  • Page 1 VONETS —— WiFi Module WiFi Module VM300/VM5G Quick Setting Guide...
  • Page 2 VONETS is the registered trademark of Shenzhen HouTian Network Communication Technology Co.,Ltd. The other all trademarks or registered trademarks mentioned in this documents are belong to the individual owners. The product specifications and information technology mentioned in this manual are just for reference, if any updates, without other not ice.
  • Page 3: Table Of Contents

    VONETS —— WiFi Module Contents Chapter 1 Application Mode ..............1 1.1 Bridge + Repeater Mode ........................1 1.2 Router Mode ............................... 2 Chapter 2 Bridge+Repeater Mode Configuration Instruction ..3 2.1 Device Connection ..........................3 2.2 Bridge+Repeater Application Configuration ................4 2.3 AP Application Configuration ......................
  • Page 4: Chapter 1 Application Mode

    VONETS module as WiFi bridge, it must be configured to source WiFi hotspot parameters, can be used for devices only with Ethernet ports to access wireless networks. ⚫ WiFi AP: VONETS module as WiFi AP, it can achieve wireless access to wired LAN, no configuration required, plug and play.
  • Page 5: Router Mode

    Ethernet cable is WAN port to use the broadband dialing function. ⚫ VONETS module is used as a wireless router. WAN port can be set to connect to the WiFi hotspot for use as a secondary router.
  • Page 6: Chapter 2 Bridge+Repeater Mode Configuration Instruction

    Chapter 2 Bridge+Repeater Mode Configuration Instruction 2.1 Device Connection Power on VONETS module by 5V/2A power supply, then connect to PC, there are two connection ways as below: A. Computer is wired connected to LAN port of VONETS module; (Recommend Method)...
  • Page 7: Bridge+Repeater Application Configuration

    VONETS —— WiFi Module B. The computer wirelessly connects to the WiFi signal of VONETS module, its default hotspot parameters are as follows: WiFi SSID WiFi Password VONETS_2.4G_**** 12345678 VONETS_5G_**** 12345678 (After the WiFi parameters are configured, the WiFi will be disconnected, that is normal.) 2.2 Bridge+Repeater Application Configuration...
  • Page 8 ⚫ The option “The configuration parameters of WiFi repeater security is synchronized with source hotspot” is default ticked, it means the SSID of VONETS repeater is associated with the SSID of the source hotspot, and the WiFi password is the same as the password of the source hotspot;...
  • Page 9 Ethernet Cable VM300 Status Light Connection Status Light Ethernet Cable 2.4G WiFi Connection 5G WiFi Connection VM5G Connection Status Status Light Status Light Light ① VONETS module is not connected to any hotspot, WiFi connection status light will flash quickly;...
  • Page 10: Ap Application Configuration

    2.3 AP Application Configuration VONETS module can be configured as an AP application. The wireless terminal device can connect to VONETS module hotspot to connect to the network; however, it is best to change its WiFi name and password for network security.
  • Page 11 Remark 2: When VONETS module connect to external network, its IP address will be changed. At this time, when log in configured page, we suggest you enter configured domain name:...
  • Page 12: Chapter 3 Router Mode Configuration Instruction

    Chapter 3 Router Mode Configuration Instruction 3.1 Change device mode 1. Power on VONETS module by 5V/2A power supply, then connect to PC, there are two connection ways as below: A. Computer is wired connected to LAN port of VONETS module;...
  • Page 13 VONETS —— WiFi Module 2. After computer is connected to VONETS module, open browser, input configured page domain name: http://vonets.cfg (or IP: 192.168.254.254), then press Enter; 3. Enter User name and Password in login page (both are “admin”), click “Login”...
  • Page 14: Wan Port Setting

    3.2 WAN port setting 3.2.1 WAN/LAN exchange In routing mode, the Ethernet port of VONETS module is divided into a WAN port and a LAN port, and WAN/LAN can be interchanged. The Ethernet port of VM300 module defaults to WAN port. The Ethernet cable defaults to LAN port.
  • Page 15: Wan Port Wired Connect Network--Dhcp

    Ethernet ports as LAN ports, while providing WiFi hotspot functions. 3.2.3 WAN port wired connect network——DHCP The default WAN port connection mode of VONETS is DHCP. The WAN port can automatically obtain an IP address after connecting with the source network.
  • Page 16: Wan Port Wireless Connect Network

    ⚫ The option “The configuration parameters of WiFi repeater security is synchronized with source hotspot” is default ticked, it means the SSID of VONETS repeater is associated with the SSID of the source hotspot, and the WiFi password is the same as the password of the source hotspot;...
  • Page 17: Set Wifi Hotspot Parameters

    Remark 1 for the description of the LED light.) Remark 3: After VONETS module sets the WAN port to access the WiFi hotspot in the routing mode, its LAN port IP is still 192.168.254.254, and the terminal device also obtains the IP address of the same network segment, can login configuration page by 192.168.254.254 or http://vonets.cfg.
  • Page 18 VONETS —— WiFi Module 2. Revise WiFi password, in “WiFi Repeater”----“WiFi Security”, enter new WiFi password in “Pass Phrase”, click “Apply”; 3. Reboot device, jump to “System Settings”---- “Reboot Device”, click “Reboot”, when it is finished, all revised options will take effort.
  • Page 19: Appendix Frequently Asked Questions

    Does VONETS module support firmware upgrade, how to upgrade? VONETS module supports firmware upgrade, and support online upgrade, please visit website: www.vonets.com to refer to the related documents. The device WiFi hot spot can be found, but the smart phone or PC can’t connect to this device hotspot? ⚫...
  • Page 20 PC has been connected the device by WiFi or Ethernet cable, but user can’t log in the device WEB page, or after log in the WEB it shows error? ⚫ Reason 1. The users don’t use the browser recommended by VONETS(IE,Google Chrome, Safari, the mobile phone browser);...
