Ultima
Bath Transfer
with foldable base
Installation and
User Manual
SIZE MEDIUM
#6035-0012-000
SIZE LARGE
#6035-0013-000
IMPORTANT CONSUMER INFORMATION NOTICE:
This manual contains important instructions that
must be passed on to the user of this product.
Please do not remove this manual before delivery
to the end user.
SUPPLIER:
This manual must be given to the user of this product.
USER:
Before using this product, read entire manual and save
for future reference.
Distributed by Medifab Ltd
32 Detroit Drive, Rolleston 7675, New Zealand
+64 3 307 9790
solutions@medifab.com
www.medifab.com
User Manual for Ultima Bath Transfer with Foldable Base
Manual: UltimaTransferFoldable201704
Serial Number:
