Summary of Contents for Evend SOLID AS 6x6
- Page 1 EBA Sp. z o.o. evend@evend.com.pl ul. Popiełuszki 86 www.evend.com.pl 38-401 Krosno, PL tel. +48 13 436 19 61 Service Manual Spring Operated Automatic Vending Machine SOLID AS 6x6 AS 6x8 AS 6x10 AS 6x12...
- Page 3 Evend brand Polish vending machines produced by EBA Sp.z o.o. a company with long tradition industrial production, strong position on Polish international market company that promotes the development and innovative technology. VENDING MACHINE...
- Page 4 Dear Customer Thank you for purchasing our spring operated automatic vending machine and congratulations on a good choice. This service manual allows you to become familiarized with the operation, start-up and proper maintenance of the machine. The information contained concerns particular functions and a method of their use.
- Page 5 VENDING MACHINE...
- Page 6 VENDING MACHINE...
-
Page 7: Table Of Contents
Table of contents 1. Information ........................7 1.1. Equipment ........................7 1.2. Specifications ......................7 1.3. External structure of automatic machine ..............8 1.4. Internal structure of automatic machine ..............8 1.5. Assembly ........................9 1.6. Power supply. Electric box..................10 1.7. - Page 8 VENDING MACHINE...
-
Page 9: Information
Information 1. Information 1.1. Equipment spring-operated automatic vending machine is the equipment used for the automatic sell of the packed products in controlled temperature. The drink and snack type products can be stored in it. The automatic machine is built of three chambers. -
Page 10: External Structure Of Automatic Machine
Information 1.3. External structure of automatic machine 1. Loudspeaker with motion sensor /optional/. 2. Banknotes accepter /optional/. 3. LCD display. 4. Numeric keyboard – used by customers to select a product and by an operator for the automatic machine servicing and programming. 5. -
Page 11: Assembly
Information 8. Payment device – used to make payments. 9. Photocell – used for product release detection. 10. Refrigerating unit – responsible for proper temperature maintenance in the product chamber. 11. Electric box with thermoregulator. The thermoregulator is a programmable controller enabling direct control of the refrigerating unit. -
Page 12: Power Supply. Electric Box
Information Fig.5 Upper Bracket Spacer Fig.4 Proper machine installation Fig.6 Lower Angle Bracket The machine should be properly levelled. The lower machine feet should be used for that. The real machine dimensions (door opened, easy access) should be taken into consideration in planning distributor layout. - Page 13 Information Fig.7 Block diagram of the automatic machine supply VENDING MACHINE...
-
Page 14: Display
Information Electric box All installation operations shall be performed by a qualified personnel only and meet all the requirements of applicable standards. The mains supply cable is led to the Input 230V AC connector. Remaining connectors are used to connect the components, according to the figure below. ➢... -
Page 15: Drawers
Information 1.8. Drawers In order to fill-in, the drawer should be slightly lifted and pulled to the stopping point. The two highest mounted drawers tilt down to facilitate filling with the goods. Before the goods insertion the springs should be verified for a proper selection for a given product. Softer packagings should refill the lower drawers. -
Page 16: Springs
Information 3. Lift the drawer so as to disengage the wheels from the guide. The machine is designed to allow any configuration of the drawers’ orientation. In order to change a height, the position of the guides, mounted on the side walls, should be changed (ensure that the position of the left and the right guide respectively, is the same). - Page 17 Information Fig.12 Spring types VENDING MACHINE...
-
Page 18: Gear Motors
Information 1.10. Gear motors In the machine, depending on the model and configuration, the number of motors (standard configuration) is as follows: ➢ SOLID 6 – 33 motors, the first drawer equipped with three motors, the remaining five drawers with six motors each. ➢... -
Page 19: Payment Device
Information 2. Pull the motor from the support bulkhead. 3. The end of dismantlement. Pull the spring from the spring fixture. The assembly procedure should be performed in the reverse sequence. 1.11. Payment device The automatic machines SOLID in SILVER version are not equipped with the payment device. -
Page 20: Transport
Information of the unit is necessary (see chapter 3.2). The vacuum cleaner or the compressed air should be used for the impurity removal from the condenser. The machine operator shall be responsible for the machine hygiene and maintenance. During all cleaning operations any water sprays should be avoided and for safety reasons the machine should be disconnected from the mains. -
Page 21: Main Board. Automatic Machine Configuration
Main board./Automatic machine configuration 2. Main board. Automatic machine configuration 2.1. Main board The main board is mounted in the sliding drawer on the right side of the automatic machine, above the coin ejector. The board is power supplied with 29V DC. -
Page 22: Main Board Connector With Pin Description
Main board./Automatic machine configuration 2.2.2. Main board connector with pin description Fig.17 Main board connector view Fig.18 Main board connector pin view Pin description acc. to the blocks. MDB interface Connector Name Block MDB interface Lighting Matrix keyboard Lighting Matrix keyboard I2C bus Matrix keyboard RFID... -
Page 23: Main Board Menu
Main board./Automatic machine configuration LCD 2x20 display Motors ROW0 LCD 2x20 display Motors COL9 LCD 2x20 display Motors COL8 LCD 2x20 display Motors COL7 LCD 2x20 display Motors COL6 LCD 2x20 display Motors COL5 LCD 2x20 display Motors COL4 LCD 2x20 display Motors COL3 LCD 2x20 display... -
Page 24: Prices
Main board./Automatic machine configuration 3.5 Energy saving 3.6 Automatic machine number 3.7 Auto-reset settings 3.8 Factory settings 4. PAYMENT SETTINGS 4.1 Coin intake settings 4.2 Acceptor settings 4.3 Maximal debt 4.2 Maximal change 5. Accessories 5.1 Music box 5.2 Smell 5.3 Lift 6. -
Page 25: Statistics
Main board./Automatic machine configuration „empty” purchase will be blocked and an information on a shortage will be sent to a serviceman. • Show stock. After pressing „#” key the stock level will be displayed for the first position in the machine. Subsequent „#” key pressing will display the stock levels for the next positions. - Page 26 Main board./Automatic machine configuration ➢ Temperature display - option on/off. When activated the temperature inside the machine values will be displayed. ➢ Photocell • Calibration - submenu enabling verification of the photocell diodes proper operation. • On – pressing „#” key will switch on the photocell. •...
-
Page 27: Accessories
Main board./Automatic machine configuration 2.3.5. Accessories ➢ Sense & Talk. The speaking system. The system task is to attract potential customers’ attention. The system operates on the motion detection principle. When the motion sensor detects a person presence (movement) in the machine proximity, the system will play a previously recorded sound sequence and change the lighting. -
Page 28: Communication
Main board./Automatic machine configuration ✓ Timing. In this mode the periods, in which the smell spraying devices operate in the machine proximity, are established. Maximum 3 devices are at disposal. The system operation periods cannot overlap. • Enable period. The parameter used for the device operation period setting. It is equivalent to the smell intensity in the machine proximity. -
Page 29: Test
Main board./Automatic machine configuration This menu can be used for the modem parameters settings, when a telemetric function is used. ➢ GPRS • Configuration ✓ Automatic. The telemetric module modem uses the telecommunication network automatic parameters settings. ✓ Manual. With this function selected the network parameters should be defined (APN, User name, Password) •... -
Page 30: Failures
Main board./Automatic machine configuration 2.3.8. Failures For that menu following submenus can be selected: Browse. If the errors occur the message will be displayed as follows: Error no. Error code Date Hour e.g.: 001-010 2011-05-23 23:43:15 Delete error list. The function running will result in the error list deletion. For the motor errors for example. -
Page 31: Refrigerating Unit
Refrigerating unit 3. Refrigerating unit 3.1. Refrigerating unit construction The refrigerating unit is designed in a single block, slide-out completely, installed behind the product drawer. The refrigerating unit elements: 1. Hermetic compressor, single-phase, with complete start-up unit. 2. Single-fan condenser, with single-phase motors, adapter for the refrigerating unit operation in the ambient temperature up to 25°C. - Page 32 Refrigerating unit Fig.21 Refrigerating unit block disassembly CAUTION. All of the assembly and disassembly operations shall be performed by the qualified personnel with the power supply disconnected. VENDING MACHINE...
-
Page 33: Pjezs0H000 Temperature Controller
Refrigerating unit 3.3. PJEZS0H000 temperature controller 3.3.1. Controller's front panel PJEZS0H000 temperature controlled is used for maintaining preset temperature in vending machines. Temperature may be set within the range of +5°C to +25°C. The preset can be adjusted with the use of buttons on the face panel. The set includes 2 NTC temperature sensors. -
Page 34: Controller's Back Panel
Refrigerating unit LED display (3- digit) ➢ Three-digit display with decimal point and operation indications. ➢ Compressor symbol: the symbol turns on when the compressor engages. It blinks if the compressor start is delayed due to protective sequence. It blinks in two blinks - stop cycle when the controller works in continuous operation mode. -
Page 35: Automatic Machine Refrigeration Unit Cautions
Refrigerating unit 3.4. Automatic machine refrigeration unit cautions The refrigeration unit performance depends on many external factors: ➢ Temperature and humidity in the installation room, ➢ Product collection and door opening frequency, ➢ Kind of products inside the automatic machine. Periodically (every 60 days) the following control activities shall be performed: ➢... -
Page 36: Environment Protection
Environment protection 4. Environment protection • Dispose in accordance with the applicable environment legislation. • The machine shall not be dispatched at municipal wastes disposal sites. All machine parts shall be disposed in accordance with the applicable environment legislation and regulations. -
Page 37: Warranty
Warranty 5. Warranty EBA Ltd. company grants a warranty in accordance with the applicable law. The warranty period begins from VAT invoice issue date. Damages resulting from improper usage or user fault are not covered with this warranty. After discovering a defect in a product, contact the service by filling a form on the website or send it by fax (the form attached to the operation manual). - Page 38 Warranty 6. The warranty is understood as the specialist operations performance by the service, appropriate for the removal of the defect covered by the warranty. The warranty repair does not cover the operations described in the operation manual as the operations, the user is obliged to perform, on his own and on his cost, e.g.
- Page 39 Warranty COMPLAINT dated ……………………. We remind you that the product under complaint should be clean and dry. PLEASE ATTACH THE PROOF OF PURCHASE (receipt/VAT invoice) COMPLETED BY THE CUSTOMER: 1. Claimant first and last name ……………….……………………………………………………………………………… 2. Address …………………………………………….……………………………………………………………………… 3. e@mail address……………………………………………………………………………………………………………… 4.
- Page 40 Warranty WARRANTY DOCUMENT Completed by the seller: Serial number:………………………………………………….. Product name:…………………………………………………… Date of sell:……………………………………………………… Catalog number:………………………………………………… Proof of purchase number:……………………………………. Repair record Date of accept. Date of repair Scope of repair Service seal & signature VENDING MACHINE...
- Page 41 All instructions, drawings and information set out in this document shall not be copied without prior authorization from Producer, exclusive copyright owner. The producer reserves the right to modify characteristics of the machine described in the operation manual without prior notification and assumes no responsibility for any error in this document resulting from printing and typing errors.
