Summary of Contents for Inrevium TB-FMCH-HDMI4K
- Page 1 TB-FMCH-HDMI4K Hardware User Manual TB-FMCH-HDMI4K Hardware User Manual Rev.2.04 Rev.2.04...
- Page 2 TB-FMCH-HDMI4K Hardware User Manual Revision History Version Date Description Publisher 1.00 2014/12/29 Initial release 2.00 2015/06/30 Updated. Released. 2.01 2015/08/10 -Updated support web link on page 8 -removed table link on page 28 -Updated Xilinx support link on page 29...
-
Page 3: Table Of Contents
HDMI Five Volts Power ......................14 Connectors ..........................15 8.1. HPC FMC Connector to Main Board ..................15 8.2. HPC FMC Connector for the Extender TB-FMCH-HDMI4K Card ........... 19 8.3. HDMI Connectors ........................21 I2C Busses ..........................22 9.1. FMC I2C EEPROM ........................22 9.2. - Page 4 Figure 4-1 TB-FMCH-HDMI4K Block Diagram .................11 Figure 5-1 External View of TB-FMCH-HDMI4K (Component Side)..........12 Figure 5-2 External View of TB-FMCH-HDMI4K (Solder Side) ............12 Figure 6-1 TB-FMCH-HDMI4K Board Dimensions (mm) ..............13 Figure 7-1 TB-FMCH-HDMI4K Power Supply Structure ..............14 Figure 7-2 HDMI Source and Sink 5 Volt Supplies ................
- Page 5 TB-FMCH-HDMI4K Hardware User Manual Introduction Thank you for purchasing the TB-FMCH-HDMI4K board. Before using the product, be sure to carefully read this user manual and fully understand how to correctly use the product. First read through this manual, and then always keep it handy.
- Page 6 TB-FMCH-HDMI4K Hardware User Manual Warning In the event of a failure, disconnect the power supply. If the product is used as is, a fire or electric shock may occur. Disconnect the power supply immediately and contact our sales personnel for repair.
- Page 7 TB-FMCH-HDMI4K Hardware User Manual Caution Do not use or place the product in the following locations. • Humid and dusty locations • Airless locations such as closet or bookshelf • Locations which receive oily smoke or steam • Locations exposed to direct sunlight •...
-
Page 8: Related Documents And Accessories
Hirosugi 2. Overview The TB-FMCH-HDMI4K is functionally divided into a source circuit and a sink circuit. Each side is designed to be compatible with the HDMI 2.0 specification, with an individual TMDS channel throughput of up to 6 Gbps thus enabling support of 4K resolution at 60fps. The source circuit is based on the Texas Instruments SN65DP159 D++ to TMDS Retimer. - Page 9 TB-FMCH-HDMI4K Hardware User Manual may or may not limit functionality (IP core dependent). Note: The TB-FMCH-HDMI4k does not support the HDMI Ethernet and Audio Return Channel (HEAC) on either HDMI interface. Note: VIO_B_M2C is directly connected to 3P3V. User is responsible for making sure that the carrier card can accept a VIO_B_M2C of 3.3V nominal.
-
Page 10: Features
TB-FMCH-HDMI4K Hardware User Manual 3. Features HDMI Source Device Texas Instruments SN65DP159RSB FMC Main Connector Samtec ASP-134488-01 FMC Extender Connector Samtec ASP-134486-01 HDMI Connectors Samtec HDMR-19-01-S-SM FPGA GPIO Signal Level 1.2V through 3.3V using voltage level translators or AC coupling... -
Page 11: Block Diagram
TB-FMCH-HDMI4K Hardware User Manual 4. Block Diagram Figure 4-1 shows the TB-FMCH-HDMI4K block diagram. The FMC-HPC main connector is mounted on the component side of the board. The FMC-HPC extender connector is mounted coincident with the main connector on the opposite side of the board. -
Page 12: External View Of The Board
5. External View of the Board HDMI Sink Connector HDMI Source Connector HPC FMC Connector for Main Board Figure 5-1 External View of TB-FMCH-HDMI4K (Component Side) 3.3V LED HPC FMC Connector for Second HDMI4K Figure 5-2 External View of TB-FMCH-HDMI4K (Solder Side) Rev.2.04... -
Page 13: Board Specification
TB-FMCH-HDMI4K Hardware User Manual 6. Board Specification The following shows the TB-FMCH-HDMI4K board physical specifications. External Dimensions 76.50 mm long x 69.00 mm wide Number of Layers 10 layers Board Thickness 1.6 mm Material Megtron 4 FMC Main Connector Samtec ASP-134488-01... -
Page 14: Supplying Power To The Board
TB-FMCH-HDMI4K Hardware User Manual 7. Supplying Power to the Board Figure 7-1 shows the TB-FMCH-HDMI4K power supply structure. There is one LDO regulator to generate 1.1 volts for the SN65DP159 and one switching regulator for 5.0 volts. Both use 3.3 volts from the carrier card to generate the lower voltages. -
Page 15: Connectors
There are four connectors on the FMC. One HPC FMC connector provides connectivity to the Main Board (J3) and another HPC FMC connector (J8) is for a second (stacked) TB-FMCH-HDMI4K, enabling additional HDMI source and sink ports. The other two connectors are the HDMI source and sink connectors, located on the front edge of the card. -
Page 16: Table 8-1 Hpc Fmc Main Board Connector Pin Assignment
TB-FMCH-HDMI4K Hardware User Manual Table 8-1 HPC FMC Main Board Connector Pin Assignment Schematic Signal Name VITA 57.1 Name Direction Type Description HDMI Source Signals TX_CH0_MGT_P DP0_C2M_P SN65DP159 channel 0 input TX_CH0_MGT_N DP0_C2M_N TX_CH1_MGT_P DP1_C2M_P SN65DP159 channel 1 input TX_CH1_MGT_N... -
Page 17: Rev.2.04
TB-FMCH-HDMI4K Hardware User Manual Schematic Signal Name VITA 57.1 Name Direction Type Description CLK_LVDS_N CLK0_M2C_N Si5324 CKOUT2 LVDS CLKIN_LVDS_P LA00_CC_P LVDS Si5324 CKIN1 CLKIN_LVDS_N LA00_CC_N REF_CLK_RST_FPGA_N LA10_P LVTTL (VADJ) Si5324 reset CLKIN_VALID LA02_P LVTTL (VADJ) Si5324 INT_C1B PLL_LOL LA02_N LVTTL (VADJ) -
Page 18: Rev.2.04
TB-FMCH-HDMI4K Hardware User Manual Schematic Signal Name VITA 57.1 Name Direction Type Description CLK_EX_I2C_TX_SCL LA28_P LVTTL OD (VADJ) Source DDC I2C EX_I2C_TX_SDA_OD LA28_N BI-DIR LVTTL OD (VADJ) EX_TX_HDMI_EN LA23_P LVTTL (VADJ) SN65DP159 OE CLK_EX_I2C_CTL_SCL LA01_CC_P LVTTL OD (VADJ) I2C for Si5324,... -
Page 19: Hpc Fmc Connector For The Extender Tb-Fmch-Hdmi4K Card
TB-FMCH-HDMI4K Hardware User Manual 8.2. HPC FMC Connector for the Extender TB-FMCH-HDMI4K Card The HPC FMC connector used to mate to the extender (stacked) FMC uses Samtec ASP-134486-01. Table 8-2 shows the FMC extender connector pin assignment. Table 8-2 HPC FMC Extender Board Connector Pin Assignment Schematic Signal Name VITA 57.1 Name... - Page 20 TB-FMCH-HDMI4K Hardware User Manual Schematic Signal Name VITA 57.1 Name Direction Type Description EX_CLK_LVDS_N CLK0_M2C_N EX_CLKIN_LVDS_P LA00_CC_P LVDS Si5324 CKIN1 EX_CLKIN_LVDS_N LA00_CC_N EX_REF_CLK_RST_N LA10_P LVTTL (VADJ) Si5324 reset EX_CLKIN_VALID LA02_P LVTTL (VADJ) Si5324 INT_C1B EX_PLL_LOL LA02_N LVTTL (VADJ) Si5324 LOL...
-
Page 21: Hdmi Connectors
TB-FMCH-HDMI4K Hardware User Manual 8.3. HDMI Connectors The HDMI connectors use Samtec HDMR-19-01-S-SM. Table 8-3 shows the HDMI Source connector (J1) pin assignments and Table 8-4 shows the HDMI Sink connector (J2) pin assignments. Table 8-3 HDMI Source Connector (J1) -
Page 22: I2C Busses
TB-FMCH-HDMI4K Hardware User Manual Table 8-4 HDMI Sink Connector (J2) Pin # Schematic Signal Name Name Description RX_TMDS_D2_P TMDS_DATA2_P TMDS receive data 2+ TMDS_SHLD2 TMDS receive data 2 shield RX_TMDS_D2_N TMDS_DATA2_N TMDS receive data 2- RX_TMDS_D1_P TMDS_DATA1_P TMDS receive data 1+... -
Page 23: I2C Control Bus
TB-FMCH-HDMI4K Hardware User Manual verification, and configuration of Main Board parameters. The contents of the EEPROM are available in Appendix A: FMC I2C EEPROM Contents. Note: The user must be cognizant that the FMC I2C EEPROM is always write-enabled. As it contains critical information required for correct operation, one must never overwrite the factory settings. -
Page 24: Hdmi Ddc
Figure 9-1 HDMI Source and Sink DDC The TB-FMCH-HDMI4K is shipped with the J4, J5, J6, and J7 jumpers placed in the normal operation positions. They can be moved for test purposes. The source DDC connections to the TPD5S116 are for ESD protection and provide pull-up resistors. -
Page 25: Hdmi Source Clock
TB-FMCH-HDMI4K Hardware User Manual also be used to synchronously generate the video clocks. The CKIN2 input is not used. Figure 10-1 shows how the Si5324 is connected to the main board and how the extender FMC Si5324 is connected. Please refer to the Si5324 data sheet for how to set the registers to produce the desired clocks. -
Page 26: Hdmi Sink Clock
Two three-pin headers (J11 and J13) provide a bypass loopback for test purposes. Figure 11-1 shows how the HPD signals are connected and how the extender FMC HPD signals are connected. Note: The TB-FMCH-HDMI4k does not support the HDMI Ethernet and Audio Return Channel (HEAC) on either HDMI interface. -
Page 27: Consumer Electronics Control (Cec)
TB-FMCH-HDMI4K Hardware User Manual HDMI Source HPD SRC HPD SINK no connection J3 FMC Connector SN65DP159 for Main Board LA31_N HPD SYS HPD CON CEC CON A3 LA31_P CEC SYS TPD5S116 LA30_N (EXT TX HPD) LA30_P (EXT TX CEC) HDMI Sink... -
Page 28: Test Points
TB-FMCH-HDMI4K Hardware User Manual protection and are designed for HDMI 2.0, as well as for other high speed interfaces. IEC 61000-4-2 level 4 ESD protection for the single-ended HDMI source and sink signals is provided by two Texas Instruments TPD5S116 HDMI companion chips. -
Page 29: Demonstration
TB-FMCH-HDMI4K Hardware User Manual Table 14-1 Test Points Test Point Schematic Signal Name Nominal Voltage Component Pin VCC_3V3 3.3V U11-1, 2 VCC_12V 12.0V J3-C35, C37 3V3_AUX 3.3V J3-D32 FMC_VADJ 1.2V to 3.3V J3-E39, F40, G39, H40 VCC_1V1 1.1V U11-9, 10 VCC_5V0 5.0V... -
Page 30: Appendix A: Fmc I2C Eeprom Contents
TB-FMCH-HDMI4K Hardware User Manual Appendix A: FMC I2C EEPROM Contents The following table describes the contents of the FMC I2C EEPROM as programmed at the factory. Table 16-1 FMC I2C EEPROM Contents Board Information Field Size Data Language Code Date / Time of Manufacture <Variable>... - Page 31 TB-FMCH-HDMI4K Hardware User Manual DC Load Record – VADJ Field Size Data Description Output Information 0x00 Bit map containing output number, etc. (VADJ) Nominal Voltage 0x00B4 In units of 10mV (1.8V) Minimum Voltage 0x0078 In units of 10mV (1.2V) Maximum Voltage 0x014A In units of 10mV (3.3V)
- Page 32 TB-FMCH-HDMI4K Hardware User Manual DC Output Record – VREF_A_M2C Field Size Data Description Output Information 0x04 Bit map containing output number, etc. Nominal Voltage 0x0000 In units of 10mV Minimum Voltage 0x0000 In units of 10mV Maximum Voltage 0x0000 In units of 10mV...
-
Page 33: Appendix B: Headers, Factory Default, And Orientation
TB-FMCH-HDMI4K Hardware User Manual Appendix B: Headers, Factory Default, and Orientation The following depicts the factory default header jumper positions and clarifies the pin numbering and orientation of the headers. Figure 17-1 Default Jumper Positions and Header Orientation Rev.2.04... - Page 34 TB-FMCH-HDMI4K Hardware User Manual inrevium Company http://solutions.inrevium.com/ URL: http://solutions.inrevium.com/jp/ E-mail: psd-support@teldevice.co.jp HEAD Quarter: Yokohama East Square, 1-4 Kinko-cho, Kanagawa-ku, Yokohama City, Kanagawa, Japan 221-0056 TEL: +81-45-443-4016 FAX: +81-45-443-4058 Rev.2.04...
