SootheNeb NBL100 Operating Instructions

NBL100
Mesh Nebulizer
Dear SootheNeb NBL100 Owner:
Thank you for purchasing the SootheNeb NBL100, before using this product, please read the following
contents thoroughly and carefully.
If you have other questions regarding this product, please contact the place of purchase or call our
customer service line at 888.307.8188.
INTENDED USE
SootheNeb NBL100 is an ultrasonic (vibrating mesh) nebulizer system designed to aerosolize
physician-prescribed solution for inhalation by the patient, except for Pentamidine. The SootheNeb
NBL100 is intended for use by patients in a home care environment.
Cautions: Federal law restricts this device to only be sold by or on the order of a physician.
FEATURES
Delivers aerosol automatically or manually
Battery powered or AC adapter connection (optional)
Small nebulization particle size – approx. 5 microns
Convenient design – compact and lightweight. Ideal for traveling.
Short treatment time – with high nebulization rate
CONTENTS INCLUDED & DESCRIPTIONS
Before you start to use your SootheNeb NBL100,
please check that the following contents are included
in the package and not broken. The use of other
contents not listed may constitute a hazard.
INCLUDED PARTS
Unit Lid
1.
Mesh Cap
2.
Connector
3.
Connector Socket
4.
Indicator
5.
Nebulizer Unit
6.
1.
AC Adapter Jack
7.
2.
Mask or Mouthpiece Adapter
8.
Medication Cup
9.
3.
ON/OFF Button
10.
4.
Battery Cover
11.
Mouthpiece 5.
12.
2 "AA" Alkaline Batteries
13.
6.
OPTIONAL PARTS**
14. Mask 7.
AC Adapter
15.
NOTE
1. Mouthpiece and mask are intended for use by one user. DO NOT SHARE.
2. Accessories are consumable parts, e.g. mesh cap. Clean the accessories after each use and
replace with new accessories when they become dirty and obstructed.
3. Mask and AC Adapter may be provided separately, please contact your local dealer for
purchase, or contact our customer service line for more information.
SAFETY PRECAUTIONS
Do not wet the connector and connector socket (refer to Description of Part 3 & Part 4).
Use the equipment only for its intended use as described in the operating instructions. Do not use
attachments not recommended by the manufacturer. Use the AC Adapter (Input: AC, 100-240V
& Output: DC, 6V) provided by ForaCare, Inc.
Do not use the device under conditions of inter-hospital transport. This device is not intended for
transport use.
Use the equipment with medications only under the instruction of your physician.
Do not use the equipment if it has any damaged parts, or it has fallen into water.
Prior to using the equipment for the first time, or after storing it for an extended period, be sure to
clean all necessary parts as described in the cleaning instructions.
Do not use while bathing.
The unit should not be left unattended while plugged in or turned on.
Keep the unit out of reach of small unsupervised children. The small parts detached from the device
may be a choking hazard if inhaled or swallowed.
To prevent any dangers or hazards, please do not try to modify the device in any way.
Do not place the device in liquid, nor put it where it could fall into liquid. If the device becomes
wet, unplug the device before touching it.
Do not use the device if it is not working properly, or if it has suffered any damage.
Avoid dropping, smashing, hitting, or tapping the nebulizer unit or the mesh cap.
Please clean the nebulizer accessories after every use, or after storing for a period of time.
Do not expose the nebulizer to direct sunlight, high temperatures or humidity.
Performance information provided by the manufacturer in accordance with the standard EN
13544-1:2007 may not apply to drugs supplied in suspension or high viscosity form. Please consult
the drug supplier for such information.
311-7001200-035
Version 4.0 2017/11
Operating Instructions
14. 15.
8.
11.
9.
10.
12.
13.
IMPORTANT INFORMATION ABOUT INHALATION THERAPY
The device is ideally suitable for inhalation at home or when traveling.
Carry out inhalation in a quiet and relaxed state, and inhale slowly and deeply, so that the medication
can penetrate to the fine, deep bronchial tubes. Exhale normally.
OPERATING INSTRUCTIONS
Important information before use. These operating instructions provide important information to
help you use the device properly.
Ensure that all parts are clean and dry.
Before starting treatment, talk to your physician about the duration, dosage and frequency of use
of the nebulizer.
The indicator light will turn green when the device is working normally.
The device automatically turns off when idle for 15 minutes.
Unit Assembly and Usage
1. Pour the prescribed
medication slowly into
the medication cup.
The maximum capacity
is 5 ml.
3. Attach the mask or
mouthpiece adapter.
4. Attach the mask or the mouthpiece to the adapter.
5. Connect the AC adapter or go to step 6 if the batteries are
6. Press the ON/OFF button to begin treatment according to
7. To end the treatment, press the ON/OFF button to turn off.
DELIVERY MODE
This system provides you with two delivery modes: automatic or manual.
* AUTOMATIC AEROSOL DELIVERY
1. Press and release the
ON/OFF button. The unit
turns on and delivers
prescribed medication
continuously for up to 15
minutes.
* MANUAL AEROSOL DELIVERY
To deliver medication manually, press the ON/OFF button intermittently to accompany your breathing
rate.
1. Press and hold the
ON/OFF button for 2
seconds or longer to
begin medication
delivery.
Repeat step 1 and 2 for additional medication deliveries.
CLEANING AND MAINTENANCE
Cleaning of Nebulizer Accessories
Please clean your device accessories after each use.
Prior to cleaning, make sure you have some distilled water on hand and ensure that the device has
completed the last medicine delivery cycle and is completely turned off.
1. Remove the Mask or Mouthpiece and remove the Mask/Mouthpiece adapter from the Main Unit.
Rinse thoroughly and set aside to dry. Then remove the Mesh Cap counterclockwise from the
Medication Cup and keep the medication cup attached.
2. Attach the mesh
cap and screw it
tightly in clockwise
direction.
already installed.
the physician's instructions. See "Delivery Mode" for details
on automatic and manual deliveries.
2. Press the ON/OFF
button to switch off
the device and
terminate the
treatment.
2. Release the ON/OFF
button to stop
medication delivery.
