Bahia CURVE BUS kitchen
DESCRIPTION
• Humidity-controlled kitchen grille suitable for Aldes
residential HRV units (Modulo, Dee Fly Cube, etc.).
• Bahia Curve L grille, model C13.
• Control addition airflow in kitchen and Boost
airflow.
• Features a Ø125 mm barrel with Roll-In seal.
• Pressure range: 80-160 Pa.
INSTALLATION
• Fixed in place by slotting into a sleeve. Leak
tightness and attachment to wall or ceiling
guaranteed by Roll-In seal.
• BUS electrical connection to HRV unit (control and
power supply).
• Possible to connect to kitchen push-button for
local control.
RANGE
Reference
Bahia Curve grille BUS C13 Kitchen
DIMENSIONS (mm)
Code
11015490
AERAULIC DETAILS
C13 CURVE BUS
163
90.8
48.8
Min. airflow (m
/h)
3
20-60
36-76%
Boost airflow
% RH
(m
/h)
3
135
