- Page 1 EMERGY 1000 User Manual Please read this User Manual first before Operating the System.
-
Page 2: Table Of Contents
Table of Contents - 2 - ABOUT THIS MANUAL Additional Information - 2 - - 2 - Symbol Used PRODUCT OVERVIEW - 3 - - 3 - Appearance and Functions - 4 - Gauge/Charging Indicators and Alarm - 7 - SYSTEM OPERATIONS - 7 - Turning On/Off System... -
Page 3: About This Manual
1. About this Manual This User Manual is for use with EMERGY 1000. User must refer to the User Manual before using to avoid abnormal situations. 1.1 Additional Information (1) The information in this document is subject to change without notice. -
Page 4: Product Overview
Management System, AC charger, Photovoltaic (PV) charger, DC to AC inverter, System Control into the compact & portable suitcase. 2.1 Appearance and Functions Figure 1 illustrates the appearance and key external parts in EMERGY 1000 . The functions of each key parts are highlighted in Table 1. Figure 1(a). Top View Figure 1(b). -
Page 5: Gauge/Charging Indicators And Alarm
DO NOT use PULL HANDLE, but LIFT HANDLE to lift up EMERGY 1000 to avoid damage to the system. 2.2 Gauge/Charging Indicators and Alarm - 4 -... - Page 6 2.2.1 Gauge Indicator The State Of Charge (SOC) or remaining capacity of the battery is illustrated thru five (3 green, 1 orange, 1 red) LED indictors on its face panel. From right to left each additional indicator corresponds to about 20% additional battery capacity as illustrated in Table 2. Table 2.
- Page 7 2.2.2 Charging Indicator CHARGING INDICATOR is used to indicate the stage of charging to the battery as illustrated in Table 3. Table 3. Charging Indicator Status Meaning Stay On Charging 1. Close to fully charged. 2. Blinking happens if charging current is less than 2A.
-
Page 8: System Operations
Figure 2. AC charging When EMERGY 1000 is charging, CHARGING INDICATOR will light up CHARGING INDICATOR will turn off automatically when charging is terminated. The charging time for EMERGY 1000 is around 2.5 hours for a full charge cycle (from empty to full). - Page 9 When EMERGY 1000 is charging by PV power, CHARGING INDICATOR will light up CHARGING INDICATOR will turn off automatically when charging is terminated. EMERGY 1000 would take about 3 hours for a full charger cycle (from empty to full) when PV power is greater than 650Wp and it is optimal solar radiation.
-
Page 10: System Outputs
3.3 System Outputs 3.3.1 AC Output AC outlet(s) of EMERGY 1000 provided is (are) also compatible with local electrical plugs. To utilize AC output, the following steps are to be followed. Step 1: Turn on the system by pressing MSW. -
Page 11: Physical Positioning
3.5 Physical Positioning EMERGY 1000 is designed to operate in an upright position as illustrated in Figure 4 Stable footing should be provided when using the system. It is also highly recommended that the two braking mechanisms be engaged to avoid possible skidding especially when the ground is inclined. - Page 12 3.6.2 Running Time Estimated run time for a fully charged EMERGY 1000 is shown in Table 5. Table 5. EMERGY 1000 Run Time for Select Loads Power Electrical Equipment Running Time Consumption Camping Lantern 162.0 hours LED Lighting 81.0 hours...
-
Page 13: Transportation
4. Transportation EMERGY 1000 is designed with a pull handle and a lift handle for easy transportations. A custom-design backpack (sold separately) is available for carrying EMERGY 1000 in rougher outdoor terrains. The correct ways for moving and carrying EMERGY 1000 are illustrated in Figure Moving and Lifting EMERGY 1000 Figure 5. -
Page 14: Storage
Figure 7. Physical Positioning for Transportation in a Vehicle 5. Storage It is highly recommended that EMERGY 1000 is turned off (MSW off) when it is not in use to conserve the battery energies. Failure to do so may deplete the battery energies prematurely and reduce system’s availability. -
Page 15: In Case Of Emergency
7. Maintenance Regular maintenance of EMERGY 1000 is not necessary except maintaining sufficient charge state of the batteries to avoid possible over-discharge during storage especially after usage. The appearance and surface can be cleaned with a damped cloth with water. -
Page 16: Warranty
8. Warranty EMERGY 1000 is warranted against defects in material and workmanship for a period of one year after purchase to the original owner. It is at the Manufacturer’s sole discretion whether to repair or to replace system assembly part(s) found to be defective. Transportation to the service center or the factory is the responsibility of the purchaser. - Page 17 WARRANTY CARD Product Name: EMERGY 1000 Date of Purchase: Purchase From: Name: Address: City / State / Zip: Phone: E-mail: Please keep this warranty card for future reference. Contact Information: FSP USA Add: 14284 Albers Way, Chino, California Tel: (909)606-0960 E-mail: info@fspgroupusa.com...
- Page 18 Contact Information: FSP USA Add: 14284 Albers Way, Chino, California Tel: (909)606-0960 E-mail: info@fspgroupusa.com Web: www.fspgroupusa.com...
