Summary of Contents for VESTEL ADB-6307
- Page 2 Dear Customer, First of all, we congratulate you for preferring a nature and technology friendly VESTEL product. This user manual is intended to guide you in using your equipment, and you will acknowledge th at your equipment has the most advanced technological solutions and that it is quite to use it. If you show due care and perform necessary maintenance, your equipment will serve you for long years. We wish you get pleasure while using your equipment. Important Safety-Related Information • Please read the instructions in this manual carefully to know your device quickly and make use of all the functions of your device. • Always keep this user manual closely to your appliance. Give this user manual along with your appliance when you lend it. • WARNING: Read this user manual carefully before starting to use your appliance to be able to prevent risks of dangerous situations, fire, electric shock and personal injury. Follow the instructions at all times. • Assembly of the appliance must be performed by Vestel Authorized Service. • Appliance must be grounded. RISK OF ELECTRIC SHOCK: Dangerous voltage. CAUTION: Risk of injury or damage to properties. WARNING: Risk of serious injury or death.
-
Page 3: Table Of Contents
Table of Contents 1 Pre-Assembly Safety Rules ..........4 2 Technical Specifications ..........6 3 General Appearance ...........7 4 Assembly of Appliance ..........8 5 Operation ............11 6 Cleaning and Maintenance ..........12 7 Replacement Of Lamps ..........12 8 Troubleshooting ........... . .13... -
Page 4: Pre-Assembly Safety Rules
1 Pre-Assembly Safety Rules • Follow the instructions in this manual. Vestel cannot be held liable for accidents, damages or • Assembly and electric connection must be fire that might occur as a result of failure to follow performed by authorized people. the instructions in this manual. User manual is an • Call the nearest Authorized Service in case of... - Page 5 Safety Information to Be Considered During Cleaning and Maintenance • The cable of the appliance must be disconnected or the fuse must be turned off prior to all cleaning and maintenance processes. • Appliance shouldn't be cleaned with steam cleaning devices. • The fire risk gets higher due to oil deposit if cleaning and maintenance are not performed. Therefore, get your appliance cleaned and maintained regularly. • Repairing should be done by technical service personnel. Efficient Ventilation In order to allow for ventilation properly, windows that open outwards in the kitchen must be kept closed. In...
-
Page 6: Technical Specifications
2 Technical Specifications ADB-6307 COOKER HOOD ADB-9307 COOKER HOOD ADW-6307 COOKER HOOD Model ADV-6307 COOKER HOOD Supply Voltage 220-240 V 50Hz Lamp Power (W) 2 x 3 W Motor Power (W) 210 W Flow Rate (m /h) Insulation Class This product complies with the 2014/30/ • Specifications of the device and this manual may EU (Regulation on Electromagnetic be modified without prior notification. Compliance) and 2014/35/EU (Regulation • Complies with the AEEE Regulation. on Low Voltage Devices (LVD)) Directives. This device complies with the Directive on the Control of Waste Electrical and Consumer Services Electronic Equipment. -
Page 7: General Appearance
3 General Appearance Figure 1 Figure 2 Dimensions given in technical drawings are in mm. 1. Inner Flue 2. Outer Flue The purpose of this image is to inform you about 3. Front Panel the parts of your appliance. The parts may vary 4. Aluminium Filter depending on the model of the appliance. Images 5. Cooker Lighting are symbolic. 6. Control Panel Position of Cooker Hood Distance between the cooker and the cooker hood must be considered prior to assembly. This distance must be 65 cm for electric cookers and 70 cm for gas cookers. -
Page 8: Assembly Of Appliance
4 Assembly of Appliance Figure 4 : Installation Diagram and Components 1. Inner Flue 6. 2x 3.9x22 Screw 2. Outer Flue 7. Flue Connection Plate 3. 2x M5x35 Screw 8. 2x Ø6mm Plastic Dowel 4. Product Hanging Plate 9. 3x 5.5x60 Wall Mount Screw 5. - Page 9 Assembly of Air Discharge Outlet 1. Ø150/120 mm Flue Adapter (Option) 2. 2x 3.5x9.5 Screw 3. Ø120/150 mm Plastic Flue 4. Body • Attach the plastic flue (3) to the product's body (Figure 5). • Connect the flue adapter (1) to the plastic flue when required.
- Page 10 Assembly of Flues • The outer and inner sheet metal flues (Figure 4) are encased one within the other. For this purpose; • The cooker hood is set in the midst, and then the flue connecting plate (8) is directly affixed to the wall, under the cover or points D and E are marked after performing a measurement (Figure 4). • Drill points D and E with Ø6mm drill bit, and insert Ø6mm and plastic dowels (9). Insert the flue connection plate with 3.9x22 screws (7) (Figure 4). • Install the External Flue to the cooker hood. Secure the inner flue (1) to the flue connection plate (3) with a screw (Figure 6). Figure 6 : Installation of the Sheet Metal Flue 1. Inner Flue 2. Flue Fixing Screws 3. Flue Connection Plate...
-
Page 11: Operation
5 Operation 1. Press this button to turn on or off the lamp. 2. When this button is pressed, product will operate at speed level 1. 3. When this button is pressed, product will operate at speed level 2. 4. When this button is pressed, product will operate at speed level 3. NOTE: To activate timer function, press and hold any of buttons 1,2 and 3 for 3 seconds. Then, 15 minute timer function will be activated and the product will turn off automatically after 15 minutes. All active functions operated prior to activation of timer function will be deactivated after 15 minutes. All active functions operated after acti- vation of timer function will be reactivated after 15 minutes. -
Page 12: Cleaning And Maintenance
6 Cleaning and Maintenance WARNING: Ensure that the appliance is Submerge the aluminium filter in hot water with dish unplugged or fuse is turned off before all cleaning detergent and wait for some time; then clean with and maintenance operations. a soft brush. Rinse with hot water after cleaning. Repeat this operation if necessary. You can wash the aluminium filter in dishwasher on normal program A) Cleaning and Maintenance Time Hood must be cleaned and maintained at regular... -
Page 13: Troubleshooting
8 Troubleshooting When you observe an abnormal condition in your appliance, you might try to solve the problem in line with the explanations in the table. If your appliance still doesn't operate, contact Vestel Customer Contact or the nearest Vestel Authorized Service. Do not try to repair your appliance yourself. You can find authorized services list and contact information from the web site. PROBLEM CAUSE SOLUTION It is not plugged properly. Plug it tightly. There's no power in the socket. Check the fuse and the socket. Appliance doesn't operate. Power On/Off switch isn't pressed. Press Power On/Off switch. Appliance might not be plugged. Make sure the power cord is plugged in. Lighting is not functioning. Appliance key may not be functioning. Check the button. Flap should cover the air outlet when the appliance is Dirty air enters through the flue. Check the plastic flap at the flue outlet. not running. Remove the obstacles that prevent this closing. - Page 14 Optional Rights of Customer Consumer may exercise any of his/her optional rights below within two years of expiry period starting with the date of delivery of the good to the consumer if the good is found to be defective as per the provisions of Law on the Protection of Consumers no. 6502, even if the defect is found later; 1) To terminate the contract by stating that he is ready to return the sold good, 2) To request a discount on the sale price proportional to the defect and keep the defective good, against the Seller; 3) To request the sold good to be repaired at the seller’s expense by bringing all repair costs to the seller if such costs are not excessive, 4) If possible, to request the purchased good to be exchanged for a non-defective good, against the Seller, manufacturer or importer. Consumer may exercise either of its rights to terminate the contract or discount from the price in proportion to the defect if free repair or replacement of the good with a non-defective fungible will bring about disproportional challenges. Consumer may apply to Consumer Courts and Arbitration Committees for their complaints and concerns. Manufacturing Place: Turkey .Manufacturing Company: Vestel Ticaret A.Ş Levent 199 Büyükdere Cad. No:199 34394 Şişli/ISTANBUL-TURKEY Tel: 0850 222 4 123 E-mail: vmh@vestel.com.tr www.vestel.com.tr/destek...
