BENDIXKing xVue Touch Experimental Pilot's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BendixKing xVue Touch
Experimental
Pilot's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the xVue Touch Experimental and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BENDIXKing xVue Touch Experimental

Summary of Contents for BENDIXKing xVue Touch Experimental

  • Page 1 BendixKing xVue Touch Experimental Pilot’s Guide...
  • Page 2 Email: techsupport@bendixking.com Copyright Notice © 2018 BendixKing. All rights reserved. BendixKing is a registered trademark of Honeywell International Inc. All other marks are owned by their respective companies. Printed in the U.S.A. Pub. No. 89000109-003 April 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 3: Preface

    Touch Experimental Pilot’s Guide PREFACE 1 OVERVIEW 2 PFD 3 MFD 4 SYSTEM CONROLS 5 MESSAGES/ALERTS 6 DATABASE UPDATES ACRONYMS AND ABBREVIATIONS INDEX © Honeywell International Inc. Do not copy without express permission of Honeywell.
  • Page 4 Touch Experimental Pilot’s Guide Blank Page © Honeywell International Inc. Do not copy without express permission of Honeywell.
  • Page 5 Touch Experimental Pilot’s Guide Preface Legal Notice Honeywell – Confidential THIS COPYRIGHTED WORK AND ALL INFORMATION ARE THE PROPERTY OF HONEYWELL INTERNATIONAL, INC., CONTAIN TRADE SECRETS, AND MAY NOT, IN WHOLE OR IN PART, BE USED, DUPLICATED, OR DISCLOSED FOR ANY PURPOSE WITHOUT PRIOR WRITTEN PERMISSION OF HONEYWELL INTERNATIONAL, INC.
  • Page 6 Touch Experimental Pilot’s Guide Rights in Materials – Honeywell retains all rights in these Materials and in any copies thereof that are not expressly granted to you, including all rights in pat- ents, copyrights, trademarks, and trade secrets. No license to use any Honey- well trademarks or patents is granted under this License Agreement.
  • Page 7 Touch Experimental Pilot’s Guide THERE ARE NO OTHER WARRANTIES, WHETHER WRITTEN OR ORAL, EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING, BUT NOT LIMITED TO, (i) WARRANTIES ARISING FROM COURSE OF PERFORMANCE, DEALING, USAGE, OR TRADE, WHICH ARE HEREBY EXPRESSLY DISCLAIMED, OR (ii)
  • Page 8 Touch Experimental Pilot’s Guide Warranty/Liability Advisory WARNING: HONEYWELL ASSUMES NO RESPONSIBILITY FOR ANY HONEY- WELL EQUIPMENT WHICH IS NOT MAINTAINED AND/OR REPAIRED IN ACCORDANCE WITH HONEYWELL’S PUBLISHED INSTRUCTIONS AND/OR HONEYWELL’S FAA/SFAR 36 REPAIR AUTHORIZATION. NEITHER DOES HONEYWELL ASSUME RESPONSIBILITY FOR SPECIAL TOOLS AND TEST EQUIPMENT FABRICATED BY COMPANIES OTHER THAN HONEYWELL.
  • Page 9 Touch Experimental Pilot’s Guide About This Guide This pilot’s guide is intended for system familiarization only. This guide does not replace any Federal Aviation Administration (FAA) or Original Equipment Manufacturer (OEM) approved procedures. IMPORTANT INFORMATION All visual depictions in this guide, including images of the...
  • Page 10 Touch Experimental Pilot’s Guide Safety and Warnings Information WARNING: Do not rely solely on the information displayed on   the Primary Flight Display (PFD) screen to maneuver the air- craft. WARNING: To reduce the risk of unsafe operation, carefully  ...
  • Page 11 Touch Experimental Pilot’s Guide WARNING: Do not use uplinked weather information for maneu-   vering in, near, or around areas of hazardous weather. Informa- tion provided may not accurately depict current weather conditions. Uplinked weather data is not a substitute for onboard weather radar.
  • Page 12 Touch Experimental Pilot’s Guide Record of Revisions REVISION REVISION DESCRIPTION DATE 11APR2018 Initial release 89000109-003 | viii | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 13: Table Of Contents

    Touch Experimental Pilot’s Guide TABLE OF CONTENTS Preface ....................i SECTION 1 OVERVIEW ............16 Basic Operation Features..................19 Touchscreen Technology................. 19 Touch Controls and Fields ................20 Color Convention ....................23 Common Screens ....................25 Power-Up Screen ..................... 25 PFD Screen......................
  • Page 14 Touch Experimental Pilot’s Guide Setting the Timer ....................46 Attitude.......................... 47 Pitch Scale ........................48 Pitch Chevrons ....................49 Excessive Attitude.................... 49 Roll Scale and Pointer..................51 Slip/Skid Indicator................... 52 Flight Path Symbol ....................53 Flight Path Reference Line ................54 Setting the FPRL ....................
  • Page 15 Touch Experimental Pilot’s Guide Current Heading/Track..................71 Selected Heading and Bug ................71 Syncing the Selected Heading Bug ............73 GPS Steering ...................... 73 Setting the GPSS ................... 74 Rate of Turn Indicator ..................74 Rate of Turn Trend Line ................75 Course Deviation Indicator Source ..............75...
  • Page 16 Touch Experimental Pilot’s Guide Crosswind ......................90 Setting the Wind Format ................90 SVS ..........................91 Setting SVS .......................92 Terrain........................92 Obstacles ......................... 93 SVS Range Markers ....................94 Setting the SVS Range Markers..............95 SVS Airport Flags....................95 Setting the SVS Airport Flags ..............96 Airport and Arrival Runway Symbols............
  • Page 17 Touch Experimental Pilot’s Guide Setting the Wx Overlays ................122 Terrain Alert Map ................... 123 Setting the Terrain Alert Inhibit............124 Setting the Map Type ................124 Map Night Mode ..................126 Map Symbols .......................127 Map Features ....................... 129 Orientation Options ..................
  • Page 18 Touch Experimental Pilot’s Guide Setting the Relative Terrain Feature ..........153 Track Line......................153 Setting the Track Line................154 SVS Field of Regard and VSD Swath ........... 154 Vertical Situation Display.................. 155 Terrain........................156 Obstacles ....................... 157 Airspace........................157 VSD Horizontal/Vertical Scale..............
  • Page 19 Touch Experimental Pilot’s Guide SECTION 5 MESSAGES/ALERTS ........188 Advisory Messages....................189 CM Error Messages ..................... 194 Warnings and Cautions ..................195 SECTION 6 DATABASE UPDATES ........196 Updating Databases ................... 197 Dataloading Errors....................202 ACRONYMS AND ABBREVIATIONS ....... Abbrev-1 INDEX..................

  • Page 20: Section 1 Overview

    Touch Experimental Pilot’s Guide OVERVIEW SECTION The BendixKing xVue Touch integrated flight deck (xVue Touch) is a touch-controlled Primary Flight Display (PFD) and Multifunction Dis- play (MFD) system that replaces the traditional 6- and 8-pack flight instruments with solid-state display of airspeed, attitude, altitude, hor-...
  • Page 21 Touch Experimental Pilot’s Guide Table 1 xVue Touch Components COMPONENT DESCRIPTION KSD 100EXP A 10.1-inch high-resolution Widescreen Ultra Extended Graphics Array (WUXGA) Liquid Crystal Display (LCD) with integrated Infrared (IR) touch control, which allows operation with a finger, pen, or glove. Displays primary flight data, Horizontal Situation Indicator (HSI), moving map, and other related data.
  • Page 22 Touch Experimental Pilot’s Guide Figure 2 xVue Touch Diagram Overview 89000109-003 | 18 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 23: Basic Operation Features

    Touch Experimental Pilot’s Guide BASIC OPERATION FEATURES The xVue Touch is controlled by the KSD 100EXP, which uses a Graph- ical User Interface (GUI) to represent information and actions avail- able. In addition to the touch GUI, the xVue Touch is also controlled by the KCP 100EXP (throughout this guide, referred to as “control panel”),...

  • Page 24: Touch Controls And Fields

    Touch Experimental Pilot’s Guide TOUCH CONTROLS AND FIELDS The touch control dialogue boxes are displayed on the right side of the screen (both in full/split screen view). Most dialogue boxes close auto- matically after 9 seconds of inactivity. Only one dialogue box can be open at a time.
  • Page 25 Touch Experimental Pilot’s Guide The KSD 100EXP has several touch fields that open keypads/menus. Figure 4 Example of a Touch Field with Keypad Figure 5 Example of a Touch Field with Menu 89000109-003 Overview Rev 0 Apr 2018 | 21 |...
  • Page 26 Touch Experimental Pilot’s Guide The charts also have several touch fields. Figure 6 Examples of Chart Touch Fields For more information on the System Controls, see Section 4. Overview 89000109-003 | 22 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 27: Color Convention

    Touch Experimental Pilot’s Guide COLOR CONVENTION Some of the common avionics color schemes used in the PFD include red for warning, amber for caution, blue for sky, and brown for ground. T Table 3 System Colors ITEM COLOR Warning...
  • Page 28 Touch Experimental Pilot’s Guide If a function or system is inoperative, the function or system indicators are replaced with a red to indicate the function is unavailable/inoper- ative. Attitude failure is displayed as a box with white text. Crew...

  • Page 29: Common Screens

    Touch Experimental Pilot’s Guide COMMON SCREENS POWER-UP SCREEN When the xVue Touch is turned on, the power-up screen appears, dis- playing different database effectivity information. When databases have been validated, touch ENTER. Figure 8 Example of a Power-Up Screen...

  • Page 30: Pfd Screen

    Touch Experimental Pilot’s Guide PFD SCREEN The xVue Touch screen is a split screen: the left side shows the PFD and the right side shows the MFD. The PFD screen can be displayed with or without the SVS. NOTE: The screen displayed varies based on the screen  ...
  • Page 31 Touch Experimental Pilot’s Guide Figure 10 Example of a PFD Screen with SVS The PFD can also be shown in full screen view, with or without SVS. Figure 11 Example of a Full PFD Screen View Without SVS 89000109-003...

  • Page 32: Setting The Pfd Screen Layout

    Touch Experimental Pilot’s Guide Figure 12 Example of a Full PFD Screen View with SVS NOTE: The MFD controls are not accessible when in full PFD   screen view. SETTING THE PFD SCREEN LAYOUT Touch Select Full or Split setting (the...

  • Page 33: Mfd Screen

    Touch Experimental Pilot’s Guide MFD SCREEN The MFD screen is divided into two windows: moving map and VSD. Figure 13 Example of a MFD Screen 89000109-003 Overview Rev 0 Apr 2018 | 29 | © Honeywell International Inc. Do not copy without express permission of Honeywell.
  • Page 34 Touch Experimental Pilot’s Guide The map displays different map views (types). The MFD screen can be modified to show the map in full view (VSD window removed).   NOTE: The MFD screen does not have a full screen option.

  • Page 35: Setting The Mfd Screen Layout

    Touch Experimental Pilot’s Guide SETTING THE MFD SCREEN LAYOUT   NOTE: Base Map setting is used as an example. Touch Touch Touch to turn the Vertical Situation On/Off (the green bar indicates the feature is on, touching the button toggles between On/Off settings) For more information on the MFD, see Section 3.

  • Page 36: Section 2 Pfd

    Touch Experimental Pilot’s Guide SECTION Figure 16 Example of a PFD Screen LEGEND Non-Touch Field Touch Field 89000109-003 | 32 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.
  • Page 37 Touch Experimental Pilot’s Guide 1. Airspeed Tape 27. Selected Altitude Bug 2. Selected Airspeed Field (Touch to Key- 28. BARO Minimums (Touch to Keypad pad) After First Set from Menu) 3. Selected Airspeed Bug 29. Current Barometric Pressure (Touch 4.

  • Page 38: Airspeed

    Touch Experimental Pilot’s Guide AIRSPEED The airspeed tape, displayed on the left side of the PFD screen, is a fixed pointer moving scale with a rolling drum digital airspeed readout. The tape has a range of 0- 350 Knots (KT) or Miles per Hour (MPH).

  • Page 39: Selected Airspeed And Bug

    Touch Experimental Pilot’s Guide The current airspeed digits are displayed as black on yellow when operating in the yellow color band, white background when operating in the color band, and white on black when operating in all other color bands.
  • Page 40 Touch Experimental Pilot’s Guide When the selected airspeed is set, the selected airspeed bug appears on the airspeed tape. The bug position corresponds to the selected air- speed value. When the selected airspeed is not the current airspeed, the color of the selected airspeed value changes to cyan.

  • Page 41: Syncing The Selected Airspeed Bug

    Touch Experimental Pilot’s Guide NOTE: The selected airspeed and bug settings are retained   during a power cycle. SYNCING THE SELECTED AIRSPEED BUG Touch Touch to sync the selected airspeed bug to the current airspeed For more information on how to set/change the settings, see “Setting Values”...

  • Page 42: Installer Set V-Speeds

    Touch Experimental Pilot’s Guide INSTALLER SET V-SPEEDS The installer set V-Speeds are determined by airplane configuration (single/multi engine, retractable/fixed landing gear, availability of flaps, etc.). Table 4 Installer Set V-Speeds V-SPEED DESCRIPTION Never Exceed Speed Min. Control Speed with the Critical Engine Inoperative* Best Single Engine Rate of Climb Speed* Max.

  • Page 43: V-Speed Labels And Speed Color Bands

    Touch Experimental Pilot’s Guide V-SPEED LABELS AND SPEED COLOR BANDS The installer set V-Speeds are displayed next to the speed color bands. Figure 22 Examples of Common V-Speed Labels and Speed Color Bands NOTE: Multi-engine airplanes use VYSE and VMC - their lines  ...

  • Page 44: Setting The V-Speed Labels

    Touch Experimental Pilot’s Guide Over speed awareness band is displayed as a white band (sim- ilar to a red barber pole) and low speed awareness band is displayed as band. Over speed is also accompanied by an aural alert.

  • Page 45: Pilot Set V-Speeds

    Touch Experimental Pilot’s Guide PILOT SET V-SPEEDS The following V-Speeds can be set by the pilot: Table 5 Pilot Set V-Speeds V-SPEED DESCRIPTION Maneuvering Speed Best Angle of Climb Best Rate of Climb Best Glide Rotation Speed Approach Reference...
  • Page 46 Touch Experimental Pilot’s Guide When the Computed Airspeed (CAS) is <20 KTS, on the ground V- Speeds are displayed (if the display of V-Speeds labels is turned on), at the bottom of the airspeed tape. Ground V-Speed Labels Figure 26 Examples of On the Ground V-Speed Labels...

  • Page 47: Setting The Pilot V-Speeds

    Touch Experimental Pilot’s Guide SETTING THE PILOT V-SPEEDS Touch Touch and select the desired V-Speed from the Set V- Speeds menu Set the V-Speed value using the keypad Figure 27 Examples of Set V-Speeds Menu and Keypad Touch to validate the entry  ...

  • Page 48: Setting The V-Speed Labels

    Touch Experimental Pilot’s Guide SETTING THE V-SPEED LABELS Touch Touch to turn the V-Speed Labels On/Off (the green bar indicates the feature is on, touching the but- ton toggles between On/Off settings) For more information on how to set/change the settings, see “Setting Values”...

  • Page 49: Outside Air Temperature

    Touch Experimental Pilot’s Guide OUTSIDE AIR TEMPERATURE Outside Air Temperature (OAT), displayed below the airspeed tape, has a range of -70 to 70°C, with a resolution of 1°. The OAT displays total air tempera- ture uncorrected for temperature rise.

  • Page 50: Setting The Timer

    Touch Experimental Pilot’s Guide SETTING THE TIMER Touch the UTC/TMR field Set the timer using the TIMER menu Figure 30 Example of the TIMER Menu NOTE: The TIMER menu is also used to toggle between the TMR   and UTC functions.

  • Page 51: Attitude

    Touch Experimental Pilot’s Guide ATTITUDE The Attitude Indicator (AI), displayed in the center of the PFD screen, provides attitude information (pitch, roll, and slip/skid). The AI is col- ored blue above the ZPRL/horizon line and brown below the line.

  • Page 52: Pitch Scale

    Touch Experimental Pilot’s Guide PITCH SCALE The pitch scale, displayed in the center of the AI, has a viewable range of 20° up and 10° down (when the SVS feature is turned off). Major tick marks and numeric labels are shown every 5° above and below the ZPRL.

  • Page 53: Pitch Chevrons

    Touch Experimental Pilot’s Guide PITCH CHEVRONS The pitch chevrons (horizon guidance) are part of the scale and begin to appear when the airplane begins to reach +30° or -15° of pitch. Figure 34 Examples of Pitch Chevrons Displayed EXCESSIVE ATTITUDE Excessive attitude occurs when the bank angle is greater than 65°...
  • Page 54 Touch Experimental Pilot’s Guide If excessive attitude continues the chevrons “nest”. Figure 36 Examples of “Nested” Chevrons in Excessive Attitude Excessive roll angle is displayed the same way as excessive attitude, i.e., as almost all brown (ground) with an eyebrow of...

  • Page 55: Roll Scale And Pointer

    Touch Experimental Pilot’s Guide ROLL SCALE AND POINTER The roll scale and pointer, displayed on top of the pitch scale, indicates the roll angle of the airplane in reference to 0° of bank. The roll pointer indicates the bank angle.

  • Page 56: Slip/Skid Indicator

    Touch Experimental Pilot’s Guide SLIP/SKID INDICATOR The slip/skid indicator, displayed under the roll pointer, shows the lat- eral acceleration of the airplane. The slip/skid indicator line replaces the traditional slip-ball indicator. The line is equivalent to the ball in a standard turn and bank indicator.

  • Page 57: Flight Path Symbol

    Touch Experimental Pilot’s Guide FLIGHT PATH SYMBOL The Flight Path Symbol (FPS) displays the flight path angle and drift information in real time. The FPS serves as a graphical representation of the airplane’s lateral and vertical path (as opposed to the direction the airplane is pointing).

  • Page 58: Flight Path Reference Line

    Touch Experimental Pilot’s Guide FLIGHT PATH REFERENCE LINE The Flight Path Reference Line (FPRL) is shown -3° below the ZPRL and provides a pitch reference for a normal approach to landing. When the FPS is placed on the FPRL, a -3° vertical flight path is made.

  • Page 59: Flight Director Bars

    Touch Experimental Pilot’s Guide FLIGHT DIRECTOR BARS The Flig ht D irector (FD) bars display flight director output from a compatible autopilot (if installed). The FD bars represent the pitch and roll command inputs from an autopilot, providing visual guidance for maneuvering the airplane.

  • Page 60: Altitude

    Touch Experimental Pilot’s Guide ALTITUDE The altitude tape, displayed on the right side of the PFD, uses a fixed pointer moving scale arrangement, with a rolling drum digital readout of the current altitude. The instrument range is -1000 to 35,000 FT at standard pressure, with a display resolution of 20 FT.

  • Page 61: Selected Altitude And Bug

    Touch Experimental Pilot’s Guide SELECTED ALTITUDE AND BUG The selected altitude field is displayed at the top of the altitude tape. The selected altitude and bug can be set through: The selected altitude field numeric keypad The ALT knob (turn) on the control panel When the selected altitude is set, the altitude bug appears on the left side of the altitude tape.

  • Page 62: Syncing The Selected Altitude Bug

    Touch Experimental Pilot’s Guide If the selected altitude exceeds the range shown on the tape, the bug appears parked at the corresponding end of the tape. Selected Altitude Bug Figure 49 Example of a Selected Altitude Bug Parked If the selected altitude data is invalid, the selected altitude value, bug, and white outline defining the touch area are removed, and the selected altitude touch area is disabled.

  • Page 63: Selected Altitude Alerts

    Touch Experimental Pilot’s Guide SELECTED ALTITUDE ALERTS Visual and aural alerts are provided when the airplane approaches or deviates from the selected altitude. When the airplane passes within 1000 FT and 200 FT of the selected altitude, the readout flashes and changes color for about 5 seconds, and is accompanied by an aural alert.

  • Page 64: Setting The Altitude Audio Alert Inhibit

    Touch Experimental Pilot’s Guide SETTING THE ALTITUDE AUDIO ALERT INHIBIT The aural alerts can be turned off: Touch Touch to turn the ALT Audio Alert Inhibit On/Off (the green bar indicates the feature is on, touching the button toggles...

  • Page 65: Setting The Baro Unit

    Touch Experimental Pilot’s Guide If the current BARO correction input from the ADAHRS is invalid, the current/selected BARO correction value and BARO units fields are dis- played in amber. Figure 53 Examples of Invalid BARO Units Displayed NOTE: If the current BARO correction input from the ADAHRS is  ...

  • Page 66: Baro Minimums

    Touch Experimental Pilot’s Guide BARO MINIMUMS The BARO minimums (MINS) is used to set approach minimums. The MINS is displayed at the bottom left of the altitude tape when set. MINS has a range of -1000 to 16000 FT Mean Sea Level (MSL).
  • Page 67 Touch Experimental Pilot’s Guide When the minimums select is set, the MINS field is displayed with the minimums select bug value and the bug is shown on the tape. The bug value, symbol, and unit are in cyan when the MINS has not been...

  • Page 68: Minimums Select Alerts

    Touch Experimental Pilot’s Guide MINIMUMS SELECT ALERTS As the airplane approaches the altitude set in the MINS field, the aural alert “Approaching Minimums” is provided and the minimums select bug flashes momentarily. When the airplane reaches the minimum altitude, the aural alert “Minimums, Minimums”...

  • Page 69: Setting The Density Altitude

    Touch Experimental Pilot’s Guide SETTING THE DENSITY ALTITUDE Touch Touch and select the desired setting from the Density ALT Display menu Figure 58 Density ALT Display Menu Example 89000109-003 Rev 0 Apr 2018 | 65 | © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 70: Vertical Speed

    Touch Experimental Pilot’s Guide VERTICAL SPEED The Vertical Speed Indicator (VSI), displayed to the right of the alti- tude tape, is a fixed scale moving pointer, with digital readout (full screen only). The digital readout range is ±5500 FPM. A zero mark arrow is shown at 0 FPM vertical speed.
  • Page 71 Touch Experimental Pilot’s Guide The fixed scale range is set during installation to ± 2000, ±3000, or ±4000 FT. ± 4000 FPM Range ± 3000 FPM Range ± 2000 FPM Range Figure 60 Examples of Vertical Speed Ranges Numerical labels are shown as follows: •...

  • Page 72: Vertical Speed Pointer

    Touch Experimental Pilot’s Guide VERTICAL SPEED POINTER The vertical speed pointer is shown above the zero mark chevron when the altitude rate is positive, below when the altitude rate is neg- ative. In full screen mode, the vertical speed value is displayed when the ver- tical speed is at least 50 FPM.

  • Page 73: Horizontal Situation Indicator

    Touch Experimental Pilot’s Guide HORIZONTAL SITUATION INDICATOR The Horizontal Situation Indicator ( HSI) area is displayed below the AI in the middle of the PFD screen. Figure 63 HSI Area Example LEGEND Non-Touch Field Touch Field 1. Selected Heading Field 10.

  • Page 74: Hsi 360/Arc Compass

    Touch Experimental Pilot’s Guide HSI 360/ARC COMPASS The HSI 360/ARC compass is displayed in the middle of the HSI area around the airplane ownship symbol. The cardinal headings are labeled N, S, E, and W. Numeric headings are shown every 30°, labeled with one- or two-digit degree markings.

  • Page 75: Setting The Compass Mode

    Touch Experimental Pilot’s Guide SETTING THE COMPASS MODE Touch Touch and select the 360 or Arc setting (the green indicates current selection, touching the button toggles between the settings) CURRENT HEADING/TRACK The Heading (HGD)/Track (TRK) field, displayed above the compass, has a range of 001- 360°, with a resolution of 1°.
  • Page 76 Touch Experimental Pilot’s Guide When the selected heading is set, the selected heading bug appears on the compass. The bug position corresponds to the selected heading value. Selected Heading Field Selected Heading Figure 67 Example of a Selected Heading Bug Set...

  • Page 77: Syncing The Selected Heading Bug

    Touch Experimental Pilot’s Guide SYNCING THE SELECTED HEADING BUG Touch key on the numeric keypad Press the HDG knob on the control panel For more information on how to set/change the settings, see “Setting Values” on page 184 and “Control Panel” on page 185.

  • Page 78: Setting The Gpss

    Touch Experimental Pilot’s Guide SETTING THE GPSS Touch Touch Touch and select the desired setting (the green indicates the feature is turned on, touching the button toggles between On/Off settings) When the GPSS in turned on the selected heading field displays the GPSS source.

  • Page 79: Rate Of Turn Trend Line

    Touch Experimental Pilot’s Guide RATE OF TURN TREND LINE The rate of turn trend line displays the current turn rate relative to a standard rate turn. A standard rate turn is shown on the indicator when the trend line reaches the standard turn rate mark.

  • Page 80: Setting The Navigation Source

    Touch Experimental Pilot’s Guide SETTING THE NAVIGATION SOURCE The navigation source can be set through:. Touch Select the navigation source from the CDI Source menu Figure 72 Example of a CDI Source Menu The selected CDI source information is displayed on the screen in...

  • Page 81: Selected Course And Cdi

    Touch Experimental Pilot’s Guide SELECTED COURSE AND CDI The selected course and CDI components represent the desired air- plane course/track. SELECTED COURSE The selected course field, displayed to the right of the current head- ing, has a range of 001-360°, with a resolution of 1°. It is shown either...

  • Page 82: Syncing The Selected Course

    Touch Experimental Pilot’s Guide SYNCING THE SELECTED COURSE Touch key on the numeric keypad Push the CRS knob on the control panel When the SYNC key is selected: • GPS source selected: The selected course is synced to the GPS bearing to Waypoint (WPT) value •...

  • Page 83: Selected Course Pointer And Tail

    Touch Experimental Pilot’s Guide SELECTED COURSE POINTER AND TAIL The selected course pointer and tail are shown either in magenta (GPS source) or green (VLOC source). Figure 76 Examples of Selected Course Pointer and Tail The selected course pointer position on the inner HSI corresponds to the current selected course and the tail position is 180°...

  • Page 84: To/From Flag

    Touch Experimental Pilot’s Guide When the course deviation exceeds the maximum displayable range of 2.5 dots, the deviation sc a l e displays an arrow on the deviation bar that points to the corresponding direction. Exceeds Scale Full Scale...

  • Page 85: Cdi - Arc Compass

    Touch Experimental Pilot’s Guide CDI - ARC COMPASS In the ARC compass, the CDI components are displayed in a modi- fied format. Selected Course Pointer CDI Source Selected Course Deviation Deviation Scale Diamond Figure 79 Examples of CDI Components - ARC Compass...

  • Page 86: Gps Navigation Parameters

    Touch Experimental Pilot’s Guide GPS NAVIGATION PARAMETERS The GPS navigation parameters, displayed to the right of the com- pass, contain information relative to the current flight plan. 1. Selected GPS Source 2. Phase of Flight (POF) 3. From/To Waypoint 4.

  • Page 87: Gps Annunciations

    Touch Experimental Pilot’s Guide GPS ANNUNCIATIONS The GPS annunciations are located to the right of the compass, above the GPS navigation parameters. The GPS annunciation data is received from the GPS1 or GPS2 navigator source. GPS Annunciations Figure 82 Examples of GPS Annunciations The GPS annunciations are: •...

  • Page 88: Setting The Bearing Pointers

    Touch Experimental Pilot’s Guide In the ARC compass, the bearing pointer head/tail are only displayed when within the visible part of the compass. 1. Bearing Pointer 1 Tail 2. Bearing Parameter Field (1&2) Figure 84 Bearing Display Example – ARC Compass...

  • Page 89: Hsi Track Line

    Touch Experimental Pilot’s Guide Set the desired setting from the Pointer 1 and/or Pointer 2 menus Figure 86 Examples of Bearing Pointer Menus NOTE: The bearing pointer(s) is not displayed when the waypoint   bearing selection is a localizer. If the waypoint bearing becomes invalid, the bearing pointer(s) is removed from the display.

  • Page 90: Setting The Hsi Track Line

    Touch Experimental Pilot’s Guide SETTING THE HSI TRACK LINE Touch Touch to turn the HSI Track Line On/Off (the green bar indicates the feature is on, touching the button toggles between On/Off settings) LATERAL DEVIATION SCALE The lateral deviation scale, displayed below the pitch scale during approaches, shows lateral deviation (left/right) from the selected course.

  • Page 91: Vertical Deviation Scale

    Touch Experimental Pilot’s Guide NOTE: The pilot can select between installed/enabled   navigation sources: GPS1, GPS2, VLOC1, VLOC2, or VLOC3. When the course deviation exceeds the maximum display range of 2.5 dots, the lateral deviation diamond appears parked (left/right) with half of the diamond colored white on the lateral deviation scale.
  • Page 92 Touch Experimental Pilot’s Guide The vertical deviation diamond is the same color as the selected navigation source (i.e., magenta for GPS and green for VLOC/ILS). Figure 92 Examples of Vertical Deviation Diamond Full scale deviation is shown when the diamond is at the farthest top/bottom dot.

  • Page 93: Wind

    Touch Experimental Pilot’s Guide WIND The wind, displayed above the selected heading field, is shown in two different formats: Vector Wind Format (single arrow) Rectangular Wind Format (Headwind/Crosswind) (double arrow) The wind speed range is 0-255 KTS, with a resolution of 1 KT. The wind direction range is 001-360°.

  • Page 94: Headwind

    Touch Experimental Pilot’s Guide HEADWIND The headwind component is shown using a vertical arrow. The arrow tail indicates whether the headwind component is positive (headwind) or negative (tailwind). The arrow points down to indicate a headwind and up to indicate a tailwind.

  • Page 95: Svs

    Touch Experimental Pilot’s Guide SVS provides a three-dimensional (3-D) realistic view of the sur- rounding terrain, similar to what the pilot sees looking out the window. Terrain, obstacles, and runways are displayed and standard flight and navigation data are overlaid on the SVS view. SVS improves over- all flight safety by increasing situational awareness.

  • Page 96: Setting Svs

    Touch Experimental Pilot’s Guide SETTING SVS Touch Turn SVS On/Off (the green bar indicates the feature is on, touch- ing the button toggles between On/Off settings) NOTE: When SVS is turned off, an SVS annunciation   is displayed on the screen (below the GS field).

  • Page 97: Obstacles

    Terrain warnings and cautions are also accompanied by alert mes- sages and aural alerts. For more information on warnings and cautions, refer to the BendixKing xVue Touch Experimental Airplane Flight Procedures. OBSTACLES Man-made obstacles with heights >199 FT AGL are displayed at their...

  • Page 98: Svs Range Markers

    Touch Experimental Pilot’s Guide When the distance is within 2 NM of the airplane the symbols change to standard aviation obstacle tower symbols. Figure 99 Examples of Aviation Obstacle Symbols SVS RANGE MARKERS The SVS range markers are shown at 3, 5, 10, and 20 NM to indicate the points on the terrain that are at the same indicated distance (ground range) from the airplane.

  • Page 99: Setting The Svs Range Markers

    Touch Experimental Pilot’s Guide SETTING THE SVS RANGE MARKERS Touch Touch to turn the SVS Range Markers On/Off (the green bar indicates the feature is on, touching the button toggles between On/Off settings) SVS AIRPORT FLAGS The SVS airport flags identify nearest airports and consist of a symbol and Identification (ID).

  • Page 100: Setting The Svs Airport Flags

    Touch Experimental Pilot’s Guide SETTING THE SVS AIRPORT FLAGS Touch Touch to turn the SVS Airport Flags On/Off (the green bar indicates the feature is on, touching the button toggles between On/Off settings) AIRPORT AND ARRIVAL RUNWAY SYMBOLS SVS displays different airport and arrival runway symbols. If an airport...
  • Page 101 Touch Experimental Pilot’s Guide When destination instrument approach has been activated in the GPS or the landing runway has been manually designated, the destination airport symbol is replaced by the arrival airport and runway symbols to easily identify the location of the arrival runway.

  • Page 102: Approach Course Line And Extended Runway Centerline

    Touch Experimental Pilot’s Guide To assist in positioning the airplane on the final approach, the leading edge of the arrival airport symbol aligns with the arrival runway. The arrival runway symbol outlines the usable landing area of the approach runway, including any available overrun areas, helping the pilot to identify the usable landing area.

  • Page 103: Runways And Runway Markings

    Touch Experimental Pilot’s Guide RUNWAYS AND RUNWAY MARKINGS SVS displays runway markings when the airplane descends within 1.5 NM of the landing runway center point.   NOTE: The runway markings locations are estimated. Figure 105 Examples of SVS Runway and Runway Markings...

  • Page 104: Section 3 Mfd

    Touch Experimental Pilot’s Guide SECTION Figure 106 Example of a MFD Screen LEGEND Touch Field Non-Touch Field 89000109-003 | 100 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 105: Map

    Touch Experimental Pilot’s Guide 1. Moving Map 19. Range Ring Distance Value 2. Map Orientation Annunciation (Touch 20. Airway Point to Menu) 21. Airspace Boundary 3. Map Type Annunciation (Touch Point 22. Visual Reference Point (VRP) to Menu) 23. Urban Area 4.

  • Page 106: Map Types

    Touch Experimental Pilot’s Guide Table 6 Map Data Displayed MAP DATA DESCRIPTION Terrain Relative Color-coded terrain based on relative altitude of a i r p l a n e terrain** ownship ≥ Obstacles Man-made obstacles 199 FT Aeronautical*** Navigation...

  • Page 107: Base Maps

    Touch Experimental Pilot’s Guide BASE MAPS The Base Maps are database driven dynamically rendered vector maps. Two types of Base Maps are available: topography on or topography off). Map Type Annunciation Map Type Annunciation Figure 107 Examples of Base Maps (Topography On/Off) NOTE: A map type annunciation is displayed below the map  ...

  • Page 108: Raster Maps

    Touch Experimental Pilot’s Guide RASTER MAPS The raster maps are raster images of standard FAA charts that have been geo-referenced. Three types of raster maps are available: VFR Sectional, I FR High, and IFR Low. Figure 108 Examples of VFR Sectional, IFR High, and IFR Low Maps...

  • Page 109: Charts Maps

    Touch Experimental Pilot’s Guide CHARTS MAPS The Charts maps display diagrams for airports, departures, arrivals, and approaches. Figure 109 Example of a Charts Map LEGEND Non-Touch Field Touch Field 89000109-003 Rev 0 Apr 2018 | 105 | © Honeywell International Inc. Do not copy without express permission of Honeywell.
  • Page 110 Touch Experimental Pilot’s Guide 1. Select Airport tab 8. Map type annunciation 2. Currently selected tab 9. Map orientation icon 3. DEP (Departures) tab 10. Example of an airport diagram 4. ARR (Arrivals) tab 11. Page Down button 5. APP (Approaches) tab 12.

  • Page 111: Select Airport Tab

    Touch Experimental Pilot’s Guide SELECT AIRPORT TAB When the Select Airport tab is selected, a list of Search, Origin (if available), Dest [destination (if available)], and 10 nearest airports is displayed. NOTE: The origin and destination reference the origin and  ...
  • Page 112 Touch Experimental Pilot’s Guide Searching for Airports Airports can be searched by the airport identifier (Ident) or Name. NOTE: Search by Name is used as an example to show the steps   for searching airports. Touch the Select Airport tab...
  • Page 113 Touch Experimental Pilot’s Guide NOTE: The SEARCH BY selection box identifies the type of   search and characters are limited to only valid entries for the search type. Touch Enter Touch the desired city in the Select City list Figure 113 Example of a City List The a va i l a b l e chart(s) for the selected airport are displayed.

  • Page 114: Airport Tab

    Touch Experimental Pilot’s Guide AIRPORT TAB When the ARPT tab is first selected, the first entry in the list is dis- played: airport diagram (if available), alternate minimums (if avail- able), hot spot (if available), radar minimums (if available), and take- off minimums (if available).
  • Page 115 Touch Experimental Pilot’s Guide Setting the Airport Diagram Feature Touch Touch Touch to turn Auto Diagram Airport On/Off (the green bar indicates the feature is on, touching the button toggles between the settings) Touch Yes to display the chart view with the Airport Diagram dis-...

  • Page 116: Departures

    Touch Experimental Pilot’s Guide DEPARTURES When the DEP tab is first selected, a list of standard instrument departure procedures is displayed for the selected airport, with the first departure in the list selected. Selecting from the list displays the associated departure procedure chart.

  • Page 117: Arrivals

    Touch Experimental Pilot’s Guide ARRIVALS When the ARR tab is first selected, a list of arrival procedures [ S t a n - d a r d Te r m i n a l A r r i va l R o u t e s (STARs)] is displayed and the first STAR is selected.

  • Page 118: Approaches

    Touch Experimental Pilot’s Guide APPROACHES When the APP tab is first selected, a list of approaches for the selected airport is displayed (with the first approach in the list selected). Selecting from the list of approaches displays the associated approach procedure chart.

  • Page 119: Wx Map

    Touch Experimental Pilot’s Guide Wx MAP The Wx Map displays weather information provided by the Flight Infor- mation Services-Broadcast (FIS-B). Map Type Annunciation METAR/TFR/ NEXRAD Annunciations FIS-B Status Wx Legend Button Button Figure 119 Example of a Wx Map WARNING: Graphical depictions of uplinked weather data (radar,  ...

  • Page 120: Weather (Fis-B)

    Touch Experimental Pilot’s Guide WEATHER (FIS-B) The weather overlays, when turned on, can display the following weather information on the map: • NEXRADs • METARs/TAFs • TFRs NOTE: The weather overlays are only available for Wx and Base  ...

  • Page 121: Metar/Taf

    Touch Experimental Pilot’s Guide The CONUS and Regional NEXRAD overlays are valid for 1 hour from the time of observation. The NEXRAD age annunciation is displayed on the left side of the MFD above the Map Detail field. Invalid Data...
  • Page 122 Touch Experimental Pilot’s Guide Display Criteria METAR/TAF graphical depictions are displayed on the map as flight categories based on ceiling/visibility. FLIGHT CATEGORY CEILING/VISIBILITY LIFR < 500 FT AGL/< 1 Mile 500-1000 FT AGL/1 Mile to Less than 3 Miles...

  • Page 123: Tfr

    Touch Experimental Pilot’s Guide TFRs provide detailed information about local short term flight restrictions. They are color-coded based on their status: Inactive and Active. Active Info Annunciation Status Figure 124 Examples of TFR Related Information Displayed Full Report Touching the Information icon for a TFR displays Notice to Airmen (NOTAM) information for the selected item.

  • Page 124: Fis-B Status

    Touch Experimental Pilot’s Guide Wx Legends To display the Wx Legends, touch displayed on the right bottom corner of the map Touch anywhere in the Legends dialog box to move to the next page/close the box Figure 126 Examples of Wx Legends...
  • Page 125 Touch Experimental Pilot’s Guide Touch the desired tab to view more information. • Stations: Provides ground station reception status • Weather: Provides weather products and outage notification infor- mation • TFR List: Provides a list of TFRs (touching a list item opens the...

  • Page 126: Setting The Wx Overlays

    Touch Experimental Pilot’s Guide SETTING THE WX OVERLAYS Touch Touch to select the desired settings from the menu Figure 129 Example of a Wx Map Overlays Menu 89000109-003 | 122 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 127: Terrain Alert Map

    Touch Experimental Pilot’s Guide TERRAIN ALERT MAP The MFD automatically switches to Terrain Alert map when terrain/ obstacle threat is detected. Figure 130 Example of a Terrain Alert Map The warning and caution areas are colored on top of relative terrain coloring.

  • Page 128: Setting The Terrain Alert Inhibit

    Touch Experimental Pilot’s Guide NOTE: The map overlays and setup functions are not available   when the terrain alert map is displayed. SETTING THE TERRAIN ALERT INHIBIT The Terrain Alert map and warnings/cautions can be turned off: Touch green...
  • Page 129 Touch Experimental Pilot’s Guide Select the desired type from the MFD menu Figure 131 Example of a MFD Menu Select the desired map overlays and setup features Figure 132 Examples of Map Overlays and Setup Menus Select the desired Airways setting: Low, High, or None. The default setting is Low.

  • Page 130: Map Night Mode

    Touch Experimental Pilot’s Guide MAP NIGHT MODE Some map types, i.e., IFR High, IFR Low, and Charts, have a Night Mode view option. Figure 133 Example of a Night Mode View - Charts Setting the Night Mode NOTE: The Night Mode view can be accessed through the Map  ...

  • Page 131: Map Symbols

    Touch Experimental Pilot’s Guide MAP SYMBOLS The map displays the following symbols: Table 7 Map Symbols SYMBOL FEATURE SYMBOL FEATURE Airport with Hard Flight Information Surfaced Runway Region (FIR)/Upper Information Region (UIR) Airport Other than Controlled Airspace Hard Surfaced...
  • Page 132 Touch Experimental Pilot’s Guide Table 7 Map Symbols SYMBOL FEATURE SYMBOL FEATURE Intersection Restrictive Airspace Danger, Prohibited and Restricted Runway Restrictive Airspace Military Restrictive Visual Reference Restrictive Airspace All Point (VRP) other restrictive Tall Obstacle Road Shield Tall Lighted Obstacle...

  • Page 133: Map Features

    Touch Experimental Pilot’s Guide MAP FEATURES The map has the following common features: • Orientation Options • Display Range • Ownship • Panning • Map Detail • Zoom • More Information • Cursor ORIENTATION OPTIONS The map display has the following orientation options:...
  • Page 134 Touch Experimental Pilot’s Guide Both the Track Up and Heading Up orientation options also display the current readout of magnetic heading or track at the top of the map. Current Track Track Readout Indication Magnetic North Arrow Map Orientation Annunciation Figure 135 Example of a Map Orientation –...

  • Page 135: Setting The Map Orientation

    Touch Experimental Pilot’s Guide SETTING THE MAP ORIENTATION Touch (Map Orientation Annunciation) Select the desired orientation from the Map Orientation menu Figure 137 Example of a Map Orientation Menu OWNSHIP The airplane ownship is displayed as a symbol on the map at the current airplane position, approximately at the intersection of the mid-point of the wings with the fuselage.

  • Page 136: Map Detail

    Touch Experimental Pilot’s Guide MAP DETAIL The map can be changed to show different levels of detail with the Map Detail feature. There are four different detail levels to choose from. Map Detail Field Map Detail Window Figure 139 Examples of Map Detail (Most and Least Detail)

  • Page 137: Information Icon

    Touch Experimental Pilot’s Guide INFORMATION ICON Map items that have more information displ ay an Information icon when touched. Items with more information available include: • Airports • NAVaids • Flight Plan Segments • Airways • METARs/TFRs • Obstacles The icon opens additional pop-up windows providing information about the selected map item.
  • Page 138 Touch Experimental Pilot’s Guide Touching an airport symbol provides more information about the air- port. Runway centerline extension can be overlaid on the map by selecting the desired runway button. Airport Information window also displays communication channel, weather, and charts information.

  • Page 139: Map Display Range

    Touch Experimental Pilot’s Guide MAP DISPLAY RANGE The map display range is displayed as a circle with a readout. The range is 0.5 - 1000 NM for a Base Map and up to 100 NM for VFR Sec- tional and IFR High and IFR Low maps. The range can be modified manually or automatically.
  • Page 140 Touch Experimental Pilot’s Guide Touching the range touch controls increases or decreases the range. Figure 144 Example of a Range+ Map (1000 NM) Figure 145 Example of a Range- Map (0.5 NM) 89000109-003 | 136 | Rev 0 Apr 2018...

  • Page 141: Setting The Auto Range

    Touch Experimental Pilot’s Guide The automatic map range function automatically changes the map range to ensure ownship and to waypoint are shown. Automatic Range Readout Figure 146 Example of an Automatic Map Range SETTING THE AUTO RANGE NOTE: Auto range is set up the same way in all map types, this  ...

  • Page 142: Over Zoom

    Touch Experimental Pilot’s Guide OVER ZOOM Over zoom annunciation is displayed on the VFR Sectional, IFR High, IFR Low, and Charts map types when the maps are zoomed in and the pixels are drawn larger than they should be.

  • Page 143: Panning

    Touch Experimental Pilot’s Guide PANNING The map display can be panned in any direction to view other areas of the map (i.e., view parts outside the displayed range without adjust- ing the map range). Pan Mode Annunciation Figure 148 Example of Map Panning When in pan mode, a Pan Mode annunciation is displayed on the top of the map.

  • Page 144: Map Cursor

    Touch Experimental Pilot’s Guide MAP CURSOR The map cursor can be moved to any location on the map and when an object or point is selected, more information for the item is dis- played (if available). Map Cursor Figure 149 Example of a Map Cursor View...

  • Page 145: Map Overlays

    Touch Experimental Pilot’s Guide MAP OVERLAYS The map has the following common overlays: • Traffic (ADS-B) • Track Line • Weather • SVS Field of Regard • Flight Plan • VSD Swath • Relative Terrain TRAFFIC (ADS-B) The Cockpit Display of Traffic Information (CDTI) function provides traffic information relative to the airplane ownship position through the Automatic Dependent Surveillance-Broadcast (ADS-B).

  • Page 146: Traffic Priority

    Touch Experimental Pilot’s Guide TRAFFIC PRIORITY The CDTI updates traffic information every second. Traffic information is prioritized to display the most relevant airborne and surface traffic on the CDTI: Selected traffic: Traffic selected on the map using touch Nearby airborne traffic: Traffic within 6 NM range and ±1200 FT...

  • Page 147: Traffic Symbols

    Touch Experimental Pilot’s Guide The following traffic display criteria are used to determine the most rel- evant traffic (to prevent displaying too many traffic elements): Table 8 Traffic Display Criteria ALTITUDE TRAFFIC RANGE (FT) Normal* 2700 ± Above -2700- 9900...
  • Page 148 Touch Experimental Pilot’s Guide The following symbols are used to display traffic: Table 9 Traffic Symbols Airborne Aircraft Symbol Non-Threat Traffic Directional (with Track) Non-Threat Traffic Non-Directional (Without Track) Surface Aircraft Symbol Directional (with Track) Non-Directional (Without Track) Surface Vehicle Symbol...

  • Page 149: Traffic Data Block

    Touch Experimental Pilot’s Guide VS Arrow Trend Line Rel. Altitude -10 = -1000 FT VS Arrow Intruder Above Intruder Below Ownship Ownship Figure 155 Examples of Traffic Data Tags TRAFFIC DATA BLOCK The traffic data block is displayed at the bottom center of the map when the traffic feature is turned on.
  • Page 150 Touch Experimental Pilot’s Guide If traffic data is not received from any ground station, the “TIS-B/ADS- R Unavailable” message is displayed above the traffic data block. Figure 158 Example of a “TIS-B/ADS-R Unavailable” Message When a traffic element is selected, a pop-up window appears and the traffic data block displays the information for the element.

  • Page 151: Setting The Traffic Overlay

    Touch Experimental Pilot’s Guide SETTING THE TRAFFIC OVERLAY NOTE: The traffic overlay is set up the same way in all map   types, this example shows Base Map setup Touch Touch Touch to turn Traffic On/Off (the green bar indicates...

  • Page 152: Weather

    Touch Experimental Pilot’s Guide WEATHER The weather overlays can also be displayed on a Base Map. Figure 162 Examples of Weather Overlays on a Base Map 89000109-003 | 148 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 153: Setting The Weather Overlay

    Touch Experimental Pilot’s Guide When the weather overlay is turned off, an annunciation is displayed on the left side of the MFD. Weather Off Annunciation Figure 163 Weather Off Annunciation SETTING THE WEATHER OVERLAY Touch Touch to select the desired settings from the menu...

  • Page 154: Flight Plan

    Touch Experimental Pilot’s Guide FLIGHT PLAN The MFD displays the current flight plan of the GPS navigator con- nected to the xVue Touch. 1. Selected GPS Source 2. Phase of Flight (POF) 3. From/To Waypoint 4. Track Angle (TRK) 5.

  • Page 155: Relative Terrain

    Touch Experimental Pilot’s Guide RELATIVE TERRAIN When the relative terrain feature is turned on, the map displays the relative terrain and obstacles with color and shading to represent geographical features with respect to airplane ownship GPS altitude. The terrain features overlay the Base Map/Terrain Alert map (or blend with the Base Map).
  • Page 156 Touch Experimental Pilot’s Guide Table 10 Relative Terrain Coloring (Topo On) No Shading (Transparent) When obstacles are shown on the map, a circle (radius o f 0.5 NM) is drawn around the obstacle and is colored based on the relative height of the obstacle compared to the airplane ownship altitude.

  • Page 157: Setting The Relative Terrain Feature

    Touch Experimental Pilot’s Guide SETTING THE RELATIVE TERRAIN FEATURE Touch Touch Touch to turn Relative TERR On/Off (the green indicates the feature is on, touching the button toggles between the settings) When the Relative Terrain feature is turned off, an annunciation is displayed on the left side of the MFD screen.

  • Page 158: Setting The Track Line

    Touch Experimental Pilot’s Guide SETTING THE TRACK LINE NOTE: The map Track Line setting can be accessed through   the Map Overlays button (all map types). Base Map is shown in this example. Touch Touch Touch to turn Map Track Line On/Off (the...

  • Page 159: Vertical Situation Display

    Touch Experimental Pilot’s Guide VERTICAL SITUATION DISPLAY The Vertical Situation Display (VSD) is located at the bottom of the MFD screen (when turned on). The VSD depicts the profile view of the airplane and can display the following information: •...

  • Page 160: Terrain

    Touch Experimental Pilot’s Guide TERRAIN The terrain is displayed on the VSD using the following criteria: Terrain is above ownship or within 200 FT below the ownship. Terrain is 600 FT to greater than 200 FT below ownship. Terrain is 1600 FT greater or 600 FT below ownship.

  • Page 161: Obstacles

    Touch Experimental Pilot’s Guide OBSTACLES Obstacles are shown in the VSD window at the appropriate hori- zontal scale distance. If the database information for an obstacle only provides location and height, the obstacle is shown as a vertical cyan line with the upper and lower limits of the line corresponding to the base and top of the obstacle.

  • Page 162: Vsd Horizontal/Vertical Scale

    Touch Experimental Pilot’s Guide NOTE: If the upper limit of the airspace is above the upper   altitude limit of the VSD, a dotted white line is displayed on the VSD to show if the airplane is outside or within the airspace.
  • Page 163 Touch Experimental Pilot’s Guide Figure 176 Example of a Map Range ≥100 NM When the VSD scale is not the same as the map scale, a message Not To Map Scale is displayed. Figure 177 Example of a “Not To Map Scale” Message Displayed The VSD displays the vertical altitude scale with tick marks at every 500 FT.

  • Page 164: Ownship

    Touch Experimental Pilot’s Guide OWNSHIP The airplane ownship symbol is shown in the VSD window to indi- cate the current airplane altitude. A horizontal white dashed line is shown to indicate the altitude across the VSD. Airplane Ownship Symbol...
  • Page 165 Touch Experimental Pilot’s Guide Blank Page 89000109-003 Rev 0 Apr 2018 | 161 | © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 166: Section 4 System Controls

    Touch Experimental Pilot’s Guide SYSTEM CONTROLS SECTION The xVue Touch is controlled by the touch screen and control panel, which can be used to manually control altitude, baro, course, and heading. TOUCH SCREEN The touch screen has several touch fields that open menus/keypads or switch between functionalities.

  • Page 167: Menus

    Touch Experimental Pilot’s Guide MENUS Most of the functions can be accessed through that is located at the top-right corner of the PFD screen. Two types of buttons are used in the menus: square buttons and but- tons that have the top right corner cut off. The look of the button indicates...
  • Page 168 Touch Experimental Pilot’s Guide Example of a second level menu. Figure 182 Example of a Second Level Menu   NOTE: Grayed-out buttons are inactive/feature not available. Example of a third level menu. Figure 183 Example of a Third Level Menu...

  • Page 169: Main Menu

    Touch Experimental Pilot’s Guide All menus can be closed by touching the gray bar or the arrow on the active menu. Close All Menus Close Sub-Menu Figure 184 Closing Menus The menus can also be closed by touching outside the menu(s).
  • Page 170 Touch Experimental Pilot’s Guide The Main Menu has the following buttons: Table 12 Main Menu Buttons BUTTON DESCRIPTION PFD layout can be set to full or split screen. Default value is split. Terrain audio alerts can be turned on/off. Default value is Opens a menu to set the PFD;...

  • Page 171: Pfd Menus - Levels 1 And 2

    Touch Experimental Pilot’s Guide PFD MENUS - LEVELS 1 AND 2 Figure 186 Examples of PFD Menus - Levels 1 and 2 89000109-003 System Controls Rev 0 Apr 2018 | 167 | © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 172: Pfd Menus - Level 3

    Touch Experimental Pilot’s Guide PFD MENUS - LEVEL 3 Figure 187 Examples of PFD Menus - Level 3 System Controls 89000109-003 | 168 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 173: Mfd Menu - Level 1

    Touch Experimental Pilot’s Guide MFD MENU - LEVEL 1 Figure 188 Example of the MFD Menu - Level 1 NOTE: The MFD menu overlay and setup buttons change   depending on which map type is selected. 89000109-003 System Controls...

  • Page 174: Mfd Menus - Base Map, Levels 2 And 3

    Touch Experimental Pilot’s Guide MFD MENUS - BASE MAP, LEVELS 2 AND 3 Figure 189 Examples of Base Map Menus System Controls 89000109-003 | 170 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 175: Mfd Menus - Irf High Map, Level 2

    Touch Experimental Pilot’s Guide MFD MENUS - IRF HIGH MAP, LEVEL 2 Figure 190 Examples of IRF High Map Menus 89000109-003 System Controls Rev 0 Apr 2018 | 171 | © Honeywell International Inc. Do not copy without express permission of Honeywell.
  • Page 176 Touch Experimental Pilot’s Guide MFD MENUS - SECTIONAL MAP, LEVEL 2 Figure 191 Examples of Sectional Map Menus System Controls 89000109-003 | 172 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 177: Mfd Menus - Ifr Low Map, Level 2

    Touch Experimental Pilot’s Guide MFD MENUS - IFR LOW MAP, LEVEL 2 Figure 192 Examples of IFR Low Map Menus 89000109-003 System Controls Rev 0 Apr 2018 | 173 | © Honeywell International Inc. Do not copy without express permission of Honeywell.
  • Page 178 Touch Experimental Pilot’s Guide MFD MENUS - WX MAP, LEVEL 2 AND 3 Figure 193 Examples of Weather Menus System Controls 89000109-003 | 174 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.
  • Page 179 Touch Experimental Pilot’s Guide MFD MENUS - CHARTS, LEVEL 2 Figure 194 Examples Charts Menus 89000109-003 System Controls Rev 0 Apr 2018 | 175 | © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 180: System Tools Menus - Levels 1 And 2

    Touch Experimental Pilot’s Guide SYSTEM TOOLS MENUS - LEVELS 1 AND 2 Figure 195 Examples of System Tools Menus BRIGHTNESS CONTROL MENU The Brightness Control menu is used to adjust the screen brightness Touch Select Display Auto, Display Manual, or System External setting from the Brightness Control menu.

  • Page 181: Screen Maint Menu

    Touch Experimental Pilot’s Guide NOTE: The External Trim Adjust is only displayed when the   System External Setting is selected. Manually adjust the brightness control by touching Adjust Display button (manual) or External Trim Adjust button (external) and slid- ing the button to the desired brightness level.
  • Page 182 Touch Select to Disable Touch Screen for 30 sec button to lock the screen for 30 seconds Figure 197 Example of Clean Screen Menu For detailed cleaning instructions, refer to the BendixKing xVue Touch Experimental Airplane Flight Procedures. Manual Touch Calibration Menu...
  • Page 183 Touch Experimental Pilot’s Guide Touch to calibrate Close the menu to exit without calibrating The Touch Calibration Utility Touch Crosshair To Calibrate screen appears and the first touch point is displayed as a plus sign.   NOTE: Figure 199 displays all the touch points.
  • Page 184 Touch Experimental Pilot’s Guide Touch the first touch point. When the touch is detected, a bloom is shown around the touch point The touch point is removed and the next touch point will be displayed. Repeat the calibration process for the other touch points When all the touch points have been calibrated, Touch Calibration Utility Test Screen appears.
  • Page 185 Touch Experimental Pilot’s Guide Restore Def. Touch Cal. menu appears. Figure 201 Example of a Restore Def. Touch Cal. Menu Touch to revert to default calibration settings Close the menu to exit without calibrating 89000109-003 System Controls Rev 0 Apr 2018 | 181 | ©...

  • Page 186: Advisory Messages

    Touch Experimental Pilot’s Guide ADVISORY MESSAGES Figure 202 Examples of Advisory Messages For more information on the Advisory Messages, see Section 5. System Controls 89000109-003 | 182 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 187: Keypads

    Touch Experimental Pilot’s Guide KEYPADS NUMERIC KEYPAD The numeric keypad is u s e d t o s e t v a l u e s . Remove Set Value Bug Key Field Number Keys Delete SYNC Enter Figure 203 Numeric Keypad Example Each keypad has its own validity logic (i.e., the keypad keys activate for...

  • Page 188: Setting Values

    Touch Experimental Pilot’s Guide SETTING VALUES The numeric keypad functions the same way regardless of the fea- ture: To set a value: Enter a value touch To remove a set value and bug: Touch To sync a value to the current value: Touch NOTE: If the value has not been set before, the set value field  ...

  • Page 189: Control Panel

    Touch Experimental Pilot’s Guide NOTE: The keypad keys activate for valid entries only. The Enter   key is enabled when enough characters are entered for a valid entry. NOTE: The keypad does not close after it has been interacted  ...
  • Page 190 Touch Experimental Pilot’s Guide The control panel knobs function the same way (regardless of the fea- ture): To set/change a value: Turn the knob To sync a value to the current value: Press the knob To set to standard baro: Press the knob NOTE: The outer altitude knob controls 1000 FT and the inner  ...
  • Page 191 Touch Experimental Pilot’s Guide Blank Page 89000109-003 System Controls Rev 0 Apr 2018 | 187 | © Honeywell International Inc. Do not copy without express permission of Honeywell.

  • Page 192: Section 5 Messages/Alerts

    Touch Experimental Pilot’s Guide MESSAGES/ALERTS SECTION AI Critical Alerts Area Message Center CAS Message Box Figure 206 Messages and Alerts Display Locations The message a n d crew alerting system provides visual and aural advisory messages, cautions, and warnings about possible malfunctions or abnormal operating conditions.

  • Page 193: Advisory Messages

    Touch Experimental Pilot’s Guide ADVISORY MESSAGES The advisory messages are non-critical messages and can be accessed through When a new unread message(s) is available, the button dis- plays an exclamation point. button also has an exclamation point to indicate that a new unread message(s) is available.
  • Page 194 Touch Experimental Pilot’s Guide NOTE: The messages are automatically removed from the list   when the state causing the advisory message is corrected. Table 13 Advisory Messages ANNUNCIATION CAUSE ACTION KCP FAIL Loss of communica- Use KSD 100EXP to adjust barometric...
  • Page 195 Touch Experimental Pilot’s Guide Table 13 Advisory Messages ANNUNCIATION CAUSE ACTION AHRS AIDED ADAHRS is in GPS No action SECONDARY aiding only mode MODE NOT AVAILABLE LIGHT SENSOR Communication fail- Use manual dimming control FAULT MANUAL ure with ambient...
  • Page 196 Touch Experimental Pilot’s Guide Table 13 Advisory Messages ANNUNCIATION CAUSE ACTION DATABASE Newer version of a Verify database effectivity date FUTURE CYCLE database has loaded • before the effectivity Navigation date • Obstacle • Cartographic • Instrument Pro- cedure Charts •...
  • Page 197 Touch Experimental Pilot’s Guide Table 13 Advisory Messages ANNUNCIATION CAUSE ACTION FPGA SPI BUS Loss of communica- Contact BendixKing for service FAULT tion with Field Pro- grammable Gate Array (FPGA) Serial Peripheral Interface (SPI) bus UAT NO ADS-B failure...

  • Page 198: Cm Error Messages

    Touch Experimental Pilot’s Guide CM ERROR MESSAGES The configuration module (APM) has additional error messages that are displayed on the PFD screen. If the APM has a configuration fail- ure, the message “APM Configuration Error Service Required” is dis- played on power up.

  • Page 199: Warnings And Cautions

    CAS message box (see Figure 206 on page 188). IMPORTANT INFORMATION For a more detailed description of warnings and cautions, refer to the BendixKing xVue Touch Experimental Airplane Flight Procedures. 89000109-003 Messages/Alerts Rev 0 Apr 2018 | 195 |...

  • Page 200: Section 6 Database Updates

    SECTION Database updates are downloaded from the Internet and can be installed using a USB drive or Wi-Fi enabled device. NOTE: BendixKing recommends to check for database updates   every 30 days. Database updates require i n d i v i d u a l subscriptions to:...

  • Page 201: Updating Databases

    Touch Experimental Pilot’s Guide UPDATING DATABASES Turn on the avionics switch to power up the xVue Touch Touch Database loading from a USB drive: Insert the USB drive into the USB port in front of the unit and touch the USB Menu button.
  • Page 202 Touch Experimental Pilot’s Guide After the database scanning is complete, the database loading page is updated with database status information. This page shows which databases to install and how much time each database installa- tion will take. Figure 210 Database Loading Page Example – 2 The KSD Database column displays the installed databases and ver- sion numbers.
  • Page 203 Touch Experimental Pilot’s Guide The External DB column lists each database as SAME, FUTURE CYCLE, or EXPIRED CYCLE. The database effectivity is displayed for each database. When the installed database and the USB database are the same, SAME is displayed.
  • Page 204 Touch Experimental Pilot’s Guide During the loading process the Progress column displays the installa- tion progress. Figure 211 Example of a Data Loading in Progress Screen The progress of each database selected for installation is displayed in the Progress column. The time remaining is displayed for each remaining database to be loaded.
  • Page 205 Touch Experimental Pilot’s Guide When the database loading is complete, a pop-up window “Database Load Successful Cycle Power on the KSD 100” appears. Figure 213 Database Loading Complete Remove the USB stick, turn the aircraft avionics switch off, wait 10 seconds, and turn it back on.

  • Page 206: Dataloading Errors

    Touch Experimental Pilot’s Guide DATALOADING ERRORS The following error messages may appear during the dataloading pro- cess: Table 14 Dataloading Errors MESSAGE xVue TOUCH CRITERIA CORRECTIVE DATABASES DATABASES ACTION Database is not pres- xVue Touch Present ent on the device...

  • Page 207: Acronyms And Abbreviations

    Touch Experimental Pilot’s Guide ACRONYMS AND ABBREVIATIONS TERM DEFINITION ADAHRS Air Data Attitude Heading Reference System ADS-B Automatic Dependent Surveillance-Broadcast Above Ground Level AHRS Attitude Heading Reference System Attitude Indicator Airborne AIRB Altitude Aircraft Personality Module Approach APPR Approach...
  • Page 208 Touch Experimental Pilot’s Guide TERM DEFINITION Flight Director Flight Information Region FIS-B Flight Information Services-Broadcast Field of Regard FPGA Field Programmable Gate Array Feet per Minute FPRL Flight Path Reference Line Flight Path Symbol Feet Global Positioning System Ground Speed...
  • Page 209 Touch Experimental Pilot’s Guide TERM DEFINITION Minimum Military Operations Area Miles per Hour Message Mean Sea Level Non-Directional Beacon NEXRAD Next Generation Weather Radar Nautical Miles NOTAM Notice to Airmen Outside Air Temperature OCEAN Oceanic Original Equipment Manufacturer OFST...
  • Page 210 Touch Experimental Pilot’s Guide TERM DEFINITION Universal Time Clock Vertical Dense Visual Flight Rules Visual Reference Point VLOC VOR/Localizer VHF Omni-Directional Radio Range Vertical Situation Display Vertical Speed indicator Wi-Fi Wireless Waypoint WUXGA Widescreen Ultra Extended Graphics Array Weather...

  • Page 211: Index

    Touch Experimental Pilot’s Guide INDEX Numeric Approach (APPR) 82, Minimums 62 Submode 83 360 Compass 70, 83 Approaches 114 ARC compass 70, 81, 84 ARPT tab 110 ARR tab 113 Advisory Messages 20, 182, 189 Arrival procedure chart 113...
  • Page 212 Touch Experimental Pilot’s Guide Database 196 Updates 196 Uploads 17 Cardinal headings 70 Dataloading Errors 202 Cartographic 101 Dead-Reckoning (DR) 83 Decreasing pitch command 55 360 Compass 78 Density Altitude 64 ARC Compass 81 DEP tab 112 Components 77, 81...
  • Page 213 Touch Experimental Pilot’s Guide Segments 133 IFR Low 104, 126, 131, 138 Fly holding patterns 150 IFR Low Alt Enroute (IFR Low) From/To Waypoint 82 Full scale deviation 79, 88 Increasing pitch command 55 Full/split screen 20 Information Box 140...
  • Page 214 Touch Experimental Pilot’s Guide Map 101 Cursor 140 Obstacles 16, 133, 151, 152, Data 101 155, 157 Detail 129, 132 Oceanic (OCEAN) 82 Display Range 135 On the ground Features 129 V-Speed labels 42 Night Mode 126 V-Speeds 42...
  • Page 215 Touch Experimental Pilot’s Guide Rate of Turn 74 Setting Indicator 74 Airport Diagram Feature 111 Trend Line 75 Altimeter 61 Regional NEXRAD 116 Altitude Audio Alert Inhibit 60 Relative 142 Auto Range 137 Altitude 142 BARO Unit 61 Bearing 142...
  • Page 216 Touch Experimental Pilot’s Guide Syncing True Airspeed (TAS) 44 Selected Airspeed Bug 37 Turn coordinator 16 Selected Altitude Bug 58 Selected Course 78 Selected Heading Bug 73 Synthetic Vision System (SVS) 16 Universal Time Clock (UTC)/TImer 32, 100, 162, 188, 196...
  • Page 217 Touch Experimental Pilot’s Guide Waypoints (WPT) 73, 83, 150 Weather 16, 121, 141, 148 (FIS-B) 116 Annunciation 149 Overlays 148 Wide Area Augmentation System (WAAS) 75 wireless (Wi-Fi) antenna 17 Legends 120 Map 102, 115 Zoom 129 89000109-003 Index...
  • Page 218 Touch Experimental Pilot’s Guide Blank Page Index 89000109-003 Index-| 8 | Rev 0 Apr 2018 © Honeywell International Inc. Do not copy without express permission of Honeywell.
  • Page 220 9201-B San Mateo Blvd. NE Albuquerque, NM 87113, U.S.A. CAGE: 6PC31 U.S.A. and Canada: 1-855-250-7027 International: 1-505-903-6148 www.bendixking.com...

Table of Contents
