- Page 1 ECOFEL /KB1-24CE BOILER SRVICE MANUAL ADVANCED CLIMATE TECHNOLOGIES PUBLICATION NO: K05-08 Revision Date: 29.02.2008, No: 0...
-
Page 3: Table Of Contents
ECOFEL BOILER SERVICE MANUAL Contents Ecofel KB1-24C Contents ................................1 Product Identification ............................2 Advantages ..............................3 Technical Specifications ..........................4 Safety Measures............................5 Detailed view diagram ..........................6 Piping Circuit Diagram ..........................6 Functional Components ..........................7 Fan ................................7 Air Pressure Switch ............................7 Burner................................7 Circulation Pump ............................7 Gas Valve ..............................8 Expansion Tank ............................8 Main Heat Exchanger ............................8... -
Page 4: Ecofel Kb1-24C
ECOFEL BOILER SERVICE MANUAL ECOFEL KB1-24C(E) 1. Product Identification: ECOFEL Code Expansion ECOFEL Code Expansion ECOFEL KB1-24C(E) Name of the wall type appliance Conventional boiler Heat exchanger type Version Capacity 24 kW Exhaust gas type Integrated hot usage water - 2 - Revision Date: 29 February 2008, Rev. -
Page 5: Advantages
As optional equipment, room thermostat can be connected. 10. TSE Certificated, efficient and widespread service within 24 hours is guaranteed. 11. For Airfel Ecofel and Weili Ecofel models, 3 years free, total 10 years original spare parts and service guarantee. - 3 -... -
Page 6: Technical Specifications
ECOFEL BOILER SERVICE MANUAL 3. Specifications: KB1-24 CE Gas Type Natural gas - LPG General Specifications UNITS VALUES Max. / Min. Heating Capacity 24,3 - 8,00 Max. Usage Water Capacity 24,3 Electrical Power Watts Supply Voltage Volts Electrical Protection Class IP X4D Combustion Efficiency / Thermal Efficiency (80-60ºC) 93,01 / 92,1... -
Page 7: Safety Measures
ECOFEL BOILER SERVICE MANUAL 4. Safety Measures: 4.1 Flue Kit Safety System: It is controlled by the differential pressure switch (pressure switch). 4.2 Pump Anti-blockage system: In case the boiler is not operated for a long time, to prevent jamming of the circulation pump it is activated every 24 hours for 30 seconds. -
Page 8: Detailed View Diagram
ECOFEL BOILER SERVICE MANUAL 5. Detailed View Diagram: Heater return piping Cold water inlet Gas inlet Usage hot water outlet Heater stream piping Gas valve Usage water temperature sensor Heater water temperature sensor Ignition electrode Burner Heat exchanger Pressure switch Expansion tank Limit thermostat Ionization electrode... -
Page 9: Functional Components
Circulation pump is mounted on the return line of the heating circuit; its function is to circulate the water in the closed system during heating and usage water production. In the body of the circulation pump there is an automatic air purger. Circulation pump used in Airfel boilers has 5 mSS total head. HEATER CIRCUIT CIRCULATION PUMP... -
Page 10: Gas Valve
ECOFEL BOILER SERVICE MANUAL 6.5 Gas Valve: Honeywell Moduplus VK4105 model gas valve is used on the boiler. There are 2 safety and 1 regulating valves. Safety valves are mechanically connected in series, however electrically they function as if they are parallel connected. The valve’s having two coils connected in parallel electrically, but in series mechanically is designed to obtain a safer structure. -
Page 11: Hydraulic Block
ECOFEL BOILER SERVICE MANUAL 6.8 Hydraulic Block: Flow Control Safety Valve Component 3 Bars Water Pressure Pressure Switch Pump Water Filler Tap Flow Control System 6.9 Automatic Bypass system: It is located in the right hydraulic block. Copper By-Pass pipe provides passage between heater stream and right hydraulic block. -
Page 12: Limit Thermostat
ECOFEL BOILER SERVICE MANUAL 6.11 Limit Thermostat: It is mounted on main heat exchanger outlet pipe via a clip. It prevents damage to the boiler due to overheat. Limit thermostat shuts down the boiler when water temperature at main heat exchanger outlet reaches 102ºC (±4ºC). -
Page 13: Flow Limiter
ECOFEL BOILER SERVICE MANUAL 6.15 Flow Limiter: Function of the flow limiter is to reduce the water flow at the inlet of usage water heat exchanger. With its o-ring inner structure, it limits the quantity of water flowing into the boiler for heating with 10 l/min. 6.16 Combustion Chamber: The walls of the combustion chamber are bended from sheet metal so as to allow the placement of mineral wool. -
Page 14: Safety Valve
ECOFEL BOILER SERVICE MANUAL 6.19 Safety Valve: Its function is to protect the heater piping and the boiler against pressure increases due to volume increase of the heated water. If the water pressure in the heater piping exceeds 3 bars, the spring in the safety valve pushes the valve and opens automatically. Thus, the pressure in the piping is reduced. -
Page 15: Operation In Heater Mode
ECOFEL BOILER SERVICE MANUAL 7. Operation in Heater Mode: When the boiler is in the heater operation mode it checks all circuit components. If there is water pressure of more than 0.8 bar in the boiler, circulation pump starts working. The main card compares the heating water temperature data coming from the stream sensor with the temperature set by the user via the heater temperature adjustment button on the front panel. - Page 16 ECOFEL BOILER SERVICE MANUAL 8. Operation in Usage Water Mode: When a hot water tap is turned on while the boiler is in heater or usage water mode and when water flow rate from the flow control switch is more than 0.3 bar (2.7 l/min), the wheel within the flow control rotates and informs the flow sensor.
-
Page 17: Control Panel
ECOFEL BOILER SERVICE MANUAL 9. Control Panel: Item Nr. Symbol Function Description Explanation Used for daily or weekly programming of the operation time of the Program timer (Optional) boiler. Indicates heater outlet water temperature and closed circuit water Thermo-manometer pressure. It should be around 1.5 bars. -
Page 18: Product Label
ECOFEL BOILER SERVICE MANUAL 9.1. Product Label: In ECOFEL KB1-24CE model boilers, declaration label is located at the right side of the appliance. All characteristic data and serial number (production date, production code) of the appliance are given on the declaration label. -
Page 19: Installation
ECOFEL BOILER SERVICE MANUAL 10.2 Installation: A. Mounting the Suspension Hook of the Appliance • Place the template on the wall. • Mark the fixation points. • Remove the template and drill the marking points on the wall. • Fix the suspension hook on the wall with dowels. •... -
Page 20: Homocentric Flue Kit Application
ECOFEL BOILER SERVICE MANUAL 10.4 Homocentric Flue Kit Application: In homocentric (Standard) flue kit connections, two metal rings for limiting the exhaust gas pipe are supplied in the user’s manual bag. Depending on the flue kit length, the corresponding ring should be placed or installed in the exhaust gas pipe. -
Page 21: Natural Gas - Lpg Conversion
ECOFEL BOILER SERVICE MANUAL 10.6 NG-LPG Conversion: • During conversion shut off the electrical fuse and gas valve of the boiler to avoid hazards. • Dismantle the outer box and combustion chamber covers. • According to the conversion gas type install 12 injectors suitable to the diameters specified in the tables. •... -
Page 22: Gas Valve Measurement Points
ECOFEL BOILER SERVICE MANUAL 10.8 Gas valve measurement points: Gas valve outlet, burner man- Brand : Honeywell ifold connection Model : VK41105 M V7335A Modulation Range : 30 mA - 165 mA Max. Operational Pressure : 60 mbar Power Supply : 230 V Outlet pressure measurement point... -
Page 23: Electrical Connections
ECOFEL BOILER SERVICE MANUAL 11.1 Electrical Connections: • Electrical connection cables of Ecofel boilers should be connected to a 3A circuit breaker. • 220V and 50Hz power supply should be provided for the boiler. In case these conditions are not satisfied, voltage regulator should be used. -
Page 24: Electrical Measurements
ECOFEL BOILER SERVICE MANUAL 11.3 Electrical Measurements: NTC Sensor ELECTRICAL MEASUREMENT TABLE Heater P2 socket 3-4 Usage water P5 socket 1-6 MEASUREMENT Temperature ºC Resistance KΩ VALUES MEASUREMENT COMPONENT NAME ENDS RESIST- VOLTAGE ANCE P9 SOCKET 220 AC 105 Ω ENDS NO. -
Page 25: Programming Of Parameters
ECOFEL BOILER SERVICE MANUAL 12.1 Programming the Parameters: To start parameter programming procedure: a) Turn the R80 potentiometer to Test and R81 potentiometer to Summer modes. b) Within 2 seconds set R81 to OFF, SUMMER – OFF, SUMMER and finally to any value in winter mode respectively. c) CR6, CR7 and CR8 leds blink simultaneously for 2 seconds. -
Page 26: Switching To Test Mode
ECOFEL BOILER SERVICE MANUAL 12.2 Switching to Test Mode: Test Mode Access Procedure: • Bring R80 to Test Mode and R81 to Summer positions. • Using R81, select UW OFF – TEST MODE / UW OFF TEST MODE in 2 seconds. Leave the button in any usage water temperature. -
Page 27: Failure Codes And Solution Techniques
ECOFEL BOILER SERVICE MANUAL 13. Failure Codes and Solution Techniques: By means of three leds on the control panel of the boiler, failures are diagnosed and the user is warned. Possible failure situations and led status are shown in the table below. Green Led Red Led Green Led... -
Page 28: Failure Solution Techniques
ECOFEL BOILER SERVICE MANUAL 3.1 Failure Solution Techniques: ⇒ Flame Cut off Ignition or gas supply error. In this case red led lights steadily. Solution: Check whether the gas valve is open, “RESET” to restart the boiler and perform ignition. Gas pressure is checked through gas valve inlet control nozzle. -
Page 29: Accessories
ECOFEL BOILER SERVICE MANUAL ⇒ Heater Circuit Water Pressure is Inadequate There is no adequate water in the heater system. In this case led blinks and led lights steadily. Solution: Primary circuit water pressure is checked. If it is below 0.8 bars, water pressure is increased / described to the customer. -
Page 30: Spare Parts Exploded View
ECOFEL BOILER SERVICE MANUAL SPARE PARTS EXPLODED VIEW ECOFEL BOILER (KB1-24CE) ASSEMBLY GROUP PICTURE PART NAME PART CODE Front Cover Sheet Painted 7021660006 Inspection Window and Gasket 7020010228 Hermetic Cabin Cover Assembly 7021070006 Hermetic Cabin Cover Gasket 6 MM Sponge - Y 7020010231 Left Side Cover 7022220005... - Page 31 ECOFEL BOILER SERVICE MANUAL ECOFEL BOILER (KB1-24CE) BURNER GROUP PICTURE PART NAME PART CODE Ignition Electrode 7020180010 Ionization Electrode 7021190006 Burner 7020450014 Gas Valve Pipe Passage Rubber 7020930004 NG Conversion Set 7020700015 LPG Conversion Set 7021510012 - 29 - Revision Date: 29 February 2008, Rev. No: 0...
- Page 32 ECOFEL BOILER SERVICE MANUAL ECOFEL BOILER (KB1-24CE) HEAT EXCHANGER GROUP PICTURE PART NAME PART CODE Heat Exchanger Bi-thermic GQ-PRB502 - Y 7020120014 Pipe Clip 13 MM G-MPMM09 7021370049 Usage Water Outlet Pipe and Passage Rubber 7021460011 Usage Water Inlet Pipe and Passage Rubber 7021460009 Surface Type NTC Sensor –...
- Page 33 ECOFEL BOILER SERVICE MANUAL ECOFEL BOILER (KB1-24CE) WATER GROUP PICTURE PART NAME PART CODE Water Pressure Pressure Switch 7021940009 Safety Valve 7020780010 Pump (CESAO-3 PUMP 15/50) 7021890013 Bypass Valve 7020520005 By-pass Pipe 7020540006 Brass Part Clip 7021370062 Clip Between Water Inlet Hydraulic Block and Pump (21mm) 7021370061 Flow control switch 7020860002...
- Page 34 ECOFEL BOILER SERVICE MANUAL ECOFEL BOILER (KB1-24CE) WATER INLET GROUP PICTURE PART NAME PART CODE Water Inlet Hydraulic Block Spare Inner Group 7022020008 Water Inlet Hydraulic Block Flow Limiter 7022280007 Water Inlet Hydraulic Block Filter 7022020007 Aluminum Shim (18x14.2 – Sp.1.5) – B0020 7020090002 Filler Tap Spare Shaft (10.0051) 7020690002...
- Page 35 ECOFEL BOILER SERVICE MANUAL ECOFEL BOILER (KB1-24CE) PANEL GROUP PICTURE PART NAME PART CODE Panel Front Cover H Type 7020750011 Potentiometer Button 7020200009 BMBC Electronic Card 7020130014 Panel Body 7020740005 Panel Back Cover 7020760011 Thermo-manometer IMIT D40 7021170006 Panel Bracket Feeder 7022610002 Panel Bracket Pin Bearing 7022620002...
- Page 36 ECOFEL BOILER SERVICE MANUAL ECOFEL BOILER (KB1-24CE) CABLE GROUP PICTURE PART NAME PART CODE Grounding cables group 7022350010 P9 Connector cable group 7021220014 P7 Connector cable group 7021220013 P5 Connector cable group 7021220012 P3 Connector cable group 7021220011 P2 Connector cable group 7021220010 - 34 - Revision Date: 29 February 2008, Rev.
- Page 38 ECOFEL /KB1-24CE BOILER SRVICE MANUAL ADVANCED CLIMATE TECHNOLOGIES...
