Summary of Contents for GameTech International Explorer
- Page 2 The players and hall operations personnel shall have no control over these parameters once the parameters are set. Only GameTech Int’l authorized personnel are allowed to set up the WiFi client by accessing the technician menu to set the SSID, authentication mode, security mode, and to enter the security key or password.
- Page 3 The Explorer incorporates two high-capacity Li Poly rechargeable batteries for long playing time. Both batteries are mounted in slots on the back (see Figure 1-3). The player unit operates exclusively from these ‘lap-top style’ battery packs. Battery charging is accomplished when the player unit is installed to its charging and storage crate.
- Page 4 To insert a battery, place the Explorer front-down on a clean surface, firmly grip the left side of the Explorer, position the battery label-side down into the slot guides, then carefully slide the battery fully to the left until it latches in place (see Figure 1-5). Figure 1-5.
- Page 5 To release the stand from the back of the Explorer case, perform the following: Place the Explorer front-down on a clean surface and firmly grip the top of the Explorer. Press all four fingers beneath the metal cross bar of the stand, as shown in Figure 1-7, and push in and up to release the stand from its secured...
