Alemlube 6III4 Owner's Manual

Description
The 61114 1/2" air impact wrench is a powerful, heavy duty and convenient tool with a twin hammer mechanism providing
instantaneous and lasting high torque. Ideal for automotive workshops, tyre workshops, industrial and diesel engine work
applications, the 61114 features a twist control knob for the simple and easy choice of speed and direction, stable and smooth torque
during operation and an ergonomically designed handle with inbuilt exhaust reduces noise levels. Robust and reliable, the 61114 1/2"
impact wrench is a great performer and a valuable addition to any busy workshop.

Specifications

Product Use
Pin Clutch
RPM
Weight
Noise Level
Recommended Minimum Hose Bore Diameter
Recommended Maximum Hose Length
Air Pressure
Vibration Level
Recommended Personal Safety Equipment
Air Inlet
Bolt Capacity
Torque
Average Air Consumption
Overall Length
Square Drive
Materials
Warning
1. This tool cannot be used in explosive atmospheres unless specially designed
for that purpose.
2. The tool is not electrically insulated. Do not use where there is a possibility
of coming in contact with live electricity.
3. Unexpected tool movement due to forces or breakages may cause injuries.
4. It is preferably to shut off the air supply before changing the socket or at least
ensure that hands are well clear of the operating trigger.
5. Be aware of the risk of crushing by torque between a reaction bar and the work area.
6. When loosening fasteners first ensure that there is a sufficient clearance behind the tool to
avoid a hand being caught. The tool will move away from the threaded joint as the nut/bolt
etc is loosened and rides up the thread moving the tool with it.
7. There is a risk of being injured especially when unscrewing in a confined work place if hands
are not kept away from the reaction bar. Keep hands away from the nut runner socket.
8. In case of nut runner socket failure, beware of high speed splinters being emitted from the
impact wrench.
9. Be aware of a whipping compressed air hose line.
10. Always ensure that the reverse valve is in the correct position before operating the tool. Do
not run the tool unless the socket is first located on the joint.
11. Prevent loose clothes, long hair, or any other personal accessories from catching on any
moving parts to reduce the risk of being caught, trapped or drawn into the rotating spindle.
NSW QLD/PNG
TEL: (02) 9939 0711 TEL: (07) 3889 8480
FAX: (02) 9939 0411 FAX: (07) 3889 8490
Visit our website at
OWNER'S MANUAL
½" Impact Wrench
" Professional Pistol Grip Impact Wrench
Twin Hammer type
10,000 RPM ± 10%
2kgs / 4.44lbs
Sound pressure level: 93.1 db(A) Sound power level: 104.7 db(A) Tested in ac-
cordance with EN ISO 15744
10mm / 3/8"
10m / 30ft
Working: 90 psi / 6.3 bar
5.7m/sec2 Tested in accordance with EN 28662-1 and EN 28662-7
Safety Glasses and Ear Protectors
¼" NPT
16mm / 5/8"
1000ft lb / 138kg/m / 1350Nm. Reverse torque: 750ft lb / 1000Nm
13 cfm / 0.37m3/min
193mm / 7.6"
"
High strength lightweight patented design of composite & aluminium alloy
components. Contoured elastomer handle grip.
