BME Nitech HL180 Zone 0 Flashlight User Manual

HL180 Zone 0 Flashlight User Manual
Descripton:
The HL-180 Zone 0 Flashlight is a batery powered, lightweight, handheld
torch certfed for safe operaton within ATEX/IECEx Zone 0, Zone I and Zone
II hazardous locatons. The fashlight has three modes: low; high; and
fashing, to allow users to select between high brightness and long operaton.
Features:
-
Intrinsically safe for use in hazardous locatons
-
Low/High/Flash mode functons
-
High power CREE LED
-
Submersible in water
-
Tough and durable casing
-
High efciency heatsink
-
Screw fastener
-
Built-in gas release vent
Certfcaton:
Class 1 Div 1&2 Grp ABCD/Class II Div 1&2 Grp EFG
Class III/Temperature Code T4 IP67
File Number: E324236
Gas: II 1G Ex ia IIC T4 Ga
Mining: I M1 Ex ia I Ma
DEMKO 15ATEX1476X
Gas: Ex ia IIC T4 Ga
Mining: Ex ia I Ma
IECEx UL15.0046X
0518
Daysun technology Limited, No. 1, Alley 2, Lane 110, Sec. 4, Hsi-Men Road, North District, Tainan City, 704 Taiwan
Standards:
1. UL 913, Eighth Editon
2. CSA C22.2 No.157-92, Reafrmed 2012
3. EN 60079-0: 2012 Editon + A11: 2013
4. EN 60079-11: 2012 Editon
5. EN 60079-26: 2007 Editon
6. EN50303: 2000 Editon
7. IEC 60079-0: Sixth Editon
8. IEC 60079-11: Sixth Editon
9. IEC 60079-26: Second Editon
Batery Replacement:
Only use the batery types as indicated below:
Alkaline
Energizer E91
Duracell MN1500
Rayovac 815
Rayovac AL-AA
Varta 4906
Ansmann 5015548
Ansmann 1502-0002
DO NOT OPEN IN HAZARDOUS LOCATIONS
REPLACE BATTERIES ONLY IN NON-HAZARDOUS AREAS
TO REDUCE THE RISK OF EXPLOSION DO NOT MIX NEW BATTERIES WITH
USED BATTERIES, OR MIX BATTERIES FROM DIFFERENT MANUFACTURERS OR
FROM DIFFERENT TYPES
REMOVE THE BATTERIES WHEN UNUSED FOR A PERIOD OF TIME TO
PREVENT DRAINAGE AND BATTERY LEAKAGE IN THE DEVICE
SUBSTITUTION OF COMPONENTS MAY IMPAIR INTRINSIC SAFETY
BME Nitech QF: 1.7
Ni-MH
Energizer NH15-2300
WARNING
Installaton:
Operaton:
Rotate the switch (A) clockwise to operate. The sequence is high-low-fash
mode.
Safety Lock:
To unlock the safety on the switch (A) push the safety up.
To lock the safety on the switch (A) push the safety down.
Fastener for Beam Adjustment:
Afer bateries have been installed, turn (B) antclockwise untl it matches
with the arrow on the switch (A). Us the hex kit to screw the fastener untl it
is fat to the surface before adjustment.
Beam Adjustment (C):
Hold onto (B), and turn (C) to
adjust beam. Turn antclockwise
for spotlight and turn clockwise
for foodlight.
Accessories:
-
Hand Strap (Optonal)
Warranty:
1 Year Limited Warranty
Safety Warnings:
1.
The fastener shall be screwed untl it is fat to the surface, afer
opening and closing of the enclosure. Do not over screw as it will
afect the IP ratng.
2.
Do not fash the light beam directly to human's eyes.
3.
Always use the device following the regulatons of each country.
BME Nitech Ltd
Unit 1 Nevis Business Park
Balgownie Road
Aberdeen
AB22 8NT
T: 01224 825320
Page 1 of 1
