Retro Style 4* Icebox Fridge
MAB340C/K/R
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
Installation and Operating Instructions
- Cream/Black/Red
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for montpellier MAB340C
Summary of Contents for montpellier MAB340C
- Page 1 LAUNDRY - DISHWASHING - COOKING - COOLING Installation and Operating Instructions Retro Style 4* Icebox Fridge MAB340C/K/R - Cream/Black/Red Please read these instructions carefully before attempting to install or use this appliance. We recommend that you keep these instructions in a safe place for future reference.
- Page 2 Welcome Thank you for choosing this Montpellier Retro Refrigerator. Our Retro Fridges have been designed to provide you with the best combination of style, reliability and performance to give you years of trouble-free use. You may be familiar with a similar product, but please take time to read these instructions carefully before installing or using your Fridge to ensure you get the most from your purchase.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS ................. 4 1.1 General Safety Warnings ....................4 1.2 Installation warnings .......................7 1.3 Electrical information (For UK type plug) ................8 1.4 During Usage........................8 2 DESCRIPTION OF THE APPLIANCE ............. 10 3 USING THE APPLIANCE ................10 3.1 Thermostat Setting .......................11 3.2 Temperature Settings Warnings ...................11 3.3 Accessories ........................12 3.3.1 Ice Tray ........................12... -
Page 4: Safety Instructions
1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings Read this user manual carefully. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. - Page 5 natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
- Page 6 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 7: Installation Warnings
• Do not cover the body or top of fridge 1.2 Installation warnings freezer with lace. This will affect the Before using your fridge freezer for the first performance of your fridge freezer. time, please pay attention to the following •... -
Page 8: Electrical Information (For Uk Type Plug)
1.3 Electrical information (For UK type 1.4 During Usage plug) • Do not connect your fridge freezer to the mains electricity supply using an Warning! This appliance must be extension lead. earthed. • Do not use damaged, torn or old plugs. The mains lead of this appliance has been •... - Page 9 Old and Out-of-order Fridges Notes: • If your old fridge or freezer has a • Please read the instruction manual lock, break or remove the lock before carefully before installing and using your discarding it, because children may appliance. We are not responsible for the get trapped inside it and may cause an damage occurred due to misuse.
-
Page 10: Description Of The Appliance
2 DESCRIPTION OF THE 3 USING THE APPLIANCE APPLIANCE “Door Open” Indicator; The "Door Open" indicator on the handle shows whether the door has closed properly or whether it remains open. If the indicator is red, the door is still open. If the indicator is white, the door is properly closed. -
Page 11: Thermostat Setting
3.1 Thermostat Setting If Super Switch is available: • Set this switch to the ‘ ‘ position, except The thermostat automatically regulates when the ambient the temperature inside the refrigerator and temperature is below 16°C, freezer compartments. Cooler temperatures such as in winter, or when can be obtained by rotating the knob to the freezer temperature higher numbers, 1 to 5. -
Page 12: Accessories
• When the appliance is first switched on, 3.3 Accessories allow it to run for 24 hours in order to reach operating temperature. During this 3.3.1 Ice Tray time, do not open the door and do not • Fill the ice tray with water and place in keep a large quantity of food inside. -
Page 13: The Magic Shelf
4 FOOD STORAGE 3.3.3 The Magic Shelf The Magic Shelf, which is on the Crisper Cover (safety glass), is designed to 4.1 Refrigerator Compartment allow for more storage space within the • To reduce humidity and avoid the appliance. The shelf is mobile so you consequent formation of frost, always can arrange long or tall containers on the store liquids in sealed containers in the... -
Page 14: Freezer Compartment
products and clean any leakages on the • Consume thawed frozen food within a shelves. short period of time after defrosting • Do not put food in front of the air flow • Never place warm food in the freezer passage. - Page 15 vinegar, assorted spices, ginger, garlic, onion, mustard, thyme, marjoram, black pepper, etc.) changes and they assume a strong taste when they are stored for a long period of time. Therefore, add small amounts of spices to food to be frozen, or the desired spice should be added after the food has thawed.
- Page 16 Maximum storage time Vegetables and Fruits Preparation (months) String beans and beans Wash, cut into small pieces and boil in water 10 - 13 Hull, wash and boil in water Beans Clean and boil in water 6 - 8 Cabbage Clean, cut into slices and boil in water Carrot Cut the stem, cut into two pieces, remove the core...
-
Page 17: Cleaning And Maintenance
5 CLEANING AND • Two-star frozen-food compartments are suitable for storing pre-frozen food, MAINTENANCE storing or making ice cream and making ice cubes. Disconnect the unit from the power • One-, two- and three-star compartments supply before cleaning. are not suitable for the freezing of fresh Do not wash your appliance by food. -
Page 18: Defrosting
5.1 Defrosting rise in temperature will shorten its storage life. Remember to use this food Defrosting the Refrigerator within a relatively short period of time. Compartment • Set the thermostat knob to position “•” and disconnect the appliance from the mains. -
Page 19: Shipment And Repositioning
6 SHIPMENT AND 7 BEFORE CALLING AFTER- REPOSITIONING SALES SERVICE If your refrigerator is not working properly, 6.1 Transportation and Changing there may be a minor problem. Check the Positioning following. The appliance does not operate • The original packaging and foam may be Check if: kept for re-transportation (optional). -
Page 20: Tips For Saving Energy
8 TIPS FOR SAVING ENERGY Recommendations • If the appliance is switched off or 1. Install the appliance in a cool, well- unplugged, wait at least 5 minutes before ventilated room, but not in direct sunlight plugging the appliance in or restarting and not near a heat source (such as a it in order to prevent damage to the radiator or oven) otherwise an insulating... - Page 21 EN - 21...
- Page 22 EN - 22...
- Page 23 THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS. Your 2 year Manufacturer’s guarantee Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during the THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS. first 24 months from date of purchase provided that:...
- Page 24 Montpellier Domestic Appliances Ltd. Unit 1, Tewkesbury Retail Park, Northway Lane, Tewkesbury, Gloucestershire GL20 8JU www.montpellier-appliances.com The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
