Tyco Electronics FOMS-FSP-O Series Installation Instruction

19” 1hu splicing and front patching shelf
Hide thumbs

Advertisement

Quick Links

Download this manual
Contents
19" 1HU Splicing and Front Patching Shelf
1 Introduction
2 General
2.1 Characteristics
1
Introduction
The FOMS-FPS-O shelf is a mechanical enclosure for a physical fiber management system.
It is used for splicing and connector patching: depending on type up to 24 fibers can be
connected (in case of SFF up to 48 connections can be made).
Follow all local safety regulations related to optical fiber plant elements.
For cleaning components, the use of isopropylalcohol is recommended.
2
General
2.1
Characteristics
Compatible with standard 19" rack, back or front mounting or in FIST-GR2 racks
Dimensions: width = 481 mm
height = 44 mm (fits in 1 HU 19")
depth = 210 mm, 270 mm including plastic frontcover (optional)
FOMS-FPS-O-XXXX-XX
I N S T A L L A T I O N
3.1 Preparation of the shelf for patch-patch
3.3 Preparation of the shelf for splice-patch
3.6 Termination of ribbon and microgain
I N S T R U C T I O N

Advertisement

loading
Need help?

Need help?

Do you have a question about the FOMS-FSP-O Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tyco Electronics FOMS-FSP-O Series

  • Page 1: Table Of Contents

    FOMS-FPS-O-XXXX-XX I N S T A L L A T I O N I N S T R U C T I O N 19” 1HU Splicing and Front Patching Shelf Contents 1 Introduction 3 Installation 3.1 Preparation of the shelf for patch-patch 2 General 3.2 Routing of the pigtails (patch-patch) 2.1 Characteristics...

  • Page 2: Kit Contents

    Installation Kit contents Preparation of the shelf in case of patch-patch Right version 3.1.1 Remove the cover of the shelf. Left version Splice-Patch configuration 1 metal shelf incorporating: front patch panel with max 24 adapters (48 in case of SFF (small form factor)-connectors) FOSC-400-A splice trays 3.1.2 Trumpet is needed where the pigtails enter the shelf.
  • Page 3 In case of 19 inch. (standard) In case of ETSI 3.1.3 Install the mounting brackets on the correct position. Respect correct orientation. 3.1.4 Place the top cover back on the shelf. 3.1.5 Determine the position of the shelf (see rack installation instruction).

  • Page 4: Routing Of The Pigtails (Patch-Patch)

    Routing of pigtails (patch-patch) 3.2.3 Entering the shelf trough the trumpet. 3.2.1 Place the connector-adaptors in the patchpanel. In the picture you also can see the blind stops. 3.2.2 Slide the drawer to the fully open position. 3.2.4 Remove the velcro. Guide the jumpers to the patch field and connect the jumpers.
  • Page 5 Preparation of the shelf in case of splice-patch/LT-cable 3.2.5 Recommend this routing for entering the shelf, and the possibility for storage of pigtail. 3.3.1 Remove top cover (place strength member connector in case of loose tube). 3.2.6 Put the velcro back in place. (it is not recommended to remove the velcro totally).

  • Page 6: Termination Of Loose Tube

    In case of 19 inch. (standard) In case of ETSI 3.3.3 Install the mounting brackets on the correct position. Respect correct orientation. 3.4.3 Put FOSC-400AA tray in place. Cut 4 pieces of spiral tube 200mm. Put foam at the ends of the spiral tubes. 3.3.4 Place the top cover back on the shelf.
  • Page 7 3.4.7 Place the connector adapters in the patchpanel. 3.4.10 In case of two trays : recommend to do it this way. Spirals coming from the lowest tray, place in position 1 and 3and spiral from tray on top place in position 2 and 4. 3.4.8 Feed the first 6 pigtails through the spiral tube and connect the pigtails.

  • Page 8: Termination Of

    Termination of ribbon cable and microgain cable Entering with fopt trough the trumpet (back or side) up to the tray 3.6.1 Entering the shelf from the side with the FOPT up to the tray. 3.5.2 Termination up to the tray, fixation together with the spiral tube.

  • Page 9: Routing And Splicing

    Routing and splicing 3.7.1 Tray for up to 24 heat-shrinkable fusion splice protectors is used (FOSC-A-TRAY-S24). 3.7.2 Remove front cover. Open tray 90°. 3.7.3 Rotate the FOSC-tray ± 45°. • The tray organizer has 6 locations to store splice protectors. Each location can hold maximum 4 fusion splice protectors of type SMOUV- 1120-02 (length 45 mm, installed outer diameter is 2,4 mm)or equivalent.

  • Page 10: Closing The Shelf

    3.7.4 Use the wedge to get access to the bottom tray for splicing. Closing the shelf 3.8.2 Additionally a plastic cover with label can be placed to protect the connectors. 3.8.3 Identify the shelf and connectors. 3.8.1 Mount the guiding snap onto the shelf. Patch the outgoing jumpers and guide them through the guiding snap.
  • Page 12 Tyco Electronics’ obligations shall only be as set forth in Tyco Electronics’ Standard Terms and Conditions B-3010 Kessel-Lo, Belgium of Sale for this product and in no case will Tyco Electronics be liable for any incidental, indirect or consequential damages arising out Tel.: 32-16-351 011 of the sale, resale, use or misuse of the product.
