FM04US Rev. 4
ULTRAMAGIC FLIGHT MANUAL SUPPLEMENT 39
39.1
GENERAL INFORMATION
This supplement details the instructions and limitations necessary to ensure the
safe operation, maintenance and continued airworthiness of CT-01 and CT-02
Ultramagic 'Tekno' Baskets.
The section indexes on this supplement are preceded with the §39.X, and the
suffix is kept in line with the Ultramagic Flight Manual. The content of this
supplement replaces or appends the information contained on the Flight Manual
for the balloon or parts to which this supplement is intended.
39.2
OPERATIONAL LIMITATIONS
The following limitations are additional to those already stated in the Flight
Manual.
39.2.3.1 Acceptable Damage
Add the following:
Damages or cuts on the fabric walls are allowed unless the consistency of the
walls is jeopardized or holes larger than 5 cm diameter are present.
No cracks or damages are allowed on the steel structure.
Any crack longer than 15 cm and 3 mm depth (two cross-banded veneers) or
more in the plywood floor is not allowed.
39.2.4
Amend point 1:
39.2.6
Applicable loading parameters are listed on section 39.5 of this supplement.
39.2.7
HOT AIR BALLOON FLIGHT MANUAL
U L T R A M A G I C , S . A
ULTRAMAGIC 'TEKNO' BASKETS
Minimum Equipment
1 kg (2.2 lb) dry powder fire extinguisher conforming to EN3
or equivalent (ANSI/UL711)
Crew
SUPPLEMENT 39, Issue 4
p a g e 1 of 8
Advertisement
Table of Contents
Summary of Contents for Ultramagic CT-01
- Page 1 Ultramagic ‘Tekno’ Baskets. The section indexes on this supplement are preceded with the §39.X, and the suffix is kept in line with the Ultramagic Flight Manual. The content of this supplement replaces or appends the information contained on the Flight Manual for the balloon or parts to which this supplement is intended.
- Page 2 FM04US Rev. 4 U L T R A M A G I C , S . A p a g e 2 of 8 Maximum number of occupants is described on section 39.D. 39.2.13 Fuel cylinders For cylinders installed inside the basket, the cross-harness supplied must be fitted to each cylinder.
- Page 3 FM04US Rev. 4 U L T R A M A G I C , S . A p a g e 3 of 8 Figure 2 – Cylinder installation outside the basket (optional fitting - accessory) 39.2.14 Tethered Flight Tethered flight is not allowed if the wind speed on the surface is above 10 knots (5 m/s or 18.5 km/h).
- Page 4 A single stainless steel karabiner with working load of 900 kg (1984 lb) may be used on each corner of the burner frame to attach the flying wires from the envelope. Those karabiners shall be properly engraved and must be supplied or approved by Ultramagic. 39.4.5.5 Mounting the ‘Tekno’ Basket The ‘Tekno’...
- Page 5 NOTE: Observe the limitations listed on 39.2.13. Information regarding the assembly or removal of the external support brackets may be found in Supplement 18 to the Ultramagic Maintenance Manual. 39.4.11.6 Folding the ‘Tekno’ Basket To fold the basket after flight, proceed in reverse order of the steps in 39.4.5.5.
- Page 6 Pv = Empty weight (without any cylinder) [Kg/lb] Lmax = Maximum authorised Lift [Kg/lb] 39.5.4 Table of Compatibility Envelopes listed on 39.5.2 are considered compatible with the CT-01 and CT-02 ‘Tekno’ Baskets. ‘Tekno’ basket is approved for flight using the following burners: ·...
- Page 7 U L T R A M A G I C , S . A p a g e 7 of 8 39.6 BALLOON AND SYSTEMS DESCRIPTION 39.6.3 Dimensions and Weights See following table corresponding to mass and dimensions: CT-02 BASKET CT-01 1,2/3,9 Length* (m/ft) 1,0/3,3 1,0/3,3 Width (m/ft) 0,8/2,6 1,1/3,6...
- Page 8 FM04US Rev. 4 U L T R A M A G I C , S . A p a g e 8 of 8 39.D MINIMUM BASKET SPACE REQUIREMENTS Consider the following table Basket Specs. Capacity Cylinders Cylinders Maximum Inside Outside* Occupants Up to 4...
