSM unit the modem has to be used with a suitable GSM antenna for the RF band, depen- ding on the type of the chosen GSM network). The antenna ca- ble has to be free from any damages. 4.
Page 8: Electrical Installation
6. Electrical installation Power supply This information is given by the product label. Connection LAN, RS 232 (Com- port) or USB according to the product label. 7. Insert the SIM- card At delivery the modem is prepared for inserting a SIM-card. Put the modem into operation as follows: Make sure that you have a SIM-card activated for all required services (e.g.
Page 9 If you use the GSM (GPRS dualband / quadband) professional modem, open the device to insert the SIM card as in figure 3. fig.3 Connect the antenna- adaptor or an antenna to the modem.
Page 10: Installation Of The Usb Driver
If the PC does not register the modem you have to restart the PC. 9. First modem settings The use of the modem is possible with any terminal software. ConiuGo delivers its own terminal software “ConiuGo Modem Terminal” (with limited features) that is available from the product- CD.
Page 11: Troubleshooting
PIN-number Check by “AT+CPIN?” if a PIN-number has been already entered, or enter the PIN- number by using “AT+CPIN="xxxx“”. The PIN has to be typed in with quotation marks! Signal quality Check the signal quality by “AT+CSQ”. With this command the physical signal quality is tested.
Page 12 The data-bits of transmitter and receiver are not equal: Adjust them by AT+FOPT=1,0 or AT+FOPT=1,1. In case of problems please consult our homepage or send an e-mail to: support@coniugo.com Please give informations regarding the following issues: • Where and when buyed? •...
