AL20RSW&AL60RSW&
AL60CSW&AL100CSW
AL20RSW
156205
CAN ICES-5(B)/NMB-5(B)
2000 Lumen
Rechargeable
LED Work Light
High efficiency COB LED
400/800/1200/1600
/2000 lumen
2.5-15h running time
3-4h charging time
7.2V 6000mAh Li-ion battery
Power bank output 5V 1A
IP67
High Efficiency COB LED
• 5 selectable brightness levels
• Display indicates which level is selected
Bluetooth Control (for model AL60RSW, AL60CSW and AL100CSW)
• Brightness can be controlled using exclusive Southwire mobile app
• Details on how to download the app are listed below
Multi-functional Design
• Power bank function: use built-in USB outlet to charge mobile devices. Output is 5V DC, 1A.
• Indicator readout shows remaining battery life.
• Model AL20RSW includes powerful magnets to allow the lamp to be temporarily mounted to a metal surface.
Durable Design
• High quality aluminum housing is impact resistant
• IP67 dust and water resistant
Work Light Series
User Manual
AL60RSW
156205
FCC ID:2AENI-AL60RSW
IC:20144-AL60RSW
CAN ICES-5(B)/NMB-5(B)
6000 Lumen
Rechargeable
LED Work Light
High efficiency COB LED
1200/2400/3600/4800
/6000 lumen
Rechargeable & cable
1-6h running time
3-4h charging time
10.8V 6000mAh Li-ion
battery
Power bank output 5V 1A
16ft 18/2 SJTOW cable
IP67
AL60CSW
256087
FCC ID:2AENI-AL60CSW
IC:20144-AL60CSW
CAN ICES-5(B)/NMB-5(B)
6000 Lumen
Corded LED
Work Light
High efficiency COB LED
1200/2400/3600/4800
/6000 lumen
Power bank output 5V 1A
16ft 18/3 SJTOW cable
IP67
AL100CSW
256087
FCC ID:2AENI-AL100CSW
IC:20144-AL100CSW
CAN ICES-5(B)/NMB-5(B)
10000 Lumen
Corded LED
Work Light
High efficiency COB LED
2000/4000/6000/8000
/10000 lumen
Power bank output 5V 1A
16ft 18/3 SJTOW cable
IP67
Advertisement
Related Manuals for Southwire Work Light Series
Summary of Contents for Southwire Work Light Series
- Page 1 • 5 selectable brightness levels • Display indicates which level is selected Bluetooth Control (for model AL60RSW, AL60CSW and AL100CSW) • Brightness can be controlled using exclusive Southwire mobile app • Details on how to download the app are listed below Multi-functional Design •...
- Page 2 PRODUCT COMPLIANCE Users of this product are cautioned not to make modifications or changes that are not approved by Southwire Company, LLC. Doing so may void the compliance of this product with applicable laws and regulatory requirements and may result in the loss of the user’s authority to operate the equipment.
- Page 3 AL20RSW&AL60RSW& AL60CSW&AL100CSW WARNING • Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. • The warnings, cautions, and instructions in this manual cannot cover all possible conditions or situations that could occur. Exercise common sense and caution when using this tool.
-
Page 4: Claims Procedure
Three (3) Year Limited Product Warranty This limited warranty is provided only to the original purchaser of LED Work Light fixtures sold under the Southwire® brand name and should be retained for your records. By using this light fixture, you as the original purchaser are asked to carefully read and agree to the following terms and conditions of this Limited Product Warranty ("Limited Warranty") before you use the product. - Page 5 Carrollton, GA 30117 3. The returned LED Work Light fixture will be tested by Southwire Company, LLC and the results of this test, together with the technical assessment(s) will be reviewed to determine whether the fixture failed to perform properly. You have the right to obtain copies of all reports at your expense.
