INDEX MECHANISMS Synchro sliding................................3 Synchro..............................4 ARMS BR02......................................5 BR03.....................................6 BR04......................................7,8 BR06....................................9 BR09.................................10,11 BR10.................................12 WHEELS Auto-braking hollow wheel...........................13... -
Page 3: Synchro Sliding
SYNCHRO SLIDING MECHANISM GAS LIFT Lifting the lever opens the gas column. With no weight, the chair rises. With the user seated, the chair lowers. When the lever is released, the gas column is closed. ADJUSTING THE INCLINATION OF THE SEAT/BACKREST (SYNCHRO) At the end of the gas lift lever is a button. -
Page 4: Synchro
SYNCHRO MECHANISM GAS LIFT Lifting the lever opens the gas column. With no weight, the chair rises. With the user seated, the chair lowers. When the lever is released, the gas column is closed. ADJUSTING THE INCLINATION OF THE SEAT/BACKREST (SYNCHRO) At the end of the gas lift lever is a button. -
Page 5: Br02
BR02 HEIGHT ADJUSTMENT Press the arm button (arrowed) and without releasing it, adjust the height of the arm. Once in the desired position, release the button. -
Page 6: Br03
BR03 HEIGHT ADJUSTMENT Press the arm button (arrowed) and without releasing it, adjust the height of the arm. Once in the desired position, release the button. MULTIPOSITION ADJUSTMENT Press the arm button (arrowed) and without releasing it, adjust the position of the armrest, both longitudinally and transversally. -
Page 7: Br04
BR04 HEIGHT ADJUSTMENT Press the arm button (arrowed) and without releasing it, adjust the height of the arm. Once in the desired position, release the button. 30º 30º ADJUSTMENT OF ARMREST DEPTH By pressing the armrest firmly, it can be moved forward or backwards to the desired position. It moves 3 cm in each direction. - Page 8 BR04 30º 30º ROTATION OF THE ARMREST By pressing the armrest firmly, it can be turned to the inwards or outwards, to the desired position. 30º 30º REGULATION OF THE WIDTH OF THE ARMS By loosening the screw located at the bottom, the arms can be moved to the desired position. The lower screw can now be retightened.
-
Page 9: Br06
BR06 HEIGHT ADJUSTMENT Press the arm button (arrowed) and without releasing it, adjust the height of the arm. Once in the desired position, release the button. -
Page 10: Br09
BR09 HEIGHT ADJUSTMENT Press the arm button (arrowed) and without releasing it, adjust the height of the arm. Once in the desired position, release the button. 30º 30º ADJUSTMENT OF ARMREST DEPTH By pressing the armrest firmly, it can be moved forward or backwards to the desired position. It moves 2,5 cm in each direction. -
Page 11: Br09
BR09 30º 30º ROTATION OF THE ARMREST By pressing the armrest firmly, it can be turned to the inwards or outwards, to the desired position. 30º 30º REGULATION OF THE WIDTH OF THE ARMS The lever located in the lower part of the arm can be lowered, allowing the arm to be located in the desired position. -
Page 12: Br10
BR10 HEIGHT ADJUSTMENT Press the arm button (arrowed) and without releasing it, adjust the height of the arm. Once in the desired position, release the button. 30º 30º 30º 30º REGULATION OF THE WIDTH OF THE ARMS The lever located in the lower part of the arm can be lowered, allowing the arm to be located in the desired position. -
Page 13: Auto-Braking Hollow Wheel
AUTO-BRAKING HOLLOW WHEEL The adjustable safety braking system allows the seat to lightly brake when the user rises from the chair, to prevent the chair moving when not in use. There is a screw in the lower mechanism which adjusts the braking force or even de-activates it completely.
