Summary of Contents for Lone Rider ADV
- Page 1 ADV Tent User Guide...
- Page 2 Contents: Quick-Start Reference ....2 Detailed Step-by-Step Setup Guide ..3 Rain Fly Setup Guide ....9 Tent Packing Guide .
- Page 3 Quick-Start Reference: Stake out tent, assemble frame and attach to corners of tent. Attach tent to frame using corresponding fasteners. Attach rain fly to tent using corresponding fasteners and stake out doors.
- Page 4 Detailed Step-by-Step Setup Guide: Step 1: Unpack contents of bag and spread out tent on a flat and suitable ground surface. Step 2: Use supplied stakes to evenly tension floor of tent from each corner, as shown: (If ground is wet or rocky, place tent on top of included groundsheet)
- Page 5 Step 3: Remove aluminum tent frame from pouch and assemble. Step 4: Insert each end of the tent frame into the aluminum pole-captures found at each corner of the tent.
- Page 6 Your tent should now appear as shown: Step 5: Fasten the top two tent clips to the tent frame, just outside of each upper pole.
- Page 7 (Photo of top tent clip properly fastened to tent frame) Step 6: Insert each end of the upper frame poles into the aluminum pole captures located above each door.
- Page 8 (Photo of upper frame poles properly fastened to aluminum pole captures) Your tent should now appear as shown:...
- Page 9 Your ADV Tent is now properly set up and suitable for use in warm and dry weather. (Continue to next page for instructions on securing rain fly to tent)
- Page 10 Step 8: Loosely place rain fly over tent, oriented as shown: Step 9: Locate aluminum pole capture found at each corner of the tent.
- Page 11 Step 10: Secure each aluminum pole capture to its corresponding pole-end, underneath the aluminum pole capture previously secured, as shown: Step 11: Unzip both sides of each door and locate aluminum pole capture found at top of each door zipper.
- Page 12 Step 12: Secure each aluminum pole capture to its corresponding pole-end. Step 13: Zip up tent doors and use supplied stakes to secure the tent doors as shown:...
- Page 13 Your Lone Rider ADV Tent is now ready for use in virtually any conditions. (Continue to next page for instructions on packing tent)
- Page 14 Step 1: Detach and remove rain fly, set aside. Detach tent from frame in the reverse order that it was attached. Remove tent frame, neatly collapse and store in designated bag. Step 2: Remove stakes from ground and store in designated pocket, then fold tent by ⅓,...
- Page 15 Step 3: Fold tent again by ⅓, then place groundsheet bag and frame/stake bag on one end of tent as shown: (Lengh of frame/stake bag should be roughly equal to width of folded tent) Step 4: Roll the folded tent tightly around the frame/stake bag and groundsheet...
- Page 16 Step 5: Place rain fly on ground surface and fold in half along it’s longest axis, as shown: Step 6: Fold rain fly in half once more along its longest axis, as shown:...
- Page 17 Step 7: Fold rain fly in half a final time along its longest axis, as shown: Step 8: Fold rain fly in half along its shortest axis and place rolled-up tent on wide end of rain fly, as shown:...
- Page 18 The entire tent roll should now fit easily back into provided dry bag. Step 10: Fold roll-top enclosure of dry bag 3 time and clip to secure. Your Lone Rider ADV Tent is now properly packed and ready for transport.
