Summary of Contents for Galaxy COE3Q
- Page 1 User Manual Countertop Convection Ovens Models: COE3Q, COE3H 5/2019 Please read the manual thoroughly prior to equipment set-up, operation and maintenance. - 1 -...
-
Page 2: Table Of Contents
User Manual Index Important Safety Information ������������������������������������������������������������� 3 Identification of Key Parts ������������������������������������������������������������������� 4 Identification of Accessories ���������������������������������������������������������������� 4 Before Using Your Oven ����������������������������������������������������������������������� 5 Using Your Oven ���������������������������������������������������������������������������������� 5 Typical Operation Sequence ���������������������������������������������������������������� 5 Timer��������������������������������������������������������������������������������������������������� 6 Temperature Control Knob ������������������������������������������������������������������ 6 Power and Heating Indicator Light �������������������������������������������������������... -
Page 3: Important Safety Information
User Manual IMPORTANT SAFETY INFORMATION When using electrical appliances, basic safety precautions should always be followed, including the following: Read all instructions carefully and completely. For commercial use only. Do not touch hot surfaces. Protect against electrical shock by keeping all cords, plugs, and other electrical components away from water or other liquids. -
Page 4: Identification Of Key Parts
User Manual Identification of Key Parts Wire Racks Identification of Accessories Roasting Racks - 177PCOE3QTG1 for 177COE3Q - 177PCOE3HTG2 for 177COE3H Recommended Bun Pans - Quarter Size (407BUNQRTR) for 177COE3Q - Half Size (407BUNHALF) for 177COE3H - 4 -... -
Page 5: Before Using Your Oven
User Manual BEFORE USING YOUR OVEN Before cooking anything in your oven for the first time, please follow these simple instructions: Using a small amount of detergent, wash the handle and roasting racks with soapy water. (NOTE: Do not use a spray or abrasive polishing agent.) Gently wipe down interior walls with a damp cloth. -
Page 6: Timer
User Manual Timer The range of the timer on this unit is 0-120 minutes. Turning the timer to the "0" position, the cooking time is over and the timer will "ding" to alert. If you need to reset the baking time while the oven is in operation, simply turn the timer to a new position. -
Page 7: Specifications
User Manual Specifications MODEL # POWER SUPPLY DIMENSIONS UNIT WEIGHT SIZE PLUG CERTIFICATIONS 177COE3Q 120V, 12 Amps, 60Hz, 1440W 18¾"W x 18"D x 15"H 30 lbs. (35 lbs. shipping) Quarter 120V NEMA 5-15 177COE3H 120V, 13.3 Amps, 60Hz, 1600W 23"W x 22½"D x 16½"H 43 lbs. -
Page 8: Parts List
User Manual Parts List ITEM NUMBER PART DESCRIPTION COMPATIBLE MODELS 177PCOE3HDR DOOR 177COE3H 177PCOE3HEL ELEMENT 177COE3H 177PCOE3HGSK GASKET 177COE3H 177PCOE3HHND HANDLE 177COE3H 177PCOE3HRK2 SIDE RACK 177COE3H 177PCOE3HTG2 GRID RACK 177COE3H 177PCOE3QDR DOOR 177COE3Q 177PCOE3QEL ELEMENT 177COE3Q 177PCOE3QGSK GASKET 177COE3Q 177PCOE3QHND HANDLE 177COE3Q 177PCOE3QRK1... - Page 9 Equipment Limited Warranty Galaxy warrants its equipment to be free from defects in material and workmanship for a period of 90 days. This is the sole and exclusive warranty made by Galaxy covering your Galaxy brand equipment. A claim under this warranty must be made within 90 days from the date of purchase of the equipment.
