Summary of Contents for Microview iSERIES NVR16
- Page 1 NVR16 Network Video Recorder Quick Operation Guide UD.6L0202B1197A02...
-
Page 2: Table Of Contents
NVR16 Network Video Recorder · Quick Operations Guide TABLE OF CONTENTS NVR Pre-Installation ........................... 2 NVR Installation ............................2 Hard Disk Installation ..........................2 Front Panel ..............................4 Rear Panel6 Peripheral Connections ..........................7 Wiring of Alarm Input / Output ........................7 Using of Alarm Connectors ......................... -
Page 3: Nvr Pre-Installation
NVR16 Network Video Recorder · Quick Operations Guide Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. This manual is applicable to the MicroView NVR16 model. NVR Pre-Installation The NVR08 is a highly advanced surveillance equipment that should be installed with care. - Page 4 NVR16 Network Video Recorder · Quick Operations Guide 3. Connect the power cable to the HDD. 4. Place the HDD on the bottom of the device and then fasten the screws on the bottom to fix the HDD.
-
Page 5: Front Panel
NVR16 Network Video Recorder · Quick Operations Guide Front Panel Name Function Description POWER Turns green when NVR is powered up. READY The LED is green when the device is running normally. The light is green when the IR remote control is enabled;... - Page 6 NVR16 Network Video Recorder · Quick Operations Guide Name Function Description In PTZ Control mode, it will turn on/off PTZ light and when the image is zoomed in, the key is used to zoom out. Enter numeral “3”; Enter letters “DEF”;...
-
Page 7: Rear Panel6
NVR16 Network Video Recorder · Quick Operations Guide Rear Panel Item Description VIDEO OUT BNC connector for video output. BNC connector for audio output. This connector is synchronized with CVBS AUDIO OUT CVBS video output. BNC connector for audio output. This connector is synchronized with VGA AUDIO OUT VGA video output. -
Page 8: Peripheral Connections
NVR16 Network Video Recorder · Quick Operations Guide Peripheral Connections Wiring of Alarm Input / Output The alarm input/output interface of the NVR is shown as below: The alarm input is an open/closed relay. If the input is not an open/closed relay, follow the connection diagram... -
Page 9: Controller Connection
NVR16 Network Video Recorder · Quick Operations Guide signal cables are in tight. 3. Connect pluggable block back into terminal block. Controller Connection To connect a controller to the NVR: Disconnect pluggable block from the KB terminal block. Unfasten stop screws from the KB D+, D- pluggable block, insert signal cables into slots and fasten stop screws. -
Page 10: Specifications
NVR16 Network Video Recorder · Quick Operations Guide Specifications Model NVR16 IP video input 16-ch Video/Audio input Two-way 1-ch, BNC (2.0 Vp-p, 1kΩ) audio Recording 5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF resolution Main stream: 25 fps (P) / 30 fps (N) -
Page 11: Hdd Storage Calculation Chart
NVR16 Network Video Recorder · Quick Operations Guide HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used... -
Page 12: Menu Operation
NVR16 Network Video Recorder · Quick Operations Guide Menu Operation Menu Structure The menu structure of the NVR16 is: Startup and Shutdown Proper startup and shutdown procedures are crucial to expanding the life of the NVR. To start your NVR: 1. - Page 13 NVR16 Network Video Recorder · Quick Operations Guide The Wizard setting interface is shown below: Operating the Setup Wizard: 1. The Setup Wizard can walk you through some important settings of the NVR. If you don’t want to use the Setup Wizard at that moment, click the Cancel button.
- Page 14 NVR16 Network Video Recorder · Quick Operations Guide Date and Time Settings 6. After the time settings, click Next button which takes you back to the Network Setup Wizard window. Dual-NIC is not supported and the internal NIC IPv4 address should be configured for the cameras connecting to the PoE network interface of the NVR.
-
Page 15: Live View
NVR16 Network Video Recorder · Quick Operations Guide 9. Click Next button. You enter the Adding IP Camera interface. 10. Click Search to find online IP Camera. Select the IP camera to be added, and click the Add button. -
Page 16: Adding And Configuring Ip Cameras
NVR16 Network Video Recorder · Quick Operations Guide Alarm (video loss, tampering, motion detection or sensor alarm) Record (manual record, schedule record, motion detection or alarm triggered record) Alarm & Record Adding and Configuring IP Cameras You should add the online IP cameras to enable the live view and recording function. -
Page 17: Record Settings
NVR16 Network Video Recorder · Quick Operations Guide Click the button to add the camera. Explanation of the icons: Icon Explanation Icon Explanation Edit basic parameters of the camera Add the detected IP camera. The camera is disconnected; you The camera is connected. -
Page 18: Instant Record
NVR16 Network Video Recorder · Quick Operations Guide the user manual for detailed information. Purpose: Two kinds of record types are introduced in the following section, including Instant Record and All-day Record. And for other record types, you may refer to the user manual for detailed information. -
Page 19: Backup
NVR16 Network Video Recorder · Quick Operations Guide OPTION 2 Steps: Enter the Playback interface. Right-click or move the mouse to the bottom of the screen when you in the live view mode and select from the menu. - Page 20 NVR16 Network Video Recorder · Quick Operations Guide Menu > Export > Normal Choose the channel(s) you want to back up and click on the Search button. Enter Export interface, choose backup device and press Export button to start exporting.
- Page 21 NVR16 Network Video Recorder · Quick Operations Guide...
