- Page 1 AXIOMWARE SYSTEMS, INC. Netrunr Series Netrunr Edge Hardware Manual axiomware.com Rev 1.0...
- Page 2 A X I O M W A R E S Y S T E M S , I N C . Netrunr Edge Hardware Manual © Axiomware Systems, Inc. 229 Polaris Ave • Suite 15 Mountain View, CA 94043 Phone +1-408-675-8382 • www.axiomware.com axiomware.com...
-
Page 3: Packing List
1. Overview. Netrunr Edge Server (NES) is designed to provide connectivity, compute and storage functionality for your IoT network deployments. The NES architecture is optimized to support large scale data networking functions. A quad-core x86-64-bit processor is connected high speed interfaces like three gigabit ethernet ports, three mini-PCI Express slots (mPCIe), two external USB 3.0 ports, four internal USB 2.0 ports, SATA port, SD card and multiple GPIOs. - Page 4 The front panel of Netrunr Edge has three user-programmable green LEDs. The LEDs are connected to following pins of AMD FCH south bridge as listed in Table 1. PIN ID Default Function LED1 Power/Heartbeat LED2 WAN activity LED3 SSD hard drive activity Table 1: LED connections Software to control is provided as Linux kernel module through Axiomware software repository on Github (https://github.com/axiomware).
- Page 5 WAN port supports Wake-on-LAN (WOL) feature. LAN 1 and LAN2 ports do not support WOL features. WOL can be activated by the events listed in Table 3. Most common WOL systems use Type G events. Event type Description Wake on PHY activity Wake on unicast messages Wake on multicast messages Wake on broadcast messages...
- Page 6 Figure 3: NES motherboard - internal component identification 4.1 Mini-PCI express slots Netrunr Edge Server provides ample expandability and customization using three mini-PCIexpress connectors. Please refer to Table 5 for details of capabilities of each slot. NES has dual SIM card. In normal configuration, J2 SIM card is connected to J14 slot and J1 SIM card is connected to J15 slot.
- Page 7 Signal USB1-DN USB2-DN USB1-DP USB2-DP NO PIN - CONNECTOR INTERLOCK Table 6: Internal USB port pinout 4.3 SD Card An SD card can be used for data-storage or as boot medium (main OS). SD card interface is directly connected to main CPU. Use sdhci driver to access this feature. 4.4 SATA J6 SATA connector can be used for drives.
-
Page 8: Temperature Monitoring
Do Not Connect Table 8: J5 Pinout 4.7 GPIO The J20 connector provides access to the GPIO port. GPIO is generated by the Nuvoton NCT5104.D I/O controller. GPIO pins operate at 3.3V logic level. The pinout for GPIO is listed in Table 9 Signal Signal GPIO0... - Page 9 # Check Wi-Fi support > sudo iwconfig enp3s0 no wireless extensions. enp2s0 no wireless extensions. wlx30eb1f04ecad unassociated Nickname:"<WIFI@REALTEK>" Mode:Auto Frequency=2.412 GHz Access Point: Not-Associated Sensitivity:0/0 Retry:off RTS thr:off Fragment thr:off Encryption key:off Power Management:off Link Quality:0 Signal level:0 Noise level:0 Rx invalid nwid:0 Rx invalid crypt:0 Rx invalid frag:0...
- Page 10 4.13 AES-NI support NES processor supports AES-NI instructions to accelerate AES-128 and AES-256 operations. All current encryption and VPN frameworks on Linux will use AES-NI instructions by default. AES-NI will provide 10x to 50x boost for encrypted streams on the gigabit interfaces. 5.
- Page 11 Figure 4: NES internal - Motherboard connector pin identification axiomware.com Rev 1.0...
