Countertop Machine
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yoghurt Machines
User Manual
Model: i18
SINGLE FLAVOUR | COUNTERTOP
Sales | Service | Supply | Installation | Worldwide
(Int.) +61 2 9612 0000 (Aus) 1800 784 448 (Fax) +61 2 9602 2606
info@brüllen.com.au www.brüllen.com.au
Advertisement
Table of Contents
Summary of Contents for Brullen i18
- Page 1 Australian Design - German Engineering Soft Serve Ice Cream & Frozen Yoghurt Machines User Manual Model: i18 SINGLE FLAVOUR | COUNTERTOP Sales | Service | Supply | Installation | Worldwide (Int.) +61 2 9612 0000 (Aus) 1800 784 448 (Fax) +61 2 9602 2606...
-
Page 2: Table Of Contents
13. Storage of Machine when not in use ....................15 14. Warranty ............................... 15 15. Troubleshooting ........................... 16 Refrigeration Fault ........................16 15.1. 15.2. Product Dispensing Issues ......................16 15.3. Miscellaneous Issues ........................17 15.4. Error Codes ..........................18 i18 User Manual V11 120219 Page 2 of 19... -
Page 3: Operational Environment
(For floor standing models only) MACHINE WITH AIRCOOLED CONDENSER • Machines with air-cooled condenser must be installed no closer than 50 cm to any wall in order to allow free air circulation around the condenser. i18 User Manual V11 120219 Page 3 of 19... -
Page 4: Staff And Operators Safety & Hygiene Standards
Warning Danger from Moving Parts • Ensure that staff and all operators are aware of the presence of moving parts and the risk of injury from failure to comply with safety regulations. i18 User Manual V11 120219 Page 4 of 19... -
Page 5: Maintenance Engineer
Brullen Engineer or a qualified skilled engineer. Failure to do so may void warranty Equipment Testing • After installing the equipment, it is important to make sure all the functions of your new BRÜLLEN i18 operate smoothly. A start up system test should be performed before equipment is put into production mode. •... -
Page 6: Diagrams Of Parts Listing
Diagrams of parts listing 9.1. Diagram description of parts i18 User Manual V11 120219 Page 6 of 19... - Page 7 9.2. Exterior Panels and Circuit Box i18 User Manual V11 120219 Page 7 of 19...
- Page 8 9.3. Mix Hopper and Freezing Cylinder i18 User Manual V11 120219 Page 8 of 19...
- Page 9 9.4. Dispensing Head i18 User Manual V11 120219 Page 9 of 19...
- Page 10 9.5. Quartet Beater Assembly i18 User Manual V11 120219 Page 10 of 19...
- Page 11 9.6. Control Panel i18 User Manual V11 120219 Page 11 of 19...
-
Page 12: Cleaning Equipment
Each scrapper blade is marked A or B – and should be assembled with each Quartet Beater having an A scrapper blade and a B scrapper blade – not A and A or B and B. If you are unsure ring the Brullen customer phone number. -
Page 13: Equipment Operations
Brullen Pty Ltd take no responsibility for setting cleaning schedules. Brullen Pty Ltd makes no recommendations regarding cleaning schedules. Brullen Pty Ltd recommends if you are in anyway unsure of what is an appropriate cleaning schedule CONTACT YOUR MIX MANUFACTURER DIRECTLY AND ASK THEM FOR ASSISTANCE. -
Page 14: Preventative Maintenance
12.6. Recommended 12 monthly service and inspection by Certified Brüllen Technician: • Inspect and if required replace Gearbox Gasket • General inspection of unit i18 User Manual V11 120219 Page 14 of 19... -
Page 15: Storage Of Machine When Not In Use
13.2. Your local Brullen Distributor can perform this storage service for you. Wrap detachable parts of the machine such as quartet beater, scrapper blades, pistons and dispenser head door, and place them in a protected dry place. -
Page 16: Troubleshooting
The hardness setting is Product is too hard allow one minute for change to too high take effect Product is too soft Hardness needs Adjust hardness settings. adjustment. Allow for adequate air flow i18 User Manual V11 120219 Page 16 of 19... -
Page 17: Miscellaneous Issues
The quartet beater repair or replace the The freezing cylinder Scoring assembly is bent. quartet beater and to correct walls are scored the cause of insufficient mix in the freezing cylinder. i18 User Manual V11 120219 Page 17 of 19... -
Page 18: Error Codes
Dispense Head sensor broken Change Dispense Head Sensor “CL” is displayed Press STOP button, fill hoppers Mix low lock Mix levels to low “CU” Error old and continue production board i18 User Manual V11 120219 Page 18 of 19... - Page 19 Call us today, we are happy to discuss your needs. Sales | Service | Supply | Installation | Worldwide (International) +61 2 9612 0000 (Australia) 1800 784 448 (Fax) +61 2 9602 2606 info@brüllen.com.auwww.brüllen.com.au i18 User Manual V11 120219 Page 19 of 19...
