Artikelnummer 5017 743-R4
Instruction manual
Horizontal Flail
SH125 / SH150 / SH170 / SH190 / SH210
SH110-TW / SH150-TW
English, User manual in original
©
Copyright
All rights reserved, including the right to reproduce this manual, or parts thereof, in any form, without the
written permission of Cranab AB.
Model:
Read through the entire instruction
manual before beginning operation.
® ® ® ®
EuroTest
Certificate
Advertisement
Table of Contents
Summary of Contents for SLAGKRAFT SH125
- Page 1 Artikelnummer 5017 743-R4 Instruction manual Horizontal Flail Model: SH125 / SH150 / SH170 / SH190 / SH210 SH110-TW / SH150-TW Read through the entire instruction manual before beginning operation. ® ® ® ® EuroTest Certificate English, User manual in original ©...
- Page 2 Products sold after 1995-01-01 are to be CE-marked and in conformance with the machine directive confirmed by EU. The manufacturer (importer) holds responsibility for this in the EU and/or EES area. EuroTest ® ® ® ® Certificate The EUROTEST mark indicates that the product has been inspected by a testing station that is independent of the maker of the product, ie, third party certification.
-
Page 3: Table Of Contents
ONTENTS 1 ..................................Introduction Limitation of application.................. 5 Range of use....................5 2 ..............................General description Identification ....................7 Direction of rotation ..................8 3 ..............................Technical description Hydraulic fluids....................9 Filter ....................... 9 Hub ......................10 Safety cover ....................10 Hydraulic motor .................... - Page 4 Lubrication schedule ..................29 Lubricating the drive axle ................30 Cleaning the chain magazine ............... 30 Loading chain into the magazine..............31 Changing the protective rubber mat ............. 32 Changing the chain curtain ................32 Retightening bolted joints................33 Inspecting slot-and-wedge bolt joints ............33 Inspecting bearings ..................
-
Page 5: Introduction
Limitation of application Slagkraft’s flails can be mounted on other carriers than Slagkraft cranes. Slagkraft’s tilting mounts are therefore available in a variety of designs. It is essential that the base machine is inspected after fitting to ensure satisfactory stability. To inspect stability, run the crane boom and horizontal flail to maximum tilting moment, ie, maximum extended mode at right angles to the direction of travel for the machine, just above ground level. - Page 6 Study the entire instruction manual before using the flail. Before mounting it, study the section “connecting to carrier” and section “Safety rules.” If the horizontal flail is included in bush clearing machine Compact or Motor package study also the instruction manual for Compact, Motor package and Crane respectively.
-
Page 7: General Description
ENERAL DESCRIPTION Identification The horizontal flail consists mainly of safety cover, hub and hydraulic motor and chain magazine, chain curtain, protective rubber mat, and wear plates. The type designation of the horizontal flail consists of a number of parts describing the configuration of the flail. How this designation is built up and what it means is shown below. -
Page 8: Direction Of Rotation
Direction of rotation Flail have clockwise rotation seen from above. Wear plates, the hood and other protections are designed for this rotation. This rotation requires that the pressure line to the hydraulic motor is connected to the hydraulic motor connection marked “A”. -
Page 9: Technical Description
Bushes and thickets are slashed and the vegetation is disintegrated into chips. The horizontal flail can be operated using different chain diameters recommended by Slagkraft, 10 or 13mm. Note that the chain magazine shall only be filled with one dimension at a time. 10 and 13mm chain may never, under any circumstances, be mixed in the same magazine. -
Page 10: Hub
Flail chains are available in two sizes 10 and 13mm. Article number 1046 010 and 1046 002 respectively. To facilitate identification of flail chain from Slagkraft it is painted blue and identification marked according to Slagkraft’s instructions. When buying chain, save the identification marking until the chain is used up. -
Page 11: Chain Magazine And Chain Locks
Replace the back plate when there is 2mm metal left at the thinnest position. The responsibility of Slagkraft (CE and ET-markning) is not available if there is used other flailchain, chainlock or chainmagazine or other not... -
Page 12: Technical Data
ECHNICAL DATA Standard models Model SH125 SH150 SH170 SH190 SH210 Working width (mm) 1250 1500 1700 1900 2100 49” 59” 67” 75” 82” Hydraulic motor (cc) 3,66 cu.in 4,88 cu.in 5,62 cu.in 6,71 cu.in 7,63 cu.in Outer dimensions (mm) Length... -
Page 13: Tw Models
TW models TW 90° Bracket sidemounted TW Standard Bracket forward Model SH110-40- SH150-60- SH150-80- SH110-40- SH150-60- SH150-80- TW-0° TW-90° TW-0° TW-0° TW-90° ° ° ° TW-90° ° ° ° Working width (mm) 1100 1100 1500 1500 1500 1500 43” 43” 59”... -
Page 14: Safety Rules
AFETY RULES See also safety rules for crane and where applicable also for Compact and Motor package. General safety rules The contents of this chapter are a summary of rules that must always be followed in connection with the horizontal flail. These rules do not, however, free the operator from the obligation to observe statutory or other current national regulations with regard to road safety and industrial safety. -
Page 15: Safety Instructions
Beware of the fire hazard when working in terrain that is dry and flammable. It is important to know the risks when using hot work processes (such as grinding, welding, sawing/cutting) on products painted with polyurethane colours. If heated above 200° C, dangerous amounts of isocyanates may be released, and this will require personal protective equipment, and that the place of work has a ventilation system that works well. - Page 16 Detected faults are to be corrected before further operation so as to avoid personal injury or material damage. • Use only Slagkraft’s genuine spares and parts subjected to wear. The outermost chain links are subjected to wear when operating the flail. When a chain link becomes worn out the flail and its diesel engine must be stopped.
-
Page 17: Warning Decal
Observe the warning decal that is to be found undamaged on top of the cover. If the warning decal is illegible, order a new one from Slagkraft and fix it on the well-cleaned surface. Article number of the warning decal is 5013 889 for the... - Page 18 Operate with the wear runners against the ground to ensure maximum safety. ALWAYS use genuine flail chain from Slagkraft. Replace the protective rubber mat when worn. Replace the chain curtain if damaged. The engine of the wheel-mounted loader must be switched off when connecting or disconnecting hydraulic fittings or electric connectors.
-
Page 19: Lifting Points
Lifting points The horizontal flail has four points that are to be used when lifting. These lifting points are marked with decals as illustrated below. Type plate The type plate on the machine is as illustrated below. Address to Product name Cranab AB Machine type designation... -
Page 20: Connecting To Carrier
ONNECTING TO CARRIER Slagkraft’s horizontal flail can be mounted on other carriers than Slagkraft cranes. Slagkraft’s tilting mounts are therefore available in a variety of designs. It is essential that an inspection is made after fitting to ensure satisfactory stability. To inspect, extend the crane boom and flail to maximum reach, at right angles to the direction of travel of the base machine, just above the ground. - Page 21 • Connect the pressure and return together (ie, “short-circuit”) and run the flow a couple of minutes to flush the leads clean (especially important if new hoses are used). • Prime the hydraulic motor housing through the drain lead connection before starting.
-
Page 22: Operating Instructions
• Always start at low revs, then slowly increase to working revs. Mode of operation The right way of working with Slagkraft’s flails is to always keep the wear runners resting against the ground. This gives the best clearing results and minimises the risk of flying stones, etc. -
Page 23: Hints For Light Clearing
Hints for light clearing • Use 10mm flail chain, approved by Slagkraft, for light clearing and clearing of grass. • Mowing grass: Operate at lower rate of flow / revs than normal and keep the flail as close to the ground as possible to achieve best results. -
Page 24: Check After Long-Term Parking / Storage
Check after long-term parking / storage • All oil and fluid levels. • That hydraulic hoses are free from cracks. Cracks in the outer layer of rubber can easily result in rust on steel reinforcement of the hose. • Tension of all belts. •... -
Page 25: Service
To check for any leakage, use a piece of paper or cardboard, etc, not your hand! Consult Slagkraft for advice if there is any doubt concerning suitable action in connection with daily service. Lubricate regularly according to the lubrication schedule. -
Page 26: Electric Welding
Electric welding Any repair-welding of the safety cover is to be done in conformance with Slagkraft’s instructions. If the flail is connected to a vehicle the vehicle manufacturer’s instructions must also be followed in connection with repairs. The following measures are to be taken in connection with welding. -
Page 27: Maintenance Schedule / Lubrication Schedule
Maintenance schedule / Lubrication schedule The table below is a summary of inspection, service and maintenance measures. It is of major significance for operational reliability and long useful life of the flail that the maintenance is carried out. Detected faults are to be corrected before continuing operation. -
Page 28: Retightening Of Bolted Joints - Table
Retightening of bolted joints - Table Inspect all bolted joints regularly. Torque-tighten the bolts according to the table below. In spare part catalogue can you find more detailed information about torque on each bolt. Inspect all bolted joints after the first 10 hours of operation. Item Dimension Bolt class Torque (Nm) Location Hydraulic motor - Hub... -
Page 29: Lubrication Schedule
Lubrication schedule These points are to be greased daily (every 8 hours of operation). Use a grease gun filled with universal grease. The grease must at least fulfil the norm SIS 155130. Pump 1-2 strokes of the grease gun. Thoroughly clean the grease nipples before greasing. -
Page 30: Lubricating The Drive Axle
Lubricating the drive axle The drive axle must be greased every day to ensure lubrication between the motor axle and the drive axle • Unscrew the plug at the back of the hub. • Rotate the chain magazine / drive axle by hand until you see the lubricant nipple. -
Page 31: Loading Chain Into The Magazine
Before loading chain into the magazine, make sure that you have the correct size of chain lock. Use only chain and locks that are approved by Slagkraft. • Turn the magazine to “1 o’clock”. • Then start to feed in chain through the upper opening. -
Page 32: Changing The Protective Rubber Mat
Protective rubber mat SH110-TWMin. 300 mm Protective rubber mat SH150-TWMin. 300 mm Protective rubber mat SH125 Min. 300mm Protective rubber mat SH150 Min. 300mm Protective rubber mat SH170 Min. 325mm Protective rubber mat SH190 Min. 325mm Protective rubber mat SH210 Min. -
Page 33: Retightening Bolted Joints
Retightening bolted joints 600Nm Inspect after the first ten hours of operation. Inspect all bolted joints on the flail at regular intervals. Torque tighten bolted joints at 600Nm. Other bolts and screws – see table. Inspecting slot-and-wedge bolt joints Wedge Drive When the flail is new it is essential that Slot bolt... -
Page 34: Inspecting Bearings
Inspecting bearings Too much play in the hub bearings normally makes it difficult to balance the flail. Bearings should be replaced after 1500 hours of operation. • Check play in the bearing by trying to “lift” the magazine in direction A, ie, radially. -
Page 35: Ec Declaration
EC D ECLARATION... - Page 38 Cranab AB Karlsgårdsvägen 56, SE-922 82 Vindeln, Sweden. Tel +46 933 135 00 Fax +46 933 617 36 info@slagkraft.se www.slagkraft.com...
