MICROENER EMS-96 User Manual

Electrical measurement supervisor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EMS-96
Electrical Measurement Supervisor
User Manual
FDE 13JMC3520859 rev A2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMS-96 and is the answer not in the manual?

Questions and answers

Summary of Contents for MICROENER EMS-96

  • Page 1 EMS-96 Electrical Measurement Supervisor User Manual FDE 13JMC3520859 rev A2...
  • Page 2 FDE N° User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 2 / 51 EMS-96 MANAGEMENT OF MODIFICATIONS Created Checked Approved Rev. Description Date First issue 2013/18/12...

  • Page 3: Table Of Contents

    EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 3 / 51 EMS-96 SOMMAIRE GENERALITY ............................ 4 Terms of warranty ..........................4 Description ............................5 Configuration Models......................... 5 Software Options ..........................5 Measures Table ..........................

  • Page 4: Generality

    Rév. UPERVISOR Fax : 01 43 05 08 24 Page 4 / 51 EMS-96 GENERALITY Information in this document is subject to change without notice and does not represent a commitment on the part of Contrel Elettronica Srl. This documentation is consigned to the customer to enable the correct and safe operation of the instrument;...

  • Page 5: Description

    UPERVISOR Fax : 01 43 05 08 24 Page 5 / 51 EMS-96 DESCRIPTION The EMS (Electrical Measurement Supervisor) has advanced analysis functions that allow the measurement of the main electrical parameters: voltage, current, frequency, power factor, active and reactive power, active and reactive energy.

  • Page 6: Measures Table

    FDE N° User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 6 / 51 EMS-96 Measures Table Min-Max Min-Max Parameters System Average Relative Absolute Demand Voltage L-N...

  • Page 7: Installation

    Rév. UPERVISOR Fax : 01 43 05 08 24 Page 7 / 51 EMS-96 INSTALLATION Warning for the user Read carefully the instructions/indications contained in this manual before installing and using the instrument. The instrument described in this manual is intended for use by properly trained staff only.

  • Page 8: Connections

    FDE N° User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 8 / 51 EMS-96 CONNECTIONS Do8- Di1- Do8+ Di1+ Do7- Di2- Do7+ Di2+ SERVICE Do6- Di3-...

  • Page 9: Voltage Inputs

    Rév. UPERVISOR Fax : 01 43 05 08 24 Page 9 / 51 EMS-96 Voltage Inputs 4 terminals are available for direct connection to 3 phase network with neutral. In case of a 3 phase  balanced system without neutral, or non distributed neutral to leave terminal N free.

  • Page 10: Current Inputs

    UPERVISOR Fax : 01 43 05 08 24 Page 10 / 51 EMS-96 Current Inputs Current measurements can be performed by connecting the terminals of Current inputs. All current inputs are isolated by current transformers with different ranges depending on the model of the instrument.

  • Page 11: Serial Ports (Option)

    Rév. UPERVISOR Fax : 01 43 05 08 24 Page 11 / 51 EMS-96 Serial ports (option) Depending on the version, the instrument can be equipped with one or two isolated half duplex RS485 serial interface. Two options are available: 1 serial port RS485 ...

  • Page 12: Digital Outputs

    LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 12 / 51 EMS-96 Digital Outputs Do1- Do1+ Do2- Do2+ 2 pulse / state digital outputs are available on the device.

  • Page 13: Digital Inputs (Option)

    Rév. UPERVISOR Fax : 01 43 05 08 24 Page 13 / 51 EMS-96 Digital Inputs (option) The EMS can be equipped with isolated Digital Inputs. The Digital Inputs are available only with the relative option. The technical feature are: number of Digital Input: 2 or 4 depending on the option version;...

  • Page 14: Digital Outputs (Option)

    FDE N° User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 14 / 51 EMS-96 6 digital outputs (option) Do8- Do8+ Do7- Do7+ Do6- Do6+ Do5- Do5+...

  • Page 15: Digital Inputs, 4 Digital Outputs (Option)

    User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 15 / 51 EMS-96 2 digital inputs, 4 digital outputs (option) Di1- Di1+ Di2- Di2+ Do6- Do6+ Do5-...

  • Page 16: Wiring Diagrams

    LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 16 / 51 EMS-96 WIRING DIAGRAMS Three-Phase, 4-Wires Y Configuration In case of connection in a 3 phase network (without neutral or with neutral not distributed) don’t connect...
  • Page 17 Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 17 / 51 EMS-96 Three-Phase, balanced loads, 4-Wires Configuration This connection can be used with distributed and equal loads. It is possible to measure the...
  • Page 18 EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 18 / 51 EMS-96 Single-Phase, 2-Wires Configuration It is mandatory to connect the current input I1 and voltage input VL1. LOAD Single-Phase, 3 multiple loads in the same network, 2-Wires Configuration...
  • Page 19 Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 19 / 51 EMS-96 Multiple Single-Phase, 3 multiple loads in 3 different networks, 6-Wires Configuration If necessary to apply a multiplier factor “K” to adapt...
  • Page 20 User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 20 / 51 EMS-96 Digital I/O and Serial communication Master Controller 12÷230 12÷230 24, 48, Concentrator Vac/dc Vac/dc...

  • Page 21: Function Keys

    Rév. UPERVISOR Fax : 01 43 05 08 24 Page 21 / 51 EMS-96 FUNCTION KEYS Directional keys (Up/Down/Left/Right) The directional keys are used to change the pages in Measures, Graphics, Info Device e Setup. In the next chapters the maps show how to move between pages. At the same time the directional keys allow to move and select items inside the Menu.

  • Page 22: Menu Map

    FDE N° User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 22 / 51 EMS-96 MENU MAP Menu Measures Instantaneous Voltages Measures Instantaneous Voltages Phase‐Neutral Graphics Phase‐Phase...
  • Page 23 UPERVISOR Fax : 01 43 05 08 24 Page 23 / 51 EMS-96 : This item is selectable only with the presence of relative option. To move inside the menu it’s necessary to use the directional keys. The arrow near the items indicates the presence of submenu (with right or enter key it’s possible to enter).

  • Page 24: Measures Pages Map

    UPERVISOR Fax : 01 43 05 08 24 Page 24 / 51 EMS-96 MEASURES PAGES MAP The default page showed at the power on is “Phase Voltage”. It’s possible to change it using the keys (left and right pressed at the same time).
  • Page 25 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 25 / 51 EMS-96 SAG (1‐5) Active Power Timeband 1 Timeband 2 Timeband 16 Max Demand Reactive Power Timeband 1...

  • Page 26: Graphics Map

    User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 26 / 51 EMS-96 GRAPHICS MAP Voltages Trend Voltages Trend Help Zoom Currents Trend Currents Trend Help Zoom...

  • Page 27: Device Map

    User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 27 / 51 EMS-96 DEVICE MAP Info Device Digital I/O Status Help Setpoint Setpoint 1 Setpoint 2 Setpoint 16...

  • Page 28: Setup Pages Map

    UPERVISOR Fax : 01 43 05 08 24 Page 28 / 51 EMS-96 SETUP PAGES MAP To move inside the Setup pages it’s necessary to use left and the right keys. Press the Enter key to go to see the item to set.

  • Page 29: Setup Items

    LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 29 / 51 EMS-96 SETUP ITEMS Password Range Default Access key 0 ÷ 999999999 The code to enter to modify the setup.
  • Page 30 User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 30 / 51 EMS-96 Date / Time Range Default Hour 0 ÷ 23 Actual hour. Minute 0 ÷ 59 Actual minutes.
  • Page 31 EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 31 / 51 EMS-96 SAG (option) Range Default Threshold [RMS voltage] 30 ÷ 400 If the voltage value drops below the setting, the software considers the event as SAG.

  • Page 32: Wiring Parameters

    LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 32 / 51 EMS-96 WIRING PARAMETERS Description Wiring SYSTEM VOLTAGE PHASE VOLTAGE L PHASE VOLTAGE L PHASE VOLTAGE L LINE TO LINE VOLTAGE L...
  • Page 33 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 33 / 51 EMS-96 calculated SYSTEM REACTIVE ENERGY IN SYSTEM REACTIVE ENERGY OUT calculated calculated SYSTEM APPARENT ENERGY ACTIVE ENERGY IN L...
  • Page 34 EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 34 / 51 EMS-96 DO-1, 2, 3, 4 (pulse/state outputs) Range Default Status On or Off DO-1, DO-2, DO-3, DO-4: select ON to close the output, OFF to open it.
  • Page 35 EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 35 / 51 EMS-96 Setpoint XX (from 1 to 16) Range Default Enable Yes or No Enable or disable the setpoint function.
  • Page 36 Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 36 / 51 EMS-96 Logic operation entry See below Disabled - No logic: the Action is executed without to verify the status of others setpoint [Default].
  • Page 37 FDE N° User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 37 / 51 EMS-96 Setpoint explanation: Thrend Measure Debounce High (Sec) DO ACTION High Threshold Hysteresis...
  • Page 38 FDE N° User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 38 / 51 EMS-96 Setpoint logic explanation: Thrend Debounce Measure Threeshold Debounce Threeshold Debounce Threeshold State Set Point 1...
  • Page 39 User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 39 / 51 EMS-96 COM1 and COM2 (option) Range Default Mode Slave or Master Slave Slave connected 1 ÷247 Number of slave connected in master mode.
  • Page 40 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 40 / 51 EMS-96 M-Bus (option) Range Default Address [node] 0 ÷ 250 Instrument identifier on the M-BUS network. 300 – 600 – 1200 – 2400 - 4800 – 9600 –...
  • Page 41 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 41 / 51 EMS-96 Daily Plan XX (from 1 to 16) Range Default (option) Start Hour 1 00 ÷ 23 Hour at which the timeband will be changed.
  • Page 42 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 42 / 51 EMS-96 Holiday (option) Range Default Month Holiday 1 January ÷ December January Month in which the holiday is present.
  • Page 43 EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 43 / 51 EMS-96 Display Range Default Return default page [min] 1 ÷ 30 After this time the instrument comes back to default page.
  • Page 44 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 44 / 51 EMS-96 Table of the displayable pages in the Change page mode Measure Graphics voltages frequency user page 1...
  • Page 45 EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 45 / 51 EMS-96 Preset Total Energies Range Default Wh IN [0.1kWh] 0÷1000000000 Value to add at the actual system active energy IN counter.
  • Page 46 EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 46 / 51 EMS-96 User Page XX (from 01 to 04) Range Default Row 1 – Group See Acronym Group table Instantaneous Selection of the group for the 1 measure on the User Page XX.
  • Page 47 EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 47 / 51 EMS-96 Generic Log (option) Range Default Log read 1 ÷ X The value set is the number of the log that is read.

  • Page 48: Acronym Tables

    User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 48 / 51 EMS-96 ACRONYM TABLES Acronyms group table Acronym Acronym Acronym Instantaneous Energies TB‐6 Energies TB‐13 Energies Energies TB‐7...

  • Page 49: Acronyms Table Of Average Group

    User Manual 13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 49 / 51 EMS-96 Acronyms table of Average group Acronym Explanation Acronym Explanation Acronym Explanation Average Reactive Power...

  • Page 50: Technical Features

    13JMC3520859 LECTRICAL EASUREMENT Tél : 01 48 15 09 09 Rév. UPERVISOR Fax : 01 43 05 08 24 Page 50 / 51 EMS-96 TECHNICAL FEATURES Auxiliary power supply Voltage range 90÷250 Vac/dc 24÷48 Vac/dc Frequency range 50/60 Hz Protection fuse...
  • Page 51 EMISSIONS = EN 50081-2, 1992 - EN 55022-CLASS B CISPR 22 IMMUNITY = EN 50082-1, 1992 - EN 61000-6-2 SAFETY = EN 61010-2 Les performances et les caractéristiques indiquées dans ce document peuvent être modifiées à tout moment et n’engagent MicroEner qu’après confirmation. http://www.microener.com...
