Summary of Contents for Doug Fleenor Design RERUN-A
- Page 1 RERUN ARCHITECTURAL DMX512 RECORDER MODEL RERUN-A OWNERS MANUAL Doug Fleenor Design 396 Corbett Canyon Road Arroyo Grande, CA 93420 (805) 481-9599 Software Version 1.5 Manual Revision 1.1 Serial # 109001...
-
Page 2: Product Description
PRODUCT DESCRIPTION The Rerun Architectural is a lighting control station capable of storing up to ten 40-minute shows. Shows are recorded by capturing the output of a DMX512 console. The recorded show start and end points may be trimmed non-destructively. Each show can be set to hold the last look, loop to itself or link to another show. -
Page 3: Specifications
SPECIFICATIONS Connector: Terminal block #1 Terminal block #2 Phoenix Contact MSTB series Phoenix Contact MSTB series 5 position two part terminal block 3 position two part terminal block Model: MSTB 2,5/5-ST-5,08 Model: MSTB 2,3-G-5,08 Order number: 17 57 04 8 Order number: 17 55 74 9 Connector pin out: Terminal Block #1 (DMX512 Output) -
Page 4: Power Supply
SPECIFICATIONS (CONTINUED) Power input: 9 to 15 volts AC or DC / 150mA per station (A 10 volt class 2 “doorbell” transformer is recommended for fixed installations) Color: Black anodized with laser engraved nomenclature Size : Faceplate: 4.5"h X 4.6"w X 0.2"d Faceplate rear inset: 4.15"h X 4.25"w X 0.1"d Electrical box minimum inside dimensions: 2.9"h X 3.5"w X 1.5 "d... -
Page 5: Wiring Information
WIRING INFORMATION Rerun Architectural is designed to use daisy-chain wiring topology. Please give us a call if you have any questions. Note: DMX512 from a console will not pass through if the Rerun Architectural is not powered . CABLE COLOR FROM S hield P in 1... - Page 6 RERUN ARCHITECTURAL FACEPLATE CONFIGURATION Each Rerun Architectural has six jumpers, JP1 through JP6, that select different modes of operation. The factory default is to have all jumpers installed. Record Lockout - When removed, the [RECORD] button is disabled. When installed, recording of presets is enabled.
- Page 7 PLAYBACK PAUSED SHOW SET TO LOOP OR LINK BLINK SHOW AT END POINT AND LOOPED TO START POINT RECEIVING DMX512 THE RERUN-A IS LOCKED OUT FROM RUNNING SHOW S AND IS PASSING CONSOLE DATA TO THE OUTPUT RECEIVING DMX512 FLASH...
-
Page 8: Recording Shows
THE ANATOMY OF A SHOW The Rerun Architectural has ten show memories each capable of recording 40 minutes of DMX512 data. Within each show memory are non-destructive trim points called the START POINT and the END POINT. The show memory is the data space used to store the show. Its time line always starts at the top of the show memory (The point at which the [SHOW] button was pressed to begin recording). -
Page 9: Locking The Front Panel
PLAYBACK OF SHOWS Recorded shows may not be played when there is incoming DMX512 unless the pile-on jumper (JP5) has been removed. When DMX512 from a console is present, the Rerun Architectural’s RED LED will be on and the only action possible is recording of a show. When the “pile-on” jumper is removed, incoming DMX512 data will be piled onto the currently running show in a highest-takes-precedence fashion. - Page 10 EDITING SHOW PARAMETERS A number of parameters can be edited in recorded shows and for system-wide functions. These include the start point, end point, looping/linking status, linked show number, cross fading, recording lockout, end of show output disable, and front panel lockout. Setting start and end points The [REWIND] and [FORWARD] buttons are used to set the start and end points.
- Page 11 EDITING SHOW PARAMETERS (CONTINUED) Looping By default, shows are looping. This means that when the show comes to its end, the show will automatically re-start itself from the START POINT and run in a continuous loop. When looping is disabled, the show stops at the END POINT and the Rerun Architectural will send the last levels of the show until another show is selected.
- Page 12 EDITING SHOW PARAMETERS (CONTINUED) Cross fading Each show can have the cross fade function enabled or disabled. When enabled (the default state), the show will execute a two second fade from the current levels to the levels at the START POINT of the show when that show is selected.
- Page 13 EDITING SHOW PARAMETERS (CONTINUED) Software record lockout In addition to the hardware jumper record lockout feature, the Rerun Architectural has a software record lockout feature. When the software record lockout is enabled, no shows can be recorded and no parameter data can be modified. The hardware record lockout jumper takes precedence over the software record lockout.
-
Page 14: Warranty
It is the customer's responsibility to return the product to Doug Fleenor Design (at the customer's expense). Doug Fleenor Design will repair the unit and return it to the customer (at Doug Fleenor Design's expense). If a trip is necessary to the customer's site to solve a problem, the expenses of the trip must be paid by the customer.
