CVS VC58SMi Manual

1.3 megapixel ip camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VC58SMi
1.3 Megapixel IP Camera
Manual
ver.0.2(2010.11.02)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC58SMi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CVS VC58SMi

  • Page 1 VC58SMi 1.3 Megapixel IP Camera Manual ver.0.2(2010.11.02)
  • Page 2 VC58SMi USER MANUAL Precautions Congratulations on your purchase of this product. Read this manual carefully and keep it in a safe place for future reference. Please read the manual carefully before the installation in order to make use the camera to be set up correctly and to have the best picture quality.

  • Page 3: Table Of Contents

    VC58SMi USER MANUAL Table of Contents 1. introduction ......................... 1. about installation manuals ..................3 2. features ......................3 3. package contents....................4 4. product view ......................5 5. system connect ....................7 2. installation ........................ 9 1. connecting to a network(LAN) ................9 2.

  • Page 4: Features

    VC58SMi USER MANUAL 1. Synopsis 1. about this article This manual explain how to use VC58Mi model that high quality network camera Throughout this article, can be found that how to install VC58Mi, Set according to the environmental changes, and how to Diagnostic error 2.

  • Page 5: Package Contents

    VC58SMi USER MANUAL If system is failure it will be trigger alarm  User interface Support remote setting, analysis, & update  SD Memory SD memory Card recording , remote search & play  High stability Based on imbedded system Watch-dog 3.

  • Page 6: Product View

    VC58SMi USER MANUAL 4. Product views ① Protective cover ② C-Mount lens adaptor ③ DC Iris Jack ④ Mounting bracket holder Mounting bracket holder can be separated and attached on the bottom side as well. Please use the supplied clamp screws only change the position of the bracket.
  • Page 7 VC58SMi USER MANUAL  Rear ⑧ ⑦ ⑥ ④ ① ⑤ ② ③ Connector Function LAN/802.3af LAN port/802.3af LED : indicate status of Power, network communication AUDIO OUT Audio output AUDIO IN Audio input RESET Button Factory Default POWER IN...

  • Page 8: Installation

    VC58SMi USER MANUAL 2. INSTALLATION 1. CONNECTING NETWORK(LAN) There is video output to check the video After connecting power & LAN connection 2. Connecting Audio If necessary connect Audio 3. Connecting Sensor & alarm Connect sensor and Alarm(relay). 4. Connecting Power Connect the power adapter to the DC-IN socket on the camera 5.
  • Page 9 VC58SMi USER MANUAL To connect to the IP camera using an Internet browser: Enter the IP address of the camera in the browser address field. http://192.168.1.100 ☞ All items on the web page can be used after the authentication process ○...
  • Page 10 VC58SMi USER MANUAL 2. Live ○ ○ ○ [Picture 2] LIVE Monitoring ○ ○ ○ ☞ [Main feature] - Live monitoring - fixed/original image size - PTZ - Screen Shot, Two-way Audio (Speaker/Mic) - OSD On/Off - Alarm Out - UPNP(Universal Plug and Play) On/Off...

  • Page 11: Live View

    VC58SMi USER MANUAL ○ Title Bar (common contents) Display title massage as current page Common contents menu Indicate capital characters in english ○ Top right Menu bar (common contents) [Emergency Call] [logout] [live view] [Set-up]  [Live view icon] –to monitor Live view ...
  • Page 12 VC58SMi USER MANUAL ○ [PTZ control] [ZOOM IN] [direction contorol] [ZOOM OUT] [FOCUS NEAR] [FOCUS FAR] [IRIS OPEN] [IRIS CLOSE] [Choose PRESET] [Goto PRESET ] [DEL PRESET ] [Set PRESET ]  [ZOOM IN] – PTZ ZOOM IN  [ZOOM OUT] – PTZ ZOOM OUT ...
  • Page 13 VC58SMi USER MANUAL ○ VIDEO & CONTROL [SNAPSHOT] [SPEAKER] [MIC] [ALARM OUT] [원본크기] [OSD] [UPNP] [HELP]  [SNAPSHOT] – TO SNAP SHOT ON LIVE VIEW  [SPEAKER] – AUDIO ON/OFF  [MIC] – MIC ON/OFF  [ALARM OUT] – ALARM OUT ON/OFF ...
  • Page 14 VC58SMi USER MANUAL The camera includes support for UPnP , which is enabled. ☞ [note]- ™ If also enabled on your computer, the camera will automatically be detected and a new icon will be added to “My Network Places.” - Click the icon for the device go to authentication of the web page, ○...
  • Page 15 VC58SMi USER MANUAL ○ ive view [Event view] [MIC] [SPEAKER]  [event information] – Motion/Alarm Event Icon display  [MIC] – DISPLAY MIC ON/OFF  [SPEAKER] – DISPLAY SPEAKER ON/OFF ☞ [note] - IF The brightness of the image is not stable, depending on the background Change option ATW->USER go to Setup>...

  • Page 16: Menu

    VC58SMi USER MANUAL 3. SETUP MENU ○ ○ ○ [Picture 3] SETUP PAGE ☞ [note] - SETUP MENU is comprised of Menu select window & Menu setup window. - First select group on the menu at the top and bottom of the group, Go to sub...
  • Page 17 VC58SMi USER MANUAL ○ view live image  It is possible to monitor during setup page  It is not display during setup page with Image (ex: Motion/Camera) ○ select menu icon ☞ [note] - Menu items are grouped into a total of 6...
  • Page 18 VC58SMi USER MANUAL  menu configuration ○ 메뉴 설정 ○ Menu settting  Selected sub Menu setting -17-...

  • Page 19: Camera Setup

    VC58SMi USER MANUAL 4. SETUP > CAMERA Camera Setup ○ ○ [Picture 4] camera setup ☞ [feature] - Camera sub menu setup - Privacy Mask (4Layer, Click & Drag) - Day & Night - Auto White Balance - Auto Exposure - Effect - each setup menu can be edit with intuitionally &...
  • Page 20 VC58SMi USER MANUAL ○ Privacy Mask Setup ☞ [notes] - 4zone Mask Area. - each Mask area can be edit size & locate by click & drag left button in Mouse. - All changed value will be applied after click SAVE button.
  • Page 21 VC58SMi USER MANUAL  Set Gray Level – SELECT Gray Level OF mask (ZONE COLOR) ☞ 0: BLACK 255: WHITE ○ Day&Night / AutoWhiteBalance / AutoExposure / Effect ☞ [note] - Menu is comprised with TAB base. - When the click menu TAB can see Sub menu ...
  • Page 22 VC58SMi USER MANUAL  Auto White Balance  ATW: (:3000°K~6500°K)  Push Lock Mode: AWB can be control within 1800°K~10500°K area  Manual Auto: (User Mode be able to control Auto in setup condition)  User Mode: adjust Red & Blue by user ...
  • Page 23 VC58SMi USER MANUAL  BLC Level: set back light compensation Level  LSC(Lens Shading Correction)Level: Lens Shading Correction)  AGC Analog Gain: set Analog Gain in low light  AGC Digital Gain: set AGC Digital Gain (it can be more bright But Noise has occurred) ...
  • Page 24 VC58SMi USER MANUAL 4.2. Image Overlay [Picture 5] Image Overlay ☞ [note] - included text on original image . - Applied with Stream2 (MJPEG). - Text Input only available with capital English & number.  Overlay Position – choose position in top & bottom ...
  • Page 25 VC58SMi USER MANUAL 4.3. Stream Setup [Picture 6] STREAM ☞ [참고] - Quality of service according to network & PC balance are derived from - Image size Resolution & Quality/Bit rate  [H.264] Resolution – image size  [H.264] Frame rate – number of image per Frame ...
  • Page 26 VC58SMi USER MANUAL 4.4. Audio Setup [Picture 7] Audio setup ☞ [참고] - Set fot Two-Way Audio - IP Camera Audio IN/OUT - PC Control Audio IN/OUT in LIVE View - Connect MIC in Audio input port, Connect Speaker in Audio output port - Audio input port (1), Audio output port(1) ...
  • Page 27 VC58SMi USER MANUAL 5. SETUP > Event Detection [MOTION AREA] [Picture 8] Motion detection ☞ [참고] - All changed value will be applied after click SAVE button. - You can edit Motion detection area by click and drag left Mouse button ...
  • Page 28 VC58SMi USER MANUAL 5.2. Notification [Picture 9] Set Notification ☞ [note] - To Set FTP server go to “NETWORK > FTP SERVER”. menu tree - To Set Mail server go to “NETWORK > SMTP”. menu tree - If when alarm trigger Video or Image will be transmit to related server/alarm out.
  • Page 29 VC58SMi USER MANUAL  [E-MAIL]  Event Type – Event Type  Interval Time – Interval Time  Num of Images – Num of Images  Attach Images – Attach Images  [FTP]  Event Type – Event Type ...
  • Page 30 VC58SMi USER MANUAL 5.3. Recording [Picture 10] Set recording ☞ [feature] - Check Recording tab to “ON”. - Set recording schedule. - Recording schedule can be set to 1 hour interval - [All] select all Schedule. - Pre Alarm -capacity, Post Alarm -time - Click “SAVE”...
  • Page 31 VC58SMi USER MANUAL 6. SETUP > USER Password Change [Picture 11] Se password ☞ [참고] - Password Change. - Changed password will be apply from the next Log in. - Password will be save by encryption algorithm  [Old Password] – Old Password ...
  • Page 32 VC58SMi USER MANUAL User Account [Picture 12] Acconut ☞ [note] - admin ID is not allowed Delete & Edit. - To change password admin ID go to SETUP>PASSWORD CHANGE - Support 16 Account. (include admin) - Selectable 3 ID group.
  • Page 33 VC58SMi USER MANUAL Group Management [Picture 13] Group Management ☞ [참고] - Selectable 3 ID group. - Mark required information. - All changed value will be applied after click SAVE button. - To categorize User ID by 3group go to “USER ACCOUNT”...
  • Page 34 VC58SMi USER MANUAL 7. SETUP > NETWORK Network Setting [Picture 14] network setting ☞ [note] - Static IP / DHCP. - If click “SAVE” button that System will be restart and reconnect to changed IP address (Static IP)  IP mode Supports two IP mode and IP settings will be change as IP mode IP 모드...
  • Page 35 VC58SMi USER MANUAL [Picture 15] DNS setting ☞ [참고] - Set DNS.  [First DNS] –First DNS address  [Second DNS] – Second DNS address   IP set in DNS server.   note)What is DNS? DNS (Domain Name Service) provides the translation of host names to IP addresses on your network.
  • Page 36 VC58SMi USER MANUAL DDNS [Picture 16] DDNS 설정 ☞ [note] - Set DDNS. - Enable/ Disable DDNS.  [ID] – DDNS 서버 아이디  [PASSWORD] – DDNS password  [HOST NAME] – DDNS host name  [Update Period] – DDNS update period DDNS ...
  • Page 37 VC58SMi USER MANUAL 7 NTP [그림 17] NTP setting ☞ [참고] - Set NTP. - Enable/Disable. -36-...
  • Page 38 VC58SMi USER MANUAL HTTP/HTTPS [Picture 18] HTTP setting ☞ [note] - Set HTTP Port. The default HTTP port number (80) can be changed to any port within the range 1024-65535. This is useful for e.g. simple security port mapping. - HTTPS (SSL). (Default Checked)
  • Page 39 VC58SMi USER MANUAL FTP Server [Picture 19] FTP setting ☞ [참고] - Set FTP Server.  [Server Address] – FTP server address  [ID] – FTP account ID  [PASSWORD] – FTP account password  [Port] – FTP Server port...
  • Page 40 VC58SMi USER MANUAL 7.7. SMTP [Picture 20] SMTP setting ☞ [Note] - Set SMTP Server & address. Enter the host names or addresses for your mail servers in the fields provided, to enable the sending of notifications and image/video email messages from the camera to predefined addresses via SMTP ...
  • Page 41 VC58SMi USER MANUAL 7.8. RTSP [Picture 21] RTSP setting ☞ [참고] Real Time Streaming Protocol - Set -40-...
  • Page 42 VC58SMi USER MANUAL 7.9. QOS [Picture 22] QOS setting ☞ [참고] - Set QOS (Quality Of Service). - Set by IP /Set by All IP MAX :10IP. - Step setting: IP/Port/Bandwith-> ADD -> SAVE -41-...
  • Page 43 VC58SMi USER MANUAL 7.10. WIRELESS [Picture 23] WIRELESS setting ☞ [note] - Set Wireless -42-...
  • Page 44 VC58SMi USER MANUAL  [AP List loading]  [AP connecting] -43-...
  • Page 45 VC58SMi USER MANUAL 7.11. CMS [Picture 24] CMS setting ☞ [note] - Set port to communication with CMS. (video/voice/event)  [AV Stream Port] – Video steaming port  [Event Port] – Video trigger port  [Two-way Audio Port] – Two-way Audio Port...
  • Page 46 VC58SMi USER MANUAL 8. SETUP > SYSTEM System Upgrade [Picture 25] System Upgrade [notes] Equipment must be maintained at power-on state -45-...
  • Page 47 VC58SMi USER MANUAL System Restart [Picture 26] System Restart ☞ [note] - system restart. - Reconnect automatically after 60 seconds -46-...
  • Page 48 VC58SMi USER MANUAL Factory Default [Picture 27] Factory Default [note] - Factory Default. - Please note that all entries are initialized -47-...
  • Page 49 VC58SMi USER MANUAL Export Setting [Picture 28] EXPORT ☞ [note] - Exporting All setting value. - Make setup file / Download.  [Make setup log file] -48-...
  • Page 50 VC58SMi USER MANUAL  [Download] [note] - Please carefully managed for download file. - If the file has been renamed can not be used -49-...
  • Page 51 VC58SMi USER MANUAL Import Setting [Picture 29] IMPORT ☞ [note] - Import setup file. - If upload finish and then system apply new setting value. - Reboot. -50-...
  • Page 52 VC58SMi USER MANUAL Date / Time [Picture 30] Date / Time ☞ [참고] - IP Camera Set time zone & date. -If NTP time was set that manually setting does not apply -51-...
  • Page 53 VC58SMi USER MANUAL Storage [Picture 31] SD card ☞ [note] - (SD Card) capacity/format/data information - Search image & video by Date.  [Show SD card capacity] -52-...
  • Page 54 VC58SMi USER MANUAL  [recording data]  [recording data play] – click left mouse button.  [back up data] – backup data ☞ [note] - May not be playing AVI file that not set automatically when you click the left mouse button on a PC and “Save as different name”...
  • Page 55 VC58SMi USER MANUAL System Log [Picture 32] system log ☞ [note] - : Click Search log after Select day & time - Display list system log and network log in/out(CMS)  [system log information] [2000-01-01 00:00:09] Network: client ipaddress => 118.46.219.82:, port => 12537 connected [2000-01-01 00:00:21] Network: client(118.46.219.82:12537) closed...
  • Page 56 VC58SMi USER MANUAL System Information [Picture 33] System Information ☞ [note] - Show system information & network information. - Support multi languages.  [Firmware Version] – information of Firmware Version  [Model Type] – information of Model Type  [Sensor Type] – information of Sensor Type ...
  • Page 57 VC58SMi USER MANUAL 9. SETUP > PTZ PTZ Setting [Picture 34] PTZ setting ☞ [note] - Set PTZ connect. - Set ID/Baudrate/Protocol.  [ID] – PTZ channel ID  [Baud rate] – RS485 Baud rate  [Protocol] – PTZ Protocol (Pelco-D, Pelco-P …)
  • Page 58 VC58SMi USER MANUAL PRESET Setting [Picture 35] PRESET setting ☞ [Note] - PTZ PRESET Set & renaming . - PRESET SAVE/DEL.  [List] – PRESET list  [Name] –current PRESET name can be create & edit  [GO] – go selected PRESET ...
  • Page 59 VC58SMi USER MANUAL Dimension(mm) 9. Specification Model VC58Mi Network Interface Ethernet 10/100Base-T (RJ-45) Network Network Protocol TCP/IP, UDP, DHCP, SMTP, HTTP, RTP, RTSP Image Device Sony 1/3“, 1.3M CMOS (Progressive Scan) Lens C/CS Mount lens Mechanical Iris Lens DC Iris Lens MIN.
  • Page 60 VC58SMi USER MANUAL Secondary : H.264 / M-JPEG (Simultaneous Dual) Resolution 1280 x720, 640 x 480, 320 x 240, Frame Rate 1 FPS ~ 30 FPS Selectable Bit Rate 30K BPS ~ 8M BPS Selectable Output Composite : 1 EA Algorithm G.711u...
