NRI G-26.4000 Series Manual

Changer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Technical Documentation
Manual for
Changer Series G-26.4000
02/94 vBi
Edition: 10.0
HB.2640-GB
National Rejectors, Inc. GmbH • Zum Fruchthof 6 • D-21614 Buxtehude • Telefon 04161/70 75 0 • Telefax 04161/70 75 55

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G-26.4000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for NRI G-26.4000 Series

  • Page 1 Technical Documentation Manual for Changer Series G-26.4000 02/94 vBi Edition: 10.0 HB.2640-GB National Rejectors, Inc. GmbH • Zum Fruchthof 6 • D-21614 Buxtehude • Telefon 04161/70 75 0 • Telefax 04161/70 75 55...
  • Page 2 Advantages Page 2 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Benefit from the Advantages of the NRI Changers G-26.4000 Standard, G-26.4400 SIMPLEX V and G-26.4800 Professional Increased sales o 20-30% increase in sales with a changer o Greater change capacity...

  • Page 3: Table Of Contents

    17. Adaptations to different machines ............. 65 18. Use of a Bill Validator ................. 67 19. Use of a Data Retrieval Unit ............... 68 20. Use of a NRI Talking Module G-58.0100 .......... 69 21. Drawing of Changer ................70 22. Appendix...

  • Page 4: General

    Page 4 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: General 1. General The G-26.4000 Standard, G-26.4400 SIMPLEX V and the G-26.4800 Professional are 3-tube- changers, accepting up to 12 different coin denominations, including up to 3 tokens, between 15 and 33 mm diameter.
  • Page 5 Page 5 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: General The changer series G-26.4800 Professional contains a further version, the so-called ‘BDV-Standard’. For this device the keyboard is optional. With a BDV-Standard device without keyboard several functions, described hereafter, are therefore only possible by the vending machine control.

  • Page 6: Technical Data

    Page 6 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Technical Data 2. Technical Data Acceptance: Up to 12 different coin denominations, incl. 3 tokens Diameter: 15 - 33 mm Thickness: 1.5 - 3.3 mm Change capacity: Approximately 70 coins per tube (depending on thickness) Dimensions: Height: 380 mm...

  • Page 7: Electronic Validator G-10.4000/5

    Page 7 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: G-10.4000/5 3. Electronic Validator G-10.4000/5 General Information The G-10.4000/5 is a microprocessor-controlled validator, which includes a serial interface for the data transfer to the control unit. Measurements When a coin passes the measurement area within the validator, the coils measure the coin characteristics of alloy, thickness, diameter and embossing.
  • Page 8 G-10.4000/5 Page 8 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Linked channels always accept the same coin value. Example I: Example I: Label of a G-10.4000/5 with German coin acceptance. This example shows the the coin channels 3 and 10, 4 and 11 as well as 5 and 12 are linked together.
  • Page 9 Page 9 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: G-10.4000/5 Individual coin inhibit It is possible to inhibit each of the channels 2 to 12. The channels 2 to 8 can be inhibited via keyboard of the changer ( see function 15). If one of the channels 2 to 8 is inhibited via the keyboard of the changer, the assigned channel, accepting the same coin value, is simultaneously inhibited.
  • Page 10 Page 10 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: G-10.4000/5 o The channels 9 to 12 are assigned to the 4 switches as follows: * By moving the appropriate switch in the upper position ( 'open' ) the channel is inhibited. By using the individual coin inhibit of channels 9 to 12 it is possible, for instance, - to increase the slug rejection by inhibiting the channels with normal bandwidth for changers with German coin acceptance...
  • Page 11 Page 11 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: G-10.4000/5 The sorting function - special function for validators with English coin acceptance - can be activated by using switch 1, - if within channel 12 no coin is programmed, - if the coin denomination, accepted by channel 9, is guided into the right tube * Move switch 1 on the 4-pole Dual-In-Line switch in the upper position o Now coins accepted within channel 9 are no longer guided into the right tube, but coins accepted within channel 8 are guided into the right tube.
  • Page 12 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: NRI Programming Unit NRI offers a programming station by which you can change the settings according to your requirements. By using the NRI programming station for validators series G-10.4000/5 you can - check the proper function of the connected validator,...

  • Page 13: Transport And Connection Of Unit

    Page 13 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Transport/Connection 4. Transport and Connection of Unit Transport o Before transport please empty all tubes o Transport and storage in factory packing prevents damage o No transit fixings required Attention Components behind validator are at line voltage. Always unplug changer before removing validator.
  • Page 14 Functions Page 14 National Rejectors, Inc. GmbH, Germany 5. Description of Operating Modes Note: The functions described hereafter can be set within units including the latest software. If necessary, please contact NRI. Mode Reason Select o Inventory - to relocate changer...
  • Page 15 Page 15 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Functions Mode Reason Select o External reset (G-26.4000 Standard) Vending machine provides reset signal Price pulse 75 up to 100 msec o Internal reset (G-26.4000 Standard) No reset signal from vending machine Determined by machine.
  • Page 16 Page 16 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Functions Mode Reason Select Prior to payout of residual 0401 o Display of credit in money, credit is displayed 'single vend' for 2.5 seconds. After reset, price line remains 0401 o Delayed reset active for 300 msec.

  • Page 17: Initial Operation

    Page 17 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Initial Operation 6. Initial Operation * Check - supply voltage - vending machine compatibility - vending machine interface * Connect earth wire to housing of vendor. Good metallic contact is absolutely necessary. * Connect changer * Switch on - external display shows 00.00 or time or residual credit...

  • Page 18: Filling Change Tubes

    Filling Change Tubes Page 18 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: 7. Filling Change Tubes It is preferable to fill tubes as follows: o Unit in standby mode * Press ‘+’ key * Insert coins * Press ‘+’ key o Possibly existing credit remains unchanged.

  • Page 19: Display Of Line Conditions

    Page 19 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Display of Line Conditions 8. Display of Line Conditions G-26.4000 Standard (Remedying faults within vending machine) o Changer in standby * Key ‘+’ * Key ‘P’ o On display appears for example: Where: 0060 = price 60 p...
  • Page 20 Page 20 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Test Vends 9. Test Vends G-26.4000 Standard o Changer in standby * Key ‘+’ * Key ‘P’ * Key ‘E’ o On display appears: * If you select now for instance selection 1, the display will indicate: This means that the vend operation for selection 1 (price: 60 p) is now initiated.

  • Page 21: Operating Keys

    Page 21 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Operating Keys 10. Operating Keys Keys F = Function select / Return to standby E = Execute function / Rapid increase of values P = Programming / Return to standby + = Increase of values Display shuts down approximately 40 msec after last use of key.

  • Page 22: Flow Chart

    Flow Chart Page 22 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: 11. Flow Chart standby P or + emptying tubes (inventory) 01 left tube middle tube right tube after display G-26.4000 Standard 10th price P or + pricing and machine no. pricing machine no.

  • Page 23: Operation

    Emptying Tubes Page 23 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: 12. Operation Function 01 = Emptying tubes (Inventory) Action Display * Select function * Inventory left tube I— * Payout coins singly E once * Payout coins rapidly E continuously * Inventory middle tube * Payout coins singly E once...

  • Page 24: Pricing And Machine Number 02

    Page 24 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Pricing and Machine No. Function 02 = Pricing and Machine Number G-26.4000 Standard Action Display * Select function F until 02 appears * Display price 1 0201 00.05 Assuming price 1 was displayed * Display prices 2 to 10 P sequentially * Increase by lowest coin...
  • Page 25 Page 25 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Machine No. Function 02 = Machine Number G-26.4800 Professional and G-26.4400 SIMPLEX V Note: The machine number cannot be changed, if a data retrieval unit is used. Action Display * Select function F until 02 appears 000000...

  • Page 26: Acceptance And Change Limitation 03

    Page 26 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Accept/Change Limit Function 03 = Acceptance and Change Limitation and Setting of Tokens Action Display * Select function F until 03 appears * Display acceptance limit 0301 00.00 * Increase by lowest coin + once 0301 value...

  • Page 27: Setting Of Tokens 03

    Page 27 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Setting of Tokens Function 03 = Acceptance and Change Limitation and Setting of Tokens Action Display * Display of set token 1 0303 00.10 * Increase by lowest coin + once 0303 value 00.15...

  • Page 28: Operating Modes 04

    Page 28 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Operating Modes Function 04 = Operating Modes Action Display * Select function F until 04 appears * Display of setting (see next page) 10000100 * Select digit to be changed P sequentially 10000100 * Change setting 11000100...
  • Page 29 Page 29 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Operating Modes Function 04 = Operating Modes Example: G-26.4000 Standard = not yet used 1 = Blocking of coins when ‘tube empty’ (unchangeable) 1 = ‘Exact change’ lamp lights up (unchangeable) 1 = reset line 6 ) G-26.4000 Standard 0 = reset line 8 )
  • Page 30 Operating Modes Page 30 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 0401 = Operating Modes G-26.4000 Standard ecological function passive cigarette mode passive delayed reset display of credit in ‘single vend’ display of time By inserting a ‘1’ following functions are selected: Display of time The time can be displayed on the credit indicator by setting this bit to ‘1’.

  • Page 31: Vending Machine Data 05

    Vending Machine Data Page 31 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 05 = Vending Machine Data Action Display * Select function F until 05 appears * Display identification 0501 number 1335 * Display audit number 0502 (with this identification no.) 0120 * Display interruptions 0503...

  • Page 32: Sales Data 06

    Sales Data Page 32 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 06 = Sales Data Action Display * Select function F until 06 apppears Since last printout: * Cash to cashbox 0601 90.75 * Cash to tubes 0602 36.45 * Change paid out 0603 15.75...

  • Page 33: Vend/Sales Data 08

    Vend/Sales Data Page 33 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 08 = Vend / Sales Data Action Display * Select function F until 08 appears Since installation: * Total sales 0801 15.50 * Total vends 0901 Since last printout: * Total sales 0802 3.50...

  • Page 34: Vend/Sales Data Per Price Line 10

    Vend/Sales Data per Price Line Page 34 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 10 = Vend/Sales Data per Price Line G-26.4000 Standard Action Display * Select function F until 10 appears * Sales per price line E sequentially 1008 to required price 09.30...

  • Page 35: Coin And Tube Data 12

    Coin and Tube Data Page 35 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 12 = Coin and Tube Data Action Display * Select function F until 12 appears * Coins in left tube (quantity) 1201 * Coins in middle tube (quantity) 1202 * Coins in right tube (quantity) 1203...

  • Page 36: Diagnostics 13

    Diagnostics Page 36 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 13 = Diagnostics Action Display * Select function F until 13 appears * Select ‘Motors to 1301 service state’ * Execute (see ‘Remedying 1301 Faults’) —- * Select ‘Motors to 1302 standby state’...
  • Page 37 Diagnostics Page 37 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 13 = Diagnostics Action Display * Select ‘Printout of 1304 data block’ * Printout 1304 ¦¦ Connect printer and key ‘PRINT’ on printer (Example of printout : see below) * Select ‘Filling of tubes 1305 through validator’...

  • Page 38: Setting Time And Date 14

    Setting Time and Date Page 38 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 14 = Setting Time and Date Action Display * Select function F until 14 appears * Time and date 1306 (example: 92114830 13.06.92 date 11.48 30 time) * Select digit to be P sequentially 1306...
  • Page 39 Setting Time and Date Page 39 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 14 = Setting Time and Date month year hours minutes seconds Seconds unit can only be set to zero. Flashing digit may be changed.

  • Page 40: Single Coin Inhibit 15

    Single Coin Inhibit Manual G-26.4000: Page 40 National Rejectors, Inc. GmbH, Germany Function 15 = Single Coin Inhibit Action Display * Select function F until 15 appears * Display of setting (see next page) 0101000 * Select digit to be P sequentially changed 0101000...
  • Page 41 Single Coin Inhibit Page 41 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 15 = Single Coin Inhibit coin 8th channel coin 2nd channel 0 = coin accepted 1 = coin inhibited Acceptance of lowest denomination coin cannot be inhibited. Flashing digit may be changed.

  • Page 42: Printout Format 16

    Printout Format Manual G-26.4000: Page 42 National Rejectors, Inc. GmbH, Germany Function 16 = Printout Format Action Display * Select function F until 16 appears * Display of setting (see next page) 0000 * Select digit to be changed 0000 * Change digit 0001 * Programme change...
  • Page 43 Printout Format Page 43 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 16 = Printout Format G-26.4000 Standard The machine data is always printed 0 = Sales data is printed 1 = Sales data is not printed 0 = Vend/sales data per price line is printed 1 = Vend/sales data per price line is not printed 0 = Time is printed 1 = Time is not printed...
  • Page 44 Printout Format Manual G-26.4000: Page 44 National Rejectors, Inc. GmbH, Germany MACHINE:111 15.06.1989 AUDIT0: 19 AUDIT1: TOTAL SALES 208.00 ========== OFF/ON money inserted by TO CASHBOX customers to cashbox 10.00 receipts from bill validator 0.00 TO TUBES money inserted by customers to tubes 58.10 money inserted during tube filling 10.00...
  • Page 45 Printout Format Page 45 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 16 = Printout Format G-26.4800 Professional/G-26.4400 SIMPLEX V The machine data is always printed 0 = Sales data is printed 1 = Sales data is not printed no influence 0 = Time is printed 1 = Time is not printed 0 = Audit data is erased after printout.
  • Page 46 Printout Format Manual G-26.4000: Page 46 National Rejectors, Inc. GmbH, Germany MACHINE:111 15.06.1989 AUDIT0: 19 AUDIT1: TOTAL SALES 208.00 ========== OFF/ON money inserted by TO CASHBOX customers to cashbox 10.00 receipts from bill validator 0.00 TO TUBES money inserted by customers to tubes 58.10 money inserted during tube filling 10.00...

  • Page 47: Coins To Be Inhibited 17

    Coins to be inhibited Page 47 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 17 = Coins to be inhibited The coins set on this function are inhibited when the ‘tube empty’ condition applies. The ‘tube empty’ condition is set on function 22. Action Display * Select function...
  • Page 48 Coins to be inhibited Manual G-26.4000: Page 48 National Rejectors, Inc. GmbH, Germany Function 17 = Coins to be inhibited coin 8th channel coin 2nd channel Acceptance of lowest denomination coin (1st channel) cannot be inhibited. Flashing digit may be changed.

  • Page 49: Communication With Audit Unit 18

    Communication Audit Unit Page 49 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 18 = Communication with Audit Unit G-26.4800 Professional and G-26.4400 SIMPLEX V An audit unit, alreday integrated within the machine control, is able to communicate with a G-26.4400 SIMPLEX V and G-26.4800 Professional.

  • Page 50: Communication With A Card System 19

    Communication Card System Manual G-26.4000: Page 50 National Rejectors, Inc. GmbH, Germany Function 19 = Communication with a Card System G-26.4000 Standard and G-26.4800 Professional Attention: A ‘1’ may only be programmed, if a credit card system is connected to the changer. When you connect a GLOBO Card system, please refer to the installation instructions for the GLOBO Card system.

  • Page 51: Communication With A Bill Validator 20

    Communication Bill Validator Page 51 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 20 = Communication with a Bill Validator G-26.4000 Standard and G-26.4800 Professional Attention: A ‘1’ may only be programmed, if a bill validator is connected to the changer. Action Display * Select function...

  • Page 52: Communication With A Talking Module 21

    Manual G-26.4000: Communication Talking Module Page 52 National Rejectors, Inc. GmbH, Germany Function 21 = Communication with a Talking Module G-26.4000 Standard and G-26.4800 Professional Attention: A ‘1’ may only be programmed, if a talking module is connected to the changer. Action Display * Select function...

  • Page 53: Setting Of 'Tube Empty' Condition 22

    Setting 'Tube empty' condition Page 53 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function 22 = Setting of ‘tube empty’ condition By using this function it is possible to determine the tube condition which will cause the display of ‘tube empty’ and to inhibit the acceptance of all coins programmed by function 17. Please refer also to function 17 'Coins to be inhibited'.
  • Page 54 Setting 'Tube empty' condition Manual G-26.4000: Page 54 National Rejectors, Inc. GmbH, Germany On the following table ‘A’ corresponds to the tube with the lowest coin value, whilst ‘C’ corresponds to the tube with the highest coin value. Note: The factory setting is ‘00’, i.e. the ‘tube empty’ condition is fulfilled when either the tube for the lowest coin value is empty, or both tubes for the higher coin values are empty.

  • Page 55: Summary Of Fault Codes

    Page 55 Summary Fault Codes National Rejectors, Inc. GmbH, Germany Manual G-26.4000: 13. Summary of Fault Codes Display Meaning Category left motor not in final position middle motor not in final position right motor not in final position left and right motors not in final position middle and right motors not in final position left and middle motors not in final position right, middle and left motors not in final position...
  • Page 56 Summary Fault Codes Manual G-26.4000: Page 56 National Rejectors, Inc. GmbH, Germany Display Meaning Category ..connecting cable or validator defective flash 22 flashes price data has invalid length alternately with four points 1 I— coin channel 1, left tube, accepted 2 -I- coin channel 2, middle tube, accepted 3 —I...

  • Page 57: Remedying Faults

    Remedying Faults Page 57 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Display Meaning Left motor not in final position Middle motor not in final position Right motor not in final position Left and right motor not in final position Right and middle motor not in final position Left and middle motor not in final position Left, middle and right motor not in final position When a motor fault occurs during payout, subsequent payout operations are made with the two other...
  • Page 58 Remedying Faults Manual G-26.4000: Page 58 National Rejectors, Inc. GmbH, Germany G-26.4000 Standard, G-26.4800 Professional: o It is a fault, which cannot be removed immediately. However, the changer should remain in operation. Therefore, for example, the other tubes have to be filled. On the display appears: * Key ‘F’...

  • Page 59: Data Block Of Validator Defective

    Remedying Faults Page 59 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Display Meaning Data block of validator defective This fault condition can be removed as follows: * Key ‘F’ 4 times * Key ‘E * Key ‘+’ 2 times * Key ‘F’ * Check setting of functions 2, 3, 4, 15, 16 and 17 Display Meaning...

  • Page 60: Price Data Is Sent To Validator

    Remedying Faults Manual G-26.4000: Page 60 National Rejectors, Inc. GmbH, Germany Display Meaning 22 flashes Price data has invalid length alternately with four points The fault conditions can be removed as follows: * Enable keyboard ( switch on connecting module - chapter 10 ) * Key ‘F’...

  • Page 61: No Answer From Vending Machine Control

    Remedying Faults Page 61 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Display Meaning No answer from vending machine control No answer from audit unit No answer from card system No answer from bill validator In case these fault codes appear, the coin acceptance is inhibited and no vend is possible. The reason may be - the connecting cable is defective - the peripheral unit is switched off...
  • Page 62 Service Functions Manual G-26.4000: Page 62 National Rejectors, Inc. GmbH, Germany Function S01 = Display of error list What Display * Select service function S-01 * Display of error list S-01 04 -03- 04 is the number of fault within the error memory and here 04 corresponds to the number of faults 03 is the code of the fault * Display prior fault...

  • Page 63: Service Functions

    Service Functions Page 63 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: Function S03 = Initialize GLOBO Card system This function appears only when a GLOBO Card system is connected to the changer. Please refer to the operating instructions 'GLOBO Card System - Installation'. Function S04 = Tube counter set to Zero What Display...

  • Page 64: Maintenance

    Maintenance Manual G-26.4000: Page 64 National Rejectors, Inc. GmbH, Germany 16. Maintenance * Adjustment of - prices (G-26.4000 Standard) see function 02 - coin acceptance see operating instructions for KUNEMP G-10.4000/5 - coin denomination see operating instructions for KUNEMP G-10.4000/5 - token denomination see function 0303 and operating instructions for KUNEMP G-10.4000/5...

  • Page 65: Adaptations To Different Machines

    Adaptations Page 65 National Rejectors, Inc. GmbH, Germany Manual G-26.4000: 17. Adaptations to different machines The changer may be modified with interchangeable interface modules, EPROM’s of the control and/ or connecting cables. Replacing interface module * Unfasten safety screw * Remove validator * Remove screws 1 and 2 * Withdraw module * Fit new module...
  • Page 66 Replacement connecting cable Manual G-26.4000: Page 66 National Rejectors, Inc. GmbH, Germany Replacement of connecting cable * Unfasten safety screw * Remove cable clamp (two screws) of the interface module * Remove cable * Refit and secure new cable * Pay attention that the cable clamp covers the shield * Refit validator and secure with safety screw...

  • Page 67: Use Of A Bill Validator

    If you would use another type of bill validator, please contact NRI. For each type of bill validator a special connecting cable is required, which can be ordered at NRI. Please refer also to the separate operating instructions “Use of Bill Validator in connection with the...

  • Page 68: Use Of A Data Retrieval Unit

    Data Retrieval Unit Manual G-26.4000: Page 68 National Rejectors, Inc. GmbH, Germany 19. Use of a Data Retrieval Unit By using an infrared adapter the data of the G-26.4000 can be read out (not possible with a G-26.4800 BDV-Standard changer). This adapter transfers the data via an infrared transmission line to a data retrieval unit.

  • Page 69: Use Of A Nri Talking Module G-58.0100

    National Rejectors, Inc. GmbH, Germany Manual G-26.4000: 20. Use of a NRI Talking Module G-58.0100 Due to its small dimensions the talking module can be used in all kinds of vending machines. The use of IC’s of state-of-the-art technology enables a natural voice reproduction.

  • Page 70: Drawing Of Changer

    Drawing Changer Manual G-26.4000: Page 70 National Rejectors, Inc. GmbH, Germany Return lever Label Display Max. Filling level Keyboard...

  • Page 71: Appendix

    Manual G-26.4000: Appendix National Rejectors, Inc. GmbH, Germany Manual for Changer Series G-26.4000 - Appendix - Index Technical Information 3/93: Latest Programme Version Technical Information 5/93: Changer Series G-26.4000/6...
  • Page 72 All validators manufactured since 1989, we received for repair, will be retrofitted automatically. This changer software offers the following functions: 1) Function 19 = Activate communication with the NRI card system GLOBO Card 2) Function 03 = Setting of a subsidy instead of token no. 2 3) Function 04 = Erase remaining credit 4) Function 04 = Activate price table within G-26.4000 Simplex V...
  • Page 73 Manual G-26.4000: Technical Information 3/93 National Rejectors, Inc. GmbH, Germany Page 2 1) Function 19 = Activate communication with NRI card system GLOBO Card Action Display * Select function F until 19 appears * Display setting 0000 (See page 3)
  • Page 74 Manual G-26.4000: Technical Information 3/93 National Rejectors, Inc. GmbH, Germany Page 3 Explanation of function 19 = Activate communication with NRI card system GLOBO Card Note: Only if a card system is connected should a '1' be programmed into any of the four digits in function 19.
  • Page 75 Manual G-26.4000: Technical Information 3/93 National Rejectors, Inc. GmbH, Germany Page 4 2) Function 03 = Setting of a subsidy instead of token no. 2 When the Globo card system is connected you can programme a subsidy within function 0304 of the changer.
  • Page 76 Manual G-26.4000: Technical Information 3/93 National Rejectors, Inc. GmbH, Germany Page 5 3) Function 04 = Erase remaining credit If you activate function 'Erase remaining credit', non-payable credit is erased after a single vend. Non-payable residual credit means a credit amount for example lower than the lowest coin within tubes of if tube store is empty.
  • Page 77 Manual G-26.4000: Technical Information 3/93 National Rejectors, Inc. GmbH, Germany Page 6 4) Function 04 = Activate price table within G-26.4000 Simplex V Using this function it is possible to set the prices within the G-26.4000 Simplex V. Thus the audit data for the G-26.4000 Simplex V now include also the information referring vend/sales per price line.
  • Page 78 Manual G-26.4000: Technical Information 3/93 National Rejectors, Inc. GmbH, Germany Page 7 5) Function 02 = Setting of prices within G-26.4000 Simplex V Up to 10 prices can be set. * Please refer to the 'Manual for Changer Series G-26.4000' function 02 = Pricing of G-26.4000 Standard.
  • Page 79 Manual G-26.4000: Technical Information 3/93 National Rejectors, Inc. GmbH, Germany Page 8 6) Function 10 = Read out of vend/sales data via display (G-26.4000 Professional and Simplex V) The new changer software records also the vend/sales data of the G-26.4000 Simplex V and Professional.
  • Page 80 Manual G-26.4000: Technical Information 3/93 National Rejectors, Inc. GmbH, Germany Page 9 8) Function 16 = Printout via printer without print key When using this function the changer checks whilst printing whether the printer is connected or not. In case the printer is not connected, the print procedure is finished immediately. However, the audit data is not erased.
  • Page 81 Manual G-26.4000: Technical Information 3/93 National Rejectors, Inc. GmbH, Germany Page 10 Annex Printout of audit data Machine No. 1 - 4 digits MACHINE: Machine No. > 4 digits 123456 19.02.1991 AUDIT0: AUDIT1: TOTAL SALES 13.00 Only if a card system is operating CASHLESSCARD sales 7.50...
  • Page 82 Technical Information 5/93 GB New Changer Series G-26.4000/6 - CPU-card with extended memory - The changer series G-26.4000/6 includes a CPU-card with extended memory: G-53.0801 with programme version 92 00 225-001 (valid for G-26.4000 4-price, 10-price) G-53.0802 with programme version 92 00 240-001 (valid for G-26.4000 BDV, Professional, Simplex V) G-53.0803 with programme version 92 00 240-001 (valid for G-26.4000 BDV)
  • Page 83 Manual G-26.4000: Technical Information 5/93 Page 2 National Rejectors, Inc. GmbH, Germany 1. Function 06 = Display of additional sales data since last printout * Please refer to function 06 Sales Data of the 'Manual for Changer Series G-26.4000'. The additional sales data are: 06 13 = Total amount of accepted tokens (since last printout) 06 14 = Erased token amount...
  • Page 84 Manual G-26.4000: Technical Information 5/93 Page 3 National Rejectors, Inc. GmbH, Germany 3. Function 07 = Display of sales data since installation Action Display * Select function F until 07 appears Since installation * Cash to cashbox 0701 865.20 * Cash to tubes 0702 250.00 * Change paid out...
  • Page 85 Manual G-26.4000: Technical Information 5/93 Page 4 National Rejectors, Inc. GmbH, Germany 4. Function 25 = Setting of maximum number of coins per tube Action Display * Select function F until 25 appears * Display of maximum 2501 number of coins in left tube * Increase by ‘1’...
  • Page 86 Manual G-26.4000: Technical Information 5/93 Page 5 National Rejectors, Inc. GmbH, Germany Up to now the function 'committed to vend' was cancelled as soon as the tube empty condition was fulfilled. Programming a '1' within function 2202 the feature 'committed to vend' remains valid even when 'tube empty'.
  • Page 87 Manual G-26.4000: Technical Information 5/93 Page 6 National Rejectors, Inc. GmbH, Germany Using function 31 you can programmme free vend for a token to allow certain customers to buy products free of charge. Possibly programmed token values within function 03 (please refer to 'Manual for Changer Series G-26.4000') are displayed, but not considered.
  • Page 88 Manual G-26.4000: Technical Information 5/93 Page 7 National Rejectors, Inc. GmbH, Germany 7. Function S-99 = Standard setting Function S-99 allows you to store the present setting of the changer and to execute the standard setting as mentioned below. Action Display * Service function S-01...
  • Page 89 Manual G-26.4000: Technical Information 5/93 Page 8 National Rejectors, Inc. GmbH, Germany 8a. Function 0401 = Display of price for selected product When activating this function the price of the selected product is shown on the external display if the credit within the changer is not sufficient for the vend. Thus the customer realizes how many coins he has to insert.
  • Page 90 Manual G-26.4000: Technical Information 5/93 Page 9 National Rejectors, Inc. GmbH, Germany 8b.Function 0401 = Working with 'two price lists' (only G-26.4000/6 4-price) The G-26.4000/6 4-price changer can process two prices per product. The prices are combined in two price lists. The switch over from one price list to the other one depends on the period of validity. It is possible that during a certain period the machine sells the products at a more favourable price.

  • Page 91: Lowest Coin Value > 2.50

    Manual G-26.4000: Technical Information 5/93 Page 10 National Rejectors, Inc. GmbH, Germany 9. Function 02 = Setting of prices for two price lists (only G-26.4000/6 4-price) Note: Please activate 'two price lists' in function 0401 (see page 9), before setting the price for the second price list.
  • Page 92 Manual G-26.4000: Technical Information 5/93 Page 11 National Rejectors, Inc. GmbH, Germany 10.Function 10/11 = Display of vend/sales data per price line for two price lists (only G-26.4000/6 4-price) Note: Before you can read the data per price line, please activate 'two price lists' within function 0401 (see page 9) and execute price setting for two price lists (see page 10).
  • Page 93 Manual G-26.4000: Technical Information 5/93 Page 12 National Rejectors, Inc. GmbH, Germany Note: If two price lists are used within the changer, the printout also includes the data for both price lists. Example: Sales/Vends Price list 1 00.00 00.00 00.00 00.00 Price list 2 00.00...
  • Page 94 Manual G-26.4000: Technical Information 5/93 Page 13 National Rejectors, Inc. GmbH, Germany 11. Function 24 = Setting of period of validity for second price list (only G-26.4000/6 4-price) Note: Please activate 'two price lists' in function 0401 (page 9) before setting the start and end for second price list.
  • Page 95 Manual G-26.4000: Technical Information 5/93 Page 14 National Rejectors, Inc. GmbH, Germany Annex I Following audit data are now printed out additionally: Total amount of accepted tokens, erased token amount, total sales and total vends with token. Example of printout Machine No.
  • Page 96 Manual G-26.4000: Technical Information 5/93 Page 15 National Rejectors, Inc. GmbH, Germany Annex II Further improvements to the changer: In function 02 of the changer G-26.40000/6 Simplex V now up to 20 prices are available. After printout the audit data are not erased immediately, but after a vend, after insertion of a coin or after pressing the return lever.

This manual is also suitable for:

G-26.4400 simplex vG-26.4000 standardG-26.4800 professional
