moistureMASTER HX User Manual Lines

Heat recovery home ventilation system
Hide thumbs

Advertisement

Table of Contents

1
moistureMASTER HX HEAT RECOVERY
HOME VENTILATION SYSTEM
USER GUIDELINES MK6 Version
(Sept 2017)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HX and is the answer not in the manual?

Questions and answers

Summary of Contents for moistureMASTER HX

  • Page 1 HX HEAT RECOVERY HOME VENTILATION SYSTEM USER GUIDELINES MK6 Version (Sept 2017)
  • Page 3 HEAT RECOVERY VENTILATION QUICK REFERENCE GUIDE TO RUNNING THE SYSTEM A heat recovery ventilation system is not in itself a heating system. It helps to preserve the heat within your home at the same time as it replaces the indoor stale air with fresh air from outside.
  • Page 5 Exhaust air temperature. (Inside Air going out, air from inside home) Selects EXHAUST FAN and HEAT levels (If heater is Supply air temperature (From HX to included) the house, fresh warmed air to house) Selects (SUPPLY) or FRESH Cost Control CCP (Running costs of...

  • Page 6: Fan Operation

    Set House This is the minimum air temperature that you want the HX system to deliver air on the supply side of the sys- tem and is delivered to the room supply diffusers. This setting is used in conjunction with the booster heater and is designed to always deliver the temperature selected.

  • Page 7: Settings Menu

    Fresh Air Supply fan will stop working at this temperature. This will prevent the system from heating your home up on a hot summers day. The HX unit can only be used for cooling in conjunction with an air conditioning unit.

  • Page 8: Cost Control

    Control. You will be able to enter a specific daily budget for the heater operation by setting your house- hold power costs and making a selection on how much money you want to limit the heater operation to in your moistureMASTER system. Move the cursor to CCP settings then press SELECT and a series of screens will appear.
  • Page 9 In this case the heat exchanger will act in reverse by cooling the warmer fresh incoming air before it is introduced. In the Summer Bypass mode there are three selections of operation. All Fresh air passes through the HX Unit All Fresh air by-passes through the HX Unit...
  • Page 10 Summer Maximum which is the first selection of the Settings Menu. When the tem- perature falls below that level the by-pass is turned off and the air resumes passing through the HX unit. ZONE CONTROL (Optional) Zone control is a motorised damper mechanism that is able to switch the supply air to two different parts of the home.

  • Page 11: Timer Function

    Timer Function The timer is used solely to control the booster heater operation of the HX Unit. It is the last selection in the Settings Menu. Place the cursor next to the Heater Timer label and press SELECT. The timer screen will automatical- ly appear.
