AIR SUPPLY MUST HAVE IN-LINE FILTER/REGULATOR/LUBRICATOR
(NOT INCLUDED) TO VALIDATE THE ROLLING AIR JACK WARRANTY
ATTENTION! This lift is intended for indoor use only. It is prohibited to install this
product outdoors. Failure to adhere will result in decertification, loss of warranty,
and possibly damage to the equipment.
Branick Industries, Inc. • 4245 Main Avenue • Fargo, North Dakota 58103
REV021513
8700 Series
8900 Series
Rolling Air Jacks
- NOTICE -
1
Installation, Operation
& Repair Parts
Information
P/N: 81-0022F
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Branick 8700 Series
- Page 1 ATTENTION! This lift is intended for indoor use only. It is prohibited to install this product outdoors. Failure to adhere will result in decertification, loss of warranty, and possibly damage to the equipment. Branick Industries, Inc. • 4245 Main Avenue • Fargo, North Dakota 58103 P/N: 81-0022F REV021513...
- Page 2 Always wear appropriate eye protection. WARNING Maximum lift capacity of 8700 series jack is 7000 lbs. (3175 kg) Maximum lift capacity of 8900 series jack is 9000 lbs. (4082 kg) Exceeding this could result in severe personal injury or death.
- Page 3 INSTALLATION Installation of jacks and lifts shall be performed in accordance with ANSO/ALI ALIS, Safety Requirements for Installation and Service of Automotive Lifts. For additional safety instructions regarding lifting, lift types, warning labels, preparing to lift, vehicle spotting, vehicle lifting, maintaining load stability, emergency procedures, vehicle lowering, lift limitations, lift maintenance, good shop practices, installation, operator training and owner/employer responsibilities, please refer to “Lifting It Right”...
- Page 4 5) To lower jack, hold the Lock Release Lever to the left while moving the Control Lever to the “LOWER” position. If jack does not lower, raise it slightly while holding the Lock Release Lever to the left until you feel the lock move past the detent, then continue to lower jack.
- Page 5 ROLLING AIR JACK REPAIR PARTS ITEM PART NO. DESCRIPTION 028-041 1/4-20 X 1 HHC SCREW 028-132 1/4-20 X 1/2 HHC SCREW 03-0126 LINKAGE BAR 03-0129 LINKAGE ROD 03-0131 LIFT PAD 03-0132 LATCH 055-160 1/4-20 NYLON HEX LOCK NUT 061-032 1/8 X 3/4 SPRING PIN...
- Page 6 ITEM PART NO. DESCRIPTION 061-091 1/4 X 7/8 SPRING PIN 096-339 1/4 TUBE UNION TEE 096-340 1/4 TUBE X 1/4 NPT M CONN 10-0017 RUBBER LIFT PAD 50-0043 1/2-13 X 1/2 HSHC SCREW 50-0065 3/8-16 X 3/4 HHSF SCREW 50-0066 1/4-20 X 3/8 SET SCREW 51-0016 1/4-20 HEAVY SQUARE NUT...
- Page 7 INSTRUCTIONAL DECALS ITEM PART NO DESCRIPTION 80-0253 8700 Series Raise/Lower Decal (7000 lb) 80-0103 8900 Series Raise/Lower Decal (9000 lb) 80-0079 Lock Release Decal 80-0080 Caution Decal 80-0083 Warning Decal 80-0254 8700 Series Warning Decal (7000 lb) 80-0104 8900 Series Warning Decal (9000 lb) M00-003 128"...
- Page 8 During the warranty period, at the discretion of Branick management, if the product is found to be defective, it will be repaired or replaced without charge. For service, contact Branick (800-437-4394) to obtain an RMA.
