Summary of Contents for PXM PX723
- Page 1 PX723 Keyboard 8 User manual...
-
Page 2: Table Of Contents
4 Device operation..................6 5 Connection scheme...................7 6 Dimensions....................8 7 Technical data.....................9 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-1 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
PX340. It is possible to create the system of additional inputs for the controllers PX710M and PX340, which include the devices PX723 and PX734. Px723 expands the system by 8 digital inputs in the from of touch buttons and PX734 expands it by one analogue input and one digital input (the movement sensor and the analogue light sensor). -
Page 4: Safety Conditions
Safety conditions PX723 is a device powered with safe voltage 12 – 24V DC, however, during its installation and use the following rules must be strictly observed: 1. The device can be connected to 12 – 24V DC with current-carrying capacity compatible with technical data. -
Page 5: Connectors And Control Elements
Connectors and control elements communication input with PX725 connector for communication with PX725 PX723 connecting tape with PX725 numery przycisków button numbers... -
Page 6: Device Operation
Device operation Owing to the keypad PX723, can be expand the operation of the system by eight additional digital inputs which are programmed with use of the PxDesigner application. Each button generates two events in the controller: from turning on and from turning off. -
Page 7: Connection Scheme
RX+ RX- TX+ TX- VCK+ SYNC REMOTE 1 2 3 4 6 7 8 10 11 12 14 15 16 0-10V OUT 0-10V IN controller e.g PX710M PX723 Keyboard 8 for next keypads (max. 32) PX734 Light & Movement Sensor... -
Page 8: Dimensions
Dimensions drawing of the keypad without the mounting plate drawing of the keypad drawing the mounting plate with the mounting plate... -
Page 9: Technical Data
Technical data type PX723 power supply PX725 bus number of the buttons LED diodes cooperation with the controllers PX710M, PX340 method of communication with the controller with the use of PX725 Keyboard Hub maximum number of the devices 64 (max. 32 for one line PX725) - Page 10 Podłęże, 03.04.2019 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: Keyboard 8 Product code: PX723 meets the requirements of the following standards, as well as harmonised standards: PN-EN IEC 63000:2019-01...
