Summary of Contents for ShowTex AutoReveal
- Page 1 S howTex Use r Manual Aut oR eve al...
-
Page 2: Table Of Contents
Ta bl e o f C o nt e n ts Introduction Safety Instructions Components Installation Open the flight case Attach the reveal curtain Connect the motor to the connector cable Connect the cable to the controller Connect the controller to the power cable Connect the controller to the power supply Assemble the glass fibre rods Position the flight case... -
Page 3: Introduction
In tro duc t io n The ShowTex AutoReveal is an extremely user friendly reveal system. · Ideal for unveiling a new car or other types of product launches. · Reveal products automatically in less than 20 seconds thanks to the easy to use remote control. -
Page 4: Safety Instructions
· Read this user manual carefully · The AutoReveal system may only be attached to light weight fabrics. · The maximum load capacity for the motor is 7kg. Overloading the system can cause damage to it and endanger the system’s users. - Page 5 C o m po ne nt Pa r t s The Auto Reveal System consists of the following parts: AutoReveal-system AutoReveal flight case Remote Control Connector cable 25m Power Cable 2m Glass fibre rods Flexible adjustment tool Sh ow Tex U s er M anu a l Au t o Reve al...
-
Page 6: Components
C o m po ne nt Pa r t s Name Art.nr. Colour Weight Information Flight Case 8160 7400 1007 32 kg/piece 100x30x50cm Remote Control 8160 0915 0257 1,55 kg/piece Connector Cable 8160 0950 0007 3,45 kg/piece Length: 25m Power Cable 8150 0903 0007 4,20 kg/piece Length: 2m... -
Page 7: Installation
As s em bl y Foll ow t h es e s teps duri ng use: O p e n t he fl i gh t cas e A tta c h t he reve al c u r t ai n If the curtain is already attached go to step 3 Pull the curtain through the opening in the front of the flight case and attach it to the roller along the Velcro strip. -
Page 8: Connect The Controller To The Power Cable
As s em bl y C on nec t t he c o n t ro l l er to th e p owe r c a b l e Connect the power cable to the “POWER IN” outlet of the remote control. Attention: The standard length of this cable is 2m. -
Page 9: Position The Flight Case
As s em bl y Attention: Make sure the glass fibre rods are securely at- tached on the inside of the flight case. ✘ ✔ U nrol ling / Ro l l in g up t h e cu r t a in Attention: Check that no loose objects are present in the flight case! Make sure the curtain remains well tensioned and straight while unrolling or rolling... -
Page 10: Maintenance Instructions
· The best way to care for the AutoReveal system is to use it often. Each mechanical part should be used at least once a week. In this way, residue and dirt can’t collect in the bearings and irregular noises can be discovered in time. -
Page 11: Trouble Shooting
Make sure the curtain remains well tensioned and straight while unrolling or rolling up, otherwise it can get stuck in the reveal case and block the rolling mechanism. For more technical assistance please contact your local ShowTex office. (see back of manual) H AVE A GRE AT S HOW! - Page 12 www. s howt e x. c om...
