Billion BiPAC GS08 Datasheet

BiPAC GS08
8-port Gigabit Green Ethernet Switch
Expanding to a Gigabit network
The BiPAC GS08 featuring 8 ports 10/100/1000Mbps is designed to expand your Gigabit network. It is fully compliant with all
kinds of network protocols. Simply plug and play - you can connect the device with up to 8 computers or network-based devices
like PS3, Xbox 360 and Network Attached Storage (NAS) for applications such as gaming, video, music and data sharing.
Enhancing network performance
The BiPAC GS08 is on non-blocking architecture that supports every switch port at full-duplex capability, enabling all its 8 ports
to boost bandwidth up to a total 16Gbps backbone link to switched workgroup or a server fat-pipe link. It eliminates users
concern of bandwidth congestion. Its store-and-forward switching mode at full wire-speed for maximum performance ensures
low-latency and error-free transmission, thus efficiently saving users' time to enjoy multimedia applications with better network
performance.
Smart Power Saving
The BiPAC GS08 with integrated Smart Power Saving technology helps your network save power by up to 60%, thus efficient
for energy consumption and money saving. It automatically powers down ports when detecting no connection and plans different
power output for different cable lengths. The stylish mini-sized switch and its power adapter require little space on your desktop,
leaving more room for other equipment.
Features & Specifications
Standards
• IEEE802.3 10Base-T Ethernet
• IEEE802.3u 100Base-TX Fast Ethernet
• IEEE802.3ab 1000Base-T Gigabit Ethernet
• IEEE802.3x Flow Control
Network Data Transfer Rate
• 10Mbps (Half-duplex)
• 20Mbps (Full-duplex)
• 100Mbps (Half-duplex)
• 200Mbps (Full-duplex)
• 2000Mbps (Full-duplex)

Rich LED indicators

• Power: Green
• Link/Act: Green

Power Supply

• Input: 100~240V AC, 50~60Hz
• Output: 12VDC 1A
All the specifications are subject to change without prior notice.
Billion Electric Co., Ltd.
8F, No.192, Sec.2, Chung Hsing Road,
Hsin T ien City, Taipei County, 23146 Taiwan
www.billion.com
Features
• Back-pressure (Half-duplex)
• NWay protocol for speed and duplex
mode auto-detection
• Wire-speed packet filtering and
forwarding rate
• Store-and-forward architecture for
filtering fragment & CRC error packets
• Supports 4K MAC address
• 1M bits buffer memory
• 9K Bytes Jumbo frame
• Supports extensive LED indicators
for network diagnostics
• Total 16Gbps network data transfer rate
V.011409
TEL : +886-2-2914-5665
FAX : +866-2-2918-6731, +886-2-2918-2895
E-mail : sales@billion.com
Power Consumption
• 12 Watts maximum
Emission
• FCC Class A, CE, VCCI
Hardware Specifications
Physical Interface
• 8 x 10/100/1000Mbps
RJ-45 switching ports
Physical Specifications
• Dimensions (W, D, H):
6.08 " x 3.35 " x 1.02 "
(154.5 x 85 x 26 mm)
Operating Environment
• Operating temperature:
0 ~ 40 °C
• Operating Humidity:
10% ~ 90% (non-condensing)
NAS
XBOX
PS3
7 8 /ACT
6 LINK
5
4
2 3
1
BiPAC GS08
ER
POW
Internet
ADSL Router
Firewall
• 8 x 10/100/1000Mbps Full-duplex, auto
MDI/MDI-X ports
• Up to a total 16Gbps network data
transfer rate
• Smart power saving technology for efficient
energy consumption
• Store-and-forward architecture for
low-latency and error-free transmission
• NWay protocol for speed and duplex mode
auto-detection
• True plug and play installation
• Ideal for home and SOHO users
