Seip TS MINI Instructions

TS MINI/TS MIDI STEEL REMOTE INSTRUCTIONS
HEALTH & SAFETY: THESE PROCEDURES ARE TO BE
CARRIED OUT BY A COMPETENT PERSON ONLY

PROGRAMMING A REMOTE

Situation 1

You have got at least one working remote and want to register the new remote to
be used in addition:

Situation 2

You do not have a working remote:
1) Open the operator's plastic cover (one Philips screw will need to be undone for TS75
and TS100 operators or remove the rear plastic cover for TM and RP series
operators)
(Picture C)
2) Press the RED learn button on the printed circuit board for
approx. 3 seconds (shown in picture C) until the light bulb on
the operator starts flashing then release the button
3) Take the new remote and press the button you would like to use
4) The light bulb on the operator will stop flashing
5) On the next push of the button on the new remote the door will
operate
1) Open the garage door at least half way and
close it again using the existing remote
2) You now have 10 seconds to press buttons 1
and 2 on the existing remote simultaneously
for approx. 3 seconds. (shown in picture A
B & C)
3) The light bulb on the operator will start
flashing – now release the two buttons
4) Take the new remote and press the button
you want to use for the operator and the
operators light bulb will stop flashing
5) On the next push of the button on the new
remote the door will operate.
P.T.O
