It is a prerequisite
for commissioning
this equipment
that you have read,
understood and accepted
the entire contents
of these operating instructions.
Identification
0123
EN 795 B and according EN 355
Inspection site: TÜV Produkt Service GmbH
Ridlerstraße 65, D-80339 München
PPE (Personal Protective Equipment)
Adjustable attachment accessoires with pulley
Hubert Kowalewski e.K.
In den Sennen 19
D-32369 Rahden-Wehe
ENGLISH
ROPEGUIDE 2010
Patented
<14mm, EN 1891
> 23 kN
telephone 0049.5771.4827
facsimile 0049.5771.608782
www.climb-ART.com
15
ZIP-
Absorber
OK
2 kN
Advertisement
Table of Contents
Summary of Contents for Art ROPEGUIDE 2010
- Page 1 ENGLISH ROPEGUIDE 2010 Patented ZIP- Absorber It is a prerequisite for commissioning this equipment that you have read, understood and accepted the entire contents of these operating instructions. <14mm, EN 1891 Identification 0123 EN 795 B and according EN 355 Inspection site: TÜV Produkt Service GmbH...
- Page 2 Ropeguide 2010:...
- Page 3 Ropeguide 2010: Body of equipment Friction clutch Spring Bearing bolts Cover Safety Screw 4-6 Nm / 35,5-53 IN-Lbs ZIP-ABSORBER 1 Bushing Screw 3-4 Nm / 26,5-35,5 IN-Lbs TRAPEZE 3 COCOON 2 O-Ring (yellow) O-Ring (black) Screw cap Bearing bolt...
- Page 4 Hubert Kowalewski e.K. does not assume any responsibility or liability in the case of: - damage arising in any way in connection with the application of ART products. - slight, serious and lethal injury of the user or persons indirectly or directly involved in the occurrence which can be in any way attributed to non-compliance with these operating instructions.
- Page 5 ART component design Since the essential parts of ART devices are replaceable, the user can renew damaged or worn elements. The precise position, name and attachment can be taken from the exploded assembly drawing and the description attached to the respective spare part. Every replacement of device components must be documented.
- Page 6 info art4trees.de Components which comprise several individual parts, but which are depicted as a whole in the exploded assembly drawing, may not be disassembled by the user. Screw connections provided with a coloured seal may not be unscrewed by the user. If the equipment begins to slip in the blocked position, the friction clutch must be replaced.
- Page 7 - at least one second trained climber must be visible and within earshot at all times. Climatic factors All ART equipment may only be deployed at ambient temperatures of -30° C to +40°C. This applies for reasons of personal protection alone.
- Page 8 info art4trees.de The attachment point (tree, part of a building, girder, scaffolding etc.) for the rope system must demonstrate a minimum load capacity of 10 kN. Following professional ascension and application of a correct short safety line the attachment device must be placed such that it is permanently positioned above the climber.
