- Page 1 ONE-XY Series Integrated XY Linear Motor Stages ’ ANUAL...
-
Page 2: Warranty
Integrated XY Linear Motor Stages Warranty Newport Corporation warrants this product to be free from defects in material and workmanship for a period of 1 year from the date of shipment. If found to be defective during the warranty period, the product will either be repaired or replaced at Newport’s discretion. -
Page 3: Table Of Contents
Encoder and End-of-Runs (SUB-D15M Connector) .......7 4.6 ONE-XY Cable Wiring................7 — Stage Installation ...............8 5.1 Unpacking ....................8 5.2 Mounting Conditions ................9 — Connection to Newport Controllers ......10 6.1 Warnings on Controllers ................10 6.2 Connection....................11 6.3 Cables .......................11 — Connection to Non-Newport Controllers ....12... - Page 4 ONE-XY Series Integrated XY Linear Motor Stages — Maintenance ................14 9.1 Maintenance ....................14 9.2 Repair .......................14 9.3 Calibration ....................14 Service Form ......................15 EDH0351En1012 — 10/18...
-
Page 5: Ec Declaration Of Conformity
ONE-XY Series Integrated XY Linear Motor Stages EC Declaration of Conformity ONE-XY Year mark affixed: 2015 EU Declaration of Conformity The manufacturer: Newport Corp. 1791 Deere Avenue Irvine, CA 92606 - USA Hereby declares that the product: Description: " ONE-XY "... -
Page 6: Definitions And Symbols
Note indicates additional information that must be considered by the user or operator. European Union CE Mark The presence of the CE Mark on Newport Corporation equipment means that it has been designed, tested and certified as complying with all applicable European Union (CE) regulations and recommendations. -
Page 7: Warnings
2006/42/EC may be required. It is the responsibility of the end-user or integrator to perform a risk-analysis and the necessary tests to conform to the EC directives. Newport is not liable for damages caused by not executing this responsibility. Warnings WARNING The motion of objects of all types carries potential risks for operators. - Page 8 If this stage has been dropped or the case has been damaged, switch off the motor power and then disconnect the electronics power supply. Contact your Newport service facility and request repairs. WARNING Do not attempt to modify this stage; this may cause an electric shock or downgrade its performance.
-
Page 9: Caution
When the carriage is in its end-of-run position, it is strongly recommended not to go beyond this point as this may damage the stage mechanism. CAUTION Contact your Newport service facility to request cleaning and specification control every year. EDH0351En1012 — 10/18... - Page 10 ONE-XY Series Integrated XY Linear Motor Stages EDH0351En1012 — 10/18...
-
Page 11: Introduction
This manual provides operating instructions for the ONE-XY stage. Inside this manual you will find useful information and technical references. It is recommended that the user download all support documentation from the ONE-XY page of the Newport website to have as reference. ONE-XY350 Stage. -
Page 12: Description
Integrated XY Linear Motor Stages —Description The ONE-XY series of integrated XY linear motor stages are designed to eliminate the integration of individual X and Y stages and increase system stiffness for dynamic applications. The available travel ranges from 60 mm to 400 mm, with precise orthogonality alignment between the X and Y axes. -
Page 13: Characteristics
168 points. Guaranteed and Typical Specifications Guaranteed maximum performance values are verified per Newport's A167 metrology test procedure. For more information, please consult the metrology tutorial section in the Newport catalog or at www.newport.com EDH0351En1012 — 10/18... -
Page 14: Mechanical Specifications
26.4 (12) 165 (75) Specifications measured on stage centerline, 50 mm above mounting surface. Newport provides NIST traceable, test results. Flatness specifications dependent on system base. Contact Newport for more information. Stage performance values at no load. Does not account for drive or resolution effects. -
Page 15: Drive And Motor
ONE-XY Series Integrated XY Linear Motor Stages —Drive and Motor Motor characteristics (Direct Drive Brushless Motor) ONE-XY50 ONE-XY100 ONE-XY200 ONE-XY300 ONE-XY400 Magnet Pitch [N-N] (mm) 30.48 30.48 30.48 30.48 30.48 Max. Voltage [Line to Line] Electrical Time Constant (ms) 0.19 0.19... -
Page 16: Position Feedback Signals
ONE-XY Series Integrated XY Linear Motor Stages Sensor Positions Stage Travel Range Negative Positive Software Limit Software Limit Home Position .08 (2) .08 (2) (Origin) – End-of-Run Limit + End-of-Run Limit Index Pulse Index Pulse 1.97 Direction – Motion Direction +... -
Page 17: Encoder And End-Of-Runs (Sub-D15M Connector)
WARNING GROUNDING: The stage's protective ground is located on pin #8 of the motor power connector. If you are using grounds other than those provided by Newport, you must connect pin #8 to a ground connection. 4.5.2 Encoder and End-of-Runs (SUB-D15M Connector) -
Page 18: Stage Installation
ONE-XY Series Integrated XY Linear Motor Stages —Stage Installation Unpacking The ONE-XY stage will be delivered to your site in packaging designed for safe transport. Larger ONE-XY stages will be delivered in Pelican cases. All accessories will be included in this case. -
Page 19: Mounting Conditions
ONE-XY Series Integrated XY Linear Motor Stages NOTE Put away shipping screws, in case the unit needs to be returned to the factory. The stage will come delivered with a control report that indicates performance of your stage within guaranteed specification. These measurements were taken in a controlled environment under flat mounting conditions. -
Page 20: Connection To Newport Controllers
Specifications listed in this guide are based on operation with Newport Control and Drive Electronics. The XPS Controller is delivered with a configuration file that has been developed at the factory for operation in a no-load condition for immediate plug-and-play operation. -
Page 21: Connection
All ONE-XY stages are delivered with a set of 3-meter cables with SUB-D connectors for direct connection to Newport Controllers. WARNING ONE-XY Series translation stages can only operate with cable lengths of 3 m or less. WARNING These cables are shielded. For correct operation, make sure to lock connectors (ground continuity provided by cables). -
Page 22: Connection To Non-Newport Controllers
Please refer to Design Details and Specifications for more information to help configure the stage with your controller. Newport also provides a tech note on configuring third party stages with Newport controllers on ONE-XY website, which may be useful as a reference. -
Page 23: Dimensions
ONE-XY Series Integrated XY Linear Motor Stages —Dimensions 3 HOLES ø.197 +.012 DEPTH .20 (5) SLIP FIT FOR M5 DOWEL PIN MODEL TRAVEL 1.97 4.92 4.92 2.36 ONE-XY60 (50) (125) (125) (60) (101.6) 3.54 7.24 7.24 2.36 ONE-XY100 (90) (184) -
Page 24: Maintenance
CAUTION Any attempt to disassemble or repair a stage without prior authorization will void the warranty. Calibration CAUTION It is recommended to return your ONE-XY stage to Newport once a year for recalibration to its original specifications. EDH0351En1012 — 10/18... -
Page 25: Service Form
Service Form Your Local Representative Tel.: Fax: Name: Return authorization #: (Please obtain prior to return of item) Company: Address: Date: Country: Phone Number: P.O. Number: Fax Number: Item(s) Being Returned: Model #: Serial #: Description: Reasons of return of goods (please list any specific problems): EDH0351En1012 —... - Page 26 Visit Newport Online at: www.newport.com North America & Asia Europe Newport Corporation MICRO-CONTROLE Spectra-Physics S.A.S 1791 Deere Ave. 9, rue du Bois Sauvage Irvine, CA 92606, USA 91055 Évry CEDEX France Sales Sales & Technical Support Tel.: (800) 222-6440 Tel.: +33 (0)1.60.91.68.68 e-mail: sales@newport.com...
