- Page 1 Knok ™ USER MANUAL...
-
Page 2: Table Of Contents
Contents Introduction Product Features LED Indicators What’s Included Wi-Fi Requirements Mobile Device Requirements Installation Requirements Knok Installation Storage Options Your Dashboard Do Not Disturb (DND) Controls Siren Activation Camera Functions Watching Live Video Taking Photos Recording Videos ... - Page 3 About Momentum © 2016 Momentum Momentum is a registered trademark in the United States. Apple and iPhone are registered trademarks of Apple Inc. Google, Google Play, and Android are trademarks of Google LLC. All other brands and product names are or may be trademarks of their respective owners.
-
Page 4: Introduction
Introduction The Knok is Wi-Fi Video Doorbell with wireless monitoring capabilities that can be accessed from anywhere where you have an internet connection. It’s great for surveillance of your doorstep and to make sure you always stay in control no matter where you are. All you need is a(n): 1. -
Page 5: Product Features
Product Features PIR Motion Sensor Camera Lens Speaker IR LEDs Light Ring Microphone Micro-SD card slot Reset button Micro-USB Port Power Input Port... -
Page 6: Led Indicators
LED Indicators The Knok displays an indicator light that lets you know what it is doing. Solid Red: Knok is booting up. Double Blinking Blue: Ready to connect to Wi-Fi. Solid Blue: Device is connected to the internet. Blinking Blue: Device has no internet connection. -
Page 7: What's Included
What’s Included A. Knok Doorbell B. Mounting Bracket C. Security Screw D. Horizontal (15°) and Vertical (5°) Angle Brackets E. Drill Bit F. Long Mounting Screws (x4) and Wall Anchors (x4) G. Short Mounting Screws (x4) H. Power Connection Screws (x2) I. -
Page 8: Wi-Fi Requirements
Wi-Fi Requirements The Knok requires a 2.4GHz (802.11b/g/n) for Wi-Fi connectivity. This is available on almost any standard Wi- Fi router. You will need your Wi-Fi name and password when pairing your mobile device and the Knok. Note: If you are using a 2.4GHz + 5 GHz dual band router, create separate SSID names for each band on your Wi-Fi router settings page. -
Page 9: Installation Requirements
Installation Requirements 1. To install the Knok, you must already have an existing doorbell you wish to replace or have a setup location with an installed chime box, transformer, and wiring. 2. The Knok will work with most mechanical and electronic chimes but will not work with wireless battery power chimes. -
Page 10: Knok Installation
Knok Installation Before you begin: - Shut OFF the power for the doorbell at the fuse or circuit breaker box. - If you’re unsure which switch it is to turn off the doorbell’s power, please consult with a licensed electrician. - Page 11 Assembly Diagram Knok Doorbell Connections Home’s Chime/Transformer Connections...
- Page 12 Make sure the app logo you download matches the one shown below. Create an Account If you don’t already have a Momentum account, you will need to create one. To create a new account, follow the in-app instructions.
- Page 13 Notes: - You may follow the in-app installation instructions or read the instructions provided in this manual. - Your power to the doorbell should be OFF already at this point from the breaker box. Step 2: Locate your chime box and transformer. - Verify the chime’s transformer can support 16-24V.
- Page 14 Step 5: Remove existing doorbell and disconnect the wiring. - Verify that the power to the doorbell and chime box is still off. Installing an Angle Bracket (OPTIONAL) If your wall is positioned in an angle where the doorbell will not be able to properly monitor the area you want, then you’ll probably want to install an angle bracket.
- Page 15 Make sure the smoother, flatter side of the angle bracket is placed directly onto the wall. d. Screw the mounting bracket into the angle bracket using the short flat screws. e. Install the mounting bracket directly onto the angle bracket using the 4 short security screws (provided).
- Page 16 Connect your existing doorbell wires into the other side of each orange connector. Step 10: Push connectors and wiring back into the wall. Step 11: Remove the color case from the Knok and secure the Knok onto the mounting bracket.
- Page 17 Step 13: Pair the Knok Note: Your Knok should already be installed and powered on before pairing. To begin using your Knok, you will first need to pair it to your Momentum account and then connect it to your Wi-Fi network.
- Page 18 - Once you’re connected, go back to the app. Note: If you’re using an Android device and cannot proceed to the next step, you may need to set the Knok Wi-Fi network to “automatically connect” or confirm the connection again from the android notification pop-up the comes up after attempting to connect to the Knok Wi-Fi network.
-
Page 19: Storage Options
Momentum Capture Cloud Storage subscription plan or with your own micro-SD card inserted into the device. The micro-SD card slot can be found behind the Knok device (see pg. 5). Momentum Capture Cloud Storage After you initially pair a Momentum device to your Momentum account, you will be provided FREE cloud recordings that last for 24hrs. - Page 20 You also have the option to use your own micro-SD card (up to 64GB) instead for back-up storage. Insert the micro-SD card into Knok’s micro-SD slot on the back of the Knok device. The camera will automatically record events and camera photos you take directly into the micro-SD card as back-up storage.
-
Page 21: Your Dashboard
Your Dashboard Your dashboard is your app’s home screen where you can view and access your paired devices. You can rearrange the Tiles on your dashboard by tapping the Pencil icon in the top right corner of the app. You can also make some device tiles larger or smaller when editing your dashboard. -
Page 22: Do Not Disturb (Dnd) Controls
This tile allows you to “snooze” the chime for a specified amount of time. This is helpful if you don’t want anyone ringing your doorbell at night. You can also control the DND from the Knok camera’s live view screen. -
Page 23: Siren Activation
Siren Activation Your Knok has a built-in siren that is loud enough to scare away your perpetrators. You can activate the siren from the Siren Tile or the Knok live view screen. -
Page 24: Camera Functions
Camera Functions Your Momentum Knok has several functions you can control through the Momentum app. To enter the camera controls, select the camera tile from the dashboard. Camera tile Watching Live Video To view live video stream, first select the Camera tile. -
Page 25: Taking Photos
Tap the Record Video icon to start recording. The video will record based on a 20 second clip. Audio Functions You can engage in two-way conversations while you’re in the Knok’s live video stream option. Record Video Take Photo Microphone... -
Page 26: Answering The Doorbell
Answering the Doorbell When a visitor presses the Knok’s doorbell button, you will receive a notification to your mobile device. Tapping on the notification will give you the option to answer or ignore the visitor. If you choose to answer the visitor, you’ll be brought to the Knok’s live stream screen where you’ll be able to remotely... -
Page 27: Motion Detection Settings
Motion Detection Settings There are two motion detection settings for the Knok: motion sensor and camera detection. The Knok uses a two-step verification on motion alerts to limit false alerts from irrelevant motion, such as trees or leaves moving in the background. - Page 28 The “Top View” motion setting allows you to adjust the PIR motion sensor detection. You may turn off any of the 3 motion zones and adjust the sensor distance from the bar at the bottom. The “Camera View” motion setting allows you to block off areas where you don’t want the camera to detect motion.
-
Page 29: Setting Up Rules
Setting up Rules Your Knok will record video when rules have been set through the Momentum App. Rules allow your device to activate and monitor the area while you are not watching the live stream. Adding a New Rule Tap on the blue “Rules” tile or select the “Rules” option from the menu tab and tap on the “+”... -
Page 30: Mobile Alerts
If you’d like to stop receiving alerts, you must delete the Rule, or you can turn it off from your mobile device’s notification settings for the Momentum App. You may also view all your previous alerts by tapping the Activity tile on your Dashboard. -
Page 31: Viewing Recorded Photos And Videos
Viewing Recorded Photos and Videos To view Cloud videos, tap the Activity tile to view recorded videos, captured photos, or alerts for a specific day. You can also access the activity list from the live camera view. When you select a video in your activity list, it will begin playing back automatically. -
Page 32: Restoring Forgotten Passwords
However, if you’d like to save your cloud or micro-SD card recordings to your mobile device’s local storage, you can do so while you’re viewing the specific recording. Press the ‘save’ button at the bottom right corner to save a copy of the footage onto your mobile device’s local storage. -
Page 33: Resetting The Device
Resetting the Device If you’re just setting up your Knok for the first time or need to repair the device to a different Wi-Fi network, you may need to first reset the device to get it in pairing mode again. -
Page 34: Troubleshooting
Troubleshooting Assistance is available both in the app and on the Momentum website. To access the most current version of the user’s manual, tap the Menu icon to launch the screen with a menu bar and tap Support. For further assistance and the latest version of the... -
Page 35: About Momentum
About Momentum Momentum provides an easy-to-setup home security camera that connects to your smart phone or tablet giving you real-time video streaming and two-way voice communication – anywhere, anytime. Momentum subscribers also have access to IOT cloud-based storage for camera-captured videos from a user-friendly mobile app. - Page 36 FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Apollo Tech USA, Inc.
- Page 37 Regulatory Information The regulatory information herein might vary according to the model you purchased. Some information is only applicable for the country or region where the product is sold. FCC Information Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 38 Battery Replacement and Disposal Applicable to products with battery. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Privacy Protection Notice As the device user or data controller, you might collect personal data of others such as face, fingerprints, car plate number, Email address, phone number, GPS and so on.
