Summary of Contents for Unipar Sentinel
- Page 1 UNIPAR UNIPAR SERVICES SENTINEL SENTINEL SENTINEL SENTINEL AUTOMATIC CAMERA SYSTEM Copyright © 2010 Unipar Services Issue 1.0 (September 2010)
-
Page 2: Table Of Contents
• Operation • The LCD monitor • Entering the user settings • Taking footage • The DVR (Digital Video Recorder) • Charging • Specifications Unipar Services, The Old Stables, 65 Lower Green Road, Rusthall, Tunbridge Wells Kent, TN4 8TW United Kingdom. -
Page 3: Introduction
INTRODUCTION The Unipar static camera system comprises of a high quality day/night infrared sensitive camera, high capacity battery pack, a solid state Digital Video Recorder, vehicle detection radar and all control circuitry in a single small lightweight package. The unit is easily configured using the supplied remote control with all the settings displayed clearly on the supplied 3.5-inch LCD monitor. -
Page 4: Operation
CONNECTIONS All the connections are via the 6pin socket on the underside and are as follows: Video out – The LCD monitor is plugged into the 6pin connector for viewing/changing the current settings and the sighting of the camera. Charge input – With the unit switched off charge the internal battery pack with the battery charger supplied. -
Page 5: The Lcd Monitor
POWERING DOWN – With the unit on or in standby press in the power button. All LED indicators will switch off. Ensure any recording has finished first. STANBY MODE - Keep the MUTE button on the remote control continually pressed for several seconds observing the red LED flashes as the remote control transmits. -
Page 6: Entering The User Settings
ENTERING THE USER SETTINGS CLEAR BACKGROUND IDENTIFIES SELECTED CHARACTER. OVERSPEED, DIRECTION & LOCATION CODE ARE ALL SET USING THE REMOTE CONTROL. REMOTE CONTROL BUTTONS THE UP & DOWN ARROWS SELECT PRESS & HOLD THE CHARACTERS 0 to 9 BUTTON TO THE BACK &... - Page 7 REVERSE ARROW – Goes back one step. The black background of the character is removed to identify which character has been selected. UP ARROW – Changes the character to the next one in the sequence i.e. if it was 1 it would now change to 2 and if pressed again change to 3 etc.
-
Page 8: Taking Footage
Use the monitor to target the Sentinel on the road. The vehicle speed is displayed live as it is detected assisting in the targeting of the vehicles. - Page 9 REVIEWING ON SITE – Any footage recorded can be played back on site by pressing the MODE button. This plays back the last 10 second piece video footage as a continuous loop i.e. over and over again. To select the previous pieces of footage press the down arrow until the desired piece of footage has been selected.
-
Page 10: Specifications
Please note: No changes or modifications should be made to the equipment. Any changes may void the users authority to operate the equipment. CONTAINS A RECHARGEABLE NiMH BATTERY. MUST BE RECYCLED OR DISPOSED OF PROPERLY. Unipar Services, The Old Stables, 65 Lower Green Road, Rusthall, Tunbridge Wells Kent, TN4 8TW United Kingdom.
