Summary of Contents for CET PMC-53A-E

  • Page 1 PMC-53A-E Intelligent Multifunction Meter User Manual Version: V1.0A March 8, 2019...
  • Page 2 The information contained in this manual is believed to be accurate at the time of publication; however, CET assumes no responsibility for any errors which may appear here and reserves the right to make changes without notice. Please consult CET or your local representative for the latest product specifications.
  • Page 3 CET Electric Technology DANGER Failure to observe the following instructions may result in severe injury or death and/or equipment damage.  Installation, operation and maintenance of the meter should only be performed by qualified, competent personnel that have the appropriate training and experience with high voltage and current devices.
  • Page 4 This warranty is on a return to factory for repair basis.  CET does not accept liability for any damage caused by meter malfunctions. CET accepts no responsibility for the suitability of the meter to the application for which it was purchased.
  • Page 5 CET Electric Technology Glossary AI/AO = Analog Input/Output = Current Transformer DI/DO = Digital Input/Output = Demand = Data Recorder FIFO = First In First Out HTTP = Hyper Text Transfer Protocol = Measured Neutral Current = Calculated Neutral Current...
  • Page 6: Table Of Contents

    Table of Contents Chapter 1 Introduction ..........................1 1.1 Overview ............................ 1 1.2 Features ............................1 1.3 PMC-53A-E application in Power and Energy Management Systems ........3 1.4 Getting more information ......................3 Chapter 2 Installation ..........................4 2.1 Appearance ..........................4 2.2 Unit Dimensions .........................
  • Page 7 CET Electric Technology 3.2.5 Detailed Description ..................... 31 Chapter 4 Applications ........................... 38 4.1 Inputs and Outputs ........................38 4.1.1 Digital Inputs ......................... 38 4.1.2 Digital Outputs ......................38 4.1.3 Energy Pulse Outputs ....................39 4.1.4 Analog Input ........................39 4.2 Power and Energy ........................
  • Page 8 2) Device Objects ........................87 3) Analog Input Objects (PMC-53A-E’s Real-Time Parameters) ..........88 4) Analog Value Objects (PMC-53A-E’s Basic Setup Registers) ............ 90 5) Binary Input Objects (PMC-53A-E’s Digital Inputs) ..............90 6) Binary Output Objects (PMC-53A-E’s Digital Outputs) ............90...
  • Page 9 CET Electric Technology 7) Additional Front Panel Setup Parameters for BACnet MS/TP ..........91 Appendix D DNP Profile .......................... 92 Appendix E Technical Specifications ..................... 100 Appendix F Standards Compliance ....................... 102 Appendix G Ordering Guide ......................... 103 Contact us ............................. 104...
  • Page 10: Chapter 1 Introduction

    This manual explains how to use the PMC-53A-E Ethernet Multifunction Meter. Throughout the manual the term “meter” generally refers to all models. This chapter provides an overview of the PMC-53A-E meter and summarizes many of its key features. 1.1 Overview The PMC-53A-E Ethernet Multifunction Meter is CET’s latest offer for the digital power/energy metering...
  • Page 11 CET Electric Technology  12 Monthly Energy Logs of kWh/kvarh Import/Export/Total/Net, kVAh, kvarh Q1-Q4  Interval Energy for kWh/kvarh Imp/Exp and kVAh  Demands, Predicted Demands and Peak Demands for kW/kvar/kVA Total and per phase Current with Timestamp for This Month (or Since Last Reset) and Last Month (or Before Last Reset) ...
  • Page 12: Pmc-53A-E Application In Power And Energy Management Systems

    Setup parameters via a standard web browser. 1.3 PMC-53A-E application in Power and Energy Management Systems The PMC-53A-E can be used to monitor 3P4W (Wye), 3P3W (Delta), 1P2W-Uln, 1P2W-Ull or 1P3W connected power system. Modbus communications allow real-time data, DI status and other information to be transmitted across a RS485 network to an Integrated Energy Management system such as PecStar®.
  • Page 13: Chapter 2 Installation

    Chapter 2 Installation Caution Installation of the PMC-53A-E should only be performed by qualified, competent personnel that have the appropriate training and experience with high voltage and current devices. The meter must be installed in accordance with all local and national electrical codes.
  • Page 14: Unit Dimensions

    CET Electric Technology 2.2 Unit Dimensions Figure 2-3 Unit Dimensions 2.3 Terminal Dimensions Figure 2-4 Terminal Dimensions Terminal Terminal Dimensions Wire Size Max. Torque Voltage Input Power Supply 5 kgf.cm/M3 2.6mm x 3.2mm 1.5mm (4.3 lb-in) I4 Input, AI, Ir Input RS485, DI, DO 1.0mm...
  • Page 15: Residual Current Ct Dimensions

    CET Electric Technology 2.4 Residual Current CT Dimensions 2.4.1 Solid Core CTs  CT517203 (160A, Ø=46mm) Figure 2-5 CT517203 Dimensions  CT517403 (400A, Ø=80mm) Figure 2-6 CT517403 Dimensions  CT517603 (1000A, Ø=120mm) Figure 2-7 CT517603 Dimensions...
  • Page 16: Split Core Cts

    CET Electric Technology  CT519703 (630A, 220x50mm) Figure 2-8 CT519703 Dimensions 2.4.2 Split Core CTs  CT553203 (160A, Ø=48mm) Figure 2-9 CT553203 Dimensions  CT553303 (225A, Ø=68mm) Figure 2-10 CT553303 Dimensions...
  • Page 17: Mounting

    2.5 Mounting The PMC-53A-E should be installed in a dry environment with no dust and kept away from heat, radiation and electrical noise source. Installation steps:  Remove the installation clips from the meter  Fit the meter through a 92mmx92mm cutout as shown in Figure 2-11 ...
  • Page 18 CET Electric Technology 2.6.1 3-Phase 4-Wire (3P4W) Wye Direct Connection with 3CTs or 4CTs Please consult the Serial Number Label to ensure that the rated system phase voltage is less than or equal to the meter’s rated phase voltage input specification. Set the Wiring Mode to 3P4W.
  • Page 19 CET Electric Technology 2.6.3 3-Phase 3-Wire (3P3W) Direct Delta Connection with 3CTs Please consult the Serial Number Label to ensure that the rated system line voltage is less than or equal to the meter’s rated line voltage input specification. Set the Wiring Mode to 3P3W.
  • Page 20 CET Electric Technology 2.6.6 3-Phase 3-Wire (3P3W) Delta with 2PTs and 2CTs Please consult the Serial Number Label to ensure that the voltage is less than or rated PT secondary equal to the meter’s rated phase voltage input specification. Set the Wiring Mode to 3P3W.
  • Page 21: Communications Wiring

    The following figure illustrates the RS485 communications connections on the PMC-53A-E: Figure 2-21 Communications Connections The PMC-53A-E provides one standard RS485 port. Up to 32 devices can be connected on a RS485 bus. The overall length of the RS485 cable connecting all devices should not exceed 1200m.
  • Page 22: Digital Output Wiring

    Figure 2-23 DO Connections 2.10 Pulse Output Wiring The following figure illustrates the Pulse Output connections on the PMC-53A-E when the DO Control Mode setup register is programmed for Energy Pulsing: Figure 2-24 Pulse Output (Solid State Relay) Connections for Energy Pulsing...
  • Page 23: Residual Current (Ir) Wiring

    2.12 Residual Current (Ir) Wiring The following figure illustrates the Residual Current connections on the PMC-53A-E: Figure 2-27 Residual Current Connections Note: 1) The Residual Current terminals (either *IR and IR) should be left open and should not be connected to ground if unused.
  • Page 24: Chapter 3 User Interface

    Chapter 3 User Interface 3.1 Front Panel The PMC-53A-E has a large, easy to read Dot-Matrix LCD display with backlight and four buttons for data display and meter configuration, one LED Pulse Output and a Communication Indicator. Figure 3-1 Front Panel 3.1.1 Front Panel Buttons...
  • Page 25: Data Display

    CET Electric Technology 3.1.2 Data Display Figure 3-2 Data Display Menu Throughout this document, the phase-to-neutral notations of A/B/C and L1/L2/L3 as well as the phase- to-phase notations of AB/BC/CA and L12/L23/L31 may be used interchangeably for specifying a certain parameter to be a phase-to-neutral or phase-to-phase value, respectively.
  • Page 26 CET Electric Technology U1 = Uan, U2 = Ubn, U3 = Ucn in 3P4W mode U1 = Uab, U2 = Ubc, U3 = Uca in 3P3W mode I1 = Ia, I2 = Ib, I3 = Ic 3.1.2.2 Power Menu Display Screens...
  • Page 27 CET Electric Technology Display 1 [HD (ODD)] HD3 ~ HD15 Display 2 [HD (ODD)] HD17 ~ HD29 Display 3 [HD (ODD)] HD31 <L1 > Display 1 [HD (Even)] HD2 ~ HD14 Display 2 [HD (Even)] HD16 ~ HD28 Display 3 [HD (Even)]...
  • Page 28 CET Electric Technology Ull avg Display 2 Timestamp Timestamp Timestamp Timestamp I avg Display 3 Timestamp Timestamp Timestamp Timestamp Freq Display 4 Timestamp Timestamp Timestamp Timestamp Display 1 Timestamp Timestamp Timestamp Timestamp Display 2 Timestamp Timestamp Timestamp Timestamp <Power> Display 3...
  • Page 29: Setup Configuration Via The Front Panel

    3.1.2.9 SOE The PMC-53A-E supports the display of the SOE Log with up to 100 Events (2 Events per page) such as I/O Changes, Setpoint, etc. on the Front Panel. In addition, the SOE Log can be reset from the Front Panel.
  • Page 30 CET Electric Technology 3.1.3.2 Setup Menu...
  • Page 31 CET Electric Technology Figure 3-4 Setup Menu 3.1.3.3 Configuration The Setup Configuration mode provides access to the following setup parameters: Label Description Range Default Menu Password Enter Password 0000 to 9999 0000 Basic DEMO/ Wiring Mode Meter’s Wiring Connection 1P2W L-N/1P2W L-L/...
  • Page 32 CET Electric Technology EN Pulse CNST Pulse Constant 1000/3200/6400 1000 Enable kWh/kvarh Energy LED EN Pulse Disabled/kWh/kvarh Pulsing EN Period Interval Energy period 5 to 60 min kvarh Calc. kvarh Calculation Method RMS/FUND Current Threshold of Device OT Threshold 1 to 1000 (x0.001In)
  • Page 33 CET Electric Technology … Digital Output Function Specifies the function of the Pulse Output.  Digital Output  kWh Import  kWh Export  DO Control Mode kWh Total Digital Output  kvarh Import  kvarh Export  kvarh Total...
  • Page 34 CET Electric Technology Pulse Counter Clear All DI Counters Yes/No DIx (x=1 to 4) Clear DIx Pulse Counter Yes/No SOE Logs Clear SOE Logs Yes/No Clear All Data Clear All of the above Yes/No DO Control DOx Manual Control Normal/On/Off...
  • Page 35 CET Electric Technology Setpoint Parameter Scale Resolution Unit None Uln (Any Phase Voltage) Ull (Any Line Voltage) 0.001 I (Any Phase Current) In (Calculated) Frequency 0.01 P (kW Total) Q (kvar Total) S (kVA Total) PF (PF Total) P DMD (kW Total Present Demand) 0.001...
  • Page 36 CET Electric Technology Figure 3-6 Reversal Setpoint Logic Diagram The table below illustrates the options for Setpoint Trigger. Please keep in mind that when the DOx is set as Setpoint Trigger, the DOx Function should be configured as Digital Output correspondingly.
  • Page 37: Web Interface

    35.0 and above Table 3-14 Web Browser Supported The default IP Address of the PMC-53A-E Ethernet Port is 192.168.0.100. Please make sure to configure the IP Address and Subnet Mask for the PMC-53A-E (via Front Panel or through communication) and the PC so that they are in the same subnet.
  • Page 38: Configure Pmc-53A-E's Ip Address

    53A-E and then enter the IP address. The default IP address is 192.168.0.100. Figure 3-10 Setting PMC-53A-E’s IP Address 3.2.3 Accessing the Web Interface Enter the IP Address of the PMC-53A-E in the Address area of Google Chrome and then press <Enter>. Figure 3-11 Web Login The PMC-53A-E’s Web Interface appears.
  • Page 39: Overview

    3.2.4 Overview The PMC-53A-E’s Web Interface provides a simple way to view the meter’s measurements and configure its setup parameters. The following screen captures illustrate the PMC-53A-E’s Web Interface. The Sub- Menu on the left-hand pane displays the available options under the selected item from the Main Menu at the top.
  • Page 40 CET Electric Technology Displays Present, Predicted and Peak Demand (This/Last Month or Demand Since/Before Last Reset) for P, Q, S and 3-Ø Current. Displays kWh/kvarh Import/Export and kVAh for TOU Tariffs T1 to T8 Displays Max./Min. values with timestamps for real-time Max./Min.
  • Page 41 CET Electric Technology Displays the programmed functions and values for DI, DO and AI (if equipped). Displays THD, TIHD, TEHD, Crest Factor, K-Factor, TDD, and the 2 Harmonics individual harmonics for Voltage and Current. Power Quality...
  • Page 42 CET Electric Technology Sym. Comp. Displays Positive, Negative, and Zero Sequence as well as Unbalance & Unb. for Voltage and Current Display the SOE events with timestamps such as DI/DO Changes, Setpoint Alarms, Setup Changes, etc. Events Basic settings such as Wiring Mode, I1/I2/I3 Polaity, PT/CT...
  • Page 43 CET Electric Technology Comm. RS-485 (P1), Ethernet (P2), SNTP and SMTP configuration. Demand Demand and Self-Read Time configuration...
  • Page 44 CET Electric Technology Clock Clock Settings including Date, Time, Time Zone and Date Format. Clear operation for different values and logs by group or individually. Maintenance Device Info. Serial Number, MAC Address, Firmware Version and Date.
  • Page 45 CET Electric Technology Table 3-15 Detailed Description of the On-board Web Server Notes: The following table illustrates the Range and Default Value for each parameter: Parameter Range/Default* Parameter Range/Default* Parameter Range/Default* Wiring Mode DEMO, 1P2W L-N, 1P2W L-L, 3P3W, 3P4W*...
  • Page 46: Chapter 4 Applications

    Please refer to Section 4.4 for a detailed description. Since there are multiple ways to trigger the Digital Outputs on the PMC-53A-E, a prioritized scheme has been developed to avoid conflicts between different applications. In general, Front Panel Control has the highest priority and can override other control schemes.
  • Page 47: Energy Pulse Outputs

    4.1.3 Energy Pulse Outputs The PMC-53A-E comes standard with one Front Panel LED Pulse Output for energy pulsing and can be equipped with two optional Solid State Digital Outputs for kWh and kvarh pulsing, replacing the default Digital Outputs.
  • Page 48: Energy Measurements

    Demand is defined as the average power consumption over a fixed interval (usually 15 minutes) based on the Sliding Window method. The PMC-53A-E provides Present Demand and Predicted Demand for Ia, Ib, Ic, kW Total, kvar Total and kVA Total, updated once a second, as well as Max Demand for Ia, Ib, Ic, kW Total, kvar Total and kVA Total of TOU Tariff 1 to 8 in This Month (Since Last Reset) and Last Month (Before Last Reset).
  • Page 49: Power Quality

    I1, I2 are the Positive and Negative Sequence Components for Current, respectively. 4.3.3 Harmonics The PMC-53A-E provides Voltage and Current with THD, TOHD, TEHD and up to the 31 individual harmonics analysis. Additionally, TDD, K-Factor, and Crest Factor for Current are provided as well. All harmonic parameters are available via the Front Panel or through communications.
  • Page 50 CET Electric Technology THDf: ∞ √∑ THDf = ×100% THDr: ∞ √∑ THDr = ×100% ∞ √∑ where I represents the RMS value of the fundamental component, and I represents the RMS value for the n harmonic. 4.3.3.2 TDD Total Demand Distortion (TDD) is defined as the ratio of the RMS of the Harmonic Current to the RMS of the Rated or Maximum Fundamental Current Demand.
  • Page 51: Setpoints

    CET Electric Technology 4.4 Setpoints The PMC-53A-E comes standard with 9 user programmable Setpoints which provide extensive control by allowing a user to initiate an action in response to a specific condition. Typical setpoint applications include alarming, fault detection and power quality monitoring.
  • Page 52 CET Electric Technology Specify the value that the setpoint parameter must go Under Limit below for Over Setpoint to become inactive or for Under Setpoint to become active. Specify the minimum duration that the setpoint condition must be met before the setpoint becomes active. An event...
  • Page 53: Logging

    4.5 Logging 4.5.1 Max/Min Log The PMC-53A-E records the Max Log and Min Log of This Month (Since Last Reset) and Last Month (Before Last Reset) with timestamp for 45 parameters. Each log includes the relevant parameter value and its timestamp. The recorded data is stored in the device’s non-volatile memory and will not suffer any loss in the event of a power failure.
  • Page 54: Peak Demand Log

    When the wiring mode is 1P3W, the demand measurements for Phase C are invalid. 4.5.3 Monthly Energy Log The PMC-53A-E stores monthly energy data for the present month and the last 12 months. The Monthly Energy Log Self-read Time setup parameter allows the user to specify the time and day of the month for the Recorder’s Self-read operation via communications.
  • Page 55: Daily And Monthly Freeze Log

    The PMC-53A-E’s 4MB log memory is divided equally into 5 buffers of 800kB each. By default, each DR is allocated one 800kB buffer, which can hold a maximum ~118 days of recording with 16 parameters at 15-minute interval.
  • Page 56: Time Of Use (Tou)

    TOU is used for electricity pricing that varies depending on the time of day, day of week, and season. The TOU system allows the user to configure an electricity price schedule inside the PMC-53A-E and accumulate energy consumption into different TOU tariffs based on the time of consumption. TOU programming is only supported through communications.
  • Page 57: Communications

     8 Tariffs Instead of using the TOU schedule to switch between Tariffs, the PMC-53A-E supports Tariff switching based on the status of DI1 to DI3. The 3 Digital Inputs (DI1, DI2 and DI3) represent 3 binary digits where Tariff 1=000, Tariff 2=001, Tariff 3= 010, …, Tariff 7=110 and Tariff 8=111 where DI1 represents the least significant digit and DI3...
  • Page 58: Smtp

    Server IP The IP Address of the SNTP Server 192.168.0.94 Table 4-17 SNTP Setup Parameters 4.7.2 SMTP The PMC-53A-E can be configured to send Alarm Emails based on the Simple Mail Transfer Protocol (SMTP). Setup Parameters Definition Options/Default* Server IP...
  • Page 59: Ethernet Gateway

    Software sends a “Modbus RTU over TCP/IP” packet (Modbus RTU packet, i.e. the payload, encapsulated in a TCP/IP frame) to the PMC-53A-E’s Ethernet port at its IP Address and IP Port No. 6000. The PMC- 53A-E receives this “Modbus RTU over TCP/IP” packet at its Ethernet port, extracts the “encapsulated”...
  • Page 60: Diagnostics

    PMC-53A-E’s Ethernet Gateway, providing that all the necessary configuration is correct. 4.8 Diagnostics The PMC-53A-E provides wiring error detection for 3P4W and 3P3W wiring modes and allows the user to check for potential problems, especially during the initial commissioning stage. The following wiring errors may be detected: ...
  • Page 61: Voltage Phase Loss

    CET Electric Technology Please note that the error detection above is based on the following assumptions:  The Voltage and Current Phase Sequences are consistent  kW is kW Import, which means the kW is over 0  3P4W wiring mode supports all detections ...
  • Page 62: Chapter 5 Modbus Register Map

    This chapter provides a complete description of the Modbus register map (Protocol Version 1.0) for the PMC-53A-E to facilitate the development of 3 party communications driver for accessing information on the PMC-53A-E. For a complete Modbus Protocol Specification, please visit http://www.modbus.org. The PMC-53A-E supports the following Modbus functions: 1) Read Holding Registers (Function Code 0x03)
  • Page 63 CET Electric Technology 0082 Scaled Float 0084 Iresidual Float 0086~0095 Reserved Float 0096 DI Status UINT16 0097 Reserved UINT16 0098 DO Status UINT16 0099 Reserved UINT16 0100 Setpoint Status UINT16 0101 Wiring Diagnostic Status UINT16 0102 SOE Log Pointer UINT32...
  • Page 64: Energy Measurements

    Table 5-3 Wiring Diagnostic Status Register The PMC-53A-E has one SOE Log and five DR Logs. Each of these logs has a Log Pointer that indicates its current logging position. The range of the Log Pointer is between 0 and 0xFFFFFFFF, and it is incremented by one for every new log generated and will roll over to 0 if its current value is 0xFFFFFFFF.
  • Page 65: Phase A (L1) Energy Measurements

    CET Electric Technology 0568 kWh Export of T5 INT32 0570 kvarh Import of T5 INT32 kvarh 0572 kvarh Export of T5 INT32 0574 kVAh of T5 INT32 kVAh 0576 kWh Import of T6 INT32 0578 kWh Export of T6 INT32...
  • Page 66: Phase B (L2) Energy Measurements

    CET Electric Technology 0704 kVAh of T6 INT32 kVAh 0706 kWh Import of T7 INT32 0708 kWh Export of T7 INT32 0710 kvarh Import of T7 INT32 kvarh 0712 kvarh Export of T7 INT32 0714 kVAh of T7 INT32 kVAh...
  • Page 67: Phase C (L3) Energy Measurements

    CET Electric Technology 0840 kvarh Import of T8 INT32 kvarh 0842 kvarh Export of T8 INT32 0844 kVAh of T8 INT32 kVAh Table 5-6 Phase B Energy Measurements 5.2.4 Phase C (L3) Energy Measurements Register Property Description Format Scale Unit...
  • Page 68: Di Pulse Counters

    CET Electric Technology 1102 kWh Export INT32 1104 kvarh Import INT32 kvarh 1106 kvarh Export INT32 1108 kVAh INT32 kVAh Table 5-8 Interval Energy Measurements Note: The EN Period (Register# 6047) determines how long the Interval Energy Measurements will be updated. For example, if EN Period = 60 min, the Interval Energy Measurements will be refreshed hourly on the hour.
  • Page 69: Voltage Harmonic Measurements

    CET Electric Technology 5.4.3 Voltage Harmonic Measurements Register Property Description Format Scale Unit 1600 Uan/Uab THD Float 1602 Ubn/Ubc THD Float 1604 Ucn/Uca THD Float 1606 Uan/Uab TOHD Float 1608 Ubn/Ubc TOHD Float 1610 Ucn/Uca TOHD Float 1612 Uan/Uab TEHD...
  • Page 70: Peak Demand Log Of Last Month (Before Last Reset)

    CET Electric Technology 3478~3483 kvar Total of T3 3484~3489 kVA Total of T3 3490~3495 kW Total of T4 3496~3501 kvar Total of T4 3502~3507 kVA Total of T4 3508~3513 kW Total of T5 3514~3519 kvar Total of T5 3520~3525 kVA Total of T5...
  • Page 71: Max/Min Log

    CET Electric Technology 5.6 Max/Min Log 5.6.1 Max Log of This Month (Since Last Reset) Register Property Description Format Scale Unit 4000~4005 4006~4011 4012~4017 4018~4023 Uln Average 4024~4029 4030~4035 4036~4041 4042~4047 Ull Average 4048~4053 4054~4059 4060~4065 4066~4071 I Average 4072~4077...
  • Page 72: Max Log Of Last Month (Before Last Reset)

    CET Electric Technology 4366~4371 I Average 4372~4377 4378~4383 4384~4389 4390~4395 kW Total 4396~4401 kvara 4402~4407 kvarb 4408~4413 kvarc 4414~4419 kvar Total 4420~4425 kVAa 4426~4431 kVAb 4432~4437 kVAc 4438~4443 kVA Total 4444~4449 4450~4455 4456~4461 4462~4467 PF Total 4468~4473 Frequency 4474~4479 In (Calculated)
  • Page 73: Min Log Of Last Month (Before Last Reset)

    CET Electric Technology 4756~4761 4762~4767 PF Total 4768~4773 Frequency 4774~4779 In (Calculated) 4780~4785 Uan/Uab THD 4786~4791 Ubn/Ubc THD 4792~4797 Ucn/Uca THD 4798~4803 Ia THD 4804~4809 Ib THD 4810~4815 Ic THD 4816~4821 Ia K-Factor 4822~4827 Ib K-Factor 4828~4833 Ic K-Factor 4834~4839...
  • Page 74: Max/Min Log Structure

    CET Electric Technology 5146~5151 Ic Crest Factor 5152~5157 Voltage Unbalance 5158~5163 Current Unbalance 5164~5169 5170~5175 Ir (Residual Current) Table 5-21 Min Log of Last Month (Before Last Reset) 5.6.5 Max/Min Log Structure Offset Description High Year - 2000 Month High...
  • Page 75: Daily And Monthly Freeze Logs

    CET Electric Technology 1058 kVAh of T5 INT32 x0.1 kVAh 1060 kWh Import of T6 INT32 x0.1 1062 kWh Export of T6 INT32 1064 kvarh Import of T6 INT32 x0.1 kvarh 1066 kvarh Export of T6 INT32 1068 kVAh of T6 INT32 x0.1...
  • Page 76: Soe Log

    CET Electric Technology 12506 kvarh Total INT32 x0.1 kvarh 12508 kVAh Total INT32 x0.1 kVAh 12510~12515 Peak Demand of kW Total See Table 5-26 12516~12521 Peak Demand of kvar Total Demand Data Structure 12522~12527 Peak Demand of kVA Total Table 5-25 Monthly Freeze Log...
  • Page 77 CET Electric Technology Notes: The return value “01” means DI Inactive/ DO Operated/Alarm (including Setpoint & Diagnosis); and the return value “00” means DI Active/ DO Released/Setpoint Return. The returned Event Value (for SOE Event Classification=Setpoint only) is in Float format, and please refer to Table 5-40 to check the Unit for each parameter.
  • Page 78 CET Electric Technology Over U2 (Negative Sequence) Setpoint Active/Return Over U0 (Zero Sequence) Setpoint Active/Return 30~40 Reserved Under Uln Setpoint Active/Return Under Ull Setpoint Active/Return Under Current Setpoint Active/Return Under In Setpoint Active/Return Under Frequency Setpoint Active/Return Under kW Total Setpoint Active/Return...
  • Page 79 CET Electric Technology Clear All Data via Front Panel Clear SOE Log via Front Panel x=1 to 4 Clear DIx Pulse Counter via Front Panel Clear All Pulse Counter via Front Panel Clear Device Operating Time via Front Panel Set Clock via Front Panel...
  • Page 80: Data Recorder Log

    CET Electric Technology 5.10 Data Recorder Log Register Property Description Format 20000~20037 DR Log #1 Buffer 20038~20075 DR Log #2 Buffer See Table 5-32 20076~20113 DR Log #3 Buffer Standard DR Log Structure 20114~20151 DR Log #4 Buffer 20152~20189 DR Log #5 Buffer...
  • Page 81 CET Electric Technology 6037 Backlight Time-out UINT16 0 to 60 (mins), 5* 6038 System Language UINT16 1=English 0=YYMMDD* 6039 Date Format UINT16 1=MMDDYY 2=DDMMYY 0=Option 1*, 1=Option 2 6040 Delimiter UINT16 See Note 4 Monthly Freeze 6041 UINT16 Self-Read Time...
  • Page 82 35 characters long. Please add the value zero “0000” at the end of the string as the string terminator. For example, if the email address is PMC-53A-E@gmail.com, so set the registers as” 0050 004D 0043 002D 0035 0033 0041 002D 0045 0040...
  • Page 83: I/O Setup

    CET Electric Technology 5.11.2 I/O Setup Register Property Description Format Range, Default* 6200 DI1 Function UINT16 0 = Digital Input* 6201 DI2 Function UINT16 1=Pulse Counting 6202 DI3 Function UINT16 2 =Tariff Switch 6203 DI4 Function UINT16 6204~6207 Reserved 6208...
  • Page 84 CET Electric Technology 6506 Active Delay UINT16 0 to 9999 s, 10* 6507 Inactive Delay UINT16 0 to 9999 s, 10* 6508 Trigger Action 1 UINT16 0 to 3 6509 Trigger Action 2 UINT16 … … … 0=Disabled* 6580 Setpoint Type...
  • Page 85: Data Recorder Setup

    CET Electric Technology Figure 5-1 Reversal Setpoint Logic Diagram The table below illustrates the options for Setpoint Trigger. Please keep in mind that when the DOx is set as Setpoint Trigger, the DOx Function should be configured as Digital Output correspondingly.
  • Page 86: Tou Setup

    Table 5-45 TOU Switch Time Format 5.12.2 Season The PMC-53A-E has two sets of Season setup parameters, one for each TOU. The Base Addresses for the two sets are 7100 and 8100, respectively, where the Register Address = Base Address + Offset. For example, the register address for TOU #1’s Season #2’s Start Date is 7100+4 = 7104.
  • Page 87: Daily Profile

    Season’s duration is from its Start Date to the end of the year. The Start Date of a particular Season must be later than the previous Season’s. 5.12.3 Daily Profile The PMC-53A-E has two sets of Daily Profile setup parameters, one for each TOU. Register Property...
  • Page 88 CET Electric Technology 7464~7487 Daily Profile #12 7488~7511 Daily Profile #13 7512~7535 Daily Profile #14 7536~7559 Daily Profile #15 7560~7583 Daily Profile #16 7584~7607 Daily Profile #17 7608~7631 Daily Profile #18 7632~7655 Daily Profile #19 7656~7679 Daily Profile #20 Table 5-47 TOU #1’s Daily Profile Setup...
  • Page 89: Alternate Days

    When the Year and/or Month are set as 0xFF, it means the Alternate Day is repetitive by year and/or month, i.e. the same day of every year or every month is an Alternate Day. 5.13 Time There are two sets of Time registers supported by the PMC-53A-E – Year / Month / Day / Hour / Minute...
  • Page 90: Remote Control

    / Second (Registers # 60000 to 60002) and UNIX Time (Register # 60004). When sending time to the PMC-53A-E over Modbus communications, care should be taken to only write one of the two Time register sets. All registers within a Time register set must be written in a single transaction. If registers...
  • Page 91: Meter Information

    CET Electric Technology 9604 Clear All Demand Registers Clear Max/Min Logs of This Month 9605 (Since Last Reset) 9606 Clear All Max/Min Log 9607 Clear Device Operating Time 9608 Clear All Data 9609 Clear SOE Log 9610 Clear DI1 Pulse Counter...
  • Page 92 CET Electric Technology The Meter Model appears from registers 60200 to 60219 and contains the ASCII encoding of the string “PMC-53A-E” as shown in the following table. Register Value(Hex) ASCII 60200 0x50 60201 0x4D 60202 0x43 60203 0x2D 60204 0x35...
  • Page 93: Appendix A Data Recorder Parameter List

    CET Electric Technology Appendix A Data Recorder Parameter List Description Description Description Real-time Measurements (Format: Float) None PF Total Frequency kW Total Uan/Uab Angle kvara Ubn/Ubc Angle Uln Average kvarb Ucn/Uca Angle kvarc Ia Angle kvar Total Ib Angle kVAa...
  • Page 94: Appendix B Data Recorder Default Settings

    CET Electric Technology Appendix B Data Recorder Default Settings Parameter DR 1 DR 2 DR 3 DR 4 DR 5 Triggered by Triggered by Triggered by Triggered by Triggered by Trigger Mode Timer Timer Timer Timer Timer Recording Mode FIFO...
  • Page 95: Appendix C Bacnet Mstp Implementation

    Appendix C BACNet MSTP Implementation 1) Basic Information The PMC-53A-E supports the BACnet MS/TP protocol and can easily be connected to a BACnet MS/TP network using an off-the shelf BACnet router. The PMC-53A-E provides four types of BACnet objects. Standard Protocol Implementation Conformance Statement (PICS) as illustrated in table below describes the required characteristics of the BACnet implementation.
  • Page 96: Analog Input Objects (Pmc-53A-E's Real-Time Parameters)

    Use the Present_Value property of the Analog_Input objects for all read-only numeric variables in PMC-53A-E. These objects support the Description and Reliability optional properties and all required Analog_Input object properties. None of them are writable. The values that are not instantaneous (i.e.
  • Page 97 CET Electric Technology AI 0502 kWh Export 99999999.9 AI 0504 kWh Net AI 0506 kWh Total AI 0508 kvarh Import* AI 0510 kvarh Export* kvarh AI 0512 kvarh Net* AI 0514 kvarh Total* AI 0516 kVAh* AI 3006 kW Total Demand...
  • Page 98: Analog Value Objects (Pmc-53A-E's Basic Setup Registers)

    The table below describes how the Setup Registers of the PMC-53A-E are represented in BACnet, their valid ranges, their defaults as well as how they are used. PMC-53A-E supports the Description, Relinquish_Default and Priority_Array optional properties.
  • Page 99: Additional Front Panel Setup Parameters For Bacnet Ms/Tp

    CET Electric Technology 7) Additional Front Panel Setup Parameters for BACnet MS/TP The following BACnet MS/TP setup parameters should be configured via the PMC-53A-E’s Front Panel before connecting the PMC-53A-E to a BACnet MS/TP network. Parameters Description Option/Range Default MS/TP ID...
  • Page 100: Appendix D Dnp Profile

    CET Electric Technology Appendix D DNP Profile This section contains the DNP Device Profile Information according to the standard format defined in the DNP 3.0 Subset Definitions Document and should provide a complete application configuration guide. DNP V3.0 Vendor Name:...
  • Page 101 CET Electric Technology DNP V3.0 Reports Binary Input Change Events when no specific Reports time-tagged Binary Input Change Events when no variation requested: specific variation requested:   Never Never   Only time-tagged Binary Input Change with Time ...
  • Page 102 Not Used Link Service Not Functioning Not Used Link Service Not Used or Implemented Physical Layer The PMC-53A-E is designed to support the DNP 3.0 protocol on one RS-485 port only at any one time. Port Configuration Description Notes Port Name...
  • Page 103 CET Electric Technology DNP Point Map Object 1 - Binary Input Status with Flags (Included in Class 0 responses) Read with Object 1, Variation 2, and Qualifier 6. Point Description Format Range UINT8 Bit Flags UINT8 Bit Flags UINT8 Bit Flags...
  • Page 104 CET Electric Technology Object 12 - Control Relay Outputs Responds to Function Codes: 03 (Select), 04 (Operate) and 05 (Direct Operate), Variation 1, Qualifier 0x28, with a Count of 1 only. Only one control object at a time may be specified.
  • Page 105 CET Electric Technology The read-out value 10000 represents the Version is V1.00.00. Object 30 - Analog Inputs Primary Readings (Included in Class 0 responses) Read with Object 30, Variation 3, and Qualifier 6. Point Description Format Scale Unit Meter Health...
  • Page 106 CET Electric Technology U2 (-ve Sequence Voltage) INT32 U0 (Zero Sequence Voltage) INT32 I1 (+ve Sequence Current) INT32 I2 (-ve Sequence Current) INT32 x1000 I0 (Zero Sequence Current) INT32 Ia TDD INT32 Ib TDD INT32 Ic TDD INT32 Ia K Factor...
  • Page 107 CET Electric Technology Bit 5 Object 40 - Analog Output Status Included in Class 0 responses? 0=No, 1=Yes (default) Bit 6- Bit 15 Reserved Object 50 - Date and Time Read and Write function is supported for this object, which occupies 6 bytes for the device's time. The time shows the number of UNIX milliseconds since 00:00:00 January 1, 1970, calculated by UNIX seconds*1000 + milliseconds.
  • Page 108: Appendix E Technical Specifications

    CET Electric Technology Appendix E Technical Specifications Voltage Inputs (V1, V2, V3, VN) Standard Un 400VLN/690VLL Range 10V to 1.2Un Overload 1.2xUn continuous, 2xUn for 1s Burden <0.02VA per phase Measurement Category CAT III up to 600VLL Frequency 45-65Hz Current Inputs (I11, I12, I21, I22, I31, I32)
  • Page 109 CET Electric Technology Mechanical Characteristics Panel Cutout 92x92 mm (3.62”x3.62”) Unit Dimensions 96x96x88 mm IP Rating IP65 (Front Panel), IP30 (Body) Accuracy Parameters Accuracy Resolution Voltage ±0.2% Reading + 0.05% F.S. 0.001V Current ±0.2% Reading + 0.05% F.S. 0.001A I4 (measurement) ±0.2%...
  • Page 110: Appendix F Standards Compliance

    CET Electric Technology Appendix F Standards Compliance Safety Requirements EN61010-1: 2010 CE LVD 2014 / 35 / EU EN61010-2-030: 2010 Electrical safety in low voltage distribution IEC 61557-12: 2008 (PMD) systems up to 1000Vac and 1500 Vdc Insulation IEC 62052-11: 2003 IEC 62053-22: 2003 AC Voltage: 2.5kV @ 1 minute...
  • Page 111: Appendix G Ordering Guide

    CET Electric Technology Appendix G Ordering Guide...
  • Page 112: Contact Us

    CET Electric Technology Contact us CET Inc. 8/F, Westside, Building 201, Terra Industrial & Tradepark, Che Gong Miao, Shenzhen, Guangdong, P.R.China 518040 Tel: +86.755.8341.5187 Fax: +86.755.8341.0291 Email: sales@cet-global.com Web: www.cet-global.com...
