- Page 1 IoT Gateway User’s Guide Version:...
-
Page 2: Revision History
This is a Class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Trademarks SiMPNiC is a registered trademark of Connection Technology Systems Inc. All trademarks belong to their respective proprietor Contents subject to change without prior notice. -
Page 3: Contact Information
18F-6, No.79, Sec.1, Xintai 5th Rd., XiZhi Dist., New Taipei City 221, Taiwan(R.O.C) Tel: +886-2-2698-9661 Fax: +886-2-2698-9662 Dir.Line:+886-2-2698-9201 www.ctsystem.com www.simpnic.com Global Authorized Representatives: ▓ Connection Technology USA Inc. Connection Technology Systems Japan 40538 La Purissima Way, Fremont, CA 94539, USA... -
Page 4: Table Of Contents
Table of Contents Revision History ..................ii CONTACT INFORMATION ................III TABLE OF CONTENTS ................IV CHAPTER 1. INTRODUCTION ..............2 1.1 O S1 ................2 VERVIEW OF 1.2 K .................. 3 EATURES 1.3 R & S & T ..............5 ANELS 1.3.1 Rear Panel ................ - Page 5 About this manual In this user’s guide, it will not only clearly introduce SiMPNiC S1 Gateway but tell you how to install this gateway with detailed instructions. Organization of the Manual Chapter 1 “Introduction” describes the features of the S1 Gateway ...
-
Page 6: Chapter 1. Introduction
Introduction Introduction SiMPNiC’s S1 Gateway is typically designed to meet the emerging Internet of Things (IoT) Ethernet requirements. This reliable solution provides the security mechanism to prevent your network from malicious attacks. 1.1 Overview of S1 With the cutting-edge technology, SiMPNiC delivers a managed Layer 2 gateway, S1, for IoT_based services in the home automation. -
Page 7: Key Features
2 x Buttons for easy Scene Control. Lightweight, Stylish Design to blend into your house. Simple installation with wall-mount kit. SiMPNiC Edge Security (SES) & Firewall. AES-128bit encryption both downstream and upstream. Utilize Secure Tunnel to communicate with mobile App. - Page 8 Introduction Weight: 0.22kg (Include the bracket) Dimensions: 120(W)x140(D)x37(H)mm Temperature: Operating: 0ºC~40ºC; Storage: -20ºC~60ºC Humidity: 5%~90%, non-condensing Publication date: Oct. 26, 2018 Revision 1.0...
-
Page 9: Rear & Side & Top Panels
1.3 Rear & Side & Top Panels 1.3.1 Rear Panel Figure 1-1 Rear View of S1 Gateway The interfaces on the rear panel of S1 Gateway are described below: A. Micro USB Power Jack B. USB Connector C. LAN Port D. -
Page 10: Side And Top Panels
Introduction 1.3.2 Side and Top Panels Figure 1-2. Side View of S1 Gateway The interfaces on the side and top panels of S1 gateway are described below: E. Pair Button (For more information, please refer to Section 1.5) F. Action Buttons (For more information, please refer to Section 1.5) -
Page 11: Led Definitions
Introduction 1.4 LED Definitions The S1 status is indicated by the Status LED on the top panel of the device. Color Operation Lit when the device is booting up. Slowly blinking when the device is upgrading the firmware or press the Pair button for 5 seconds and then release to restart the system. -
Page 12: Buttons Description
The following table contains various functions that will be proceeded when pressing Pair/Action button of S1 Gateway. Button Description Press the Pair Button of S1 for 3 seconds to enable the WPS function. Press the Pair Button of S1 for 5 seconds to reboot the system. -
Page 13: Chapter 2. Installation
Installation Installation To properly install S1 Gateway, please follow the procedures listed below. These procedures will be respectively described in detail in the following sections. Installation Requirements Checking the Package Contents Installing S1 Gateway Powering on S1 Gateway ... -
Page 14: Installation Requirements
Installation 2.1 Installation Requirements ATTENTION Be sure to power off before installing or wiring your S1 Gateway. 2.2 Checking the Package Contents Unpack the package carefully and check the package contents. The standard package should contain the following items: ... -
Page 15: Installing S1 Gateway
Installation 2.3 Installing S1 Gateway 2.3.1 Wall-Mounting Installation Just follow the procedures listed below for step-by-step instructions to mount S1 on the wall. Select a proper space to drill 3 holes upon the mounting holes of the wall- mount bracket shipped with the package. -
Page 16: Connecting S1 Gateway To Network
S1 Gateway, please make sure that network cables and power cables are securely connected. Connect the LAN Port of S1 to a router using the RJ-45 network cable. (Skip this step if you decide using the wireless connection.) ... -
Page 17: Operation
Direct RJ-45 LAN cable connection between a router and the gateway is required for this local management. Note: The default IP Configuration Type of S1 is DHCP mode, a router with DHCP server function is required in order to automatically provide IP address for S1. -
Page 18: Maintenance
Maintenance Maintenance This S1 Gateway is easy to maintain. The procedures are suggested when you would like to identify faults, perform hardware replacement and do the firmware upgrade. 4.1 Fault Identification Identifying faults can greatly reduce the time required to find problem and solution. Users may perform local check or remote check to find the problems. -
Page 19: Hardware Replacement Procedures
Failure to observe the above warning will immediately void any Warranty. 4.3 Firmware Upgrade This S1 Gateway may perform the firmware upgrade when required. The latest firmware can be downloaded using OTA (Over-the-Air) technology via your mobile phones/tablets to have your S1 Gateway updated automatically with the latest firmware. - Page 21 A Brand of CTS Inc. 18F-6, No. 79, Sec 1, Xintai 5 Rd., Xizhi Dist., New Taipei City 221, Taiwan TEL: +886-2-6616-1016 www.simpnic.com...
