PH-SERIES

Specifications, Installation, Operation Service and Spare Parts Manual

MODELS PH40, 50, 75, 80, 100 and 125 ONLY: For either indoor or outdoor installation/Installer à l'intérieur

WARNING:

MODELS PH-40HO, PH-75HO, PH-80,

PH-100HO, PH-125HO Are For Outdoor Use Only

WARNING:

Improper installation, adjustment,

alteration, service or maintenance can cause

property damage, injury or death. Read (refer to)

the installation operating and maintenance

instructions thoroughly before installing or

servicing this equipment. For assistance or

additional information consult a qualified installer,

service agency or the gas supplier.

WARNING:

If the information in these instructions

is not followed exactly, a fire or explosion may result;

causing property damage, personal injury or loss of

life.

-Do not store or use gasoline or other flammable vapors

and liquids in the vicinity of this or any other appliance.

- WHAT TO DO IF YOU SMELL GAS:

1) Extinguish any open flame

2) DO NOT try to light any appliance.

3) DO NOT use or touch any electrical switches.

4) DO NOT use any phone in your building

5) Turn off gas.

6) Open Windows

7) Leave the building

8) Immediately call your gas supplier from a

neighbor's phone or after you have left the

building. Follow the gas supplier's instructions.

9) If you cannot reach your gas supplier, call the fire

department.

- Installation and service must be performed by a

qualified installer, service agency or the gas supplier

WARNING:

Heat exchanger surface is hot. Do not touch surface or burn may result. Combustible material or articles should

not be placed on or near heater. Observe clearance to combustibles as noted on heater and in this manual.

INSTALLER: Leave this manual with the

appliance.

CONSUMER: Retain this manual for future

reference.

Printed in USA

Gas Fired Outdoor Infrared Patio Heater/Gas-Fired Infrared Patio Heater

Vented Radiant Tube Heater/ L'Appareil de chauffage de Tube Rayonnant donné vent

Gravity Vented Wall Furnace/ La gravité A Donné vent Fournaise de Mur

For Industrial, Commercial, and Residential Patio and Restaurant Applications.

INSATLLATEUR: Laissez cette notice

avec I' appareil.

CONSOMMATEUR: Conservez cette

notice pour consultation ultérieure.

ou à l'extérieur

ADVERTISSEMENT.

l'ajustement, le changement, le service ou

l'entretien peuvent causer les dommages de

propriété, la blessure ou la mort. Lire (se référer à)

l'installation qui fonctionne et les instructions

d'entretien à fond avant d'installer ou entretenir

cet équipement. Pour obtenir de l'aide ou les

informations supplémentaires consultent un

programme d'installation, une agence de service

ou le fournisseur de gaz qualifié.

ADVERTISSEMENT:

suivre les instructions données dans cette notice

pour réduire au minimum le risqué d'incendie ou

d'explosion ou pour éviter tout dommage

matériel, toute blessure ou la mort.

- Ne pas entreposer ni utiliser d'essence ni d'autres

vapours ou liquidés inflammables à proximité de cet

appareil ou de tout autre appareil.

- QUE FAIRE SI VOUV SENTEZ UNE ODEUR DE GAZ:

1) Éteindre la flamme ouverte

2) Ne pas tenter d'allumer d'appareils

3) Ne touchez à aucun interrupteur.

4) Ne pas vous server des téléphonés dans le

bâtiment ou vous vous trouvez.

5) le Virage du gaz.

6) Ouvrir Windows

7) Part le bâtiment

8) Appelez immédiatement votre fournisseur de

gaz depuis un voisin ou âpres que vous êtes

parti le bâtiment. Suivez les instructions du

fournisseur.

9) Si vous ne pouvez rejoindre le service des

incendies.

- L'installation et I' entretien doivent être assures par

un installateur ou un service d'entretien qualifié ou

par fournisseur de gaz.

L'installation déplacée,

Assurez-vous de bien

Calcana USA Ltd.

30201 Country Road 49

Loxley, AL, 36551

Tel: 251-964-4400

Fax: 251-964-4404

Rev 5

1/19

Table of Contents

Summary of Contents for Calcana PH Series

Page 1 30201 Country Road 49 appliance. avec I’ appareil. Loxley, AL, 36551 CONSUMER: Retain this manual for future CONSOMMATEUR: Conservez cette Tel: 251-964-4400 reference. notice pour consultation ultérieure. Fax: 251-964-4404 Printed in USA © 2019 Calcana USA Ltd. Rev 5 1/19...
Page 2 PH-SERIES WHEN AN EXISTING CATEGORY I HEATER IS REMOVED OR REPLACED, THE ORGINAL VENTING SYSTEM MAY NO LONGER BE SIZED TO PROPERLY VENT THE ATTACHED APPLIANCES. The effects of an improperly sized venting system can include but not limited to: the formation of condensate, leakage, spillage etc.
Page 3 PH-SERIES TABLE OF CONTENTS CHECK COMBUSTION AIR INTAKE FOR BLOCKAGE. ----------- 48 OWNERS RESPONSIBILITY --------------------------------- 1 CHECK EXHAUST TERMINAL FOR BLOCKAGE. ------------------ 48 INSTALLER RESPONSIBILITY------------------------------ 3 OPEN SERVICE DOOR. ----------------------------------------------- 48 CHECK BLOWER MOTOR AND SCROLL FOR DIRT AND/OR CODE COMPLIANCE ------------------------------------------ 5 LOCKED ROTOR.
Page 4: Table Of Contents
PH-SERIES TABLE OF FIGURES Figure 1. PATIO HEATER SIDE DIMENSION ....... 7 Figure 2. PATIO HEATER END PROFILES ........8 Figure 3. OUTDOOR END CLEARANCES ........9 Figure 4. VENTED CLEARANCES ..........9 Figure 5. STANDARD REFLECTOR ........... 10 Figure 6. 25' TO 45' TILT ............10 Figure 7.
Page 5 PH-SERIES OWNERS RESPONSIBILITY Thank you for purchasing our product. We have designed this unit to provide you with years of trouble-free heating enjoyment. READ THIS MANUAL IN ITS ENTIRERTY! If you do not understand any of the safety or hazardous warnings contained in this manual, or have questions or concerns about the installation, operation, maintenance or service of this heater, or any other questions or concerns relating to this heater, you MUST CALL THE FACTORY at the telephone number noted on the front cover of this manual or as detailed on the rating...
Page 6 PH-SERIES WARNING: Improper installation, adjustment, alteration, servicing or maintenance can cause property damage, injury, or death WARNING: Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the same place as the heater.
Page 7 PH-SERIES INSTALLER RESPONSIBILITY WARNING: FIRE OR EXPLOSION HAZARD The heater and related gas piping and wiring must be installed only by individuals or firms well qualified and licensed in the required field of work. Read and understand this manual in its entirety BEFORE you install this heater. If you have any questions call your local representative.
Page 8 PH-SERIES FIRE OR EXPLOSION HAZARD The PH-40, 50, 75, 80, 100, and 125 heaters must not be connected to a chimney flue serving a separate solid- fuel burning appliance. These models, in a space heating application, must only be installed with the venting that they are certified for.
Page 9 PH-SERIES CODE COMPLIANCE Installation shall be in accordance with local building codes, or in the absence of local codes, in accordance with: FUEL SUPPLY: CANADA: Natural Gas and Propane Installation Code, CSA B149.1 or latest edition. USA: National Fuel Gas Code, ANSI Z223.1/NFPA 54, or latest edition. ELECTRICAL GROUNDING: CANADA: Canadian Electrical Code, CSA C22.1 or latest edition.
Page 10 PH-SERIES SPECIFICATIONS: GENERAL SPECIFICATIONS Rating: (Input: Natural and Propane Gas) In Canada: 0-4500' (1372 m) In USA: 0-2000' (610 m) - De-rate Above 2000' (610 m) (see page 37) MODEL BURNER INPUT BTU/hr TUBE LENGTH PH-40 20,000 40,000 137” (341 cm) PH-40 HO 20,000 50,000...
Page 11: Figure 1. Patio Heater Side Dimension
PH-SERIES PATIO HEATER SIDE DIMENSIONS PATIO HEATER SIDE DIMENSIONS Figure 1. PATIO HEATER SIDE DIMENSION...
Page 12: Figure 2. Patio Heater End Profiles
PH-SERIES PATIO HEATER END PROFILES Figure 2. PATIO HEATER END PROFILES...
Page 13: Figure 3. Outdoor End Clearances
PH-SERIES INSTALLATION CLEARANCES AND CLEARANCE TO COMBUSTIBLES Installation of overhead heaters in garages or hangars MUST meet the requirements for bottom (below) clearances detailed in CANADA: Natural Gas and Propane Installation Code, CSA B149.1 or latest edition or USA: National Fuel Gas Code, ANSI Z223.1/NFPA 54, or latest edition. Minimum mounting height from ground or floor to bottom portion of tube is 78"...
Page 14: Figure 5. Standard Reflector
PH-SERIES HORIZONTAL TILT INSTALLATION TYPE 1 INSTALLATION TYPE 2 Input* Input* 4" (10.2 cm) 12" (31 cm) 34" (87 cm) 12" (31 cm) 4" (10.2 cm) 4" (10.2 cm) 31" (79 cm) 28" (72 cm) 4" (10.2 cm) 12" (31 cm) 41"...
Page 15 PH-SERIES PRE-INSTALLATION INSPECTION: Inspect the shipping container and heater for any evidence of shipping damage. If heater damage is found, notify freight carrier and file a claim. WARNING: IF HEATER IS DAMAGED, DO NOT INSTALL Check that all parts and pieces are present and accounted for. Report any missing items to carrier or point of purchase at once.
Page 16 PH-SERIES INSTALLATION Provide for adequate clearance around air openings into the combustion chamber, clearances from combustible material, provisions for accessibility and for combustion and ventilating air supply. PLANNING • Familiarize yourself with the equipment and any accessories that you may require. •...
Page 17 PH-SERIES ASSEMBLY OF COMPONENTS WARNING: SEE PAGE 20 FOR VENTILATION REQUIREMENTS FOR THIS HEATER. MAKE SURE YOU HAVE THE CORRECT MODEL FOR THE INTENDED APPLICATION. IF IN DOUBT CONTACT THE FACTORY FOR DETAILS PRIOR TO INSTALLATION OR OPERATION. GENERAL INSTRUCTIONS Refer to figures on page 11 to 15 Note: If unit is to be installed on a 25 degree tilt refer to page 11 for this type of installation.
Page 18 PH-SERIES 9) Install retaining clips (6 per section of screen) 10) If installing models PH-40, 50, 75, 80, 100, or 125 indoors, attach venting as per pages 22-29, NOTE: PH40HO, PH75HO, PH-80HO, PH-100HO and PH-125HO models cannot be vented. See page 20 for Ventilation requirements to make sure you have the correct heater for your application.
Page 19: Figure 7. Chain Mounting
PH-SERIES Figure 7. CHAIN MOUNTING RIGID MOUNTING (See warning on Page 9) 25 DEGREE TILT HORIZONTAL Figure 8. RIGID MOUNTING...
Page 20: Figure 9. Ph-50 & 75 Assembly
PH-SERIES 10.0 ASSEMBLY OF COMPONENTS PH-50 & 75 ASSEMBLY Figure 9. PH-50 & 75 ASSEMBLY...
Page 21: Figure 10. Joint Hanger Installation
PH-SERIES 10.1 COMPONENT ASSEMBLY JOINT HANGER TO REFLECTOR (PH-50 & 75 MODELS) Figure 10. JOINT HANGER INSTALLATION...
Page 22: Figure 11. Clamp Coupler Installation
PH-SERIES CLAMP COUPLER (PH-50 & 75 MODELS) Figure 11. CLAMP COUPLER INSTALLATION END CAP TO REFLECTOR (PH-50 & 75 MODELS) Figure 12. END CAP INSTALLATION...
Page 23: Figure 13. 90° Elbow Kit Installation
PH-SERIES 90° ELBOW KIT (PH-50 & 75 MODELS) Figure 13. 90° ELBOW KIT INSTALLATION 180° U-BEND KIT (PH-50 & 75 MODELS) Figure 14. 180° U-BEND KIT INSTALLATION...
Page 24 PH-SERIES 11.0 VENTING REQUIREMENTS (UNVENTED APPLICATIONS: (All Models) This appliance shall only be used in a well vented space and shall not be used in a building, garage or any other enclosed or semi enclosed space unless the space conforms to the specifications under the sections titled: "FOR UNVENTED INSTALLATIONS IN SEMI ENCLOSED APPLICATIONS"...
Page 25 PH-SERIES FOR VENTED INSTALLTIONS: (For PH -4O, 50, 75, 80, 100 and 125 models only) WARNING: DO NOT ATTEMPT TO CONNECT ANY HO (HIGH OUTPUT) MODEL TO ANY VENTING. If adequate ventilation cannot be provided by the methods previously described under the heading "FOR UNVENTED INSTALLATIONS IN SEMI ENCLOSED APPLICATIONS", an approved chimney or sidewall venting system must be used.
Page 26 In North America (Canada and the USA) the SPECIAL VENTING method, as detail below, is approved as a Category III venting system for Calcana installations where venting is required. The venting system is to be provided by the installer. The use of readily available, single wall venting materials with a thickness no less than 26 gauge is to be used.
Page 27 PH-SERIES HORIZONTAL AND VERTICAL VENTING APPLICATIONS Venting of the unit must comply with the Installation Codes CAN/CGA-B149.1. In the USA, refer to NATIONAL FUEL CODE ANSI Z223.1/NFPA 54; current edition or local codes. Select exhaust point: A vent shall not terminate: a.
Page 28 PH-SERIES HORIZONTAL VENTING – SINGLE UNIT: For horizontal, sidewall venting a single unit, use 4" (10.16 cm) “B-Vent” equal to DuraVent PIN# 4GV36 in combination with a combustible wall thimble, a “B-vent” to “C-Vent” (single wall) adaptor equal to DuraVent PIN#4GVC, and HIGH WIND VENT TERMINAL equal to DuraVent PIN# 4GVVTH.
Page 29: Figure 15. Side Wall Venting, Single Unit
PH-SERIES ALTERNATIVELY, for models PH-40, PH-50, PH-75, installer can use material equal to Calcana 3” x 16 gauge sidewall vent kit PIN#800208, c/w 4” x 3” 16 gauge reducer. NOTE: MAKE SURE THAT ALL FLUE/EXHAUST JOINTS ARE SEALED. USE ONLY SUITABLE PRODUCTS EQUAL TO GENERAL ELECTRIC RTU 106 OR PERMATEX FORM A GASKET RED HIGH TEMPERATURE SILICONE ADHESIVE SEALANT.
Page 30: Figure 16. Vertical Venting, Single Unit
PH-SERIES ROOF EXHAUST – VERTICAL VENTING: Use 'B' style chimney. SIDE VIEW WARNING: MAKE SURE VENT CAP IS NOT OBSTRUCTED BY SNOW. ADJUST ACCORDINGLY. Figure 16. VERTICAL VENTING, SINGLE UNIT...
Page 31: Figure 17. Common Vertical Venting, Two Or More
PH-SERIES VERTICAL VENTING (CONTINUED) ROOF EXHAUST : TWO OR MORE UNITS - USE 'B' STYLE CHIMNEY. TWO OR MORE UNITS INTO A COMMON CHIMNEY – SIDE VIEW NOTE: For venting of two or more heaters into one common chimney, in Canada refer to the Natural Gas and Propane Installation Code, CSA B149.1 or latest edition and in the USA, the National Fuel Gas Code, ANSI Z223.1/NFPA 54 or latest edition.
Page 32 PH-SERIES Vent terminal must be installed at a height sufficient to prevent any blockage by snow. Protect building materials from any degradation that may be caused by flue gases. Support vent to prevent sagging. Make sure that all flue joints are sealed. Use only suitable products equal to General Electric RTU106 or Permatex Form a Gasket Red High Temperature Silicone Adhesive Sealant (not supplied).
Page 33 PH-SERIES 12.0 GAS PIPING WARNING: All gas work MUST be performed by qualified/licensed personnel with adequate training and experience in this field. WARNING: Use only the type of gas for which the heater is equipped. Using the wrong gas could create a hazard, resulting in damage, personal injury or death.
Page 34: Figure 18. Hard Pipe Installation
PH-SERIES 13.0 GAS CONNECTION HARD PIPE Figure 18. HARD PIPE INSTALLATION FLEX CONNECTOR WARNING: FIRE AND/OR EXPLOSION HAZARD Can cause properly damage, severe injury or death. With each firing cycle, the radiant pipe will expand and contract which can cause the burner head to move horizontally with reference to the gas supply line.
Page 35: Figure 19. Gas Line Connection With Certified Flexible
PH-SERIES CORRECT POSITIONS INCORRECT POSITIONS WARNING: CONNECTOR MUST BE INSTALLED AS PER THE CONFIGURATION ILLUSTRATED ABOVE. USE ONLY THE 36" (90 cm) CONNECTOR OF ½" (1.27 cm) NOMINAL ID FOR LENGTHS FROM 10' (3m) TO 70' (21.3 m) AND A 36" (90 cm) CONNECTOR OF ¾" (1.905 cm) NOMINAL ID FOR LENGTHS GREATER THAN 70' (21.3m). IN CANADA: "A radiant tube-type infrared heater shall only be connected with a Type 1 hose connector that is (a) certified as being in compliance with the Standard for Elastomeric Composite Hose and Hose couplings for Conducting Propane and Natural Gas, CAN/CGA 8.1 and (b) of a length of 36 +/- 6"...
Page 36: Figure 20. Electrical Connections 120 Volt
PH-SERIES 14.0 ELECTRICAL CONNECTION 120 VOLTS Refer to rating plate on heater for electrical specifications. Supply adequate grounded electrical power supply to heater via watertight, outdoor rated electrical wiring. Fasten ground wire to grounding lug on frame of burner head and connect 120 volts to the black and white pigtail wires from the transformer.
Page 37: Figure 21. Wiring Diagram 120 Volt
PH-SERIES 14.1 120 VOLT WIRING DIAGRAM MODELS PH-40, 50, 75, 80, 100 and 125 ONLY: THERMOSTAT CONNECTION: USE THERMOSTAT EQUAL TO: HONEY WELL LINE VOLTAGE MODEL T4098A or T410A. INSTALLED SUCH THAT THE THERMOSTAT CONTROLS THE VOLTAGE BEING SUPPLIED TO THE UNIT. Figure 21.
Page 38: Figure 22. Electrical Connections 24 Volt
PH-SERIES 15.0 ELECTRICAL CONNECTION 24 VOLT (ALTERNATE POWER SUPPLY) 1) Locate 24 VAC volt transformer near 120 volt source. 2) Supply wire from transformer to heater must have adequate capacity and insulation temperature ratings for total connected load. Use 18 gauge wire from transformer to heater for distances up to 50 feet.
Page 39: Figure 23. Wiring Diagram 24 Volt
PH-SERIES 15.1 24 VOLT WIRING DIAGRAM MODELS PH-40, 50, 75, 80, 100, and 125 ONLY: THERMOSTAT CONNECTION: USE THERMOSTAT EQUAL TO: HONEY WELL LINE VOLTAGE MODEL T4098A or T410A. INSTALLED SUCH THAT THE THERMOSTAT CONTROLS THE VOLTAGE BEING SUPPLIED TO THE UNIT. Figure 23.
Page 40 PH-SERIES 16.0 INITIAL START-UP WARNING: DO NOT ATTEMPT TO IGNITE HEATER BY HAND!! IMPORTANT NOTICE: This heater is not to be used as a construction heater to supply heat to an unfinished building during the finishing phases of Construction. This practice exposes the unit to an abnormally corrosive atmosphere from sources such as paint, varnish and adhesives, which can lead to premature radiant tube exchanger or vent failure.
Page 41: Figure 24. Gas Valve
FAILURE TO DO SO WILL VOID ALL WARRANTIES AND MAY CAUSE DAMAGE, INJURY AND/OR DEATH. IF YOU HAVE ANY QUESTIONS CONCERNING THESE INSTRUCTIONS, CALL CALCANA AT 800-778-6729 BEFORE YOU VERIFY No one should work on or install this heater unless AND/OR ADJUST THE MANIFOLD FUEL PRESSURE ON THE HEATER.
Page 42 PH-SERIES START BY opening the service door and identifying the location of the gas valve and the modulator. Remove the black plastic cap from the adjustment tower. Service Door Black Plastic Cap Adjustment Tower 1of 3 Locate manifold pressure tap. Open the manifold pressure tap by using a small flathead screwdriver to turn the screw inside the brass fitting counterclockwise 3 turns.
Page 43 PH-SERIES FOR LOW PRESSURE VERIFICATION and/or ADJUSTMENT: CAUTION: Always adjust low pressure setting first since the low setting will affect the high setting. Remove the electrical connection from the modulator. (Brown and White Wires) Start the heater and take a pressure reading. The manifold pressure required on the low setting for natural gas is 1.25 “W.C.
Page 44 PH-SERIES 12) Start heater and take a pressure reading. For natural gas, manifold pressure should be 3.5 “ W.C. on high. For liquefied petroleum gas, manifold pressure should be 10.5” W.C. on high. 13) If adjustment is needed, insert a 2mm allen wrench into the adjustment tower and turn clockwise to lower pressure and counterclockwise to increase pressure.
Page 45 PH-SERIES 17.0 GAS INPUT RATE WARNING: Natural gas heating values can vary widely. It is the responsibility of the Installer to make sure that the input rate to the heater as installed does not exceed the nameplate rating of the heater. Failure to do so can cause radiant tube failure, resulting in injury or death.
Page 46 PH-SERIES 18.0 SEQUENCE OPERATION 18.1 DESCRIPTION OF 3-TRY DIRECT SPARK IGNITION SYSTEM: The TRITON 2461D is a 24 VAC Microprocessor Based Direct Spark Ignition Control designed for use in all types of heating applications such as gas furnaces, boilers, water heaters and other similar appliances: The control utilizes a microprocessor to continually and safely monitor, analyze and control the proper operation of the gas burner.
Page 47 PH-SERIES 19.0 TROUBLESHOOTING NO POWER TO HEATER CAUTION: Prior to performing any service or maintenance work on the unit: a) disconnect the electrical supply b) shut off gas to supply unit c) make sure unit has cooled down before opening service panel Warning: Only allow qualified, licensed, service people trained to service gas fired heating equipment to perform any repairs on this unit.
Page 48 PH-SERIES INITIAL GAS CHECKS a) Make sure manual valve is turned on. b) Make sure gas valve knob is turned on. c) Check for gas supply and proper pressure to valve. d) Check wires and make sure that they and their connections are in g ood condition. e) Check for power to valve.
Page 49 PH-SERIES CHECK CONTROL BOARD Open access door and view the diagnostic red LED, located on the grey direct spark ignition module. FAULT CONDITIONS Error Mode LED Indication Internal Control Failure Steady On Air Flow Fault 1 flash Flame with No Call for Heat 2 flashes Ignition Lock Out 3 flashes...
Page 50: Figure 25. Flame Sensor Current Check
PH-SERIES FLAME WITH NO CALL FOR HEAT (FLAME FAULT) • If at any time the main valve fails to close completely and maintains a flame, the full time flame sense circuit will detect it and energize the combustion blower. Should the main valve later close off completely removing the flame signal, the combustion blower will power off.
Page 51: Figure 26. Proper Electrode Location
PH-SERIES PROPER ELECTRODE LOCATION Proper location of the electrode assembly is important for optimum system performance. The electrode assembly should be located so that the tips are inside the flame envelope about ¾” (1.9 cm) to 1” (2.54 cm). CAUTIONS: 1) Ceramic insulators should not be in or close to the flame 2) Electrode assemblies should not be adjusted or disassembled, Electrodes should have a gap spacing of .125"...
Page 52 PH-SERIES 20.0 MAINTENANCE Maintenance is required once a year. Annually inspect your heater, before the heating season starts. If unit is in a dusty environment, maintenance will be required more often. If dust conditions are extreme, monthly or weekly maintenance may be required. WARNING: Disconnect electrical supply to heater and shutoff gas prior to inspection.
Page 53: Figure 27. Burner Head Parts
PH-SERIES 21.0 PARTS: 21.1 BURNER HEAD AND RELATED PARTS (Refer to pages 51 & 47 for part number & description) Figure 27. BURNER HEAD PARTS...
Page 54: Figure 28. Reflector And Tube Parts
PH-SERIES 21.2 REFLECTOR AND TUBE PARTS (Refer to page 51 & 47 for part number & description) Figure 28. REFLECTOR AND TUBE PARTS...
Page 55 PH-SERIES 21.3 PARTS LIST: (See page 49 & 50 for visual details) REPLACEMENT BURNER HEADS: ITEM INPUT FUEL WEIGHT 5120000 PH-40 32 lbs (36 kg) 5120001 PH-40 Propane 32 lbs (36 kg) 5120002 PH-50 32 lbs (36 kg) 5120003 PH-50 Propane 32 lbs (36 kg) 5120004...
Page 56 PH-SERIES REFLECTOR COMPONENTS: ITEM DESCRIPTION WEIGHT 5120034 PH Bulkhead SS 5 lbs (2.3 kg) 5120033 PH End Cap SS Exhaust 5 lbs (2.3 kg) 5120040 PH - 50 & 75 Hanger Assembly 5 lbs (2.3 kg) 5180161 Reflector 5' (1.53m) 10 lbs (4.54 kg) 5180162 Reflector 10' (3m)
Page 57 (1) Shipment to the Manufacturer of that part of the Product year from date of shipment from the factory. Calcana further thought to be defective. Goods can only be returned with warrants that the heat exchanger, reflectors, brackets, prior written approval of the Manufacturer.
Page 58 CONVERSION KITS ARE FOR UNITS RATED FOR THE FOLLOWING LOCATIONS AND ELEVATIONS: CANADA: 0 – 4500 FT (1372 m) FOR INSTALLATIONS ABOVE THE DESIGNATED ELEVATIONS, CONTACT FACTORY. USA: 0 – 2000 FT (610 m) Calcana USA Ltd. 30201 Country Road 49 Loxley, AL. 36551 Tel: 251-964-4400...
Page 59 PH-SERIES BURNER AND GAS ORIFICE LOCATION...
Page 60 PH-SERIES 24.0 EXAMPLE OF CONVERSION KIT LABEL TO BE COMPLETED AS PER INSTRUCTIONS IN KIT This appliance was converted on DAY: _______________ MONTH: ________________YEAR: ___________________ _____Propane. ______ with _______________ by: NAME: _______________________________________ COMPANY: ______________________________________ ADDRESS: _______________________________________ CITY/TOWN: __________________ STATE/PRO: ________ TELEPHONE: _____________________________________ Orifice Size: _______ leak Test Performed: Yes: _______ Manifold Pressure: Min____________ Max____________...
Page 61 PH-SERIES 25.0 SAFETY AND OPERATING INSTRUCTIONS ! WARNING: ! Failure to follow these instructions will cause death, personal injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. SAFETY INSTRUCTIONS OPERATING READ BEFORE OPERATING INSTRUCTIONS 1.
