K&C Tech Universal Smart Drive Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Precautions
1.
When removing the Universal Smart Drive from the USB port, please ensure that the Red light on the
Universal Smart Drive is not flashing and that the light is in fact Green. This will ensure that your data on
the device is not lost. It is very important that you check Universal Smart Drive light even if the dialog
box on your computer shows that the data transfer is finished.
2.
When disconnecting the Universal Smart Drive in Windows Me, Windows 2000 and Windows XP , you
must double click the icon "Unplug or Eject Hardware" which is located at the bottom right corner of
your screen and follow the instructions before removing. If you are using a Macintosh OS, we suggest
that you use the "Eject" or "Put Away" option before unplugging the Universal Smart Drive. In LINUX
you should unmount the Universal Smart Drive before unplugging.
3.
Please disconnect the Universal Smart Drive from the USB port before turning your computer on/off. It
is also important to ensure your computer has finished booting before connecting the Universal Smart
Drive.
4.
Please ensure that you follow the instruction manual for proper driver installation if your operating
system is Windows 98/SE (see section: 6.Driver Installation for Windows 98/SE).
Universal Smart Drive

Advertisement

Table of Contents
loading

Summary of Contents for K&C Tech Universal Smart Drive

  • Page 1 When removing the Universal Smart Drive from the USB port, please ensure that the Red light on the Universal Smart Drive is not flashing and that the light is in fact Green. This will ensure that your data on the device is not lost. It is very important that you check Universal Smart Drive light even if the dialog box on your computer shows that the data transfer is finished.

  • Page 2: Table Of Contents

    Contents 1. Introduction 2. Features 3. Specifications 4. Precautions for Using the Universal Smart Drive 5. How to use the Universal Smart Drive? 6. Driver Installation for Windows 98/SE 7. Linux Instructions for the Universal Smart Drive 8. Warranty Disclosure 9.

  • Page 3: Introduction

    Just plug the Universal Smart Drive into the USB port of your computer and the drive installs immediately on it's own. It is truly a Plug and Play device. No more hassles of downloading software. You can also cross platform your data from PC to Mac and vice versa.

  • Page 4: Specifications

    3. Specifications Supported OS Windows 98/SE, Windows ME, Windows 2000, Windows XP and Mac 8.6 or higher, Linux 2.4X or higher System Requirements IBM PC/AT or compatible Desktop / Notebook / Sub-Notebook / Laptop computers / Mac (Pentium® @ 100MHz or better) with USB ports Power Supply USB Bus-powered (4.5V to 5.5V) Capacities...

  • Page 5: Precautions For Using The Universal Smart Drive

    4.1 When removing the Universal Smart Drive from the USB port, please ensure that the Red light on the Universal Smart Drive is not flashing and that the light is in fact Green. This will ensure that your data on the device is not lost.

  • Page 6: How To Use The Universal Smart Drive

    The Universal Smart Drive functions as a removable disk drive on your computer. When you insert the Universal Smart Drive to the USB port of your PC or Mac, then the "removable disk" icon will appear in the "My Computer Folder". You can use the Universal Smart Drive the same way as a Floppy disk or a Hard drive on your computer.

  • Page 7: Driver Installation For Windows 98/Se

    6. Driver Installation for Windows®98/SE 6.1 Auto Setup 6.1.1 Installation 1) Please ensure that the Universal Smart Drive is disconnected from computer. 2) Execute the setup file (Setup.exe) from the installation CD (or download from http://www.universalsmartdrive.com/ 3) Select ‘ Install or update driver’ in the dialog box and press ‘ Start’ .
  • Page 8 If your computer does not have USB controllers, then the USB device will not work. 2) Insert the Windows 98/SE device driver CD in the computer, and plug the Universal Smart Drive into the USB port. A “USB Mass storage Device” message appears and the following dialog box “Add New Hardware...
  • Page 9 3) Dialog box shows how Windows searches for the USD drivers. Choose “ Search for the best driver.” and press “Next” . 4) The dialog box shows where to locate the Universal Smart Drive device drivers. Select the option “CD-ROM drive”. Press “Next” button.
  • Page 10 5) The dialog box shows that Windows has located the Universal Smart Drive device driver in drive ‘ D’ . Press “Next” button. 6) The dialog box shows that Windows has finished the installation of the Universal Smart Drive device driver.

  • Page 11: Linux Instructions For The Universal Smart Drive

    4. In Red Hat Linux, you can use 'Disk Management(User Mount Tool)' in 'GNOME' for Mount management. 5. You should unmount the Universal Smart Drive before you remove the Universal Smart Drive when the LED turns from Red to Green in a few seconds.

  • Page 12: Warranty Disclosure

    Universal Smart Drive, such as, but not limited to, excessive heat or humidity, power failure or improper installation or removal of the device.
