USER MANUAL
QSW-9010 CLI Configuration user manual
QSW-9010
www.qtech.ru

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QSW-9010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for q-Tech QSW-9010

  • Page 1 USER MANUAL QSW-9010 CLI Configuration user manual QSW-9010 www.qtech.ru...

  • Page 2: Table Of Contents

    User Manual Index GPON properties ..............................8 1.1. Introduction ............................... 8 1.2. Reference Standards and Protocols ........................8 1.3. System Overview ..............................9 1.4. Management Configuration ..........................9 1.4.1. Serial Port ............................10 1.4.2. Telnet ............................... 10 1.5. Configure NTP system time synchronization ....................12 1.6.
  • Page 3 User Manual 3.3. ONU Information View ............................. 26 3.4. ONU uni Port Enable/Disable ........................... 26 3.5. ONU capability set query ..........................26 3.6. Optical Module and ONU current, voltage, temperature, Tx & Rx optical power reading ......28 3.7. Optical module and ONU threshold configuration for Tx / Rx optical power ..........28 3.8.
  • Page 4 User Manual 5.2.3. MLD Controllable Multicast ......................56 5.3. Multicast bandwidth downlink rate limit ......................57 QoS service configuration ..........................58 6.1. Simple scheduling mode ..........................59 6.2. Hierarchical scheduling ............................ 59 6.3. Profile configuration............................60 6.3.1. CoS-Queue-Map ..........................60 6.3.2.
  • Page 5 User Manual 9.2. DHCPv6-Option18 / 37 ............................. 87 9.3. DHCPv4-relay point to dhcp ip pool ......................... 88 10. Uplink port LAG service Configuration ......................89 10.1. Dynamic trunk configuration steps ........................89 10.2. Static trunk configuration steps: ........................91 10.3. Load balancing (take Static LAG as example) ....................
  • Page 6 Figure 12-1 PM on statistics and management chart for each port ........... 93 Outline This document describes the OLT-QSW-9010 product location and characteristics (1U) of the system equipment, the typical application scenarios, the whole structure and appearance, product characteristics, and maintenance and management of system parameters for the user to understand the use, management, and maintenance OLT- QSW-9010 (1U) type Device provides reference information.
  • Page 7 OLT-QSW-9010 (1U) Dtype Device provides reference information. To simplify the description, hereinafter OLT-QSW-9010 (1U) is described as a unified OLT. www.qtech.ru...

  • Page 8: Gpon Properties

    User Manual 1. GPON properties GPON PROPERTIES GPON (Gigabit Passive Optical Network) is a PON (Passive Optical Network) technology, is a series of ITU-T G.984.x&G.988 standards Gigabit PON. GPON access is used to support higher bandwidth. 1.1. Introduction GPON Technology highlight: ...

  • Page 9: System Overview

    User Manual 1. GPON properties 1.3. System Overview GPON is a gigabit passive optical network technology, is currently the most widely used optical access mainstream technology.  The GPON network uses a single fiber to connect the OLT, splitter and ONU, uplink and downlink data with different carrier wavelengths.

  • Page 10: Serial Port

    1.4.2.1. Out band Configuration QSW-9010 has two out-band management ports, the first (the upside one) IP address is 192.168.100.2, which can not be changed, while the second (the downside one) IP is 192.168.1.32. In addition, OLT can be managed by Telenet after in-band IP configuration.
  • Page 11 User Manual 1. GPON properties Configuration Item Data Uplink Port xe1/2 In-band management VLAN VLAN ID：1000 In-band Management IP Address 10.1.1.1/24 Gateway 10.1.1.254/24 OLT#configure terminal OLT(config)# Add uplink port to in-band management VLAN: OLT(config)#interface xe1/2 OLT(config-xe1/2)#no shutdown OLT(config-xe1/2)#speed 1000 OLT(config-xe1/2)#switchport mode trunk OLT(config-xe1/2)#switchport trunk tag 1000 Configure in-band management IP address: OLT(config)#ip address 10.1.1.1/24 vlan 1000...

  • Page 12: Configure Ntp System Time Synchronization

    User Manual 1. GPON properties Note: Out-band and In-band management IP address can not be in one network segment. We suggest configure only one in-band management IP. If more IP are configured, other will not be able to connect to the network, but can connect to PC by configuring PVID. Configure in-band Gateway: OLT(config)#gateway 10.1.1.254 Note:...

  • Page 13: System Time Configuration

    User Manual 1. GPON properties Configure NTP Server: OLT(config)#sntp unicast-server 192.168.17.117 The source address used when sending synchronization request for connecting NTP: OLT(config)#sntp connect 192.168.17.117 Configure the NTP synchronization interval, the time unit is seconds: OLT(config)#sntp auto-sync timer 10 (Optional) Check the running status of NTP: OLT# show sntp Simple ntp client: Status: Enable...

  • Page 14: System Configuration Operation

    User Manual 1. GPON properties 2016-05-31 11:02:40 [gmt +03:00] OLT# write OLT# reboot Are you sure reboot [y/n] y Unsaved configuration will be lost. Save now? [y/n] OLT# default configure OLT# reboot Are you sure reboot [y/n] y Unsaved configuration will be lost. Save now? [y/n] n 1.7.

  • Page 15: Configuration Saving And Restore

    User Manual 1. GPON properties OLT# zlog upload tftp 192.168.1.111 When the command execution succeed, in the TFTP server folder, you can see diag.tar.gz compressed package files, including unos.log and other diagnostic information. 1.7.5. Configuration Saving and Restore OLT supports the saving and restore of system configuration, saves the configuration of the system in the main.conf folder, and saves it to the local computer and restore through TFTP.

  • Page 16: Operation User Management

    User Manual 1. GPON properties On the computer by using the ping command, you can reach the corresponding management IP address. Open the TFTP server or FTP server locally, and upgrade the software to the file path specified by TFTP or FTP. Run in administrator mode: OLT# upgrade TFTP 192.168.17.117 GPON3116.tar.gz OLT # upgrade FTP 192.168.17.117 GPON3116.tar.gz username...

  • Page 17: Create Operation User

    User Manual 1. GPON properties Level 1 user can only operate on level 1 orders. Level 2 user can only operate on level 1~2 orders. Level 15 user can only operate on level 1~15 orders 1.9.2. Create Operation User When you create a user, you need to configure the user's attributes, including the user's account number, password, and permissions.

  • Page 18: Delete User

    User Manual 1. GPON properties 1.9.4. Delete User OLT (config)# no username 111 1.10. Trap Configuration Set the IP address of the destination host for the Trap message. When the IP address of the host of the Trap message destination is successfully set, the Trap message of the device will be sent to the host corresponding to the IP address when the Trap message is enabled.

  • Page 19: View The Current System Cpu|Pon Optics| Switching Chip|Pon Chip Temperature

    : 38 C Pon Chip Temperture : 35 C Note: The OLT QSW-9010 can view the device temperature; does not support this command. 1.13. CTC-enable When this feature is enabled, OLT will follow the CTC standard, which defaults to "ITU" rules.

  • Page 20: Basic Service Configuration

    GPON (config) # show profile onutype Figure 2-1 View onutype Configuration Delete onutype: QSW-9010 (config-gpon) # no profile onutype onu-4fe Note: All the above configuration contains ONU 4 Ethernet ports, 4 cardholders, both up and down que are 8. The number of card is 1 by default.

  • Page 21: Configure A Dba Profile

    View DBA Profile configuration: GPON (config) # show profile bandwidth Delete DBA profile: QSW-9010 (config-gpon) # no profile bandwidth dba-typex Description: The default profile can not be deleted, The binded ONU should be unbinded firstly before deleting the DBA profile.

  • Page 22: The Onu Configuration

    Total: 0 Step 3, add the corresponding ONU: QSW-9010 (config) # interface gpon-olt 1/1 QSW-9010 (config-gpon-olt1 / 1) # onu 2 type onu-4fe sn QTEC001f28ca Step 4, add ONU status: QSW-9010 (config-gpon-olt1 / 1) # show onu status www.qtech.ru...
  • Page 23 User Manual 2. Basic service configuration www.qtech.ru...
  • Page 24 User Manual 2. Basic service configuration ONU status Description:  Added ONU has been added but is offline.  Authpass ONU has been authenticated.  Operational ONU operable. Description: When the PW authentication is the same as the PW part of SN+PW authentication, SN can not be shown normally, please ensure that the ONU do not have the same SN and PW before delivery.

  • Page 25: Remote Onu Function Configuration

    User Manual 3. Remote ONU function configuration 3. REMOTE ONU FUNCTION CONFIGURATION 3.1. ONU automatic discovery In the corresponding PON port, open ONU automatic discovery function, and ONU can be in operational state automatically if the optical power is normal, unnecessary to be manually added. Enable: OLT (config) interface gpon-olt1 / 1 OLT (config-gpon-olt1 / 1) # onu auto-learn enable...

  • Page 26: Onu Information View

    This command is used to query ONU actual ability. After the query to the actual capability of the ONT, it can create the appropriate profile of ONT capability set based on it. . QSW-9010 (config-gpon-onu7 / 6: 3) # show onu remote capability www.qtech.ru...

  • Page 27: Table 3-1 Onu Hardware Capabilities Parameter

    User Manual 3. Remote ONU function configuration Table 3-1 ONU hardware capabilities parameter Parameter Explanation TCONT number The T-CONT number supported by the ONU GEMPort number GEM Port number can be provided by ONU Total priority queue number Total uplink/downlink queue number supported by ONU...

  • Page 28: Optical Module And Onu Current, Voltage, Temperature, Tx & Rx Optical Power Reading

    OLT (config-gpon-onu1 / 2: 1) # show onu power ONU reads the Tx/Rx power and voltage, current and temperature. QSW-9010(config-gpon-onu1 / 2: 1) # show onu remote optical info Query ONU Rx Power at PON Port: GPON (config-gpon-olt1 / 8) # show optical module rxpower onuid 1 OLT rx power: -19.02 dbm...

  • Page 29: Remote Onu Restart And Restore

    User Manual 3. Remote ONU function configuration The threshold for the PON port optical module can not be modified, and the threshold reported is from the SFP module. Different manufacturers or types of SFP modules have different threshold phenomena. 3.8. Remote ONU restart and restore Remote ONU restore: OLT (config) #interface gpon-onu1 / 5: 1 OLT (config-gpon-onu1 / 5: 1) # remote onu restore...

  • Page 30: Uplink Packet Gem Port Service Flow Encryption Enable

    User Manual 3. Remote ONU function configuration Configuration Key Update interval (ms): OLT (config-gpon-olt1 / 4) # aes encryption key_exchange interval 10000 3.9.2. Uplink packet GEM port service flow encryption enable Enable encryption: OLT (config-gpon-onu1 / 4: 1) # gemport 1 encryption enable Encryption disable: OLT (config-gpon-onu1 / 4: 1) # gemport 1 encryption disable 3.10.

  • Page 31: Onu Remote Upgrade

    User Manual 3. Remote ONU function configuration remote mac_filter service 1 mode dynamic | static Description: When static constraint is used, learn and forward according to the configured static MAC address; For Dynamic constraints, use MAC learning. Uplink Dynamic MAC limits: OLT (config-gpon-onu1 / 1: 1) # remote uni eth_1 / 1 mac-limit 1 When the mode is statically limited, you can configure data that allows only fixed (source / destination) MAC addresses, or discard only the data stream of the fixed (source / destination) MAC...

  • Page 32: Onu Manage-Ip

    User Manual 3. Remote ONU function configuration ONU version delete: OLT # delete onuversion VERSION Update the ONU version, manual upgrade can only update the current working status of operational ONU, the upgrade process to ensure that the ONU state is normal: OLT # cpe update tclinux.bin gpon-olt1 / 4 onuid 1 View ONU version: OLT # show cpe information gpon-olt1 / 5 onuid 2...

  • Page 33: Pon Port Isolation Function Disabling

    User Manual 3. Remote ONU function configuration OLT (config-gpon-onu12 / 4: 1) #remote onu mgmt-ip 11.0.0.2 255.255.255.0 11.0.0.1 vlan 101 Ping the ONU IP from OLT: OLT # ping 11.0.0.2 !!!!! VLAN 101 configured in uplink port can be forwarded to PC, thus switching to the EOC configuration management.

  • Page 34: Unicast Service Configuration

    User Manual 4. Unicast service configuration 4. UNICAST SERVICE CONFIGURATION 4.1. MAC address management MAC address management is a basic function of two-layer network management, including setting MAC address aging time, limiting dynamic MAC address learning number and static MAC address. 4.1.1.

  • Page 35: Static Mac

    8 ge port xe uplink 2 xe port Note: QSW-9010- supports 2*10GE or 8*GE, OLT needs to be restarted if you want to change the uplink mode. The default is 8*GE mode. 4.2.1.2. The uplink port VLAN attributes configuration In the uplink interface configuration mode, configuration port supports two modes: trunk (hybrid) and access.
  • Page 36 User Manual 4. Unicast service configuration OLT (config-xe1 / 1) #switchport access 100 Note: When the uplink interface VLAN is configured, the system will automatically create the corresponding VLAN 4.2.1.3. The uplink port rate configuration The OLT has two 10G uplink ports, which can be configured as a 1G. The uplink ports stay in "shutdown"...
  • Page 37 User Manual 4. Unicast service configuration ------------------------------------------- 0018-7d9d-2ffb 17 xe1 / 2 dynamic 00e0- 4c60-7348 17 xe1 / 2 dynamic 28a0- 2b2b-821e 17 xe1 / 2 dynamic 3891- d5ad-9678 17 xe1 / 2 dynamic c4ca- d930-de0d 17 xe1 / 2 dynamic 0000- 0400-0001 100 gpon-onu1 / 5: 5 dynamic 0000-0500-0001 100 xe1 / 1 dynamic...

  • Page 38: Pon Port Vlan

    User Manual 4. Unicast service configuration 4.2.1.8. VLAN Layer 3 sub-interface Configuration This command is used to create the VLAN interface from the global configuration mode and the VLANIF mode. Use this command when you need to configure a virtual layer three interface in VLANIF mode.
  • Page 39 User Manual 4. Unicast service configuration 4.4.1.2. VLAN passthrough configuration Configure uplink port: OLT (config) #interface xe1 / 1 OLT (config-xe1 / 1) #switchport mode trunk OLT (config-xe1 / 1) #switchport trunk tag 100 Add t-tcont and bind gemport: OLT (config) #interface gpon-onu1 / 1: 1 OLT (config-gpon-onu1 / 1: 1) # tcont 1 profile 100 OLT (config- gpon-onu1 / 1: 1) # gemport 1 tcont 1 Configue service:...

  • Page 40: Add Svlan Service

    User Manual 4. Unicast service configuration Configure 1: 1 service: OLT (config-gpon-onu1 / 1: 1) # service-port 1 gemport 1 user-vlan 100 vlan 300 priority 2 OLT (config-gpon-onu1 / 1: 1) # service-port 2 gemport 2 user-vlan 200 vlan 400 priority 2 Configure remote ONU: OLT (config-gpon-onu1 / 1: 1) # remote service 1 gem 1 vlan 100 OLT (config-gpon-onu1 / 1: 1) # remote service 2 gem 2 vlan 200...
  • Page 41 User Manual 4. Unicast service configuration The added SVLAN can modify the priority cos value or directly copy the cos value of the user VLAN. 4.4.2.1. Add SVLAN for VLAN Packet Configure uplink port: OLT (config) #interface xe1 / 1 OLT (config-xe1 / 1) #switchport mode trunk OLT (config-xe1 / 1) #switchport trunk tag 200 Add t-cont...
  • Page 42 User Manual 4. Unicast service configuration Configure the remote ONU: OLT (config-gpon-onu1 / 1: 1) # remote service 1 gem 1 OLT (config-gpon-onu1 / 1: 1) # remote uni eth_1 / 1 vlan-mode transparent 4.4.2.3. Add SVLAN for All tag packet Configure uplink port: OLT (config) #interface xe1 / 1 OLT (config-xe1 / 1) #switchport mode trunk...

  • Page 43: Vlan Filter And Mapple Mode Configuration For Remote Onu

    User Manual 4. Unicast service configuration Configure the remote ONU: OLT (config-gpon-onu1 / 1: 1) # remote service 1 gem 1 OLT (config-gpon-onu1 / 1: 1) # remote uni eth_1 / 1 vlan-mode transparent Note: When the the service configuration model is untag-add | tagged-add, the default priority is 0 if adding the outer VLAN.

  • Page 44: Remote Uni Configuration

    User Manual 4. Unicast service configuration Service binding port: OLT (config-gpon-onu1 / 1: 1) # remote service 1 gem 1 eth_1 / 1 Note: QTECH OLT supports up to 32 remote service configurations. The Remote service configuration is strictly filtered and requires all the same service when configuring it, that is, which means VLAN and VLAN+COS service can't be mixed.

  • Page 45: Multicast Service Configuration

    User Manual 5. Multicast service configuration 5. MULTICAST SERVICE CONFIGURATION Multicast is the form of communication from point to multi-point where the source sends information to a subset of all nodes in the network. The core of multicast technology is to make the message replication work as far as possible from the nearest recipient to reduce the multicast data traffic on the network.

  • Page 46: Multicast Igmp Configuration

    User Manual 5. Multicast service configuration Backbone Internet Metro backbone Router BRAS / SR Broadband Access Access Network User Home Home Gateway 5.1. Multicast IGMP configuration 5.1.1. General Multicast Configuration Table 5-1 General Multicast Configuration Configuration Item data Multicast service VLAN ID Service priority Uplink port XE1 / 2...
  • Page 47 User Manual 5. Multicast service configuration Index: 1 Name: T1 T-CONT T-CONT Profile: 20M Index: 1 GEM Port Name: gemport1 T-CONT Index: 1 Service type: internet GEM Port Index: 1 Priority: 0 Service Channel VLAN ID: 510 Port: eth_1 / 1 User port VLAN VLAN modes: transparent VLAN ID: 510 OLT configuration:...

  • Page 48: Igmp Span-Vlan Multicast

    User Manual 5. Multicast service configuration OLT (config-gpon-onu1 / 4: 3) # remote uni eth_1 / 1 vlan-mode trunk tag 510 OLT (config-gpon-onu1 / 4: 3) # remote multicast eth_1 / 1 enable OLT (config-gpon-onu1 / 4: 3) # remote multicast eth_1 / 1 igmp version 3 OLT (config-gpon-onu1 / 4: 3) # remote multicast eth_1 / 1 up vlan 510 tag-action transparent...

  • Page 49: Igmp Controllable Multicast

    User Manual 5. Multicast service configuration OLT (config) # igmp mvlan 510 receive-port gpon-onu1 / 4: 3 OLT (config) # igmp interface gpon-onu1 / 4: 3 version 3 ONU configurations: OLT (config-gpon-onu1 / 4: 3) # tcont 1 profile T4-200M OLT (config-gpon-onu1 / 4: 3) # gemport 1 tcont 1 OLT (config-gpon-onu1 / 4: 3) # service-port 1 gemport 1 user-vlan 500 vlan 510...
  • Page 50 User Manual 5. Multicast service configuration ================================================== ============= GPON (config) # show igmp ========================================= IGMP Global Configuration ----------------------------------------- Global: Enable WorkMode: Proxy Span-Vlan: Enable CDR: Enable Robustness: 10 Snooping Aging Time: 3600 Proxy Member Aging Time: 310 Query Max Resp Time: 100 General Query Interval: 30 Startup Query Interval: 31 Startup Query Number: 2...
  • Page 51 User Manual 5. Multicast service configuration Start the interval query, under proxy mode, in order to quickly restore the service, after the system successfully started, OLT immediately will send to all receiving ports general query package, the interval is [Startup, Query, Interval] seconds; ...

  • Page 52: Multicast Mld Configuration

    User Manual 5. Multicast service configuration  IGMP Version: Maximum supported version number of IGMP message. If the IGMP message received by OLT is larger than the version number specified by this parameter, OLT will discard the message.  IGMP Run Version: The current IGMP version number running on the port.

  • Page 53: General Multicast Configuration

    User Manual 5. Multicast service configuration 5.2.1. General Multicast Configuration Table 5-3 General Multicast Configuration Configuration Item data Multicast service VLAN ID Service priority Uplink port XE1 / 2 Service port ONU Interface: gpon-onu1 / 4: 1 Service-port ID: 1 T-CONT Index: 1 Name: T1 T-CONT Profile: 20M...
  • Page 54 User Manual 5. Multicast service configuration OLT (config-gpon-onu1 / 4: 1) # remote multicast eth_1 / 1 up vlan 410 tag-action transparent OLT (config-gpon-onu1 / 4: 1) # remote multicast eth_1 / 1 down vlan 410 tag-action transparent View MLD entry: OLT (config) # show mld dynamic-group ================================================== ============= MVLAN SOURCE GROUP TYPE INTERFACE...

  • Page 55: Mld Span-Vlan Multicast

    User Manual 5. Multicast service configuration 5.2.2. MLD SPAN-VLAN multicast Table 5-4 MLD multicast VLAN Cross Configuration Item data Multicast service VLAN ID Business priorities Uplink port Xe1 / 2 Service port ONU Interface: gpon-onu1 / 4: 1 Service-port ID: 1 Index: 1 Name: T1 T-CONT T-CONT Profile: 20M...

  • Page 56: Mld Controllable Multicast

    User Manual 5. Multicast service configuration Remote ONU configurations: OLT (config-gpon-onu1 / 4: 1) # tcont 1 profile 20M OLT (config-gpon-onu1 / 4: 1) # gemport 1 tcont 1 OLT (config-gpon-onu1 / 4: 1) # service-port 1 gemport 1 user-vlan 400 vlan 410 OLT (config-gpon-onu1 / 4: 1) # remote uni eth_1 / 1 vlan-mode trunk tag 400...

  • Page 57: Multicast Bandwidth Downlink Rate Limit

    User Manual 5. Multicast service configuration 5.3. Multicast bandwidth downlink rate limit OLT (config-gpon-olt1 / 4) # scb max-bandwidth 200000 It must be configured in "qos-queue-scheduler mode hierarchy" mode, if it is in switch mode you need to manually shutdown PON port before switching. OLT (config-xe1 / 2) # storm-control multicast kbps 5000 Configuration will valid...

  • Page 58: Qos Service Configuration

    User Manual 6. QoS service configuration 6. QOS SERVICE CONFIGURATION QoS:Quality of Service, which means during the network communication process, to allow users to achieve the desired level of service in terms of bandwidth, delay, jitter and packet loss rate. The indicators for measuring QoS are as follows: ...

  • Page 59: Simple Scheduling Mode

    User Manual 6. QoS service configuration 6.1. Simple scheduling mode  In simple scheduling mode, for incoming packets, according to the conversion of the outer VLAN cos value (VLAN is the single VLAN cos, VLAN SVLAN double cos value) the uplink port will determine the packet Local Priority (internal use priority with 0-0 mapping by default, the ACL rule can be used to modify the message Local Priority);...

  • Page 60: Profile Configuration

    User Manual 6. QoS service configuration When the PON port is configured as a hierarchical scheduling model,  According to the converted outer VLAN 802.1Q cos (single-layer VLAN is the VLAN cos, dual-layer VLAN is SVLAN cos) to determine the packet Local Priority (internal priority, 0- 0 mapping by default, ACL rule can be used to modify the the Local Priority of the message);...
  • Page 61 User Manual 6. QoS service configuration Viewing configured Profile: OLT (config-gpon) # show profile cos-queue-map profile cos-queue-map 1 name 1 cos0 0 cos1 0 cos2 0 cos3 0 cos4 0 cos5 0 cos6 0 cos7 0 profile cos-queue-map 2 name 2 cos0 0 cos1 1 cos2 2 cos3 3 cos4 4 cos5 5 cos6 6 cos7 7 profile cos-queue-map 3 name 3 cos0 7 cos1 6 cos2 5 cos3 4 cos4 3 cos5 2 cos6 1 cos7 0...

  • Page 62: Qos-Queue-Scheduler

    User Manual 6. QoS service configuration When the PON port is simple scheduling mode, the configuration on the ONU does not take effect and cannot be modified; in hierarchical mode, ONU maps all priority to queue 0 by default. View the mapping of the port message scheduling between internal priority and the queue. ...
  • Page 63 User Manual 6. QoS service configuration Description: When there is no que of weight is 0, the profile is WRR policy scheduling; When there is the entry with weight 0 in the queue, the profile is a SP+WRR hybrid scheduling policy scheduling.
  • Page 64 User Manual 6. QoS service configuration When the PON port is a simple scheduling mode, before scheduling for downlink queue, the scheduling policy should be configured at the exit, i.e. PON port. Note: PON port is hierarchical scheduling mode, this attribute is not valid, and can not be modified OLT (config) # interface gpon-olt 1/1 OLT (config-gpon-olt1 / 1) # qos-queue-scheduler 1 When the PON port is hierarchical scheduling mode, the queue scheduling policy should be...

  • Page 65: Qos-Queue-Traffic

    User Manual 6. QoS service configuration 6.3.3. QoS-Queue-Traffic Qos-queue-traffic is to guarantee and limit the queue bandwidth, in which the minimum bandwidth is the guaranteed bandwidth of the queue, and the maximum bandwidth is the maximum bandwidth allowed by the queue. The qos-queue-traffic default command is used to recover the default queue bandwidth limiting policy for the system.
  • Page 66 User Manual 6. QoS service configuration OLT (config-gpon-olt1 / 1) # show profile qos-queue-traffic profile qos-queue-traffic 1 name 1 queue0 1-1 queue1 1-1 queue2 1-1 queue3 1-1 queue4 1-1 queue5 1-1 queue6 1-1 queue7 1-1 profile qos-queue-traffic 2 name 2 queue0 10-1000000 queue1 10- 100000 queue2 10-10000 queue3 10-1000 queue4 10-100 queue5 10-10 queue6 0-1 queue7 0-0 profile qos-queue-traffic 3 name 3 queue0 0-1000000 queue1 0-...

  • Page 67: Qos-Onu-Bandwidth

    User Manual 6. QoS service configuration When the PON port is a hierarchical scheduling mode, before scheduling to the ONU downlink queue, configurable queue bandwidth is in ONU (Note: PON is simple scheduling mode, this property is not valid, and can not be modified), for example: OLT (config) # interface gpon-onu1 / 1: 1 OLT (config-gpon-onu1 / 1: 1) # qos-queue-traffic 1 Restore the default queue scheduling policy.

  • Page 68: Qos-Onu-Weight

    User Manual 6. QoS service configuration View the ONU downlink bandwidth configuration: OLT (config) # show qos-onu-bandwidth interface gpon-onu1 / 1: 1 qos-queue-bandwidth min 100 max 1000 6.3.5. QoS-ONU-Weight The configuration can only be configured and effective on the ONU when the PON port is a hierarchical scheduling mode.

  • Page 69: Simple Downlink Qos Scheduling Configuration

    User Manual 6. QoS service configuration OLT (config-xe1 / 1) # rate-limit 1000 2000 egress // uplink rate limit 6.5. Simple downlink QoS Scheduling Configuration When the QoS is simple mode, the profile is binding in the Xe port and PON port, according to the principle: in-bound to the queue, out-bound for scheduling and rate limiting;...

  • Page 70: Downlink Hierarchical Qos Scheduling Configuration

    User Manual 6. QoS service configuration 6.6. Downlink hierarchical QoS scheduling configuration The OLT three-layer QoS scheduling is only for ONU downlink service, for uplink service support only 8 queue scheduling of unicast in a single ONU, for each ONU to provide up to 8 queues used to distinguish the services (Note: the supported queue number is related with the ONU registration profile, refer to "the ONU type profile configuration"...
  • Page 71 User Manual 6. QoS service configuration www.qtech.ru...
  • Page 72 User Manual 6. QoS service configuration ： Note When there is downlink traffic congestion, the WRR weighted unicast polling is carried out for each ONU unicast service under the PON port according to the weight value, and the default ONU weight is 1.

  • Page 73: Optional Configuration

    User Manual 6. QoS service configuration 6.6.3. Optional Configuration When the QoS stream speed limit for downlink unicast/multicast data streams is required, the PON port speed limit can be configured in kbps. OLT (config-gpon-olt1 / 1) # rate-limit 1000 2000 egress // speed downlink When it is necessary to limit the downlink multicast data speed, the maximum bandwidth of the PON outlet multicast can be configured in kbps.

  • Page 74: Acl Service Configuration

    User Manual 7. ACL service configuration 7. ACL SERVICE CONFIGURATION ACL (Access Control List) policy is to filter a specific packet by configuring a series of matching rules, so as to identify the packets that need to be filtered. After identifying a particular object, the corresponding packets will be allowed or prohibited in accordance with a predetermined policy.
  • Page 75 User Manual 7. ACL service configuration ACL extend ipv4 <3000-3999> Make rules according to the protocol type code (ip|tcp|udp|gre|ipinip|icmp) , source IP and mask, source port, destination IP and mask, and the destination port number, dscp<0-63> precedence<0-7> cos<0-15> field, analyze the data packets accordingly.
  • Page 76 User Manual 7. ACL service configuration ACL extend ipv6 <8000-8999> Make rules according to the protocol type code (ip|tcp|udp|gre|ipinip|icmp v6), source IP and prefix, source port, destination IP and prefix, the destination port number, flow- label <0-1048575>, traffic-class <0-255> field, analyze the data packets accordingly.

  • Page 77: Acl Rule Configuration

    User Manual 7. ACL service configuration 7.3. ACL rule configuration Figure 7-2 ACL rule configuration Description: Command Format ACL {standard-ACL-number | extend-ACL-number | link - ACL-number | hybrid-ACL-number} no ACL {all | standard-ACL-number | extend-ACL-number | link - ACL-number | hybrid-ACL-number} Each ACL can create up to 128 rules.
  • Page 78 User Manual 7. ACL service configuration ACL name can be configured with infinite length, but at MIB level only take the first 30 bits. Don't configure mutually-exclusive rule like tcp\arp, otherwise it will not hit the rules, action will not be effective.
  • Page 79 User Manual 7. ACL service configuration Ipv6 hybrid OLT (config) # ACL ipv6 hybrid 9999 OLT (config-ACL-ipv6-hyb-rule) # rule 1 permit protocol ip source any ignore destination any ignore flow-label any traffic-class any type ip vlan any cos any src-mac any ignore dst-mac any ignore Parameter description: ...

  • Page 80: Acl Action Configuration

    User Manual 7. ACL service configuration The ACL rule does not support multicast MAC address. 7.4. ACL Action Configuration Figure 7-3 ACL Action Configuration 7.4.1. Packet-Filter The packet-filter command is used to configure the ACL filtering rule for the specified port and enable it.

  • Page 81: Traffic-Mirror

    User Manual 7. ACL service configuration The "no traffic-limit" command is used to cancel restrictions on the traffic received on the specified port. After the configuration is successful, the system will not have any speed limit on the port. OLT (config) # no traffic-limit ingress ACL 2222 rule 1 port gpon- olt1 / 11 7.4.3.

  • Page 82: Traffic-Redirect

    User Manual 7. ACL service configuration OLT (config) # no traffic-priority ingress ACL 2222 rule 1 port gpon-olt1 / 11 7.4.5. Traffic-Redirect The "traffic-redirect" command is used to redirect messages that match the ACL rule on the specified port to other ports. Use this command when you need to redirect specific traffic to other ports. After successful configuration, the source port will not forward the redirection message, but by the redirected destination port, note that the destination port need to configure the corresponding VLAN to forward the traffic successfully.

  • Page 83: Stp Service Configuration

    User Manual 8. STP service configuration 8. STP SERVICE CONFIGURATION OLT supports three STP (Spanning Tree Protocol) modes:  STP (Spanning Tree Protocol)  RSTP (Rapid Spanning Tree Protocol)  MSTP (Multiple Spanning Tree Protocol) STP mode: STP comply with IEEE802.1d standards. RSTP mode: RSTP follows IEEE802.1w standard, a faster convergence rate than STP.
  • Page 84 User Manual 8. STP service configuration OLT (config) # spanning-tree instance 0 vid 100 Description: By default, all VLAN are mapped to CIST (Common And Internal Spanning Tree), that is, instance 0. A VLAN cannot be mapped to a different instance, that is, if the mapped VLAN is re-mapped to a different instance, the original mapping relationship will be automatically canceled.
  • Page 85 User Manual 8. STP service configuration Set a specific port priority OLT (config-xe1 / 1) # spanning-tree mstp 0 port-priority 16 Set the port is an edge port OLT (config-xe1 / 1) # spanning-tree mstp edge auto Set whether backward compatible with STP version OLT (config-xe1 / 1) # spanning-tree mstp migration-check Set the link connected with the port is point-to-point or not OLT (config-xe1 / 1) # spanning-tree mstp point-to-point auto...

  • Page 86: Dhcp-Relay Service Configuration

    User Manual 9. Dhcp-relay service configuration 9. DHCP-RELAY SERVICE CONFIGURATION 9.1. DHCPv4-Option60 / 82 The OLT DHCP v4 function does not do anything for the option60. After enabling the DHCP v4 relay function, the DHCP message is transparently forwarded. After enabling DHCP (Dynamic Host Configuration Protocol) Option 82 function, DHCP v4 L2 Relay work process is as follows: DHCP V4 client broadcast the request message when initializing.

  • Page 87: Dhcpv6-Option18 / 37

    User Manual 9. Dhcp-relay service configuration Description: Where the RID field is configured, the "access-node-id" field is covered, corresponding to the "Agent Remote ID" field in the option82 option 9.2. DHCPv6-Option18 / 37 DHCPv6, that is, DHCP protocol under IP V6 protocol. The OLT DHCPv6 function does not do anything for the option18.

  • Page 88: Dhcpv4-Relay Point To Dhcp Ip Pool

    User Manual 9. Dhcp-relay service configuration 9.3. DHCPv4-relay point to dhcp ip pool When the service VLAN in the OLT is different from the upper equipment address pool VLAN, by using "dhcp-relay" service VLAN need to jump to the VLAN interface address where DHCP address pool is This command is used to set how three-layer DHCP Relay will fill in the message source IP.

  • Page 89: Uplink Port Lag Service Configuration

    User Manual 10. Uplink port LAG service Configuration 10. UPLINK PORT LAG SERVICE CONFIGURATION OLT uses double uplink protection mechanism to ensure the stability of the service. When the physical connection between the OLT and the upper equipment is interrupted, the equipment automatically switches to the standby line to ensure that the service can recover quickly.
  • Page 90 User Manual 10. Uplink port LAG service Configuration Configure dynamic trunk VLAN and negotiating rates. OLT (config) # interface xe1 / 1 OLT (config-xe1 / 1) # no shutdown OLT (config-xe1 / 1) # speed 1000 OLT (config-xe1 / 1) #duplex full OLT (config-xe1 / 1) # switchport mode trunk OLT (config-xe1 / 1) # switchport trunk tag 200 OLT (config) # interface xe1 / 2...

  • Page 91: Static Trunk Configuration Steps

    User Manual 10. Uplink port LAG service Configuration 10.2. Static trunk configuration steps: The default configuration is trunk 1: OLT (config) #interface trunk 1 In the uplink interface configuration mode, add the port to trunk. OLT (config) #interface xe1 / 1 OLT (config-xe1 / 1) # trunk 1 OLT (config) #interface xe1 / 2 OLT (config-xe1 / 2) # trunk 1...

  • Page 92: Load Balancing (Take Static Lag As Example)

    User Manual 10. Uplink port LAG service Configuration 10.3. Load balancing (take Static LAG as example) OLT supports 3 traffic load balancing ways(based on source MAC, destination MAC, and both source/destination MAC). The default value is based on both source and destination MAC. OLT configuration (take source MAC as an example): OLT (config) # interface trunk 1 OLT (config-trunk1) # load-balance...

  • Page 93: Alarm Management

    User Manual 11. Alarm Management 11. ALARM MANAGEMENT OLT alarm information can be viewed by QNMS network management software (need to enable trap, IP is local address). OLT support the alarm of uplink port / PON port fiber broken, ONU power failure, UNI offline, etc.

  • Page 94: View Alarms On The Ne

    User Manual 11. Alarm Management Description: The low optical power alarm can also be viewed on the NMS. If the ONU cannot report its Tx and Rx optical power alarm information, the OLT will not be able to view the ONU optical power alarm. If ONU does not report an alarm with low power output, need to check whether the ONU can support it.

  • Page 95: Port Statistics And Pm Statistics

    This command is used to query the statistics of Ethernet ports. Use this command when you need to judge whether the device is running normally according to the statistics of the Ethernet port. 12.1.1. Message statistics of uplink-port View port statistics: QSW-9010 (config) # show interface xe9 / 4 www.qtech.ru...
  • Page 96 User Manual 12. Port statistics and PM statistics www.qtech.ru...

  • Page 97: Table 12-1 Packet Statistics Parameters Uplink Port Description

    User Manual 12. Port statistics and PM statistics Table 12-1 Packet statistics parameters uplink port description parameter Parameter parameter Parameter Description Description xe9 / 4 The current port PVID Pvid Configuration, default is 1 Hardware address Port MAC address Tag vid Configurable list available tags...

  • Page 98: Packet Statistics Of Pon Port

    Clear linked port packet statistics: OLT (config) # clear counters xe9 / 4 12.1.2. Packet statistics of PON port QSW-9010 (config) # show interface gpon-olt7 / 6 Clear PON port packet statistics: QSW-9010 (config) # clear counters gpon-olt7 / 6...

  • Page 99: Pm Statistics

    User Manual 12. Port statistics and PM statistics Description: Port statistics does not need to enable If the displayed value is 0, means that no frames received for this type or the port has no traffic currently. 12.2. PM Statistics This command is used to query performance statistics of ports, ONU, and gem.

  • Page 100: Pm Statistics Of Onu

    View protocol message: OLT (config) # show statistic gpon-olt7 / 6 protocol 12.2.2. PM statistics of ONU Enable: QSW-9010 (config-gpon-onu7 / 6: 2) # pm enable View: QSW-9010 (config-gpon-onu7 / 6: 2) # show statistic gpon-olt7 / 6 onu 2 www.qtech.ru...

  • Page 101: Pm Statistics Of Gem

    QSW-9010 (config-gpon-onu7 / 6: 2) # show statistic gpon-olt7 / 6 onu 2 gem 1 12.2.4. PM statistics of uni Enable: QSW-9010 (config-gpon-onu7 / 6: 2) # show onu remote uni eth_1 / 1 View: QSW-9010(config-gpon-onu7 / 6: 2) # show onu remote uni eth_1 / 1 Description: PM statistics are based on a historical performance statistics for 15 minutes.
